Advantech ARK-1551 User manual

User Manual
ARK-1551
Fanless Embedded Box PC

ARK-1551 User Manual ii
Attention!
This product contains a hard copy of the Chinese user manual for China CCC
certification purposes. A PDF of the English user manual is included on the
accompanying CD. Please disregard the hard copy of the Chinese user man-
ual if the product is not sold and/or installed in China.

iii ARK-1551 User Manual
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to improve the products described in this manual at any time without notice. No part
of this manual may be reproduced, copied, translated, or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd. The infor-
mation provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
on the rights of third parties that may result from its use.
Acknowledgments
Award is a trademark of Award Software International, Inc
VIA is a trademark of VIA Technologies, Inc
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration
Intel® and Pentium® are trademarks of Intel® Corporation
Microsoft Windows® is a registered trademark of Microsoft Corp
RTL is a trademark of Realtek Semi-Conductor Co., Ltd
ESS is a trademark of ESS Technology, Inc
UMC is a trademark of United Microelectronics Corporation
SMI is a trademark of Silicon Motion, Inc
Creative is a trademark of Creative Technology LTD
CHRONTEL is a trademark of Chrontel Inc
All other product names or trademarks are properties of their respective owners
For more information about this or other Advantech products, visit our website at
http://www.advantech.com/
https://www.advantech.com/products/fanless-embedded-computers/sub_1-2jkeuf
For technical support and customer service, visit our support website at
http://support.advantech.com.tw/support/
Part No. 2006155100 Edition 1
Printed in China June 2020

ARK-1551 User Manual iv
Product Warranty (2 Years)
Advantech warrants the original purchaser that all of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers are billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more details.
If you believe that your product is defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software, etc.) Note any-
thing abnormal and list any onscreen messages displayed when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package, and ship the pack-
age prepaid to your dealer.
Declaration of Conformity
FCC Class B
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in residential installations.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, users are encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
Consult your dealer or an experienced radio/TV technician for help

v ARK-1551 User Manual
Technical Support and Assistance
1. Visit the Advantech website at www.advantech.com/support to obtain the latest
product information.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before calling:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Warnings, Cautions, and Notes
Warning! Warnings indicate conditions that if not observed can cause personal
injury!
Caution! Cautions are included to help prevent hardware damage and data
losses.
Note! Notes provide additional optional information.

ARK-1551 User Manual vi
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect the equipment from all AC outlets before cleaning. Use only a damp
cloth for cleaning. Do not use liquid or sprayed detergent.
4. For pluggable equipment, the power outlet should be near the equipment and
easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
the equipment fall may cause damage.
7. The openings on the enclosure are for air convection and protect the equipment
from overheating. Do not cover the openings.
8. The power outlet sockets should have grounded connections.
9. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect the equipment from the
power source to avoid damage from transient over-voltage.
12. Never pour liquid into an opening as this can cause fire or electrical shock.
13. Never open the equipment. For safety reasons, only qualified service personnel
should open the equipment.
14. If one of the following occurs, have the equipment checked by service person-
nel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment is malfunctioning or does not operate according to the user
manual.
The equipment has been dropped and damaged.
The equipment shows obvious signs of breakage.
15. Do not leave the equipment in an environment with a storage temperature of
below -40 °C (-40 °F) or above 85 °C (185 °F) as this may cause damage. The
equipment should be stored in a controlled environment.
16. Any unverified component may cause unexpected damage. To ensure correct
installation, always use the components (e.g., screws) provided in the acces-
sory box.
17. CAUTION: The equipment is equipped with a battery-powered real-time clock
circuit. There is a risk of explosion if a battery is incorrectly replaced. Replace
only with same or equivalent type as recommended by the manufacturer. Dis-
card all used batteries according to the manufacturer’s instructions.
18. Always disconnect the power cord from the chassis before manually handling
the hardware. Do not implement connections or configuration changes while the
device is powered on. Sudden power surges may damage sensitive electronic
components.
19. In accordance with IEC 704-1:1982 specifications, the sound pressure level at
the operator’s position does not exceed 70 dB (A).
20. The equipment should only be installed in a restricted access area.
21. DISCLAIMER: These instructions are provided according to IEC 704-1 specifi-
cations. Advantech disclaims all responsibility for the accuracy of any state-
ments contained herein.

