User Manual
UTC-515/520/532
15.6”, 21.5”, 32”
Ubiquitous Touch Computer

UTC-515/520/532 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2014
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Award is a trademark of Award Software International, Inc.
AMD is a trademark of Advanced Micro Devices
Corning Gorilla is a trademark of Corning Inc.
Intel, Atom, Celeron, Core, Bay Trail and Haswell are trademarks of Intel corp.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Microsoft Windows is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semiconductor Co., Ltd.
All other product names or trademarks are properties of their respective owners.
For more information on this and other Advantech products, please visit our websites at:
http://www.advantech.com
For technical support and service, please visit our support website at:
http://support.advantech.com
This manual is for the UTC-515/520/532.
Part No. 2008050010 Edition 1
Printed in Taiwan September 2014

iii UTC-515/520/532 User Manual
Declaration of Conformity
FCC Class A
Packing List
Before you begin installing UTC, please make sure that the following materials have
been shipped:
UTC-515/520/532 unit
Accessories for UTC-515/520
–DC 12V/5A 60W adaptor (UTC-515, UTC-520 A, B & D Sku)
–DC 12V/7A 84W adaptor (UTC-520 C & E Sku)
–SATA cable
–Packet of screws
Accessories for UTC-532
–SATA cable
–Packet of screws
–Antenna
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately.
Note! This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These lim-
its are designed to provide reasonable protection against harmful inter-
ference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency
energy, and if it is not installed and used in accordance with the instruc-
tion manual, it may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harm-
ful interference, in which case the user will be required to correct the
interference at his or her own expense.
Warning! Any modifications made to this device that are not approved by the rele-
vant standards authority may void the authority granted to the user by
the FCC to operate this equipment.

UTC-515/520/532 User Manual iv
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Warnings
Contact information
Manufacturer:
Advantech Co., Ltd.
No.1, Alley 20, Lane 26, Rueiguang Road Neihu District, Taipei, Taiwan 114, R.O.C.
TEL: [phone]
Distributed in Europe by:
Advantech Europe GmbH Kolberger Straße 7 D-40599 Düsseldorf, Germany
Tel: [phone]
Fax: [phone]
Warning! Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dis-
pose of used batteries according to the manufacturer's instructions.
Warning! – Input voltage rated 12V/5A (UTC-515, UTC-520 A, B & D Sku).
– Input voltage rated 12V/7A (UTC-520 C & E Sku).
– Input voltage rated 100-240 VAC 50/60 Hz for UTC-532.
– Use 3V/195mA lithium battery.
– Packing: please carry the unit with both hands, handle with care.
– Maintenance: to properly maintain and clean the surfaces, use only
approved products or clean with a dry applicator.
– CompactFlash: Turn off power before inserting or removing Com-
pactFlash storage card.

v UTC-515/520/532 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
17. CAUTION: USE RECOMMENDED MOUNTING APPARATUS TO AVOID RISK
OF DANGER.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

UTC-515/520/532 User Manual vi

vii UTC-515/520/532 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.2.1 UTC-515A/B/C .............................................................................. 2
1.2.2 UTC-515E ..................................................................................... 3
1.2.3 UTC-520A/B/C .............................................................................. 5
1.2.4 UTC-520D/E ................................................................................. 7
1.2.5 UTC-532A/C ................................................................................. 9
1.2.6 UTC-532D/E ............................................................................... 10
1.3 Dimension ............................................................................................... 11
1.3.1 UTC-515 ..................................................................................... 11
1.3.2 UTC-520 ..................................................................................... 12
1.3.3 UTC-532 ..................................................................................... 13
Chapter 2 System Setup.....................................15
2.1 Quick Start Tour ...................................................................................... 16
2.1.1 Front View................................................................................... 16
2.1.2 Rear View ................................................................................... 17
2.1.3 Side View .................................................................................... 17
2.2 I/O Ports .................................................................................................. 18
2.2.1 UTC-515 ..................................................................................... 18
2.2.2 UTC-520 ..................................................................................... 18
2.2.3 UTC-532 ..................................................................................... 19
2.3 Setup Procedures ................................................................................... 19
2.3.1 Power on UTC ............................................................................ 19
2.3.2 BIOS setup on UTC .................................................................... 19
2.3.3 Installing System Software.......................................................... 20
2.3.4 Installing Drivers ......................................................................... 20
Chapter 3 Hardware Upgrade & Installation .....21
3.1 Introduction ............................................................................................. 22
3.2 Installing the 2.5” Storage ....................................................................... 22
3.3 Installing CFAST (A/B platform only) ...................................................... 23
3.4 Installing the Memory .............................................................................. 23
3.5 Installing wireless LAN Card (option) ...................................................... 24
3.6 Installing UTC peripherals (option).......................................................... 24
Appendix A Installation Accessories ...................25
A.1 Introduction ............................................................................................. 26
A.2 Wall Mount .............................................................................................. 26
A.3 Floor Stand.............................................................................................. 27
Appendix B UTC Peripherals.................................29
B.1 UTC-P01 (Camera Module) .................................................................... 30
B.1.1 Specifications.............................................................................. 30
B.1.2 Packing List................................................................................. 30
B.1.3 Ordering Information ................................................................... 30

