Advantech AIM8IEM User manual

1
AIM8IEM/AIM8Q Computer
User Manual

2
V1.0
Copyright
The documentation and the software included with this product are copyrighted
2017 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves
the right to make improvements in the products described in this manual at any time
without notice. No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written permission of
Advantech Co., Ltd. Information provided in this manual is intended to be accurate
and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor
for any infringements of the rights of third parties, which may result from its use.
Acknowledgements
All other product names or trademarks are properties of their respective owners.

3
Declaration of Conformity
CE Conformity Statement
Radio products with the CE alert marking comply with the R&TTE Directive
(1999/5/EC) issued by the Commission of the European Community. Compliance
with this directive implies conformity to the following European Norms (in brackets
are the equivalent international standards).
• EN 60950-1 (IEC60950-1) - Product Safety
• EN 300 328 Technical requirement for radio equipment
• ET S301 489 General EMC requirements for radio equipment
Products that contain the radio transmitter are labeled with CE alert marking and
may also carry the CE logo.
FCC Compliance Statement
15.105
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
15.21
Any changes or modifications not expressly approved by the party responsible for
compliance could void the authority to operate equipment.
This device and its antenna must not be co-located or operating in conjunction with
any other antenna or transmitter.

4
End-users and installers must be provided with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure compliance.
For product available in the USA/Canada market, only channel 1~11 can be operated.
Selection of other channels is not possible.
To assure continued compliance, any changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to
operate this equipment. (Example: use only shielded interface cables when
connecting to computer or peripheral devices).
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that
may cause undesired operation.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment for body-worn configuration in direct contact to the
phantom. Portable Device body-SAR contact 0 cm
This device complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves. This
device is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications Commission of
the U.S. Government.
The exposure standard for wireless devices employing a unit of measurement is
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is
1.6W/kg.
The FCC has granted an Equipment Authorization for this device with all reported
SAR levels evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this device is on file with the FCC and can
be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID: M82-AIM8IEM
Result for highest Simultaneous Transmission SAR value is 1.588 W/kg.

5
IC warning statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions: (1) This device may not cause interference;
and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
This radio transmitter has been approved by Industry Canada to operate with the
antenna types listed below with the maximum permissible gain and required
antenna impedance are strictly prohibited for use with this device.
Le present emetteur radio a ete approuve par Industrie Canada pour fonctionner
avec les types d'antenne enumeres ci-dessous et ayant un gain admissible maximal
et l'impedance requise pour chaque type d'antenne. Les types d'antenne non inclus
dans cette liste, ou dont le gain est superieur au gain maximal indique, sont
strictement interdits pour l'exploitation de l'emetteur.
IC Radiation Exposure Statement
This EUT is compliance with SAR for general population/uncontrolled exposure limits
in IC RSS-102. This equipment should be installed and operated with minimum
distance 0 cm between the radiator & your body.
Cet EUT est la conformite avec SAR pour la population generale / les limites
d'exposition incontrolees dans IC RSS-102. Cet equipement doit etre installe et
utilise a une distance minimale de 0 cm entre le radiateur et votre corps.
This equipment complies with ISED radiation exposure limits set forth for an
uncontrolled environment. End user must follow the specific operating instructions
for satisfying RF exposure compliance. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.

6
The portable device is designed to meet the requirements for exposure to radio
waves established by the ISED. These requirements set a SAR limit of 1.6 W/kg
averaged over one gram of tissue. The highest SAR value reported under this
standard during product certification for use when properly worn on the body.
Cet équipement est conforme aux limites d’exposition aux rayonnements ISED
établies pour un environnement non contrôlé. L’utilisateur final doit suivre les
instructions spécifiques pour satisfaire les normes. Cet émetteur ne doit pas être
co-implanté ou fonctionner en conjonction avec toute autre antenne ou
transmetteur.
Result for highest Simultaneous Transmission SAR value is 1.588 W/kg.
NCC Warning Statement
Article 12
Without permission, any company, firm or user shall not alter the frequency,
increase the power, or change the characteristics and functions of the original design
of the certified lower power frequency electric machinery.
Article 14
The application of low power frequency electric machineries shall not affect the
navigation safety nor interfere a legal communication, if an interference is found,
the service will be suspended until improvement is made and the interference no
longer exists.

7
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this user manual for later reference.
3. Disconnect this equipment from AC outlet before cleaning. Do not use liquid or
spray detergents for cleaning.
4. Keep this equipment away from hazard locations.
5. Put this equipment on a reliable surface during installation. Dropping it or
letting it fall could cause damage.
6. Do not leave this equipment in an environment unconditioned where the
storage temperature under -20°C or above 60°C, it may damage the
equipment.
7. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
8. Place the AC power adapter such a way that people cannot step on it. Do not
place anything over the power adapter.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not used for long time, disconnect it from the power
source to avoid being damaged by transient over-voltage.
11. Never pour any liquid into slots of the AIM8IEM and AIM8Q Series. This could
cause fire or electrical shock.
12. Never open or disassemble the equipment. For safety reasons, the equipment
should be opened only by qualified service personnel.
13. If any of the following situations arises, get the equipment checked by service
personnel:
a.The power adapter plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well or you cannot get it to work according to
user manual.
e.The equipment has obvious signs of breakage.
14. This product is intended to be supplied by a UL Listed Power Adapter or DC
power source, rated 5.0 - 5.15 Vdc, 3A min. for model AIM8IEM, rated 9.0 – 9.1
Vdc, 2A min for model AIM8Q and Tma 50 degree C, if need further assistance,
please contact Advantech for further information.

