Advantech IPPC-6172F Series User manual

IPPC-6172F Series
17" SXGA TFT LCD Celeron M
Fanless Industrial Panel PC
with 2 x PCI Slots
User Manual

IPPC-6172F User Manual ii
Copyright
The documentation and the software included with this product are copy-
righted 2008 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this man-
ual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reli-
able. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result
from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of
Microsoft Corp.
All other product names or trademarks are properties of their respective
owners.
Part No. 2003617210 1st Edition
Printed in Taiwan November 2008

iii
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its prod-
ucts will be free from defects in materials and workmanship for two years
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal-
lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous test-
ing, most of our customers never need to use our repair service. If an
Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for war-
ranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

IPPC-6172F User Manual iv
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test
conditions for passing included the equipment being operated within an
industrial enclosure. In order to protect the product from being damaged
by ESD (Electrostatic Discharge) and EMI leakage, we strongly recom-
mend the use of CE-compliant industrial enclosure products.
FCC Class A
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful inter-
ference in which case the user will be required to correct the interference
at his own expense.
Technical Support and Assistance
Step 1. Visit the Advantech web site at www.advantech.com/support
where you can find the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before
you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (OS, version, software, etc.)
- A complete description of the problem
- The exact wording of any error messages

v
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning.
Use a damp cloth. Do not use liquid or spray detergents for clean-
ing.
4. For plug-in equipment, the power outlet socket must be located
near the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Drop-
ping it or letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before con-
necting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or elec-
trical shock.
13. Never open the equipment. For safety reasons, the equipment
should be opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked
by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.

IPPC-6172F User Manual vi
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE MAY GO BELOW
-40° C OR ABOVE 85° C. THIS COULD DAMAGE THE
EQUIPMENT. THE EQUIPMENT SHOULD BE IN A CON-
TROLLED ENVIRONMENT.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the
products from damage.
1. To avoid electrical shock, always disconnect the power from your
PC chassis before you work on it. Don't touch any components on
the CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card may
damage sensitive electronic components.

vii Table of Contents
Contents
Chapter 1 General Information ....................................... 2
1.1 Introduction ....................................................................... 2
1.2 Specifications .................................................................... 3
1.2.1 General ........................................................................... 3
1.2.3 Display ........................................................................... 4
1.2.4 Audio Functions ............................................................. 4
1.3 Dimensions........................................................................ 5
Chapter 2 System Setup.................................................... 8
2.1 General .............................................................................. 8
2.1.1 PS/2 Mouse & Keyboard ............................................... 8
2.1.2 Parallel Port .................................................................... 9
2.1.3 VGA port ....................................................................... 9
2.1.4 Serial COM ports ........................................................... 9
2.1.5 USB ports ..................................................................... 10
2.1.6 Audio Interface ............................................................ 10
2.1.7 Ethernet ........................................................................ 10
2.2 Installing a 2.5" SATA HDD .......................................... 11
2.3 Installing Add-on Cards .................................................. 12
2.4 Installing Power Connector............................................. 12
2.5 Mounting Instructions ..................................................... 13
2.5.1 Panel Mounting ............................................................ 13
2.5.2 Rack Mounting ............................................................ 13
Chapter 3 Jumper Settings &Connectors ..................... 16
3.1 Jumper Settings ............................................................... 16
3.1.1 Jumpers & Switches ..................................................... 17
3.1.2 Connectors ................................................................... 18
3.1.3 LCD Power Select(JP1) ............................................... 19
3.1.4 CPU VCCA Power Select (JP2) .................................. 20
3.1.5 Measure Battery Current Jumper (JP3) ....................... 20
3.1.6 Clear CMOS (JP4) ....................................................... 20
3.1.7 LVDS Mode Select(JP5) ............................................. 21
3.1.8 Touchscreen Mode Select (JP6) .................................. 21
3.1.9 CPU Setting (CN20 and JP2) ....................................... 22
Chapter 4 Software Configuration ................................ 24
4.1 Overview ......................................................................... 24
4.2 Utilities and Drivers ........................................................ 24
4.2.1 Installing the IPPC-6172F Watchdog Timer Driver .... 26
4.2.2 How to Use the IPPC-6172F Watchdog Timer ........... 31
4.2.3 Dual Display Setting .................................................... 33
4.2.4 Touchscreen Installation & Configuration .................. 34
Chapter 5 Award BIOS Setup........................................ 36

