Advantech PCM-9375 A3 Installation and operation manual

PCM-9375 A3 Startup Manual 1
Before you begin installing your card, please make sure that
the following materials have been shipped:
• 1 PCM-9375 A3 SBC
• 1 Startup Manual
• 1 Utility CD
• 1 Mini Jumper Pack p/n: 9689000002
• 1 Audio Cable p/n: 1700160160
• 1 IDE 44 Pin p/n: 1701440351
• 1 USB 2 Port Cable p/n: 1703100121
• 1 Parallel Port Cable p/n: 1700001977
• 1 Keyboard/Mouse Cable p/n: 1700060202
• 1 x COM2/3/4 Cable p/n: 1700001971
• 1 x LAN Cable p/n: 1701100202
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately
Note 1: For detailed contents of the PCM-9375 A3,
please refer to the enclosed CD Disc or disk (in
PDF format)
Note 2: Acrobat Reader is required to view any PDF file
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/read-
step2.html (Acrobat is a trademark of Adobe.)
PCM-9375 A3 3.5” SBC w/AMD LX800, VGA, LCD,
LAN, USB 2.0, and SSD
Startup Manual
Standard SBC Functions
• CPU: AMD Geode® LX800 processor, up to 500 MHz
• System Memory: 1x SODIMM socket, supports Double
Data Rate (DDR) SDRAM, Max, 512 MB, accepts
128/256/512 MB, DDR333 SDRAM
• 2nd Cache Memory: 128 KB on the processor
• System Chipset: AMD Geode LX800
• BIOS: Award 8Mbit Flash BIOS
• Watchdog Timer: 255 levels timer interval
• Expansion Interface: PC/104
• Battery: Lithium 3 V / 196 mAH
• Power Management: APM1.2, ACPI supported
• Enhanced IDE Interface: One channel supports up to
two EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, supports UDMA 33 mode
• Serial Ports: Four serial RS-232 ports (CN19: COM1)
in one DB-9 connector and one Hirose 40 pin connector
(CN16: COM2/3/4). RS-422 and RS-485 can be config-
ured via CN18 connector and Jumper J3
• Parallel Port: One parallel port, supports SPP/EPPmode
• Keyboard/Mouse Connector: Supports one standard
PC/AT keyboard and a PS/2 mouse
• Audio: Supports AC97 Audio stereo sound
• USB: Four USB 2.0 compliant universal serial bus ports
• GPIO: 8-bit general purpose input/output
Solid State Disk
• Supports one 50-pin socket for CFC type I (type II
optional)
VGA/LVDS Interface
• Memory Size: Optimized Shared Memory Architecture,
supports up to 64MB frame buffer using system memory
• Resolution:
CRT resolution: up to 1600 x 1200 x 16 bpp at 100 Hz
and up to 1024 x 768 x 32 bpp at 60 Hz for TFT LCD
LCD Interface: Supports up to 24-bit TFT LCD (TTLsignal)
LVDS Interface: Supports one channel 24-bit LVDS
Interface (JEIDA mod)
• Dual Simultaneous Display: CRT+LCD, CRT+LVDS
Ethernet Interface
• Chipset Support: 2 x 10/100Mbps - Realtek RTL8139
• Ethernet Interface: IEEE 802.3 z/ab (1000BASE-T) or
IEEE 802.3u (100 BASE-T) protocol compatible
• Built-in Boot ROM (Realtek RTL8139)
• Connector: One RJ-45 connector, and one internal box
header
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCM-9375 Rev. A3
Part No. 2006937502
Printed in China
1st Edition
June 2019

2 PCM-9375 A3 Startup Manual
Specications (Cont.)
Audio Function
• Audio Controller: Realtek ACL605 chipset, supports
AC97 3D Audio stereo sound
• Audio Interface: Microphone in, Line in, Line out,
Speaker out
Mechanical and Environmental
• Dimensions: 145 x 102 mm (5.9”x 4.2”)
Mechanical Drawing (dxf file) is available
• Power Supply Type: AT/ATX
• Power Requirement: +5 V ± 5%, +12 V ± 5% (Optional),
5 V standby for ATX mode or single +5 V power only
• Power Consumption: (Geode LX800, 256 MB DDR333)
Max: +5 V@ 1.2 A, +12 V@ 0.23 A
Typical: +5 V@ 0.6 A, +12 V@ 0.03 A
• Operating Temperature: 0 ~ 60°C (32 ~ 140°F)
• Weight: 0.85 kg (reference weight of total package)
The board has a number of jumpers that allow you to con-
figure your system to suit your application
The table below lists the function of each of the jumpers and
connectors
Jumpers
Label Function
J2 Clear CMOS
J3 COM2 Setting
J4 Audio Power
Connectors
Label Function
CN1 Stand-by Power Input
CN2 Power Input
CN3 Reset Button
CN4 TFT LCD
CN5 Inverter Power
CN6 SMBus
CN7 DDR-SODIMM
CN8 ATX Power Button
CN9 GPIO
CN10 CF
CN11 IDE
CN12 CRT
CN13 USB1/2
CN14 Keyboard/Mouse
CN15 USB3/4
CN16 COM2/3/4
CN17 Print Port
CN18 RS-422/485
CN19 COM1
CN20 PC/104
CN21 ISA -5 V & -12 V Input
CN22 Audio
CN23 LAN1
CN24 LAN2
J2: Clear CMOS
Pin Signal
1-2
BAT
2-3 Clear CMOS
J3: COM2 Setting
Pin Signal
1-2
RS-232
3-4 RS-485
5-6 RS-422
J4: Audio Power
Pin Signal
1-2
With+12 V
2-3 Without+12 V
123
1 2 3
Jumpers and Connectors
Jumpers and Connectors (Cont.)
123
1 2 3

PCM-9375 A3 Startup Manual 3
PCM-9375 A3 Mechanical Drawing
PCM-9375 A3 Location Connectors & Jumpers (Component Side)
PCM-9375 A3 Location Connectors (Solder Side)

4 PCM-9375 A3 Startup Manual
Dimensions of PCM-9375 A3 (Top Side)
Dimensions of PCM-9375 A3 (Bottom Side)
Dimensions of PCM-9375 A3 (For H)
1.60
0
59.08 27.66 76.74 107.05 127.63 136.35 146
0 8.89 3.48 87.63 142.82
0
3.18
10.16
83.82
98.37
87.63
7.62
146
102
40.64
25.40
PCM-9375 A3 Mechanical Drawing
1.60
0
59.08 27.66 76.74 107.05 127.63 136.35 146
0 8.89 3.48 87.63 142.82
0
3.18
10.16
83.82
98.37
87.63
7.62
146
102
40.64
25.40
1.60
0
59.08 27.66 76.74 107.05 127.63 136.35 146
0 8.89 3.48 87.63 142.82
0
3.18
10.16
83.82
98.37
87.63
7.62
146
102
40.64
25.40
