Advantech ITA-3650G Series User manual

User Manual
ITA-3650G Series
Compact Fanless Embedded
High-Performance Industrial
Computer
嵌入式無風扇電腦

ITA-3650G_Series User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to improve the products described in this manual at any time without notice. No part
of this manual may be reproduced, copied, translated, or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd. The infor-
mation provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
of the rights of third parties that may result from its use.
Acknowledgements
The ITA-3650G is trademark of Advantech Co., Ltd.
All other product names or trademarks are properties of their respective owners.
Online Technical Support
For technical support and customer service, visit the Advantech support website at
http://support.advantech.com.cn
Part No. 2001365010 Edition 1
Printed in China February 2020

iii ITA-3650G_Series User Manual
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers are billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more details.
If you believe your product is defective product, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any messages displayed onscreen when the prob-
lem occurs.
2. Call your dealer and describe the problem. Have your manual, product, and any
helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of the sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package, and ship the pack-
age prepaid to your dealer.

ITA-3650G_Series User Manual iv
A Message to the Customer
Advantech Customer Services
Every Advantech product is built to the most exact specifications to ensure reliable
performance in the harsh and demanding conditions typical of industrial environ-
ments. Whether your new Advantech equipment is destined for the laboratory or the
factory floor, you can be assured that your product will provide the reliability and ease
of operation for which the Advantech brand has come to be known. Your satisfaction
is our primary concern. To ensure you get the full benefit of our services, follow the
instructions below carefully.
Technical Support
We want you to get the best performance from your products. However, should you
encounter technical difficulties, we are here to help. For the most frequently asked
questions, you can easily find answers in the product documentation. These answers
are typically a lot more detailed than the ones we can provide over the phone. So
please consult this manual first. If you still cannot find the answer, gather all the infor-
mation or questions that apply to your problem, and with the product within reach, call
your dealer. Our dealers are well trained and ready to provide the support you need
to get the most from your Advantech products. In fact, most problems reported are
minor and can be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice about application requirements or spe-
cific information regarding the installation and operation of any of our products.
Initial Inspection
Upon opening the product, check to ensure that the following items have been
included in the shipment:
1 x ITA-3650G series industrial computer
1 x ITA-3650G accessory box
1 x Warranty card
If any of the above items are missing or damaged, contact your distributor or sales
representative immediately. We have carefully inspected ITA-3650G mechanically
and electrically before shipment. It should be free of marks and scratches and in per-
fect working order upon receipt. As you unpack ITA-3650G, check it for signs of ship-
ping damage (for example, box damage, scratches, dents, etc.). If the product is
damaged or fails to meet the specifications, notify our service department or your
local sales representative immediately. Additionally, notify the carrier. Retain the ship-
ping carton and packing material for inspection by the carrier. After inspection, we will
make arrangements to repair or replace the unit.

v ITA-3650G_Series User Manual
RoHS Declaration
設備名稱：電腦ġġġġġ型號（型式）：ŊŕłĮ ġ ĩ型號參見說明書Ī
單元 烤nit ġ
限用物質及其化學符號
鉛 Lead ġ
ĩőţĪġ
汞 Mercury ġ
ĩʼnŨĪġ
鎘 Cadmium ġ
ĩńťĪġ
六價鉻
Hexavalent
chromium
ĩńų+6Ī
多溴聯苯
Polybrominated
biphenyls ġ
ĩőŃŃĪġ
多溴二苯醚
Polybrominated
diphenyl ethers
ġ
ĩőŃŅņĪġ
電路板ġ—ġŐġ Őġ Őġ Őġ Őġ
外殼ġ—ġŐġ Őġ Őġ Őġ Őġ
線材ġ—ġŐġ Őġ Őġ Őġ Őġ
螺絲ġ—ġŐġ Őġ Őġ Őġ Őġ
附件（介
面，支架）
ġ—ġŐġ Őġ Őġ Őġ Őġ
備考IJį〝超出ıįIJġŸŵġĦ〞及〝超出ıįıIJġŸŵġĦ〞係指限用物質之百分比含量超出百分比含量基準值。ġ
備考ijį〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。ġ
備考Ĵį〝－〞係指該項限用物質為排除項目。ġ
Equipment name
Type designation (Type)
Restricted substances and its chemical symbols
Note 1
烉
“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the
reference percentage value of presence condition.
Note 2
烉
“
˕
” indicates that the percentage content of the restricted substancedoes not exceed the percentage of reference value of presence.
Note 3
烉
The “

