Advantech HPC-7282 User manual

User Manual
HPC-7282
2U Rackmount Chassis for a
Micro/ATX Server Board with
8 Hot Swappable Drive Bays and
7 Low Profile Expansion Slots

HPC-7282 User Manual ii
Copyright
The documentation and software included with this product are copyrighted by
Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. also reserves the
right to improve the products described in this manual at any time without notice. No
part of this manual may be reproduced, copied, translated, or transmitted in any form
or by any means without the prior written permission of Advantech Co., Ltd. The
information provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
on the rights of third parties that may result from its use.
Acknowledgements
HPC-7282 is a trademark of Advantech Co., Ltd.
All other product names or trademarks are properties of their respective owners.
Online Technical Support
For technical support and services, please visit our support website at
http://www.advantech.com/support
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced at no charge during the warranty period. For out-of-war-
ranty repairs, customers are billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more details.
If you think you have a defective product, follow the steps outlined below.
1. Collect all information about the problem encountered (for example, CPU
speed, Advantech products used, other hardware and software used, etc.). Note
anything abnormal and list any onscreen messages received when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and proof of the purchase date (such as a photocopy of your sales
receipt) in a shippable container. Products returned without a proof of purchase
date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2001728200 Edition 1
Printed in Taiwan November 2015

iii HPC-7282 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use only a damp
cloth for cleaning. Do not use liquid or spray detergents.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect this equipment from humidity.
6. Place this equipment on a reliable surface during installation. Dropping or letting
the equipment fall may cause damage.
7. Do not leave this equipment in an unconditioned environment where the room
temperature fluctuates below 0 °C (32°F) or above 40 °C (104°F). This may
damage the equipment.
8. The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
9. Ensure the power source voltage is correct before connecting the equipment to
a power outlet.
10. Position the power cord away from high traffic areas. Do not place anything over
the power cord.
11. All cautions and warnings on the equipment should be noted.
12. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
13. Never pour liquids into an opening. This may cause fire or electrical shock.
14. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
15. If one of the following occurs, have the equipment checked by service person-
nel:
The power cord or plug is damaged.
Liquid has penetrated the equipment.
The equipment has been exposed to moisture.
The equipment is malfunctioning or does not operate according to the user
manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
16. The computer is equipped with a battery-powered real-time clock circuit. Batter-
ies are at risk of exploding if incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Discard used batteries
according to the manufacturer’s instructions.
17. The CD drives provided with the computer are compliant with relevant safety
standards, including IEC 60825.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
18. This device complies with Part 15 of the FCC Regulations. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference
that may cause undesired operation.
19. Always completely disconnect the power cord from the chassis before manually
handling the hardware. Do not make connections while the power is on. Sudden
power surges can damage sensitive electronic components.

HPC-7282 User Manual iv
20. Always ground yourself to remove any static charge before touching the mother-
board, backplane, or add-on cards. Contemporary electronic devices are very
sensitive to static electric charges. As a safety precaution, wear a grounding
wrist strap at all times. Place all electronic components on a static dissipative
surface or in a static-shielded bag when not in the chassis.
21. Any unverified component may cause unexpected damage. To ensure correct
installation, always use the components (screws) provided in the accessory box.
A Message to the Customer
Advantech Customer Services
Every Advantech product is built to the most exact specifications to ensure reliable
performance in the harsh and demanding conditions typical of industrial environ-
ments. Whether your new Advantech product is destined for a laboratory or factory
floor, be assured that your product will deliver the reliability and ease of operation for
which Advantech is renowned. Your satisfaction is our primary concern. This section
will provide a guide to Advantech's customer services. To ensure you receive the full
benefit of our services, please carefully follow the instructions below.
Technical Support
We want all customers to get the best performance possible from our products.
Should you experience technical difficulties, we are available to help. Answers to the
most frequently asked questions can be easily found in the product documentation.
Because these answers are normally a lot more detailed than those provided over
the phone, we recommend consulting this manual first. If you are still unable to find a
solution, gather all information or questions that apply to your problem, and with the
product in hand, call your dealer. Our dealers are well trained and ready to provide
the support you need to get the most from your Advantech products. Generally, most
of the problems reported are minor and can be easily solved over the phone.
Additionally, Advantech engineers are available to provide free technical support
every business day. We are always ready and willing to give advice about application
requirements or specific information regarding the installation and operation of any of
our products.

