Advantech POC-S176 Series User manual

User Manual
POC-S176
Point-of-Care Terminal

POC-S176 User Manual ii
Instructions for the User
The document combines text and illustrations, providing a comprehensive overview
of the system. The information is presented as sequential steps of action, allowing
the user to learn directly how to use the device.
The text provides explanations and instructs the user step-by-step in the practical
use of the product, with short, clear instructions in easy-to-follow sequence.
Definitions
Part No. 2008017600-01 Edition 1
Printed in Taiwan February 2009
Warning! A WARNING statement provides important information about a poten-
tially hazardous situation which, if not avoided, could result in death or
serious injury.
Caution! A CAUTION statement provides important information about a poten-
tially hazardous situation which, if not avoided, may result in minor or
moderate injury to the user or patient or in damage to the equipment or
other property.
Note! A NOTE provides additional information intended to avoid inconve-
niences during operation.

iii POC-S176 User Manual
Safety Instructions
Strictly follow these Instructions for Use, please read these safety instructions care-
fully.
Remind to keep this User's Manual for later reference, and any use of the product
requires full understanding and strict observation of all portions of these instructions.
Observe all WARNINGS and CAUTIONS as rendered throughout this manual and on
labels on the equipment.
Repair of the device may also only be carried out by trained service personnel.
Advantech recommends that a service contract be obtained with Advantech Service
and that all repairs also be carried out by them. Otherwise the correct functioning of
the device may be compromised.
If one of the following situations arises, have the equipment checked by service per-
sonnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to the
user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do
not use liquid or spray detergents for cleaning and keep this equipment away from
humidity.
Put this equipment on a reliable surface during installation. Dropping it or letting it fall
may cause damage. For plug-in equipment, the power outlet socket must be located
near the equipment and must be easily accessible.
Warning! Because of the danger of electric shock, never remove the cover of a
device while it is in operation or connected to a power outlet.
Caution! To avoid short-circuits and otherwise damaging the device, do not allow
fluids to come in contact with the device. If fluids are accidentally spilled
on the equipment, remove the affected unit from service as soon as pos-
sible and contact service personnel to verify that patient safety is not
compromised.
Caution! To prevent overheating, it is recommended to install the unit in an
upright position. Do not lie it flat on a table and do not cover the open-
ings or place the device in direct sunlight or near radiant heaters.

POC-S176 User Manual iv
Make sure the voltage of the power source is correct before connecting the equip-
ment to the power outlet. Position the power cord so that people cannot step on it. Do
not place anything over the power cord. If the equipment is not used for a long time,
disconnect it from the power source to avoid damage by transient over voltage.
If your computer clock is unable to keep accurate time or the BIOS configuration
resets to default, please check the battery.
Improper installation of VESA mounting can result in serious personal injury! VESA
mount installation should be completed by a professional technician, please contact
the service technician or your retailer if you need this service. The detailed installa-
tion procedure is specified in Appendix A.
CLASSIFICATION:
!Supply Class I adapter
!No applied parts
!IPX1
!Continuous operation
!Not AP or APG category
Maintenance: To properly maintain and clean the surfaces, use only the approved
products or clean with a dry applicator.
Make sure users do not come in contact with SIP/SOPs and the patient at the same
time.
Caution! Do not leave this equipment in an uncontrolled environment where the
storage temperature is below -20°C (-4°F) or above 60°C (140°F). This
may damage the equipment.
Caution! Do not replace the battery yourself. Please contact a qualified technician
or your retailer.
The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.
Warning! This device is not suitable for use in the presence of flammable anes-
thetic mixtures with air, oxygen, nitrous oxide, or as a life support sys-
tem.
Caution! When servicing the device, always use replacement parts that meet
Advantech standards. Advantech Medical cannot warrant or endorse
the safe performance of third-party replacement parts for use with our
medical device.

v POC-S176 User Manual
When connecting electrical devices, the operator is responsible for ensuring that the
resulting system meets the requirements set forth by the following standards:
EN 60601-1 (IEC 60601-1)
Medical electrical equipment
Part 1: General requirements for safety
EN 60601-1-1 (IEC 60601-1-1)
Medical electrical equipment
Part 1-1: General requirements for safety
Collateral standard: Safety requirements for Medical electrical systems
EN 60601-1-2 (IEC 60601-1-2)
Medical electrical equipment
Part 1-2: General requirements for safety
Collateral standard: Electromagnetic compatibility; Requirements and tests
Accessory equipment connected to the analog and digital interfaces must be in com-
pliance with the respective nationally harmonized IEC standards (i.e. IEC 60950 for
data processing equipment, IEC 60065 for video equipment, IEC 61010-1 for labora-
tory equipment, and IEC 60601-1 for medical equipment). Furthermore all configura-
tion should comply with the system standard IEC 60601-1-1. Anyone who connects
additional equipment to the signal input or signal output is configuring a medical sys-
tem, and is therefore responsible that the system complies with the requirements set
forth in standard IEC 60601-1-1. The unit is for exclusive interconnection with IEC
60601-1 certified equipment in the patient environment and IEC 60XXX certified
equipment outside of the patient environment. If in doubt, consult the technical ser-
vices department or your local representative.