” indicates that the restricted substance corresponds to the exemption.
3650G

ITA-3650G_Series User Manual vi
Warnings, Cautions, and Notes
警告使用者！這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，
在這種情況下，使用者會被要求採取某些適當的對策。
Warning! Warnings indicate conditions that, if not observed, can cause personal
injury!
Caution! Cautions are included to help prevent hardware damage and data
losses.
For example, “Batteries are at risk of exploding if incorrectly installed.
Replace the battery only with the same or equivalent type as recom-
mended by the manufacturer. Discard used batteries according to the
manufacturer's instructions.”
Note! Notes provide additional optional information.

vii ITA-3650G_Series User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
it fall may cause damage.
7. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
8. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is left idle for a long time, disconnect it from the power source
to avoid damage from transient overvoltage.
11. Never pour liquid into an opening. This may cause fire or electrical shock.
12. Never open the equipment. For safety reasons, the equipment should only be
opened by qualified service personnel.
13. If one of the following occurs, have the equipment checked by qualified service
personnel:
The power cord or plug is damaged.
Liquid has penetrated the equipment.
The equipment has been exposed to moisture.
The equipment is malfunctioning, or does not operate according to the user
manual.
The equipment has been dropped and damaged.
The equipment shows obvious signs of breakage.
14. Do not leave the equipment in an environment with a storage temperature of
below -25 °C (-13 °F) or above 40 °C (104 °F) as this may damage the equip-
ment.
15. The equipment has been tested and found to comply with the limits for a Class
A digital device. Operation of the equipment in a residential area is likely to
cause harmful interference. In this event, users are required to correct the inter-
ference at their own expense.
16. Advantech does not provide the power component for this equipment. Users are
instructed to purchase power components that have been CCC certified. This
equipment is intended to be supplied by a UL-certified power adapter or UL-cer-
tified DC power source rated 9 ~ 36VDC, 18 ~ 9A minimum, with a max. temper-
ature of 40 °C. If you require additional assistance, contact Advantech for further
information.
17. CAUTION: This equipment is equipped with a battery-powered real-time clock
circuit. There is a risk of explosion if the batteries are incorrectly replaced.
Replace only with same or equivalent type as recommended by the manufac-
turer. Discard used batteries according to the manufacturer’s instructions.
18. In accordance with IEC 704-1:1982 specifications, the sound pressure level at
the operator's position does not exceed 70 dB (A).
19. Disposing of a battery into a fire or a hot oven, or by mechanically crushing or
cutting it, can cause an explosion.
20. The power cord should be connected to an earthed power outlet socket.