IPPC-6172F User Manual viii
5.1 Introduction ..................................................................... 36
5.2 Entering Setup................................................................. 37
5.2.1 Standard CMOS Setup ................................................. 37
5.2.2 Advanced BIOS Features Setup .................................. 38
5.2.3 Advanced Chipset Features Setup ............................... 42
5.2.4 Integrated Peripherals .................................................. 44
5.2.5 Power Mangement Setup ............................................. 48
5.2.6 PNP/PCI Configuration Setup ..................................... 51
5.2.7 PC Health Status .......................................................... 53
5.2.8 Spread Spectrum Control ............................................. 54
5.2.9 Load Optimized Defaults ............................................. 54
5.2.10 Set Password ................................................................ 55
5.2.11 Save & Exit Setup ........................................................ 56
5.2.12 Exit Without Saving ..................................................... 56
Appendix A IO & Connector Pin Assigns ........................ 58
A.1 CN1,CN2 LVDS ............................................................. 58
A.2 CN9 LCD INVERTER ................................................... 59
A.3 CN12 Touchscreen ......................................................... 59
A.4 CN15/CN17 USB 6,7...................................................... 60
A.5 CN19,CN21 SATA POWER ......................................... 60
A.6 CN10 IDE ....................................................................... 61
A.7 CN18 Panel Header......................................................... 61
A.8 CN34 : DB-15 VGA Connector Definitions ................... 62
A.9 CN30 : PS/2 K/b & Mouse Connector Definitions ......... 63
A.10 CN28,CN29 : USB 0,1,2,3 Connector Definitions ......... 63
A.11 10/100/1000Base-TX Ethernet........................................ 64
Appendix B System Assignments ...................................... 68
B.1 System I/O Ports.............................................................. 68
B.2 DMA Channel Assignments............................................ 69
B.3 Interrupt Assignments ..................................................... 69
B.4 1st MB Memory Map...................................................... 70
B.5 PCI Bus Map ................................................................... 70
Appendix C Watchdog Timer............................................ 72
C.1 Overview ......................................................................... 72
C.2 Watchdog Timer Programming....................................... 72
C.3 Example Programs .......................................................... 75

CHAPTER
1
General Information
Sections include:
• Introduction
• Specifications
• Dimensions

IPPC-6172F User Manual 2
Chapter 1 General Information
1.1 Introduction
The IPPC-6172F series of industrial panel PCs is especially designed to
fit in space-limited environments where expansion is restricted. Its solid-
structure enables systems to operate under harsh industrial conditions.
Sturdy Structure
The whole system is protected by a firm solid structure. The front panel is
made of sturdy aluminum and has strengthened glass. It is shock resistant,
and complies with NEMA4/IP65.
Fanless
By using a low power processor, the system does not have to rely on fans,
which are unreliable, and cause dust to circulate inside the equipment.
Economical
The IPPC-6172F motherboard has a Celeron M 1GHz processor, provid-
ing an economical yet powerful system. Its reliability enables the system
to operate faultlessly in industrial environments.
Friendly HMI
Systems in the IPPC-6172F series are equipped with a 17" LCD screen,
which provides high resolution display quality. The result is vivid, bright,
and sharp quality images. The panel PC is perfectly suited for Windows
OS. The touschscreen version enables simple operation, making the Panel
PC a solid industrial digital controller interface. In addition friendly HMI
design of the IPPC-6172F series offers front USB access port and reset
key for various requirements.