POC-S176 User Manual vi
FCC Class B
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interfer-
ence when the equipment is operated in a residential environment. This equipment
generates, uses, and can radiate radio frequency energy. If not installed and used in
accordance with this user's manual, it may cause harmful interference to radio com-
munications.
Note that even when this equipment is installed and used in accordance with this
user's manual, there is still no guarantee that interference will not occur. If this equip-
ment is believed to be causing harmful interference to radio or television reception,
this can be determined by turning the equipment on and off. If interference is occur-
ring, the user is encouraged to try to correct the interference by one or more of the
following measures:
!Reorient or relocate the receiving antenna.
!Increase the separation between the equipment and the receiver.
!Connect the equipment to a power outlet on a circuit different from that to which
the receiver is connected.
!Consult the dealer or an experienced radio/TV technician for help.
List of Accessories
Before installing your Point-of-Care Terminal, ensure that the following materials
have been received:
!POC-S176 series Point-of-Care Terminal
!Accessories for POC-S176
–CD-ROM disc-"Drivers, User's manual and Utilities"
–Mounting kits and packet of screws
–External DC adapter (Manufacturer: SINPRO Model no.: MPU100-107)
Warning! Any changes or modifications made to the equipment which are not
expressly approved by the relevant standards authority could void your
authority to operate the equipment.
Warning! No user serviceable parts inside, refer servicing to qualified personnel.
Only the accessories indicated on the list of accessories above have
been tested and approved to be used with the device. Accordingly
It is strongly recommended that only these accessories be used in con-
junction with the specific device. Otherwise the correct functioning of the
device may be compromised.

vii POC-S176 User Manual
Additional Information and Assistance
Contact your distributor, sales representative, or Advantech's customer service cen-
ter for technical support if you need additional assistance. Please have the following
information ready before you call:
!Product name and serial number
!Description of your peripheral attachments
!Description of your software (operating system, version, application software,
etc.)
!A complete description of the problem
!The exact wording of any error messages
!This equipment is a source of electromagnetic waves. Before use please make
sure that there are not EMI sensitive devices in its surrounding which may other-
wise malfunction.
Manufacturer
Advantech Co., Ltd.
No.1, Alley 20, Lane 26, Reuiguang Road Neihu District, Taipei,
Taiwan 114, R.O.C.
TEL: [phone]
Distributed in Europe by:
Advantech Europe GmbH Kolberger Straße 7
D-40599 Düsseldorf, Germany
Tel: [phone]
Fax: [phone]
Visit the Advantech websites at www.advantech.com or www.advantech.com.tw if
you need more information.

POC-S176 User Manual viii

ix POC-S176 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
Table 1.1: Touchscreen Specification ......................................... 4
1.3 LCD Specifications.................................................................................... 4
1.4 Dimensions ............................................................................................... 5
Figure 1.1 Dimensions of the POC-S176 .................................... 5
Chapter 2 System Setup.......................................7
2.1 A Quick Tour of the POC-S176................................................................. 8
Figure 2.1 Front view of the Point-of-care terminal...................... 8
Figure 2.2 Rear view of the Point-of-Care Terminal .................... 8
2.2 Installation Procedures.............................................................................. 9
2.2.1 Connecting the Power Cord.......................................................... 9
2.2.2 Switching on the Power ................................................................ 9
Figure 2.3 Connecting the power cord......................................... 9
2.3 Running the BIOS Setup Program .......................................................... 10
2.4 Installing System Software...................................................................... 10
2.5 Installing the Drivers................................................................................ 11
Figure 2.4 File directory "Drivers and Utilities" CD-ROM........... 11
Chapter 3 Chipset and Graphics Setup ............13
3.1 Introduction ............................................................................................. 14
3.1.1 Chipset........................................................................................ 14
3.1.2 Display Memory .......................................................................... 14
3.1.3 DVI Transmitter........................................................................... 14
3.1.4 Display Types ............................................................................. 14
3.2 Installation of Chipset Driver ................................................................... 15
3.2.1 Installation for Windows XP ........................................................ 16
Chapter 4 Audio Interface ..................................21
4.1 Introduction ............................................................................................. 22
4.2 Installation of Audio Driver ...................................................................... 22
4.2.1 Installation for Windows 2000/XP ............................................... 23
4.3 Further Information.................................................................................. 24
Chapter 5 PCI Express Ethernet Interface ........25
5.1 Introduction ............................................................................................. 26
5.2 Installation of the Ethernet Driver............................................................ 26
5.2.1 Installation for Windows XP ........................................................ 26
5.3 Further Information.................................................................................. 27
Chapter 6 Touch Panel Interface .......................29
6.1 Introduction ............................................................................................. 30
6.2 Installation of Touch Panel Driver ........................................................... 30