ITA-3650G_Series User Manual viii
DISCLAIMER: These instructions are provided in accordance with the IEC 704-1
specification. Advantech disclaims all responsibility for the accuracy of any state-
ments contained herein.
Consignes de sécurité
1. Lisez attentivement ces consignes de sécurité.
2. Gardez ce manuel pour référence future.
3. Déconnectez cet équipement de toute prise secteur avant de le nettoyer. Utili-
sez un chiffon humide. Ne pas utilisez de liquide ou de sprays détergents pour
le nettoyage.
4. La prise de courant doit être située près de l'équipement et doit être facilement
accessible.
5. Gardez cet équipement à l'abri de l'humidité.
6. La chute de l'équipement pouvant l'endommager, celui-ci doit être installé sur
une surface stable.
7. Assurez-vous que la tension de la source d'alimentation est correcte avant de
brancher l'appareil à la prise de courant.
8. Placez le cordon d'alimentation de manière à éviter que des personnes march-
ent dessus.
9. Tous les conseils et avertissements concernant ce matériel et son utilisation doi-
vent être lus et compris.
10. Si l'appareil n'est pas utilisé pendant une longue période, débranchez-le de la
source d'alimentation pour éviter les dommages causés par des surtensions
transitoires.
11. Ne jamais verser de liquide dans une ouverture. Cela peut provoquer un
incendie ou un choc électrique.
12. Ne jamais ouvrir l'équipement. Pour des raisons de sécurité, l'équipement ne
peutêtre ouvert que par du personnel qualifié.
13. Si l'une des situations suivantes se présente, faites vérifier le matériel par le
personnel de service:
Le cordon d'alimentation ou la prise est endommagé.
Du liquide a pénétré dans l'appareil.
L'équipement a été exposé à l'humidité.
L'équipement ne fonctionne pas bien, ou vous ne pouvez pas le faire fonction-
ner selon le manuel d'utilisation.
L'appareil est tombé et est endommagé.
L'équipement présente des signes évidents de casse
14. Ne pas laissez ce matériel dans un environnement où la température de stock-
age peut descendre en dessous de -25 °C (-13 °F) ou être supérieure à 40 °C
(104 °F). Ceci pourrait endommager l'équipement. L'équipement doit être main-
tenu dans un environnement contrôlé.
15. Cet équipement a été testé et déclaré conforme aux limites imposées aux appa-
reils numériques de classe A. L'utilisation de cet équipement dans une zone
résidentielle est susceptible de provoquer des interférences nuisibles. Dans ce
cas, l'utilisateur sera tenu de corriger les interférences à ses frais.
16. Advantech ne fournit pas de composant d'alimentation pour ce produit, les utilis-
ateurs doivent donc en acheter avec un certificat CCC. Ce produit est destiné à
être alimenté par un adaptateur secteur certifié UL ou une source CC certifiée
UL de classe 9. Pour toute assistance supplémentaire, veuillez contacter
Advantech pour plus d'informations.

ix ITA-3650G_Series User Manual
17. ATTENTION: Risque d’explosion si la batterie est remplacee de maniere incor-
recte.
Remplacer uniquement avec un modèle recommandé par le fabricant, et élimi-
ner les piles usages selon les instructions du fabricant.
18. Conformément à la norme CEI 704-1:1982, l'opérateur ne doit pas experimenter
un niveau sonore supérieur à 70 dB (A).
19. Éliminer une batterie dans un feu ou un four chaud, ou écraser ou couper méca-
niquement une batterie peut provoquer une explosion.
20. Veillez à connecter le cordon d'alimentation à une prise de courant avec mise à
la terre.
AVERTISSEMENT: Ces consignes suivent la norme CEI 704-1.
Advantech décline toute responsabilité concernant l'exactitude des déclarations
contenues dans ce document.
Safety Precautions - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
1. To avoid electrical shock, always disconnect the power from the PC chassis
before manual handling. Do not touch any components on the CPU card or
other cards while the device is powered on.
2. Disconnect the power before making any configuration changes. A sudden rush
of power after connecting the jumpers or installing a card may damage sensitive
electronic components.

ITA-3650G_Series User Manual x

xi ITA-3650G_Series User Manual
Contents
Chapter 1 Overview...............................................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.3 Power ........................................................................................................ 2
Table 1.1: Power Specifications .................................................. 2
1.4 Environmental ........................................................................................... 3
Table 1.2: Environmental Specifications ..................................... 3
1.5 Dimensions ............................................................................................... 3
Figure 1.1 ITA-3650G Dimensions .............................................. 3
1.6 Exploded Diagram..................................................................................... 4
Figure 1.2 ITA-3650G Diagram ................................................... 4
Table 1.3: Parts List..................................................................... 4
Chapter 2 System Setup.......................................5
2.1 Introduction ............................................................................................... 6
2.2 System Status ........................................................................................... 6
2.2.1 System Status LED Indicators ...................................................... 6
Figure 2.1 ITA 3650G Indicator Locations ................................... 6
2.3 Jumpers and Connectors .......................................................................... 7
2.3.1 Jumper Description ....................................................................... 7
2.3.2 Jumper and Connector Locations ................................................. 8
Table 2.1: Jumpers and Connectors ........................................... 8
Figure 2.2 Motherboard Connectors and Jumpers...................... 9
Figure 2.3 Expansion I/O Card Connectors and Jumpers........... 9
Table 2.2: JCOMS1: Clear COMS Selection............................. 10
Table 2.3: VCCGPIO1: GPIO Voltage Selection ....................... 10
Table 2.4: PSON1: Startup Mode Selection.............................. 10
Table 2.5: AMPL1: L Sound Channel Amplifier Switch ............. 11
Table 2.6: AMPR1: R Sound Channel Amplifier Switch ............ 11
2.4 I/O Connectors........................................................................................ 12
Figure 2.4 ITA-3650G-00A1 Front View .................................... 12
Figure 2.5 ITA-3650G-00A1 Rear View..................................... 12
2.4.1 COM Connectors ........................................................................ 13
2.4.2 USB Connectors ......................................................................... 13
2.4.3 VGA Connector........................................................................... 14
2.4.4 Audio-In Connector ..................................................................... 14
2.4.5 LAN Connector ........................................................................... 15
2.4.6 Phoenix Terminal Connector ...................................................... 15
Chapter 3 H/W Installation..................................17
3.1 Introduction ............................................................................................. 18
3.1.1 mSATA Installation ..................................................................... 18
Figure 3.1 Installing an mSATA Card ........................................ 18
3.1.2 Mini PCIe Installation .................................................................. 19
Figure 3.2 Installing a Mini PCIe Card ....................................... 19
3.1.3 SDD Installation .......................................................................... 20
Figure 3.3 Installing an SDD Module ......................................... 20
3.1.4 MXM GPU Installation................................................................. 21
Figure 3.4 Installing an MXM GPU Card ................................... 21
3.1.5 Mount Bracket Installation........................................................... 22
Figure 3.5 Installing Mount Brackets ......................................... 23