vii ARK-1551 User Manual
22. ARK-1551 is intended to be powered by a UL Listed dc source suitable for use
at Tma 55 °C/ 131 °F minimum. ARK 1551’s output is rated 12-24VDC, 7.5-
3.75A min., ES1. If further assistance is needed, please contact Advantech for
more information.
Consignes de Sécurité
1. Veuillez lire attentivement ces instructions de sécurité.
2. Veuillez conserver ce manuel de l'utilisateur pour référence ultérieure.
3. Veuillez débrancher cet équipement de la prise secteur avant le nettoyage. Utili-
sez un chiffon humide. Ne pas utiliser de détergent liquide ou pulvérisé pour le
nettoyage. Utilisez une feuille ou un chiffon humide pour le nettoyage.
4. Pour les équipements enfichables, la prise de courant doit être à proximité de
l'équipement et doit être facilement accessible.
5. S'il vous plaît garder cet équipement de l'humidité.
6. Posez cet équipement sur une surface fiable lors de l'installation. Une chute ou
une chute pourrait causer des blessures.
7. Les ouvertures sur le boîtier sont destinées à la convection d'air, protégeant.
ainsi l'équipement de la surchauffe. NE COUVREZ PAS LES OUVERTURES.
8. La prise de courant doit avoir une connexion mise à la terre.
9. Placez le cordon d'alimentation de sorte que personne ne puisse marcher des-
sus. Ne placez rien sur le cordon d'alimentation.
10. Tous les avertissements et mises en garde sur l'équipement doivent être notés.
11. Si l'appareil n'est pas utilisé pendant une longue période, débranchez-le du sec-
teur pour ne pas être endommagé par une surtension transitoire.
12. Ne jamais verser de liquide dans les ouvertures de ventilation; Cela pourrait
provoquer un incendie ou un choc électrique.
13. N'ouvrez jamais l'équipement. Pour des raisons de sécurité, seul le personnel
de maintenance qualifié doit ouvrir l'équipement.
14. Si l'une des situations suivantes se présente, faites vérifier le matériel par le
personnel de service:
Le cordon d'alimentation ou la fiche est endommagé
Un liquide a pénétré dans l'appareil
L'équipement a été exposé à l'humidité
L'équipement ne fonctionne pas bien ou vous ne pouvez pas le faire
fonctionner conformément au manuel d'utilisation
Equipment L'équipement est tombé et a été endommagé
Equipment L'équipement présente des signes évidents de rupture
15. Ne laissez pas cet équipement dans un environnement où la température de
stockage peut être inférieure à -40 °C (-40 °F) ou supérieure à 85 °C (185 °F).
Cela pourrait endommager l'équipement. L'équipement doit être dans un envi-
ronnement contrôlé.
16. Tout composant non vérifié peut causer des dommages inattendus. Pour garan-
tir une installation correcte, veuillez toujours utiliser les composants (ex. Vis)
fournis avec la boîte d'accessoires.
17. ATTENTION: L'ordinateur est équipé d'un circuit d'horloge temps réel alimenté
par batterie. Il y a un risque d'explosion si la batterie est remplacée de manière
incorrecte. Remplacez uniquement avec le même type ou un type équivalent
recommandé par le fabricant. Jetez les piles usagées conformément aux
instructions du fabricant.
18. Débranchez toujours complètement le cordon d'alimentation de votre châssis
lorsque vous utilisez du matériel. Ne faites pas de connexion quand l'appareil