8
Battery Safety
Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the
same type recommended by the manufacturer, discard used batteries according to
the manufacturer's instructions.
Attention : Danger d'explosion si la batterie est inexactement remplacée. Remplacez
seulement avec la même chose ou le type recommandé par le fabricant, jettent les
batteries utilisées instructions de s selon fabricant des'.
Mistreat the battery used in this device may present a risk of fire or chemical burn.
Do not attempt to disassemble the computer or its accessories.
Only qualified personal is allowed to replace the battery.
Do not dispose batteries in a fire and check with local authorities for disposal
instructions.
AIM8IEM/AIM8Q can only be equipped with standard battery pack with Getac,
AIM-BAT-8, 4900mAH Polymer Lithium Ion Battery. Use of another battery may
present a risk of fire or explosion.
Battery Charge Notice
It is important to consider the environment temperature whenever you are charging
the Lithium-Ion battery pack. The process is more efficient at normal room
temperature or slightly cooler. It is essential that you charge batteries within the
stated range of 0°C to 40°C. Charging batteries outside of the specified range could
damage the batteries and shorten their charging life cycle.
Storage and Safety Notice
Although charge Lithium-Ion batteries may be left unused for several months, their
capacity may be depleted due to the buildup of internal resistance. If this happens
they will require recharging prior to use. Lithium Ion batteries may be stored at
temperatures between -10°C to 60°C, however they may be depleted more rapidly
at the high end of this range. It is recommended to store AIM8IEM/AIM8Q within
normal room temperature ranges.T-W101 User Manual

9
WEEE
EN
Following information is only for EU-member states:
The use of the symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this product. For more
information about recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you purchased the product.
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
– Product name and serial number
– Description of your peripheral attachments
– Description of your software (operating system, version, application software,
etc.)
– A complete description of the problem
– The exact wording of any error messages

10
TABLE OF CONTENT
Chapter 1 Introduction.............................................................................................12
1.1 Symbols Used in this Manual......................................................................................... 13
1.2 Product Features ........................................................................................................... 13
1.3 Package Contents .......................................................................................................... 13
1.4 Product Specifications ................................................................................................... 14
1.4.1 Technical Specifications .......................................................... 14
1.4.2 Product Outlook and Dimensions ................................................ 16
1.5 Exploring the AIM8IEM/AIM8Q..................................................................................... 17
1.5.1 Front View ............................................................................1
1.5.2 Rear View ........................................................................... 18
1.5.3 Right View........................................................................... 19
1.5.4 Left View............................................................................ 20
1.5.5 Bottom View........................................................................ 20
Chapter 2 Getting Started.......................................................................................21
2.1 Charge the Computer .................................................................................................... 21
2.2 Turn on the Computer................................................................................................... 22
2.3 Sleep Mode.................................................................................................................... 22
2.4 Operate the computer................................................................................................... 23
2.5 LED indicator status....................................................................................................... 23
Chapter 3 Basic Setups.............................................................................................24
3.1 Windows 10 IoT Enterprise Basic Setups ...................................................................... 25
3.2 Android 6.0.1 Basic Settings.......................................................................................... 26
Chapter 4 Running applications..............................................................................28
4.1 Installing applications.................................................................................................... 28
4.1.1 Install applications with Windows 10 IoT Enterprise.......................... 29

11
4.1.2 Install applications with Android 6.0.1 ......................................... 30
Chapter 5 Maintenance............................................................................................34
5.1 Maintaining the LCD Display.......................................................................................... 34
5.2 Cleaning the AIM8IEM/AIM8Q...................................................................................... 34
5.3 Trouble Shooting ........................................................................................................... 34
5.4 ENERGY STAR............................................................................................................... 35

12
Chapter 1 Introduction
Congratulations on your purchase of the AIM8IEM/AIM8Q Computer.
AIM8IEM/AIM8Q has two variants and the main difference is that AIM8IEM is powered
by Intel Atom x5-Z8350 and supports Windows 10 IoT Enterprise while AIM8Q is
equipped with Qualcomm APQ8074 and supports Android 6.0 OS.
This product combines stylish design with reliable performance and powerful
functionality to best suit all your needs, in a wide range of working conditions. This
user manual outlines all you need to know to set up and use your AIM8IEM/AIM8Q. If
you have any further questions or queries, contact our technical support team via
our website:
http://support.advantech.com.tw/