ITA-3650G_Series User Manual xii
3.1.6 Expansion Module Installation .................................................... 24
Figure 3.6 Installing an Expansion Module................................ 24
Chapter 4 AMI BIOS............................................ 25
4.1 Introduction ............................................................................................. 26
Figure 4.1 BIOS Setup Program Main Screen .......................... 26
4.2 Entering the BIOS ................................................................................... 27
Figure 4.2 Press <DEL> to Enter Setup .................................... 27
4.2.1 Main Setup.................................................................................. 28
Figure 4.3 Main Setup Screen................................................... 28
4.2.2 Advanced Setup ......................................................................... 29
Figure 4.4 Advanced Setup Screen........................................... 29
4.2.3 Advanced Chipset Setup ............................................................ 36
4.2.4 Security Setup ............................................................................ 37
4.2.5 Boot Setup.................................................................................. 38
4.2.6 Save & Exit Setup....................................................................... 39
Chapter 5 Driver Installation.............................. 41
5.1 Introduction ............................................................................................. 42
5.2 Driver Installation .................................................................................... 42
5.2.1 Platform Windows Driver Setup.................................................. 43
Chapter 6 GPIO Programming Guide ............... 45
6.1 Digital I/O Definition ................................................................................ 46
6.2 Configuration Sequence ......................................................................... 46
6.3 Function Call Reference ......................................................................... 46
Appendix A Programming the Watchdog Timer .49
A.1 Watchdog Timer Overview...................................................................... 50
A.2 Programming the Watchdog Timer ......................................................... 50
Table A.1: Watchdog Timer Registers....................................... 50
A.3 Program Examples ................................................................................. 51

Chapter 1
1Overview
This chapter provides general
information about ITA-3650G.

ITA-3650G_Series User Manual 2
1.1 Introduction
The ITA-3650G is a compact fanless industrial computer equipped with a 6th/7th gen
Intel® processor that supports MXM-type GPU cards. Designed for intelligent trans-
portation and edge AI-based traffic management applications, this powerful comput-
ing platform has a wide voltage input range and can withstand 24/7 operation under
harsh conditions.
1.2 Specifications
System Chipset: 6th/7th gen Intel® processor
BIOS: AMI SPI 64 Mb Flash
System Memory: Onboard 16 GB of DDR4 2133 MHz
Display: Intel® HD Graphics 630/610/530/510
Multiple Display:
–VGA: 1 x DB15, max. resolution 1920 x 1080 @ 60Hz
–HDMI: 1 x HDMI with support for HDMI 1.4 standard, max. resolution 3840 x
2160 @ 30Hz
–DP: 4 x DP, max. resolution 4096 x 2160 @ 60Hz
Storage: 1 x mSATA, 2 x 2.5” HDD
Expansion: 1 x Mini PCIe
Ethernet: 6 x 10/100/1000M Ethernet RJ45 ports
USB: 6 x USB 3.0
Serial I/O: 2 x COM ports, switchable RS-232/422/485
Audio: 1 x Speaker-Out with 2 x 4W amplifier; 1 x Mic-In
Weight: 7.05 kg/15.54 lb
Dimensions (W x H x D): 210 x 120 x 240 mm/8.26 x 4.72 x 9.44 in
1.3 Power
ITA-3650G supports 9 ~ 36 VDC voltage input.
Table 1.1: Power Specifications
DC Voltage Input 9 ~ 36V
DC Current 18 ~ 9A
DC Power Interface 4P Phoenix (European standard)