3 Chapter1
1.2 Specifications
1.2.1 General
Dimensions (W x H x D):
Front Panel: 481.92 x 355.87 x 26 mm
Control Box: 362 x 285 x 112.2 mm
Cut out Dimensions: 457 x 342 mm
Weight: 13 kg (28 lb)
Power Supply: 85W
Input Voltage: 18~30Vdc, 18A
Output Voltage: +3.3V@8A,+5V@10A,+12V@4A,[email protected],
-12V@1A
Disk Drive Housing: Supports 1 x 2.5"SATA HDD, 1 x slim CD-ROM
1.2.2 Standard PC Functions
CPU: Intel Celeron M ULV 1GHz
BIOS: Award 256KB Flash BIOS
Chipset: Intel 915 GM GMCH/ICH6M
2nd Level Cache: 512KB
RAM: Two 240pin 512MB 533 DRAM
Parallel Port: One parallel port, supports SPP/EPP/ECP parallel mode.
BIOS configurable to LPT1, LPT2, LPT3 or disabled
Serial Ports: One serial port with one RS-232 port (COM1)
Universal Serial Bus (USB) Port: Supports up to 5 USB (2.0) ports.
PCI Bus Expansion Slots: Two expansion slots for PCI cards(total 25W)
Watchdog Timer:255-level interval timer, setup by software, Super I/O
integrated, SMSC controller
Battery: 3.0 V @ 196 mAH lithium battery

IPPC-6172F User Manual 4
1.2.3 Display
Chipset: Intel 915GM chip integrated Intel Extreme Graphics 2
for 2D/3D video accelerator
Display memory: 128 MB frame buffer using system memory
Display type: Simultaneous support of CRT & flat panel displays (TFT)
Display resolution: LCD displays up to 1280 x 1024 @ 16.7M colors
1.2.4 Audio Functions
Chipset: Integrated in Intel 9151GM ICH6M South Bridge
Audio controller:
AC97 Ver.2.0 compliant interface, Multi stream, Direct sound and
Direct Sound 3D acceleration
Stereo sound: 18-bit full-duplex codec
Audio interface:
Microphone-in, line-in, line-out, and game ports MPU-401.
1.2.5 PCI bus Ethernet Interface
One Intel 82573/L PCI Express Controller 10/100/1000Mb LAN support
Pre-boot Execution Environment (PXE), One Intel 82562GZ for ICH6M
LAN controller 10/100MB
Chipset: Intel 82573/L & Intel 82562GZ local bus.
Ethernet Interface: One Intel 82573/L PCI Express Controller 10/100/
1000Mb LAN support Pre-boot Execution Environment (PXE), One Intel
82562GZ for ICH6M LAN controller 10/100MB
1.2.6 Analog Resistive Touchscreen (Optional)
Type: Analog resistive
Resolution: 1024 x 1024
Light Transmission: >80%
Controller: RS-232 interface
Power Consumption: +5.5 V @ 20 mA
Software Drivers: Supports DOS, Win 95/98/Me, Win NT, Win 2000/XP

5 Chapter1
1.2.7 Environmental
Operating Temperature: 0 ~ 50° C (32 ~ 122° F)
Storage Temperature: -20 ~ 60° C (-4 ~ 140° F)
Relative Humidity: 10 ~ 90% @ 40° C (non-condensing)
Shock: 30 G peak acceleration (11 ms duration)
Power MTBF: 100,000 hrs
Certifications: CE, CCC, FCC Class A, UL, BSMI
1.3 Dimensions

IPPC-6172F User Manual 6

CHAPTER
2
System Setup
Sections include:
• General
• Installing a 2.5" HDD
• Installing Add-on Cards
• Mounting Instructions

IPPC-6172F User Manual 8
Chapter 2 System Setup
2.1 General
Before you start the computer, please follow these procedures for set up:
1. Check and adjust jumpers on the motherboard (see Chapter 3)
2. Install add-on cards
3. Connect the wires, cables and accessories
4. Mount the computer
5. Program the BIOS settings
6. Install an operating system.
2.1.1 PS/2 Mouse & Keyboard
If you wish to use a full-size desktop keyboard and PS/2 mouse with your
panel PC, follow these instructions:
1. Be sure the panel PC is turned off.
2. Attach the keyboard adapter to the 5-pin green port on the rear bot-
tom side of the rear cover.
3. Attach the mouse adapter to the 5-pin purple port on the rear bot-
tom side of the rear cover.
Warning: 1. Switch off and unplug every time you access its interior.
2. The motherboard inside the system is composed of many
delicate ICs, chips and other integrated circuit components.
These components are easily damaged by static shock.
Installing SDRAM module by yourself may cause thermal
issue. If needed, pls contact Advantech RMA center.

