Advantech SOM-6898 User manual

User Manual
SOM-6898
COM Express Compact Module

SOM-6898 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2017
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel is a trademark of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2006689800 Edition 1
Printed in Taiwan July 2017

iii SOM-6898 User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test conditions
for passing included the equipment being operated within an industrial enclosure. In
order to protect the product from being damaged by ESD (Electrostatic Discharge)
and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-
sure products.
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FM
This equipment has passed the FM certification. According to the National Fire Pro-
tection Association, work sites are classified into different classes, divisions and
groups, based on hazard considerations. This equipment is compliant with the speci-
fications of Class I, Division 2, Groups A, B, C and D indoor hazards.
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

SOM-6898 User Manual iv
Warnings, Cautions and Notes
Document Feedback
To assist us in making improvements to this manual, we would welcome comments
and constructive criticism. Please send all such - in writing to: support@advan-
tech.com
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
SOM-6898 CPU module
1 x Heatspreader (1960080159N000)
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.

v SOM-6898 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

SOM-6898 User Manual vi
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

vii SOM-6898 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.2.1 Board Information ......................................................................... 2
1.2.2 System Information ....................................................................... 2
1.2.3 Display .......................................................................................... 3
1.2.4 Expansion Interface ...................................................................... 3
1.2.5 I/O ................................................................................................. 4
1.2.6 iManager 2.0 ................................................................................. 4
1.2.7 Mechanical and Environmental Specification ............................... 4
1.3 Functional Block Diagram ......................................................................... 5
Chapter 2 Mechanical Information ......................7
2.1 Board Information...................................................................................... 8
Figure 2.1 Board Chips Identify - Front........................................ 8
Figure 2.2 Board Chips Identify - Back ........................................ 8
2.2 Mechanical Drawing.................................................................................. 9
Figure 2.3 Board Mechanical Drawing - Front ............................. 9
Figure 2.4 Board Mechanical Drawing - Back ............................. 9
2.3 Assembly Drawing .................................................................................. 10
Figure 2.5 Assembly Drawing.................................................... 10
2.4 Assembly Drawing .................................................................................. 10
Figure 2.6 Main Chip Height and Tolerance (GT2).................... 11
Figure 2.7 Main Chip Height and Tolerance (GT3).................... 11
Chapter 3 BIOS Operation..................................13
Figure 3.1 Setup program initial screen..................................... 14
3.1 Entering Setup ........................................................................................ 15
3.1.1 Main Setup.................................................................................. 15
Figure 3.2 Main setup screen .................................................... 15
3.1.2 Advanced BIOS Features Setup................................................. 16
Figure 3.3 Advanced BIOS features setup screen .................... 16
Figure 3.4 Power & Performance .............................................. 18
Figure 3.5 CPU- Power Management Control ........................... 19
Figure 3.6 GT- Power Management Control.............................. 20
Figure 3.7 Firmware Update Configuration................................ 22
Figure 3.8 PTT Configuration .................................................... 23
Figure 3.9 Trusted Computing ................................................... 24
Figure 3.10ACPI Settings ........................................................... 25
Figure 3.11iManager Configuration ............................................ 26
Figure 3.12Serial Port 1 Configurations...................................... 27
Figure 3.13Serial Port 2 Configurations...................................... 28
Figure 3.14Hardware Monitor ..................................................... 29
Figure 3.15W83627DHGSEC Super IO Configuration ............... 30
Figure 3.16Serial Port 3 Configurations...................................... 31
Figure 3.17Serial Port 4 Configurations...................................... 32
Figure 3.18Parallel Port Configuration........................................ 33
Figure 3.19Serial Port Console Redirection ............................... 34
Figure 3.20Legacy Console Redirection Settings....................... 35
Figure 3.21Network Stack Configuration .................................... 36
Figure 3.22CSM Configuration ................................................... 37