3 ITA-3650G_Series User Manual
Chapter 1 Overview
1.4 Environmental
1.5 Dimensions
Figure 1.1 ITA-3650G Dimensions
Table 1.2: Environmental Specifications
Operating Temperature With SSD/mSATA card: -25 ~ 40 °C/-13 ~ 104 °F
Storage Temperature -40 ~ 85 °C/-40 ~ 185 °F
Humidity 95% @ 40 ºC, non-condensing
Vibration With SSD: 2 Grms @ 5 ~ 500 Hz, random, 1 hr/axis
IEC60068-2-6 Sine 2G @ 5 ~ 500 Hz, 1 hr/axis
Shock With SSD: 20G, IEC-68-2-27, half sine wave, 11 ms duration
Safety UL, CCC, CE, FCC, CB and BSMI compliant

ITA-3650G_Series User Manual 4
1.6 Exploded Diagram
Figure 1.2 ITA-3650G Diagram
Table 1.3: Parts List
1 Heat sink
2 I/O cover
3Chassis
4 I/O expansion card
5 HDD cooling AL
6 Connector card
7 Connector card bracket

Chapter 2
2System Setup
This chapter explains the initial
setup of ITA-3650G.

ITA-3650G_Series User Manual 6
2.1 Introduction
This chapter provides instructions for setting the internal jumpers and definitions of
the external connector pin assignments.
2.2 System Status
2.2.1 System Status LED Indicators
The LED indicators located at the top right of the front panel are used to show the
system health and active status.
Figure 2.1 ITA 3650G Indicator Locations
The table below provides an explanation of the LED indicator behaviours.
Item LED Status Color Description
1 PWR/Fault On Green System power is on, system is safe
On Red System is overheating
2 HDD On Yellow Data is being received/transmitted
Off No data is being received/transmitted
HDD indicator
Power/alarm indicator

7 ITA-3650G_Series User Manual
Chapter 2 System Setup
2.3 Jumpers and Connectors
2.3.1 Jumper Description
ITA-3650G can be configured according to the application requirements by setting
jumpers. To close a jumper, simply remove the clip. Occasionally a jumper will have
three pins, labelled 1, 2, and 3. With these types of jumpers, connect either pins 1
and 2, or pins 2 and 3.
The jumper settings are schematically depicted in this manual as shown below.
A pair of needle-nose pliers may be helpful when working with jumpers. If you have
any doubts about the best hardware configuration for your application, contact your
local distributor or sales representative before making any changes. Generally, only a
standard cable is required to make most connections.
Open Closed 2-3 Closed
断开 闭合 闭合 2-3
Open Closed
2-3 Closed

ITA-3650G_Series User Manual 8
2.3.2 Jumper and Connector Locations
The board features a number of connectors and jumpers for configuring the system
according to your application requirements. The table below lists the function of each
connector and jumper. The location of the jumpers and connectors on the board is
shown in Figs. 2.2 and 2.3.
Table 2.1: Jumpers and Connectors
Label Function
JCMOS1 Clear CMOS settings
AMPL1 L sound channel amplifier switch
AMPR1 R sound channel amplifier switch
PSON1 AT/ATX mode selection
VCCGPIO1 GPIO voltage selection
SATA1 SATA data interface 1
SATA2 SATA data interface 2
SATA3 SATA data interface 3
SATA_PWR1 SATA power interface 1
SATA_PWR2 SATA power interface 2
DP1 DP digital display interface 1
LPT1 LPT interface
USB1 USB interface 1
COM3456 COM port interface
KBMS Keyboard/mouse
M-SATA mSATA storage card interface
MiniPCIe Mini PCIe module interface
MXM MXM GPU card interface