ARK-1551 User Manual viii
est sous tension. Les composants électroniques sensibles peuvent être endom-
magés par des surtensions soudaines.
19. Niveau de pression acoustique au poste de l'opérateur selon la norme CEI 704-
1: 1982 n'est pas supérieur à 70 dB (A).
20. L'équipement ne doit être installé que dans une zone d'accès restreint.
21. AVERTISSEMENT: Cet ensemble d'instructions est donné conformément à la
norme CEI 704-1. Advantech décline toute responsabilité quant à l'exactitude
des déclarations contenues dans ce.
22. Pour les modèles ARK-1551 est destiné à être alimenté par Source cc réper-
toriée UL à courant continu adaptée à une utilisation à Tma 55 degrés C min. et
la sortie est nominale 12-24 Vdc, 7,5-3,75 A min., ES1, si vous avez besoin
d'une assistance supplémentaire, veuillez contacter Advantech pour plus
d'informations.
Packing List
Before installation, check that the following items were included with the product:
 1 x ARK-1551 unit
1 x 2-pin terminal block
1 x 3-pin terminal block
1 x 2 years warranty card
1 x wall mount kit
1 x China RoHS
1 x Chinese user manual
Ordering Information
Model Number Description
ARK-1551-S6A1 ARK-1551 Intel® i5-8365UE, VGA+HDMI, 4 x USB, 4 x COM, TPM, 12-
24VDC In
ARK-1551-U0A1 ARK-1551 Intel® Celeron 4305UE, VGA+HDMI, 4 x USB, 4 x COM,
TPM, 12-24VDC In

ix ARK-1551 User Manual
Optional Accessories
Part Number Description
XARK-ADP-90MDH AC to DC adapter , 19V/90W
96PSA-A120W24T2-3 AC to DC adapter, 24V/120W
1700001524 Power Cable 3-pin 180cm, USA type (for XARK-ADP-90MDH)
170203183C Power Cable 3-pin 180cm, Europe type (for XARK-ADP-90MDH)
170203180A Power Cable 3-pin 180cm, UK type (for XARK-ADP-90MDH)
1700008921 Power Cable 3-pin PSE Mark 183cm (for XARK-ADP-90MDH)
1702002600 Power cable 3-pin 183cm, USA type (for 96PSA-A120W24T2-3)
1702002605 Power cable 3-pin 183cm, EU type (for 96PSA-A120W24T2-3)
1702031801 Power cable 3-pin 183cm, UK type (for 96PSA-A120W24T2-3)
1700000237 Power cable 3-pin 183cm, PSE type (for 96PSA-A120W24T2-3)
1700023855-01 1M lockable HDMI cable
1700023856-01 3M lockable HDMI cable
AMK-V004E VESA mounting kit
AMK-R004E DIN-rail mounting kit

ARK-1551 User Manual x

xi ARK-1551 User Manual
Contents
Chapter 1 General Introduction ...........................1
1.1 Introduction ............................................................................................... 2
1.2 Product Features....................................................................................... 2
1.2.1 General ......................................................................................... 2
1.2.2 Display .......................................................................................... 3
1.2.3 Ethernet ........................................................................................ 3
1.3 Chipset ...................................................................................................... 3
1.3.1 Functional Specifications .............................................................. 3
1.3.2 WISE-PaaS/DeviceOn .................................................................. 4
1.4 Mechanical Specifications......................................................................... 5
1.4.1 System Dimensions ...................................................................... 5
Figure 1.1 ARK-1551 Mechanical Dimensions ............................ 5
1.4.2 Weight........................................................................................... 5
1.5 Power Requirements................................................................................. 5
1.5.1 System Power............................................................................... 5
1.5.2 RTC Battery .................................................................................. 5
1.6 Environmental Specifications .................................................................... 6
1.6.1 Operating Temperature................................................................. 6
1.6.2 Relative Humidity .......................................................................... 6
1.6.3 Storage Temperature.................................................................... 6
1.6.4 Vibration Tolerance....................................................................... 6
1.6.5 Shock Tolerance ........................................................................... 6
1.6.6 Safety Certification........................................................................ 6
1.6.7 EMC Certification .......................................................................... 6
Chapter 2 Hardware Installation ..........................7
2.1 Introduction ............................................................................................... 8
2.2 Jumpers .................................................................................................... 8
2.2.1 Jumper Description ....................................................................... 8
2.2.2 Jumper List ................................................................................... 8
Table 2.1: Jumper Settings.......................................................... 8
2.2.3 Jumper Locations.......................................................................... 9
Figure 2.1 Jumper Location (Top) ............................................... 9
Figure 2.2 Jumper Location (Bottom) .......................................... 9
2.2.4 Jumper Settings .......................................................................... 10
2.3 System I/O .............................................................................................. 12
2.4 External I/O ............................................................................................. 12
2.4.1 Power On/Off Button................................................................... 12
Figure 2.3 Power On/Off Button ................................................ 12
2.4.2 Power Input Connector ............................................................... 13
2.4.3 Ethernet Connector (LAN) .......................................................... 13
Figure 2.4 Ethernet Connector (LAN) ........................................ 13
Table 2.2: Ethernet Connector (LAN) Pin Definition.................. 13
2.4.4 USB 3.1 Connector ..................................................................... 14
Figure 2.5 USB Connector......................................................... 14
Table 2.3: USB Connector Pin Definition .................................. 14
2.4.5 Audio Connector ......................................................................... 14
Figure 2.6 Audio Connector....................................................... 14
2.4.6 COM Connector .......................................................................... 15
Figure 2.7 COM Connector........................................................ 15
Table 2.4: COM Connector Pin Definition ................................. 15
2.4.7 HDMI Connector ......................................................................... 16
Figure 2.8 HDMI Connector....................................................... 16

