Advantech TPC 51T 3BE Series User manual

User Manual
TPC-xx51T-x3BE 電腦
Industrial Touch Panel
Computers with Intel® Atom™
Processors or Intel® Celeron®
Processors

TPC-xx51T-x3BE User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgments
Intel® and Pentium™ are trademarks of Intel® Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
This manual covers the following models:
TPC-1251T-E3BE
TPC-1551T-E3BE
TPC-1751T-E3BE
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any on-screen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
Part No. 2003025161 Edition 2
Printed in Taiwan June 2020

iii TPC-xx51T-x3BE User Manual
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
甲類警語：
警告使用者：這是甲類資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在
這種情況下，使用者會被要求採取某些適當對策。

TPC-xx51T-x3BE User Manual iv
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Warnings, Cautions, and Notes
Document Feedback
To assist us in making improvements to this manual, we would welcome comments
and constructive criticism. Please send all such - in writing to: support@advant-
ech.com
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
Please keep equipment away from sunlight, which may cause equip-
ment damage.
Note! Notes provide optional additional information.

v TPC-xx51T-x3BE User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Do not expose or install this equipment under direct sunlight environment, which
may cause damage.
7. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
8. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
9. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
10. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
11. All cautions and warnings on the equipment should be noted.
12. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
13. Never pour any liquid into an opening. This may cause fire or electrical shock.
14. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
15. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to the
user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
16. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20 °C (-4 °F) OR ABOVE 60 °C
(140 (-4 ~ 140 °F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIP-
MENT SHOULD BE IN A CONTROLLED ENVIRONMENT.
17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
18. The equipment is intended for installation only in a wall or cabinet where both
these conditions apply: access can only be gained by SERVICE PERSONS or
by USERS who have been instructed about the reasons for the restrictions
applied to the location and about any precautions that shall be taken; and
access is through the use of a TOOL or lock and key, or other means of security,
and is controlled by the authority responsible for the location.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

TPC-xx51T-x3BE User Manual vi
安全指示
1. 請仔細閱讀此安全操作說明。
2. 請妥善保存此用戶手冊供日後參考。
3. 用濕抹布清洗設備前，請確認拔除電源線。請勿使用液體或去污噴霧劑清洗設備
4. 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。
5. 請勿在潮濕環境中使用設備。
6. 請勿將設備安裝或置於陽光直射之環境中，以避免設備損壞。
7. 請在安裝前確保設備放置在可靠的平面上，意外摔落可能會導致設備損壞。
8. 設備機殼的開孔適用於空氣對流 , 從而防止設備過熱。
9. 請勿覆蓋開孔。
10. 當您連接設備到電源插座前，請確認電源插座的電壓符合要求。
11. 請將電源線布置在人們不易絆倒的位置，請勿在電源線上覆蓋任何雜物。
12. 請注意設備上所有的警告標示。
13. 如果長時間不使用設備，請拔除與電源插座的連結，避免設備被超標的電壓波動
損壞。
14. 請勿讓任何液體流入通風口，以免引起火災或短路。
15. 請勿自行打開設備。為了確保您的安全，請透過經認證的工程師來打開設備。
16. 如欲下列情況，請由專業人員維修：
電源線或插頭損壞；
設備內部有液體流入；
設備曾暴露在過度潮濕環境中使用；
設備無法正常工作，或您無法透過用戶手冊來正常工作；
設備摔落或損壞；
設備有明顯外觀損壞。
17. 請勿將設備放置在超出建議溫度範圍的環境，即不要低於 -20°C(-4°F) 或高
於 60°C(140°F)，否則可能會造成設備損壞。
18. 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一
種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。
19. 根據 IEC 704-1:1982 規定，操作員所在位置音量不可高於 70 分貝。
20. 限制區域：請勿將設備安裝於限制區域使用。
21. 免責聲明 : 該安全指示符合 IEC 704-1 要求。研華公司對其內容之準確性不承
擔任何法律責任。
22. 使用過度恐傷害視力。使用 30 分鐘請休息 10 分鐘。
23. 未滿 2 歲幼兒不看螢幕，2 歲以上每天看螢幕不要超過 1 小時。
24. 本產品於國內裝置使用時，其電源僅限使用機架電源模組所提供直流電源輸入，
不得使用交流電源及附加其他電源轉換裝置提供電源，其電源輸入電壓及電流請
依說明書規定使用。
Caution! Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dis-
pose of used batteries according to the manufacturer's instructions.
Danger d'explosion si la pile est remplacée de fa?on incor- recte. Rem-
placez seulement avec le même type ou équivalent recom- mandé par
le fabricant. disposer des piles usagées selon les instructions du fabri-
cant.