9 Chapter2
2.1.2 Parallel Port
IPPC’s support the latest EPP and ECP parallel port protocols for
improved performance with compatible printers or other devices.
To connect the panel PC to a printer or other devices:
1. Make sure both the panel PC and the printer/devices are turned off.
2. Connect the 25-pin male connector of the printer cable to the 25-
pin female port on the panel PC labelled "parallel port."
3. If necessary, attach the other end of your printer cable to your
printer, and fasten any retaining screws.
4. Turn on the printer and any other peripheral devices you may have
connected to the panel PC. Then turn on the panel PC.
5. If necessary, run the panel PC’s BIOS setup program to configure
the parallel port to respond as required by your printer and software
operating environment.
2.1.3 VGA port
An external VGA-compatible device may be connected to the system via
15-pin external port on the rear of the unit. The panel PC simultaneously
supports an external monitor in addition to its own LCD display.
2.1.4 Serial COM ports
There is one serial COM ports on the bottom of the rear cover. You can
easily attach a serial device to the panel PC, such as an external modem or
mouse. Follow these instructions:
1. Make sure the panel PC and any other peripherial devices you may-
have connected to the panel PC are turned off.
2. Attach the interface cable of the serial device to the panel PC’s
serial port. If necessary, attach the other end of the interface cable
to your serial device. Fasten any retaining screws.
3. Turn on any other peripheral devices you may have connected to
the panel PC, and then turn on the panel PC.
4. Refer to the manual(s) which accompanied your serial device(s) for
instructions on configuring your operating environment to recog-
nize the device(s).
5. Run the BIOS setup program to set the I/O address and IRQ, and
configure the jumper settings to change the mode of the COM ports
(refer to section 3.3).

IPPC-6172F User Manual 10
2.1.5 USB ports
An external USB device may be connected to the system via the 4-pin
USB ports located on the rear side of the system unit.
1. Connect the external device to the system.
2. The USB ports support hot plug-in connection. You should install
the device driver before you use the device.
2.1.6 Audio Interface
The audio interface includes three jacks: microphone-in, line-out and
line-in. Their functions are:
Microphone-in: Use an external microphone to record voice and sound.
Line-out: Output audio to external devices such as speakers or ear-
phones. The built-in speaker will not be disabled when the line-out jack is
connected to external audio devices.
Line-in: Input audio from an external CD player or radio.
1. Connect the audio device to the system.
2. Install the driver before you use the device.
2.1.7 Ethernet
To install Ethernet for your system:
1. Connect the Ethernet cable.
2. Turn on the panel PC.
3. Run the Ethernet driver to connect up to the network.

11 Chapter2
2.2 Installing a 2.5" SATA HDD
You can attach one enhanced Serial Advanced Technology Attachment
(SATA) hard disk drive to IPPC-6172F’s internal controller which uses
PCI local bus interface. Please use a wide-temperature industrial hard
disk to meet the thermal requirement. The following instructions are for
installation:
1. Unscrew the back cover and open it.
2. Remove the two screws and take off CD-ROM, HDD cover.
3. Remove four screws and take off HDD bracket.
4. Insert the HDD into the bracket (see figure )
5. Put the HDD bracket into the Chassis and fasten the four screws.
6. Then attach the HDD flat cable and power cable.
7. Close the rear cover
AA
AA

IPPC-6172F User Manual 12
2.3 Installing Add-on Cards
This system supports two PCI expansion cards, total 25w.
1. Detach the five screws on the back to open the lid.
2. Take away the slot bracket.
3. Insert the add-on card, and put on the lid.
2.4 Installing Power Connector
1. Use the tool from the accessory box in the picture 1
2. Press down to open connector hole and insert power wire