SOM-6898 User Manual viii
Figure 3.23NVMe Configuration ................................................. 38
Figure 3.24USB Configuration.................................................... 39
3.1.3 Chipset........................................................................................ 40
Figure 3.25Chipset Setup........................................................... 40
Figure 3.26System Agent (SA) Configuration ............................ 41
Figure 3.27Memory Configuration .............................................. 42
Figure 3.28Graphics Configuration............................................. 43
Figure 3.29PCH-IO Configuration .............................................. 44
Figure 3.30PCI Express Configuration ....................................... 45
Figure 3.31PCI Express Root Port 0 Configuration.................... 46
Figure 3.32PCI Express Root Port 1 Configuration.................... 47
Figure 3.33PCI Express Root Port 2 Configuration.................... 48
Figure 3.34PCI Express Root Port 3 Configuration.................... 49
Figure 3.35PCI Express Root Port 4 Configuration.................... 50
Figure 3.36SATA And RST Configuration .................................. 51
Figure 3.37USB Configuration.................................................... 52
Figure 3.38HD Audio Configuration............................................ 53
Figure 3.39SCS Configuration.................................................... 54
Figure 3.40SB Porting Configuration.......................................... 55
3.1.4 Security Setting........................................................................... 56
Figure 3.41Security Setup .......................................................... 56
3.1.5 Boot Settings .............................................................................. 57
Figure 3.42Boot Settings ............................................................ 57
3.1.6 Save & Exit ................................................................................. 58
Figure 3.43Save & Exit............................................................... 58
Chapter 4 S/W Introduction & Installation........ 61
4.1 S/W Introduction ..................................................................................... 62
4.2 Driver Installation .................................................................................... 62
4.2.1 Windows Driver Setup ................................................................ 62
4.2.2 Other OS..................................................................................... 62
4.3 Advantech iManager ............................................................................... 63
Appendix A Pin Assignment................................. 65
A.1 SOM-6898 Type 6 Pin Assignment......................................................... 66
Appendix B Watchdog Timer................................ 71
B.1 Programming the Watchdog Timer ......................................................... 72
Appendix C Programming GPIO........................... 73
C.1 GPIO Register......................................................................................... 74
Appendix D System Assignments........................ 75
D.1 System I/O Ports..................................................................................... 76
Table D.1: System I/O ports....................................................... 76
D.2 Interrupt Assignments ............................................................................. 77
Table D.2: Interrupt Assignments .............................................. 77
D.3 1st MB Memory Map............................................................................... 78
Table D.3: 1st MB Memory Map ................................................ 78

Chapter 1
1General Information
This chapter gives background
information on the SOM-6898 CPU
Computer on Module.
Sections include:
Introduction
Specification
Functional Block Diagram

SOM-6898 User Manual 2
1.1 Introduction
SOM-6898 is a COM Express Compact module with type 6 pin-out that fully complies
with the PICMG (PCI Industrial Computer Manufactures Group) COM.0 R2.1 specifi-
cation. The CPU module uses an Intel 7th Generation Core i processor and other
peripheral chips in a basic size 95x95mm COM Express form factor. SOM-6898 fea-
tures a 15 watt TDP and is equipped with a power-saving ULV-SoC on new 14nm
micro architecture. SOM-6898 supports up to 32GB dual channel DDR4 2133 non-
ECC, with higher memory bandwidth for better performance. SOM-6898 is equipped
with an integrated Intel Gen 9 LP graphics micro architecture, supplying up to three
independently operated 4K displays via DisplayPort. It also supports HW accelerated
video decoding for AVC, VC1, MPEG2, HEVC, VP8, JPEG. SOM-6898 I/O includes
PCI Express Gen 3, 2 SATA G3, 4 USB 3.0, 8 USB 2.0. Moreover, 5 PCIe x1 (4 PCIe
x1 + 1 PCIe x4 (support up to 5 devices and 8 lanes) can be supported at a time to
make the IO design more flexible. In addition, SOM-6898 adds mounting holes
around the processor to strengthen the board structure and avoid board bending.
Advantech iManager was designed to satisfy a lot of embedded application require-
ments such as multi-level watchdog timer, voltage and temperature monitoring, and
thermal protection through processor throttling, as well as LCD backlight on/off,
brightness control, and embedded storage information. Combined with Advantech
SUSI Access, it can remotely monitor and control devices via the internet for easy
maintenance. All Advantech COM Express modules integrate iManager and SUSI
Access to benefit customer’s applications. SOM-6898 is suitable for computing inten-
sive, thermal sensitive, graphics/media intense, and I/O demanding applications.
1.2 Specifications
1.2.1 Board Information
Pin Definition: PICMG COM.0 R2.1 Type 6 pin-out definition
Form Factor: PICMG COM.0 R2.1 Compact Module 95 x 95 mm
1.2.2 System Information
CPU: 7th Gen Intel® Core Processors
Memory: 2 SODIMM Socket for DDR4 2133, up to 32 GB
BIOS: AMI UEFI
Power management: Supports power saving modes including Normal /
Standby / Suspend modes. ACPI 2.0 compliant.
CPU Standard Freq. Max. Turbo Freq. Core Cache (MB) TDP(W)
i7-7600U 2.8GHz 3.9GHz 2 4 15
I5-7300U 2.6GHz 3.5GHz 2 4 15
i3-7100U 2.4GHz NA 2 4 15
Celeron 3965U 2.2GHz NA 2 2 15