ARK-1551 User Manual xii
Table 2.5: HDMI Connector Pin Definition ................................ 16
2.4.8 GPIO........................................................................................... 17
Table 2.6: GPIO Connector Pin Definition................................. 17
2.4.9 VGA Connector........................................................................... 17
Figure 2.9 VGA Connector ........................................................ 17
Table 2.7: VGA Connector Pin Assignments ............................ 17
2.4.10 Power Switch Connector ............................................................ 18
Figure 2.10 Power Switch Connector Pin Assignments ............. 18
Table 2.8: Power Switch Connector Pin Assignments .............. 18
2.4.11 LED Indicators ............................................................................ 18
Figure 2.11LED Indicators.......................................................... 18
2.4.12 Antenna Socket ......................................................................... 19
Figure 2.12Front I/O ANT Placement ......................................... 19
Figure 2.13 Rear I/O ANT Placement......................................... 19
2.5 Installation............................................................................................... 20
2.5.1 2.5” HDD/SSD Installation .......................................................... 20
2.5.2 RAM Installation.......................................................................... 21
2.5.3 miniPCIe Module Installation ...................................................... 22
2.5.4 M.2 Installation............................................................................ 23
2.5.5 Optional Adapter Installation....................................................... 25
2.5.6 Wall Mount Installation................................................................ 26
Chapter 3 BIOS Settings .................................... 27
3.1 Introduction ............................................................................................. 28
3.2 Entering BIOS Setup............................................................................... 29
3.2.1 Main Setup.................................................................................. 29
3.2.2 Advanced BIOS Setup................................................................ 30
3.2.3 Chipset Configuration ................................................................. 52
3.2.4 Security....................................................................................... 64
3.2.5 Boot ............................................................................................ 65
3.2.6 Save & Exit ................................................................................. 66
Appendix A Watchdog Sample Code................... 67
A.1 Watchdog Timer Sample Code............................................................... 68
Appendix B SUSI API Introduction....................... 69
B.1 SUSI API Introduction ............................................................................. 70
B.1.1 Watchdog API............................................................................. 70
B.1.2 Hardware Monitor API ................................................................ 70

Chapter 1
1General Introduction
This chapter details background
information on the ARK-1551
series