vii TPC-xx51T-x3BE User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.2.1 System Kernel............................................................................... 2
1.2.2 I/O Ports........................................................................................ 2
1.2.3 O/S support................................................................................... 2
1.2.4 Safety and Environment................................................................ 3
1.3 LCD Specifications.................................................................................... 3
Table 1.1: LCD Specifications ..................................................... 3
1.4 Touchscreen Specifications ...................................................................... 4
1.5 Power ........................................................................................................ 4
1.6 I/O Port Arrangement ................................................................................ 4
Figure 1.1 I/O Port Arrangement ................................................. 4
1.7 Panel Mounting ......................................................................................... 5
1.8 Dimensions and Cutout............................................................................. 5
Figure 1.2 TPC-1251T Dimensions ............................................. 6
Figure 1.3 TPC-1551T Dimensions ............................................. 7
Figure 1.4 TPC-1751T Dimensions ............................................. 8
Chapter 2 System Setup.......................................9
2.1 Transport and Unpacking........................................................................ 10
2.2 System Setup.......................................................................................... 11
Figure 2.1 Unpack the Package ................................................ 11
Figure 2.2 Power Connector and Power Lines .......................... 12
Figure 2.3 Power Receptor & Button Pin Assignment ............... 12
2.2.1 Installing SSD/DD ....................................................................... 13
2.2.2 Installing an iDoor Module .......................................................... 14
2.2.3 Installing the Drivers ................................................................... 16
2.3 Panel Mounting ....................................................................................... 16
2.4 VESA Mounting....................................................................................... 17
2.5 Cabinet Installation and Earth Grounding Setup..................................... 18
2.6 Power/Digital Ground and Earth/Ground ................................................ 19
Chapter 3 Features in Windows Embedded .....21
3.1 Features in Windows Embedded ............................................................ 22
3.2 Enhanced Write Filter (EWF) .................................................................. 22
3.3 File-Based Write Filter (FBWF) ............................................................... 23
3.4 HORM ..................................................................................................... 24
Appendix A Serial Port Settings ...........................27
A.1 Jumper, Dip Switch, and Connector Location ......................................... 28
A.1.1 Board Placement ........................................................................ 28
A.2 Jumper Setting and Description .............................................................. 28
A.2.1 CMOS Clear Function (CN1) ...................................................... 28
Table A.1: CMOS Clear Function (CN1).................................... 28
A.3 Connector Pin Definition ......................................................................... 29
A.3.1 SATA Connector (CN12) ............................................................ 29
Table A.2: 1654004659 Serial ATA 7P 1.27mm 180D(M) DIP
WATM-07DBN4A3B83.12 ........................................ 29

TPC-xx51T-x3BE User Manual viii
A.3.2 SATA Power Connector (CN8) ................................................... 29
Table A.3: WAFER BOX 4P 2.50mm 180D(M) DIP 24W1170-
04S10-01.................................................................. 29
A.3.3 Mini PCIE Slot (MINIPCIE) ......................................................... 30
Table A.4: 1654002538 MINI PCI E 52P 6.8mm 90D SMD
AS0B226-S68N7H Supports PCI1.1, PCI1.2 Power
Definition .................................................................. 30
A.3.4 Power in connector (CN18) ........................................................ 31
Table A.5: 1652003104 PLUG-IN BLOCK 3P 5.08mm 90D(M) DIP
ME050-50803........................................................... 31
A.3.5 LAN RJ45 Connector (CN7,CN8) ............................................... 32
Table A.6: 1652002996 PHONE JACK RJ45 14P 90D(M) DIP
RTA-195AAK1A ....................................................... 32
Table A.7: LED .......................................................................... 32
A.3.6 USB Connector (CN10) .............................................................. 33
Table A.8: 1654010199 USB Conn. 2.0+3.0 13P 90D(F) DIP
UEA1112C-UHS6-4 ................................................. 33
A.3.7 COM1 RS232 Connector (CN15) ............................................... 33
Table A.9: 1654000056 D-SUB Conn. 9P 90D(M) DIP
070241MR009S200ZU............................................. 33
A.3.8 COM2 RS232/422/485 Connector (CN16) ................................. 34
Table A.10:1654000056 D-SUB Conn. 9P 90D(M) DIP
070241MR009S200ZU............................................. 34
Appendix B Driver Installation & Configuration . 35
B.1 Intel Chipset Software Installation Utility Installation............................... 36
B.2 Intel Graphics Driver Installation ............................................................. 38
B.3 LAN Driver Installation ............................................................................ 41
B.4 Intel® Trusted Execution Engine Driver Installation................................ 43
B.5 Windows 7 USB 3.0 Driver Installation ................................................... 45
B.6 Advantech EC Driver Installation ............................................................ 48
B.7 Advantech EC Brightness Control Tool Installation ................................ 50
B.8 Advantech EC Watchdog Timer Driver Installation................................. 52
B.9 Advantech LMsensor Driver Installation ................................................ 55
Appendix C BIOS Setup ........................................ 57
C.1 Entering Setup ........................................................................................ 58
C.1.1 Main Setup.................................................................................. 58
C.1.2 Advanced BIOS Features Setup................................................. 60
C.1.3 Chipset Configuration ................................................................. 72
C.1.4 Security....................................................................................... 73
C.1.5 Boot ............................................................................................ 74
C.1.6 Save & Exit ................................................................................. 75