POC-S176 User Manual x
6.2.1 Installation for Windows XP ........................................................ 30
6.3 Further Information ................................................................................. 34
Chapter 7 Utilities and Hot Fixes ...................... 35
7.1 Introduction ............................................................................................. 36
7.2 Wake up by External USB Device at S3 Resume (Wake up) ................. 36
7.2.1 Installation for Windows XP ........................................................ 36
Chapter 8 Operation Information ...................... 37
8.1 Plug in the Power Adapter ...................................................................... 38
8.2 Thermal................................................................................................... 38
8.3 Disconnect the power ............................................................................. 38
8.4 Point-of-Care Terminal Cleaning and Disinfecting.................................. 39
8.5 General Safety Guide ............................................................................. 40
Appendix A Description of Connectors............... 41
A.1 Description of Connectors....................................................................... 42
Figure A.1 Top Side Global View of POC-S176 Motherboard indi-
cates all connectors’ location. .................................. 42
Figure A.2 Bottom Side Global View of POC-S176 Motherboard
indicates all connectors’ location.............................. 43
Appendix B Windows Display Hot Key Function 45
B.1 Windows Display Hot Key Function ........................................................ 46

Chapter 1
1General Information
Sections include:
!Introduction
!Specifications
!LCD Specifications
!Dimensions

POC-S176 User Manual 2
1.1 Introduction
The POC-S176 is an Intel® CoreTM Duo / Intel® Core 2 Duo Mobility processor-
based computer that is designed to serve as a Point-of-Care terminal (POC.) It is a
PC-based system with 17" color TFT LCD display, Single DVI-I Port, Dual on-board
10/100/1000 PCI-E Ethernet controller, Single COM port, Quad USB 2.0 port and a
24-bit stereo audio controller. With a built-in 2.5” HDD drive, the POC-S176 is as slim
and user-friendly as a notebook computer and generates low audible noise. For sys-
tem integrators, this silent, compact, mobile and highly integrated multimedia system
lets you easily build a Point-of-Care Terminal into your applications. The low audible
noise of POC-S176 makes it an ideal and safe Point-of-Care solution for patients and
hospital practitioners.
The POC-S176 is specially designed to resist spills and water damage, and ensures
dust resistance with its protected LCD, sealed ports, like a closed system. The high
contrast ratio (500:1) of POC-S176 makes it a perfect image terminal for PACS and
DICOM applications. The POC-S176 is a reliable solution to your application's pro-
cessing requirements.
1.2 Specifications
General
!Dimensions (W x H x D): 436.5 x 376.5 x 91.5 mm (17.18" x 14.82" x 3.60")
!Weight: 8 kg (17.6 lb)
!Power Supply:
–DC model: 100 watts max External DC Adapter- (Manufacturer: SINPRO
Inc. Model no.: MPU100-107) used within POC-S176XXXXXXXX
–Input voltage: 100-240 VAC, 47-63 Hz, 1.25-0.5 A
–Output voltage: +18 VDC, 5.55 A max
!Disk drive housing: Space for one 2.5" SATA HDD
!Entire system:
–IPX1 water resistant rating
Hardware
!CPU: Intel® Core Duo® / Core 2 Duo® processor low voltage 1.66/1.5 GHz
(uFC BGA479)
!BIOS: Award 512 KB Flash BIOS, supports Plug & Play, APM
!Chipset: 945 GME GMCH, (ICH7M)
!Front side bus: FSB 533/667 MHz
!RAM: 200-pin DDR2 SODIMM slots x 2, supports unbuffered 533/667 MHz
DDR2-SDRAM (Non ECC), maximum capacity to 4 GB “For the memory-
mapped I/O (MMIO) space reserved, the 32-bit operating systems limit the total
available memory to 3.12 GB to avoid potential driver compatibility issues.”
!IDE interface: ATA/100 x 1. Supports one IDE device.
!SATA interface: SATA x 2. Supports one SATA device.
!Serial ports: RS-232 port x 1, all compatible with 16C550 UARTs. COM1 has
optical isolation; COM1 supports +5V by jumper selection.
!Universal serial bus (USB) port: USB 2.0 port x 6 (4 external, 2 internal)
!Expansion slot: Mini PCI/33MHz slot x 1, Mini PCI-E(2.5Gb/s) slot x 1
!Watchdog timer: supports Super I/O embedding watchdog function. Automati-
cally generates system reset when the system stops due to a program error.
!CMOS battery (BIOS): 3.0 V @ 195 mA lithium battery