ARK-1551 User Manual 2
1.1 Introduction
ARK-1551 Fanless Embedded Box PC is an application ready system platform solu-
tion. All electronics are protected in a compact sealed aluminum case for easy inte-
gration into a specific housing, or as a stand-alone application. ARK-1551 is suitable
for applications with limited space in hazardous environments.
High Performance Slim Box PC
ARK-1551, a high performance system powered by Intel® Core™ i5-8365UE / Cele-
ron® 4305UE CPU processor, can be used in different applications according to dif-
ferent computing requirements. ARK-1551 supports dual DDR4 SO-DIMM memory
slots. Each memory slot supports up to 2400MHz 16GB. Users can install up to
32GB memory. Due to its slim form factor, ARK-1551 can be easily integrated with
panel/displays within limited spaces.
Rugged and Multi-Function I/O
ARK-1551 provides 12 - 24VDC input for industrial equipment integration. ARK-1551
offers 3 Grm vibration resistance and 30 G shock resistance. ARK-1551 in broad
temperature ranges -20 °C ~ 55 °C (-4 ~ 131 °F), making it an excellent choice for
diverse environments.
ARK-1551 features 4 x USB 3.1 Gen 2,1 x VGA, 1 x HDMI, 4 x COM, 1 x DIO, 2x
Intel® GbE LAN, ARK-1551 also provides one full-size miniPCIe slot and 1 M.2 2230
E Key slot for device integration. ARK-1551 supports two independent storages
including one 2.5” removable HDD/SSD bay and one mSATA slot. ARK-1551 also
supports Intel® software RAID 0/1 feature.
Built-In Intelligent Management Tools - WISE-PaaS/DeviceOn
Advantech’s WISE-PaaS/DeviceOn platform provides a valuable suite of program-
mable APIs, such as a multi-level watchdog, hardware monitor, system restore, and
other user-friendly interfaces. With the inclusion of WISE-PaaS/DeviceOn, ARK-1551
can be used for remotely managing, monitoring, configuring, and controlling numer-
ous terminals to ensure easy maintenance and recovery.
1.2 Product Features
1.2.1 General
CPU:
–Intel® Core™ i5-8365UE QC 1.6 GHz
–Intel® Celeron® 4305UE DC 2.0 GHz
BIOS: AMI UEFI 256 Mbit
System Memory: 2 x DDR4 2400MHz 260-pin SO-DIMM, up to 32 GB
Watchdog Timer: Single-chip watchdog with 255-level interval timer, setup via
software
Serial Port: 4 x RS-232/422/485 with auto flow control, COM3 with 5V/12V
power via jumper
USB: USB 3.1 Gen 2
Audio: High-definition (HD) audio, Line Out or Mic In

3 ARK-1551 User Manual
Chapter 1 General Introduction
Storage:
–1 x full-size mSATA (shared with full-size PCIe) and 1 x 2.5" SATA SSD (max.
height: 7 mm)
 Expansion Interface:
–1 x full-size mini PCIe with SIM holder
–1 x M.2 2230 E key
1.2.2 Display
Controller:
–Intel® UHD Graphics 620 (Core I5)
–Intel® UHD Graphics 610 (Core Celeron®)
Resolution:
–1 x HDMI 1.4b, up to 4096x2160 @ 30Hz
–1 x VGA, up to 1920x1200 @ 60Hz
Dual Display: HDMI + VGA
1.2.3 Ethernet
Chipset:
–LAN1 Intel® I210
–LAN2 Intel® I219
Speed: 10/100/1000 Mbps
Interface: 2 x RJ45
Standard: Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3y,
IEEE 802.ab.
1.3 Chipset
1.3.1 Functional Specifications
1.3.1.1 Processor
1.3.1.2 Chipset
Processor Intel® Core i5-8365UE QC 1.6 GHz
Intel® Celeron® Celeron 4305UE DC 2.0 GHz
Memory Supports DDR4 2400MHz up to 16GB in each slot
2 x 260-pin SODIMM socket type, up to 32G totally
Internal Graphics
Features
OpenGL 4.5, DirectX 11.3/12, OpenCL 2.1
Display Ports: 1 x HDMI +1 x VGA
Video Accelerator H/W accelerated video decoding
Video decoder: H.264 AVC, H.265 8b/10b, M/JPEG, MPEG2 , VC-
1, VP8,VP9
SATA Interface Supports several optional selections of Serial ATA III:
Supports mSATA socket (shared with miniPCIe)
USB Interface USB host interface with support for up to 4 x USB 3.1 Gen2 ports
All ports are High-Speed, Full-Speed, and Low-Speed capable
Supports legacy keyboard/mouse software
BIOS UEFI 256 Mbit