v HPC-7282 User Manual
Initial Inspection
Before system installation, please ensure that the following items have been included
in your shipment:
Chassis
–1 x HPC-7282 chassis
Components
–3 x 80*25 mm 4-pin PWM fan
–8 x HDD tray
–1 x SAS/SATA hard drive backplane
Accessories
–1 x accessory box with a package of screws
–2 x HDD tray key
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately. The HPC-7282 has been mechanically and electrically
inspected before shipment. Thus, the system should be free from blemishes and
scratches and in perfect working order upon receipt. While unpacking, double check
the system for signs of shipping damage (for example, a damaged box, scratches,
dents, etc.). If the system is damaged or fails to meet the specifications, notify our
service department or your local sales representative immediately. Additionally,
please notify the carrier. Retain the shipping carton and packing material for inspec-
tion by the carrier. After inspection, we will make arrangements to repair or replace
the unit.

HPC-7282 User Manual vi

vii HPC-7282 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.3 Environmental Specifications .................................................................... 2
Table 1.1: Environmental Specifications ..................................... 2
1.4 Dimensions Diagram................................................................................. 3
Figure 1.1 Dimensions Diagram .................................................. 3
Chapter 2 System Setup.......................................5
2.1 Overview ................................................................................................... 6
2.2 Removing the Chassis Cover.................................................................... 6
2.2.1 Disconnecting the Chassis from the Power Source...................... 6
2.2.2 Removing the Chassis Cover ....................................................... 6
Figure 2.1 Top Cover Removal.................................................... 6
Figure 2.2 Top Cover Reattachment ........................................... 7
2.3 Removing and Replacing the System Fans .............................................. 7
2.3.1 Fan Installation.............................................................................. 7
Figure 2.3 Fan Removal and Installation ..................................... 7
2.4 Installing a Motherboard............................................................................ 8
Figure 2.4 Motherboard Installation ............................................. 8
2.5 Installing a Power Supply Unit .................................................................. 9
Figure 2.5 Single Power Supply Unit Installation......................... 9
Figure 2.6 2U Redundant Power Supply Unit Installation............ 9
Chapter 3 Operation............................................11
3.1 Overview ................................................................................................. 12
Figure 3.1 Chassis User Interface ............................................. 12
3.2 Control Panel Buttons ............................................................................. 12
3.3 Control Panel LEDs................................................................................. 13
3.4 Front Control Board................................................................................. 14
Chapter 4 2U 8-Bay SAS Backplane..................15
4.1 HDD Backplane Top View....................................................................... 16
Table 4.1: Rear SAS/SATA Connectors.................................... 16
Table 4.2: Rear LED Indicators ................................................. 16
4.1.1 HDD Backplane (Mini-SAS) Top View (optional) ........................ 17
Table 4.3: Rear SAS/SATA Connectors.................................... 17
Table 4.4: Rear LED Indicators ................................................. 17
4.2 HDD Backplane Rear View ..................................................................... 18
4.2.1 HDD Backplane (Mini-SAS) Rear View (optional) ...................... 18
4.3 Rear Connector and Pin Definitions........................................................ 19
4.3.1 Backplane Main Power Connectors............................................ 19
Table 4.5: Backplane Main Power 4-Pin Connector.................. 19
4.3.2 Fan Connectors .......................................................................... 19
Table 4.6: 3-Pin Fan Connectors............................................... 19
4.3.3 Redundant Power Supply Fail Alarm Connector ........................ 19
Table 4.7: Redundant Power Supply 2-Pin Connector.............. 19
4.3.4 SATA Ports ................................................................................. 19