3 POC-S176 User Manual
Chapter 1 General Information
Display interface
!SDVO interface: Chrontel 7307C Single channel DVI transmitter to support
External Single display
!Display resolution: Supports 24-bit digital output (DVI-I port) resolutions up to
1600 x 1200 at 60 Hz
!Graphic chipset: Intel® Graphics Media Accelerator 950 engine
!Shared memory: Dynamic Video Memory Technology (DVMT) 3.0 to dynami-
cally allocate up to 224 MB of system memory for graphics usage.
!Display type: Simultaneously supports CRT
Audio function
!Chipset: Realtek ALC888, compliant with Intel HDA
!Audio controller: 24-bit codec, full-duplex stereo codec
!Audio interface: Microphone-in, Line-out
Ethernet interface
!Chipset: RTL8111B PCI express high performance Gigabit Ethernet controller
!Ethernet interface: Gigabit Ethernet port x 2, fully integrated Gigabit Ethernet
Media Access Control (MAC) and Physical Layer (PHY) functions, and each
provides a standard IEEE 803.3 Ethernet interface for 10/100/1000 Mbps appli-
cation
Optional modules
!Memory: 512 MB/1GB/2GB, DDR2-533/667 MHz SODIMM
!HDD: 2.5", SATA HDD
!Mini PCI WLAN module: 802.11 a/b/g WLAN
!Mini PCI-E WLAN module: 802.11 b/g/n WLAN
Environment
!Temperature: 0 ~ 40° C
!Relative humidity:
–10 °C to 40 °C / 20% RH to 90% RH operating
–-20 °C to 50 °C/ 10% RH to 95% RH Storage (Non-condensing)
!Shock: 20 G, half sine, 11 msec duration
!Vibration: 0.047 double amplitude displacement (5~32 Hz) 2G Peak (32 -500
Hz)
!Power MTBF: 100,000 hrs
!Altitude: Operational: 6,000 feet; Shipping: 40,000 feet
!Certifications:
–EMC: CE, FCC approved
–Safety: UL60601-1 and EN60601-1 approved
This device bears the CE label in accordance with the provisions of the EMC Direc-
tive 89/336/EMC and the Low Voltage Directive 73/23/EEC.

POC-S176 User Manual 4
Touchscreen (optional)
Cleaning/Disinfecting
During normal use of the POC-S176 may become soiled and should, therefore, be
cleaned regularly. Agents: Green tinctured soap and Enzymatic detergents
Steps:
1. Wipe the POC-S176 with a clean cloth that has been moistened in the cleaning
solution.
2. Prepare agent per manufacturer’s instructions or hospital protocol.
3. Wipe thoroughly with a clean cloth
1.3 LCD Specifications
!Display type: 17" TFT LCD.
!Resolution: 1280 x 1024
!Colors: 16.7 M (8-bit/color)
!Dot size (mm): 0.264 x 0.264
!Viewing angle: 140°/130°
!Luminance: 300 cd/m2
!Contrast ratio: 500: 1
!LCD MTBF: 50,000 hours
!Backlight lifetime: 50,000 hours
Table 1.1: Touchscreen Specification
Type Analog Resistive
Resolution Continuous
Light Transmission 75%
Controller RS-232 interface (uses COM3)
Power Consumption +5V@200 Ma
Software Driver Supports Windows 2000,Windows XP
Durability (touches in a lifetime) 30 million
Note! The Point-of-Care Terminal with the optionally installed touchscreen will
share COM3. Once the touchscreen is installed, COM3 cannot be used
for other purposes.
Caution! Do not immerse or rinse the POC-S176 and its peripherals. If you acci-
dentally spill liquid on the device, disconnect the unit from the power
source. Contact your Biomed unit regarding the continued safety of the
unit before placing it back in operation.
Do not spray cleaning agent on the chassis.
Do not use disinfectants that contain phenol. Do not autoclave or clean
the POC-S176 or its peripherals with strong aromatic, chlorinated,
ketone, ether, or Esther solvents, sharp tools or abrasives. Never
immerse electrical connectors in water or other liquids.