13
1.1 Symbols Used in this Manual
Denotes information that must be observed.
Failure to do so may result in personal harm or damage to
the product.
Denotes information that must be observed.
This is informative notification to have a better
experience while using this computer.
1.2 Product Features
• Low power Intel® ATOM™ / Qualcomm® Snapdragon™ processor designed for
mobile applications.
• Support Windows 10 IoT Enterprise(AIM8IEM) and Android 6.0 (AIM8Q) OS.
• 8“ WUXGA projected capacitive multi touch display.
• -10°C to 50°C, IP65, MIL-STD 810G / 4ft drop compliant.
• Compact/slim design: 14.5 mm height, 600g weight.
• Seamless communications, including Wi-Fi, BT, NFC, 3G/4G.
• Optional extension modules, including 1D/2D barcode scanner, MSR, RJ45+COM,
UHF RFID Reader and more.
• Optional dock stations, including VESA/Vehicle dock & multi charger design.
1.3 Package Contents
Ensure all the following items are present when you receive your AIM8IEM/AIM8Q. If
any of these items are missing, contact your dealer immediately.
• AIM8IEM/AIM8Q Computer
• Startup Manual
• AC power adaptor

14
1.4 Product Specifications
1.4.1 Technical Specifications
Model Name AIM8IEM AIM8Q
Computing
System
CPU Intel Atom x5-Z8350 Qualcomm APQ8074
Max Speed 1.44 GHz 2.2 GHz
Memory 2GB LPDDR3
OS Windows 10 IoT Enterprise 64 bit Android 6.0.1 32 bit
Storage
On-board
eMMC 32GB/64GB ( Default 32GB)
Micro-SD Micro-SD Card Slot for Storage Expansion
Display
Display Type 8” TFT IPS LCD Panel
Max
Resolution WUXGA, 1200x1920, 400 nits
Touch Type Projected Capacitive Multi-Touch
Class Type G/G Direct Bonding, Corning GG3 Glass
Communication
WIFI 802.11b/g/n (2.4Ghz) Dual Band : 802.11ac (5Ghz) or
802.11n(2.4Ghz)
Bluetooth Bluetooth v4.0 CLASS II/BLE
NFC (13.5MHz) Read/ Write Device Compatible With ISO15693, ISO14443A, ISO14443B, Felica
AGPS
GPS
AGPS
GPS & GLONASS & (Optional)
Beidou
AGPS
GPS & GLONASS & (Optional)
Beidou
WWAN/ LTE
(Optional)
M.2 Module
NA
Micro-SIM Slot
Mini-PCIe Module
EU, NA & China
Micro-SIM Slot
Audio Build-In Digital MIC, x1 80dB 1Watt SPK 0.5M, x1 Audio combo jack
Connectivity I/O Port
Interfaces
x1 Micro USB 2.0 (Charging) x1 Micro USB 2.0 (OTG & Charging)
x1 Micro HDMI: Display
x1 AIM Dock 16-pin Pogo Connector: USB 3.0
x1 AIM Extension 14-pin Pogo Connector: USB 2.0 + TX/RX + Power
Camera Front 2MP Fixed Focus 5MP Fixed Focus
Rear 5MP Auto Focus with LED Flash 13MP Auto Focus with LED Flash
Sensor G-sensor + E-compass, Gyroscope, ALS

15
Hard Buttons Function
x1 Power Button
x2 Volume Control Button
x1 Programmable Button ( Default as BCR Trigger Key)
System Indicators x1 Power / Battery Status
Power Input Micro USB DC 5V, 3A DC 9V, 2A
Battery
Capacity Swappable Battery with Battery Meter
3.8Vdc ; 4900mAH ; 18.62Wh
Operating
Temperature 0~40 °C (Charging)
Environment
Temperature Operating: -10°C ~ +50°C, Storage: -20°C ~ +60°C,
System Charging mode: 0~40 °C
Operating
& Storage
Humidity
5% ~ 95% @ 40° C (non-condensing)
Vibration Operation: (5-500GHz) 1G, Non-operating: (5-500GHz) 0.04PSD
Ingress
Protection
Dust/ Water
Resistance IP-65 compliant
Ingress
Protection
Dimensions 142 x 240 x 14.5mm (W x H x D)
Weight 600g
Color Black/Orange, Grey/Blue, White/Blue

16
1.4.2 Product Outlook and Dimensions
All AIM8IEM/AIM8Q Series share the same dimension, the following illustration uses
AIM8IEM as example.

17
1.5 Exploring the AIM8IEM/AIM8Q
1.5.1 Front View
No. Component
1 Front Camera
2 Power LED
3 Light Sensor
4 Speaker
1 2
3
4

18
1.5.2 Rear View
No. Component
1 Extension Module
2 NFC
3 Rear Camera with LED Flash
4 Battery Cover
1
2
3
4

19
1.5.3 Right View
No. Component
1 SIM & SD Card Door
2 Programmable Key (Default BCR)
3 Pogo Pin (USB3.0)
4 Micro USB Door
3
4
1
2

20
1.5.4 Left View
No. Component
1 Micro HDMI Door
2 Power Button
3 Volume Key UP/Down
1.5.5 Bottom View
No. Component
1 Audio Jack (Headset Combo)
1
2
3
1