3 SOM-6898 User Manual
Chapter 1 General Information
1.2.3 Display
Graphic Core: Intel® Gen 9 LP Graphic supports full HW accelerated video
decoding for AVC/VC1/MPEG2/HEVC/VP8/JPEG.
VGA: Resolution up to 1920 x 1200
LVDS: Single and dual channel 18/24-bit resolutions up to 1920 x 1200 @ 60
Hz
eDP: optional, up to 3840 x 2160 @ 60Hz 24bpp or 4096 x 2304 @ 60Hz 24bpp
HDMI/DVI/DP: Supports 3 ports HDMI (default), DVI, or DP multiplexed.
Resolution: HDMI up to 4096 x 2160 @24Hz
DVI up to 1920 x 1080 @ 60 Hz
DP up to 3840 x 2160 @ 60Hz 24bpp
or 4096 x 2304 @ 60Hz 24bpp
Dual Display: VGA + LVDS, VGA + HDMI/DVI/DP, LVDS + HDMI/DVI/DP, VGA
+ eDP (Optional), eDP + HDMI/DVI/DP (Optional), HDMI/DVI/DP + HDMI/DVI/
DP (Optional)
Triple Display: VGA + LVDS + HDMI/DVI/DP, VGA + eDP + HDMI/DVI/DP
(Optional), eDP + HDMI/DVI/DP + HDMI/DVI/DP (Optional)
1.2.4 Expansion Interface
PCI Express x1: Supports default 5 ports PCIe x1 compliant.
To PCIe Gen3* (8.0 GT/s) specification, several configurable
combinations may need BIOS modifies. Please contact
Advantech sales or FAE for more detail.
(PCIe x1 Port #7 option with SATA2)
Audio Interface: Intel HD Audio interface
LPC Bus: Yes (24MHz)
SMBus: Yes
I2C Bus: Up to 400KHz
SPI: Supports SPI BIOS only
CPU Graphics Core Base Freq. Max Freq.
i7-7600U Intel® HD Graphics 620 300MHz 1.15GHz
I5-7300U Intel® HD Graphics 620 300MHz 1.1GHz
i3-7100U Intel® HD Graphics 620 300MHz 1GHz
Celeron 3965U Intel® HD Graphics 610 300MHz 900MHz
x4 x2 x1
Default104
Option 1 0 0 5
Option 2 2 0 0
Option 3 1 2 0
Option 4 1 1 2
Option 5 0 4 0
Option 6 0 2 3

SOM-6898 User Manual 4
1.2.5 I/O
Ethernet: Intel I219LM Gigabit LAN supports 10/100/1000 Mbps Speed
SATA: Supports 2 ports SATA 3.0 (6 Gbit/s)
Support RAID 0/1/5/10, AHCI 1.3
*optional support 3 SATA 3.0 (6 Gbit/s)
USB Interface: Supports 4 ports USB3.0, 8 ports USB 2.0
Serial Port: Supports 2 ports 2-wire serial port
Express Card: 2 ports
Panel Control: Supports panel backlight on/off control, brightness control
Thermal Protection: Supports thermal shutdown or CPU throttling
Watchdog Timer: 65536 level timer interval, from 0~65535 sec, multi-level,
multi-option watchdog timer
Smart Fan: 1 port on Module, 1 port down to carrier board
GPIO: 8-bit GPIO
Hardware Monitor: Vin, 5VSB, CMOS
TPM: Optional TPM2.0 (Infineon SLB9665)
1.2.6 iManager 2.0
Refer to section 4.3.
1.2.7 Mechanical and Environmental Specification
Dimensions: 95 x 95 mm (3.74" x 3.74")
Power Type and Supply Voltage:
–ATX: +8.5~20V and +4.75~5.25VSB (standby power)
–AT: +8.5~20V
–CMOS Battery: +3.3V
Power Requirement:
–Test condition: SOM-6898C7-U8A1E (i7-7600U), ADVANTECH 16GB SO-
DDR4-2133 I-GRD 2PCS, Windows 10 Pro, rated voltage DC +5.0V, +12.0V,
+20.0V
–Idle: 4.16W
–Max: 24.61W (BurnIn Test V8.1 Pro (1016) for 64 bit Windows)
Temperature Specification:
–Operating: 0 ~ 60°C (32 ~ 140°F)
–Storage: -40 ~ 85°C (-40 ~ 185°F)
Humidity Specification:
–Operating: 40°C @ 95% relative humidity, non-condensing
–Storage: 60°C @ 95% relative humidity, non-condensing