5 POC-S176 User Manual
Chapter 1 General Information
1.4 Dimensions
Figure 1.1 Dimensions of the POC-S176
A. Audio Control Button
B. Power Light
C. Brightness Control Button
A B C

POC-S176 User Manual 6
A. 4-pin mini-DIN DC connector
B. USB 2.0 ports x 2
C. USB 2.0 ports x 2
D. DVI port
E. 10/100/1000 Base-T Ethernet interface (RJ-45)
F. 10/100/1000 Base-T Ethernet interface (RJ-45)
G. Isolated RS-232/422/485 COM port (By jumper setting)
G F E D C B A

Chapter 2
2System Setup
Sections include:
!A Quick Tour of the POC-S176
!Installation Procedures
!Running the BIOS Setup Pro-
gram
!Installing System Software
!Installing the Drivers

POC-S176 User Manual 8
2.1 A Quick Tour of the POC-S176
Before you start to set up the POC-S176, take a moment to become familiar with the
locations and purposes of the controls, drives, connections and ports, which are illus-
trated in the figures below.
When you place the POC-S176 upright on the desktop, its front panel appears as
shown in Figure 2.1.
Figure 2.1 Front view of the Point-of-care terminal
When you turn the Point-of-Care Terminal around and look at its rear cover, the
sunken I/O section is at the bottom of the panel PC, as shown in Figure 2-2. (The I/O
section includes various I/O ports, including serial ports, DVI port, the Ethernet port,
USB ports, the DC power adapter jack, and so on.)
Figure 2.2 Rear view of the Point-of-Care Terminal

9 POC-S176 User Manual
Chapter 2 System Setup
2.2 Installation Procedures
2.2.1 Connecting the Power Cord
The POC-S176 could only be powered by a DC power adapter (SINPRO Model No.
MPU100-107). Be sure to always handle the power cords by holding the plug ends
only.
Follow these procedures in order:
1. Connect the female end of the power adapter to the DC jack of the panel PC.
(See Figure 2.3.)
2. Connect the female end of the power cord to the DC power adapter.
3. Connect the 3-pin male plug of the power cord to an electrical outlet.
2.2.2 Switching on the Power
Switch on the power switch on the back I/O.
Figure 2.3 Connecting the power cord
Warning! The POC-S176 is supplied by a 100 Watt power supply and a special
adapter as depicted in the model above.
If a medical adaptor is connected to the POC-S176, the customer must
ensure legal and regulatory compliance and that the device meets the
law and standards compliance requirements of this hardware.

POC-S176 User Manual 10
2.3 Running the BIOS Setup Program
Your POC-S176 has more than likely been properly set up and configured by your
dealer prior to delivery. You may still find it necessary to use the BIOS (Basic Input-
Output System) setup program to change system configuration information, such as
the current date and time or your type of hard drive. The setup program is stored in
read-only memory. It can be accessed either when you turn on or reset the panel PC,
by pressing the "Crtl+Alt+Del" key on your keyboard immediately after powering on
the computer.
The settings you specify with the setup program are recorded in a special area of
memory called CMOS RAM. This memory is backed up by a battery so that it will not
be erased when you turn off or reset the system. Whenever you turn on the power,
the system reads the settings stored in CMOS RAM and compares them to the
equipment check conducted during the power on self-test (POST). If an error occurs,
an error message will be displayed on screen, and you will be prompted to run the
setup program.
2.4 Installing System Software
Recent releases of operating systems from major vendors include setup programs
which load automatically and guide you through hard disk preparation and operating
system installation. The guidelines below will help you determine the steps necessary
to install your operating system on the panel PC hard drive.
If required, insert your operating system's installation or setup diskette into the exter-
nal diskette drive until the release button pops out.
The BIOS supports system boot-up directly from the CD-ROM drive. You may also
insert your system installation CD-ROM disk into your external CD-ROM drive.
Power on or reset the system by pressing the "Ctrl+Alt+Del" keys simultaneously.
The Point-of-Care Terminal will automatically load the operating system from the dis-
kette or CD-ROM.
If you are presented with the opening screen of a setup or installation program, follow
the instructions on screen. The setup program will guide you through preparation of
your hard drive, and installation of the operating system.
Note! Some distributors and system integrators may have already pre-
installed system software prior to shipment of your panel PC.