Chapter 1
1General Information

TPC-xx51T-x3BE User Manual 2
1.1 Introduction
The TPC-XX51T Touch Panel Computer is a state-of-the-art Human Machine Inter-
face featuring displays ranging from 12", 15" and 17" and an Intel® Atom™ E3845
1.9 GHz / Intel®Celeron J1900 2.0GHz Quad-core Processor.
The key features are as follows:
True-flat touch screen
The TPC-XX51T is a true-flat touch screen designed with IP66 front protection.
Fanless
By using a low-power processor, the system does not have to rely on fans,
which often are unreliable and cause dust to circulate inside the equipment.
Wide operating temperature (E38xx series only)
The TPC-XX51T series supports -20 ~ 60 °C (-4 ~ 140 °F) wide operating tem-
perature solution to provide flexibility in harsh environments.
Bright Display
The TFT LED LCD display suits industrial demands for clear interfaces. Wide
Operating Temperature & Isolation Protection.
1.2 Specifications
1.2.1 System Kernel
CPU: Intel® Atom™ E3845 1.9 GHz Processor /(Optional) Intel® Celeron J1900
2 GHz Quad-core Processor
BIOS: AMI UEFI BIOS
VGA: Integrated in Intel® Atom™ E3845 /Intel® Celeron J1900 2 GHz Quad-
core Processor
Ethernet: 10/100/1000Base-T x 2
Watchdog Timer: EC watchdog timer; 1.0 second timeout
Storage:
mSATA via mPCIe (MPCIE2)
2.5" SATA HDD/SSD slot
1.2.2 I/O Ports
1 x RS-232, 1 x RS-232/422/485
1 x USB 3.0
3 x USB 2.0
1 x Full-size Mini PCIe Card (MPCIE1)
1.2.3 O/S support
Microsoft® Windows
–WES7 32-bit/64-bit
–WEC7 (IDE configuration must set SATA Mode to IDE Mode in BIOS for boot-
ing successfully)
–Windows 7 32-bit/64-bit
–Windows 10 32-bit/64-bit
Android v6.0
AdvLinux v20.04

3 TPC-xx51T-x3BE User Manual
Chapter 1 General Information
1.2.4 Safety and Environment
Safety
FCC Class A
CE certificated
The front bezel is compliant with IP66 for true flat models and IP65 for the TPCs
with the traditional front bezel
Environment
Operating Temperature:
–-20 ~ 60 °C (-4 ~ 140 °F)
Storage Temperature:
–-30 ~ 70 °C (-22 ~ 158 °F)
Humidity: 40 °C (104 °F) @ 10~95% relative humidity (non-condensing)
Vibration:
With SSD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)
1.3 LCD Specifications
Table 1.1: LCD Specifications
TPC-1251T TPC-1551T TPC-1751T
Display Type TFT LED LCD TFT LED LCD TFT LED LCD
Size 12.1" 15" 17"
Maximum Resolution 1024 x 768 (XGA) 1024 x 768 (XGA) 1280 x 800 (SXGA)
Maximum Colors 262K/16.2 M 1.62M 1.67M
Viewing Angle (CR≥10) 160°/140° 176°/176° 160°/140°
Luminance (cd / m2) 500 300 350
Contrast Ratio 700:1 2000:1 800:1
Operating Temperature -20~60 °C (-4 ~
140 °F)
-20~60 °C (-4 ~ 140
°F)
-20~60 °C (-4 ~ 140
°F)
Backlight Lifetime 50,000 hours 70,000 hours 50,000 hours
Backlight LED LED LED
Note! There might be several bright or dark pixels on the LCD. This phenome-
non is normal in today's LCD manufacturing. Inspection criteria are fol-
lowing specifications defined by LCD vendor.