5 SOM-6898 User Manual
Chapter 1 General Information
1.3 Functional Block Diagram
Connector Row C, D
260pin SO-DIMM x 2
1866/2133MHz
eMMC (Optional)
DDI Port 2 HDMI / DisplayPort / DVI
DDI Port 1 HDMI / DisplayPort / DVI
1 x PCIEx1 (PCIE6)
Dual Channel DDR4
1 x PCIEx1 (PCIE7)*
* Default Setting
4 x USB3.0
7th Gen Intel® Core™ /
Celeron® Processors
U-Series (SoC)
HD Audio
2 x SATA3 (SATA0 ~ SATA1)*
6 x PCIEx1 (PCIE0 ~ PCIE5)
8 x USB2.0
1 x SATA3 (SATA2)
WDT / GPIO* / I
2
C
* Default Setting
SMBus
SPI Bus
LPC BUS
GPIO
Option with Analog VGA
1 x PCIEx1 Giga LAN
eDP
Option with LVDS
RS1/ RS2/ FAN
Dual LVDS Channel*
* Default Setting
EC
TPM2.0
SPI BIOS
IMVP8
eDP to LVDS
(CH7511)
DDI Port 2 DP Analog VGA*
* Default Setting
DP to VGA
(CH7517)
LAN
Option with SATA2
Connector Row A, B

SOM-6898 User Manual 6

Chapter 2
2Mechanical
Information
This chapter gives mechanical
information on the SOM-6898 CPU
Computer on Module.
Sections include:
Board Information
Mechanical Drawing
Assembly Drawing

SOM-6898 User Manual 8
2.1 Board Information
The figures below indicate the main chips on SOM-6898 Computer-on-Module. Be
aware of these positions when designing your own carrier board to avoid mechanical
issues, as well as designing a thermal solution with contact points for the best ther-
mal dissipation performance.
Figure 2.1 Board Chips Identify - Front
Figure 2.2 Board Chips Identify - Back
DDR4
SODIMM Socket
SoC
EC Chip
COM Express
Connector
DDR4
SODIMM Socket
eMMC
Optional)

9 SOM-6898 User Manual
Chapter 2 Mechanical Information
2.2 Mechanical Drawing
For more details about 2D/3D models, please look on the Advantech COM support
service website http://com.advantech.com.
Figure 2.3 Board Mechanical Drawing - Front
Figure 2.4 Board Mechanical Drawing - Back
0
49.8
95
0
48.6
87.2
95
81.3
9.9
78.7
Ø6
Ø2.7
0
6
18
83.5
87.2
91
4
31.7
91
0
15
20.8
62.7
78.5
91
4
9.9
78.7
84.7
91
R2

SOM-6898 User Manual 10
2.3 Assembly Drawing
These figures demonstrate the assembly order from the thermal module, COM mod-
ule to the carrier board.
Figure 2.5 Assembly Drawing
2.4 Assembly Drawing
Please consider the CPU and chip height tolerance when designing your thermal
solution.
F2=Option1 NOM: 0.315, TOL: ±0.018
Option 2 NOM: 0.415, TOL: ±0.018
F3=Option1 NOM: 0.537, TOL: ±0.07
Option 2 NOM: 0.537, TOL: ±0.07
F4=Option1 NOM: 0.852, TOL: ±0.072
Option 2 NOM: 0.952, TOL: ±0.072
F5=Option1 NOM: 1.08, TOL: ±0.092
Option 2 NOM: 1.18, TOL: ±0.092 (POST SMT STACKUP HEIGHT BASED ON
LIMITED DATA FROM INTEL REFERENCE BOARD DESIGN)
Semi-cooler
Heatspreader
Stand off
Nut
SOM-6898
Carrier Board

11 SOM-6898 User Manual
Chapter 2 Mechanical Information
Figure 2.6 Main Chip Height and Tolerance (GT2)
F5= NOM: 1.213, TOL: ±0.108 (PRE SMT PACKAGE HEIGHT)
NOM: 1.16, TOL: ±0.108 (POST SMT STACKUP HEIGHT BASED ON LIMITED
DATA FROM INTEL REFERENCE BOARD DESIGN)
Figure 2.7 Main Chip Height and Tolerance (GT3)

SOM-6898 User Manual 12