ARK-1551 User Manual 4
1.3.1.3 Others
1.3.2 WISE-PaaS/DeviceOn
Serial Ports 4 x RS-232/422/485, supports auto-flow control; COM3 sup-
ports 5V/12V power
COM Connector: D-SUB connector 9P
Ethernet LAN1 Intel® I210, LAN2 Intel® I219
Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE
802.3y, and IEEE 802.ab
Supports 10/100/1000 Mbps.
LAN Connectors: Phone Jack RJ45 8P 90D(F)
Audio Audio Codec: Realtek ALC892:
Compliant with HD audio specifications
Supports 16/20/24-bit DAC and 16/20/24-bit ADC resolution
Supports Line Out or Mic In audio
Connectors: 1 x Earphone jacks
Battery 1 x 3V/210 mAh battery with wire
Sequence Control Supported
Watchdog Timer Multi-level WDT, programmable 1 ~ 255 sec/min
Hardware Monitor CPU temperature/input current/input voltage
Power Saving Deep sleep S5 mode
System Information Running HR/boot record

5 ARK-1551 User Manual
Chapter 1 General Introduction
1.4 Mechanical Specifications
1.4.1 System Dimensions
L x W x D: 195 x 55 x 140 mm (7.68 x 2.16 x 5.52 in)
Figure 1.1 ARK-1551 Mechanical Dimensions
1.4.2 Weight
1.9 kg (4.19 lb)
1.5 Power Requirements
1.5.1 System Power
Minimum Power Input: 12 ~ 24VDC
Optional Adaptor:
–90W @19V/4.74A power adaptor (optional)
–120W @ 24V/5A power adaptor (optional)
1.5.2 RTC Battery
Lithium: 3 V/210 mAH

ARK-1551 User Manual 6
1.6 Environmental Specifications
1.6.1 Operating Temperature
With industrial-grade SSD/mSATA: -20 ~ 55 °C (-4 ~ 131 °F), with airflow rate =
0.7 m/sec
With 2.5-inch hard disk: 0 ~ 40 °C (32 ~ 104 °F), with airflow rate = 0.7 m/sec
1.6.2 Relative Humidity
95% @ 40 °C/104 °F (non-condensing)
1.6.3 Storage Temperature
-40 ~ 85 °C (-40 ~ 185 °F)
1.6.4 Vibration Tolerance
When the system is equipped with an SSD/mSATA: 3 Grms, IEC 60068-2-64,
random, 5 ~ 500 Hz, 1 hr/axis, (x, y, z) 3 axes
1.6.5 Shock Tolerance
When the system is equipped with an SSD/mSATA: 30 G, IEC 60068-2-27, half
sine, 11 ms duration
1.6.6 Safety Certification
UL, CB, CCC, BSMI
1.6.7 EMC Certification
CE, FCC, CCC, BSMI

Chapter 2
2Hardware Installation
This chapter details instructions
for installing ARK-1551 hardware
and external I/O

ARK-1551 User Manual 8
2.1 Introduction
The following sections show the internal jumper settings and the external connector
pin assignments.
2.2 Jumpers
2.2.1 Jumper Description
ARK-1551 can be configured to satisfy specific application requirements by setting
jumpers. A jumper is a metal bridge used to close an electric circuit. It consists of two
metal pins and a small metal clip (often protected by a plastic cover) that slides over
the pins to connect them. To close a jumper, connect the pins with the clip. To open a
jumper, remove the clip. Sometimes a jumper will have three pins, labeled 1, 2, and
3. For these jumpers, connect either pins 1 and 2, or 2 and 3.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be necessary when working with jumpers. Users
with concerns regarding the ideal hardware configuration for your application should
contact your local distributor or sales representative before making any changes.
Generally, only a standard cable is required to make most connections.
2.2.2 Jumper List
Table 2.1: Jumper Settings
J1 ATX/AT mode
J3 COM3 5V/12V Power Mode
SW1 CMOS Clear
SW6 COM 1 RS422/RS485 Fail Safe Mode
SW7 COM 2 RS422/RS485 Fail Safe Mode