TPC-xx51T-x3BE User Manual 4
1.4 Touchscreen Specifications
Touch Type: 5- wire Resistive
Base Glass Construction: Tempered glass
Resolution: (follows the resolution of the system)
Light Transmission: 80% ± 3% (Measured by BYK-Gardner)
Controller: USB Interface
Lifespan: 1 million touches at single point
1.5 Power
Input Voltage: 24VDC +/- 20% (the fuse will become an open circuit if the input
level exceeds 32 VDC)
Typical:
–TPC-1251T: 24 VDC @ 1.9Amp
–TPC-1551T: 24 VDC @ 1.7Amp
–TPC-1751T-E3BE: 24VDC @ 1.8Amp
1.6 I/O Port Arrangement
The arrangement of the I/O ports is shown in Figure 1.1
Figure 1.1 I/O Port Arrangement
Note! Touchscreen ITO maybe crash duo to heavy usage.

5 TPC-xx51T-x3BE User Manual
Chapter 1 General Information
1.7 Panel Mounting
1. There is a rubber waterproof gasket on the AL front bezel. Make sure the water-
proof gasket is in position before installing TPC into the panel opening.
2. Install the TPC into the panel opening.
3. Take the clamps and long screws from the accessory box. Hook the clamps to
the holes around the four sides of the bezel. Insert the screws into every clamp
and fasten them. These screws will push the mounting panel and fix the unit.
4. The suggested mounting panel thickness is less than 6 mm (.236 in).
1.8 Dimensions and Cutout
TPC-1251T Series
Weight: 2.55 kg (5.62 lb)
Dimensions (W x H x D): 311.8 x 301.6 x 55.4 cm (12.28 x 11.87 x 2.18 in)
Cutout: 303 x 229 mm (11.93 x 9.02 in)
TPC-1551T Series
Weight: 3.9 kg (7.49 lb)
Dimensions (W x H x D): 383.2 x 307.3 x 61.1 mm (15.09 x 12.10 x 2.41 in)
Cutout: 374.5 x 298.5 mm (14.74 x 11.75 in)
TPC-1751T Series
Weight: 4.8kg (10.58 lb)
Dimensions (W x H x D): 534 x 494 x 225 mm (21.02 x19.45 x 8.86 in)
Cutout: 401.3 x 334.8 mm (15.80 x 13.18 in)

TPC-xx51T-x3BE User Manual 6
Figure 1.2 TPC-1251T Dimensions
301.6
227.6
269
15.6
100
100
150
7
55.4
192
28.9
311.8
247.2
186.3
238
150
180
180

7 TPC-xx51T-x3BE User Manual
Chapter 1 General Information
Figure 1.3 TPC-1551T Dimensions
306.1
230.1
383.2
307.3
7
55.9
100
100
10
372.89
296.89

TPC-xx51T-x3BE User Manual 8
Figure 1.4 TPC-1751T Dimensions
100
100
10
333.38
399.88
7
56.9
272.9
339.9
410.4
343.4

Chapter 2
2System Setup

TPC-xx51T-x3BE User Manual 10
2.1 Transport and Unpacking
When accepting a delivery, please check the packaging for visible transport damage
and check the delivery for completeness by comparing it with your order. If you notice
any shipping damage or inconsistencies between the contents and your order,
please inform the responsible delivery service immediately.
During transportation, the TPC should be protected from excessive mechanical
stress. If the TPC is transported or stored without packaging, shocks, vibrations,
pressure and moisture may impact the unprotected unit. Damaged packaging indi-
cates that ambient conditions have already had a massive impact on the device.
Therefore, please use the original packaging during transportation and storage.
If the TPC is transported in cold weather or is exposed to extreme variations in tem-
perature, make sure that moisture (condensation) does not build up on or inside the
HMI device. Moisture can result in short-circuits in electrical circuits and damage the
device. To avoid that, please store the TPC in a dry place and bring the TPC to room
temperature before starting it up. If condensation occurs, a delay time of approxi-
mately 12 hours must be allowed to make sure the TPC is completely dry before the
TPC is switched on.

11 TPC-xx51T-x3BE User Manual
Chapter 2 System Setup
2.2 System Setup
You can easily get TPC started by following the steps below.
1. Unpack the TPC package. Check the packing list at the beginning of this man-
ual to make sure all items have been included.
Figure 2.1 Unpack the Package

TPC-xx51T-x3BE User Manual 12
2. Connect the power connector to the 24 VDC power lines. The power lines can
either be of some power adapter or in-house power source.
Figure 2.2 Power Connector and Power Lines
Figure 2.3 Power Receptor & Button Pin Assignment
3. Plug the power lines into the system’s power receptor.
4. Attach power to the system.
5. Calibrate the touchscreen.
Note! If you want to install the touchscreen driver & use the touchscreen utility,
please refer the user manual "PenMount 6000 Installation-Guide" on the
CD-ROM.