HPC-7282 User Manual viii

Chapter 1
1General Information

HPC-7282 User Manual 2
1.1 Introduction
HPC-7282 is a 2U rackmount industrial computer chassis for high-performance and
high-capacity computing applications. The equipment meets a variety of application
requirements for filing, printing, e-mail, and web access. This powerful computing
platform is suitable for mission-critical computer telephony applications, industrial
automation, and factory management. A wide range of standard computing peripher-
als can be integrated with the chassis to satisfy the demands of various applications
and need for 24/7 operation under harsh conditions.
1.2 Specifications
Construction: Heavy-duty steel
Disk Drive Capacity: One slim ODD bay
Front Panel LED Indicators: Power, HDD activity, LAN status, and system
information
Front Panel Switch and Button: Power switch, system reset button
Front Panel I/O Interfaces: Two USB2.0 ports, one COM port
Cooling System: Three 80 x 25 mm hot swappable cooling fans
Weight: 15 kg
Dimensions (W x H x D): 437 x 88 x 533.4 mm
1.3 Environmental Specifications
Table 1.1: Environmental Specifications
Environment Operating Non-Operating
Temperature 0 °C ~ 40 °C -40 °C ~ 70 °C
Humidity 10 ~ 85% @ 40 °C non-condensing 10 ~ 95% @ 40 °C non-condensing

3 HPC-7282 User Manual
Chapter 1 General Information
1.4 Dimensions Diagram
Figure 1.1 Dimensions Diagram

HPC-7282 User Manual 4

Chapter 2
2System Setup

HPC-7282 User Manual 6
2.1 Overview
The following instructions explain the procedures for installing a motherboard, add-on
cards, and disk drives into the HPC-7282.
2.2 Removing the Chassis Cover
2.2.1 Disconnecting the Chassis from the Power Source
1. Turn off all peripheral devices and turn off the power supply to the HPC-7282.
2. Disconnect the AC power cords from the system.
3. Disconnect all cables and label the cables for easy identification.
After completing the above steps, remove the chassis cover and install components
and devices into the chassis by following the instructions provided in this chapter.
2.2.2 Removing the Chassis Cover
Figure 2.1 Top Cover Removal
Caution! Use caution when installing or operating the components with the chas-
sis open. Always turn off the power, unplug the power cord, and ground
yourself by touching the metal chassis before handling any components
inside the machine.
Warning! Use a grounding wrist strap designed to prevent static discharge when
handling components.
ߑ
ߑ
偖ߓ

7 HPC-7282 User Manual
Chapter 2 System Setup
Figure 2.2 Top Cover Reattachment
2.3 Removing and Replacing the System Fans
Before installing a motherboard into the chassis, or accessing the motherboard after
installation, the system fans must be removed. One set of fans is located at the rear
of the chassis, the other set is located in the middle of the chassis.
2.3.1 Fan Installation
Figure 2.3 Fan Removal and Installation
Note! Press the metal button to remove the top cover (see Figure 2.1). After
installing any additional components, reattach the top cover (see Figure
2.2).
ߑ
偖
Note! Slide module A into fan bracket B then affix in place using the screws
provided.
A
B

HPC-7282 User Manual 8
2.4 Installing a Motherboard
Figure 2.4 Motherboard Installation
Note! Install I/O shielding in the rear window opening.
Next, install the motherboard into the chassis and affix in place with the
9 screws provided.

9 HPC-7282 User Manual
Chapter 2 System Setup
2.5 Installing a Power Supply Unit
Figure 2.5 Single Power Supply Unit Installation
Figure 2.6 2U Redundant Power Supply Unit Installation
Note! Install the single power supply unit in the chassis and affix it in place
with 3 screws in the rear window and 2 screws in the chassis. Next,
install the 2U redundant power supply unit in the chassis and affix it in
place with 4 screws in the rear window and 2 screws in the chassis.

HPC-7282 User Manual 10

Chapter 3
3Operation

HPC-7282 User Manual 12
3.1 Overview
Several LEDs are provided on the control panel and the drive carriers to keep users
informed of the overall system status, as well as the activity and health of specific
components. The HPC-7282 chassis control panel features two buttons - a power on/
off switch and a reset button. This chapter describes the LED indicator meanings and
the appropriate response potentially required.
Figure 3.1 Chassis User Interface
3.2 Control Panel Buttons
Two push-buttons are located on the front of the chassis - a reset button (located on
the left) and a power on/off button (located on the right).
Power: The main power switch is used to supply or disconnect power
to the server system. Turning off the system power using this button
disconnects the main power supply but retains the standby power sup-
plied to the system. Therefore, the power cable must be disconnected
from the power outlet before the system is serviced.
Reset: The reset button is used to reboot the system.