UTC-515/520/532 User Manual viii
B.2 UTC-P02 (MSR)...................................................................................... 31
B.2.1 Specifications.............................................................................. 31
B.2.2 Packing List ................................................................................ 31
B.2.3 Ordering Information................................................................... 31
B.3 UTC-P03 (RFID Reader) ........................................................................ 32
B.3.1 Specifications.............................................................................. 32
B.3.2 Packing List ................................................................................ 33
B.3.3 Ordering Information................................................................... 33
B.4 UTC-P06 (Smart Card Reader) .............................................................. 34
B.4.1 Specifications.............................................................................. 34
B.4.2 Packing List ................................................................................ 34
B.4.3 Ordering Information................................................................... 34
B.5 UTC-P07 (Barcode Reader) ................................................................... 35
B.5.1 Specifications.............................................................................. 35
B.5.2 Packing List ................................................................................ 36
B.5.3 Ordering Information................................................................... 36
B.6 UTC-P21 (4-in1 Module)......................................................................... 37
B.6.1 Specifications.............................................................................. 37
B.6.2 Packing List ................................................................................ 37
B.6.3 Ordering Information................................................................... 37
Appendix C Touch Screen Options...................... 39
C.1 Touch Screen Options ............................................................................ 40

Chapter 1
1General Information

UTC-515/520/532 User Manual 2
1.1 Introduction
UTC-500 Series products deliver 15.6”, 21.5”, and 32” fanless, low-power, all-in-one
touch panel solutions suitable for many applications including control room Industrial
PCs, production line industrial digital signage, showroom interactive signage, self-
service kiosks, and public service terminals. They also fulfill much digital retail and
hospitality service needs such as in healthcare, vending, education, entertainment
and information handling. They are beautiful, durable, and reliable. The systems per-
form extremely well, with advanced touchscreen technology, wireless support, cus-
tomized peripherals, rich I/O features, protective covers, and a full-range of
installation accessories.
1.2 Specifications
1.2.1 UTC-515A/B/C
Processor
System
CPU
AMD® G-Series
T40E Dual-core 1.0
GHZ (UTC-515A)
Intel Atom Dual
Core D2550 1.8
GHz (UTC-515B)
Intel Core™ i3
3217UE 1.6 GHz
(UTC-515C)
Chipset T40E + A50M
Intel Atom D2550 +
Intel NM10 Intel QM77
L2 Cache 512 KB 1 MB 1 MB (L3, 3 MB)
Memory 1
x SO-DIMM DDR3
1066 MHz up to 4
GB
1 x SO-DIMM
DDR3 1066 MHz up
to 4 GB
1 x SO-DIMM
DDR3/DDR3L
1333/1600 MHz
up to 8 GB
SSD Support 1 x CFast Support 1 x CFast
HDD 1 x 2.5 internal SATA HDD bay
Network
(LAN) 2 x Gigabit Ethernet ports (Supports Wake on LAN)
I/O Ports
3 x RS-232 COM
(RS-422/485)*
3 x RS-232 COM
(RS-422/485)*
2 x RS-232 COM
(RS-422/485)*
4 x USB 2.0 4 x USB 2.0 2 x USB 2.0, 2 x
USB 3.0
2 x Gigabit Ethernet
(RJ-45)
2 x Gigabit Ether-
net (RJ-45)
2 x Gigabit Ether-
net (RJ-45)
1 x VGA & HDMI 1 x VGA & HDMI 1 x VGA & HDMI
Audio Line-out x 1,
Mic-in x 1
Audio Line-out x 1,
Mic-in x 1
Audio Line-out x 1,
Mic-in x 1
Stereo Speaker 1 W x 2
Bus
Expansion Full-size MiniPCIe/mSATA
Mounting VESA 100 x 100 mm
Dimensions
(W x H x D) 389.81 x 240.12 x 45.20 (mm)
Weight 4.85 kg (10.67 Ib)
OS Support
Windows XP/ XPE/
Embedded 7
Embedded
Windows 8
Embedded Linux
3.0
Embedded Win-
dows 7 32bit
Windows XP/
XPE/ Embedded 7
Embedded
Windows 8
Embedded Linux
3.0

3 UTC-515/520/532 User Manual
Chapter 1 General Information
1.2.2 UTC-515E
Environmental
Specifications
Operating
Temperature 0 ~ 40° C (32 ~ 104° F)
Relative
Humidity 10 ~ 95% @ 40° C non-condensing
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC/ Safety CE, FCC, UL, CCC CB,BSMI
Front Panel
Protection IP65/ NEMA4 Compliant
Power Supply
Input Rating 12 V/5 A
(60 W ITE Adapter)
12 V/5 A
(60 W ITE Adapter)
Power
Consumption
Typical 32W Typical 40W
Max. 40W Max. 50W
LCD Display
Size/Type 15.6" TFT LCD
Max.
Resolution 1366 x 768
Max. Color 262 K
Pixel Pitch
(mm) 248.25 (H) x 248.25 (V)
Brightness
(cd/m2) 300
View Angle 170°/160°
Touch Screen
Option
(PE/RE/GE)
Type Projected Capacitive. Antimicrobial Corning® Gorilla® Glass
/ Analog Resistive 5-wires / Glass Panel
Light
Transmission 90% ± 2% / 80% ± 5% / 90%
Controller USB Interface / USB Interface / -
Processor
System
CPU
Intel® Core™ i5-4300U (UTC-515E)
Intel® Core™ i3-4010U (Available)*
Intel® Celeron 2980U (Available)*
Base Frequency 1.9 GHz (Dual-Core)
Cache L3 Cache 3MB
Memory 1 x SO-DIMM DDR3L 1333 / 1600 MHz up
to 8 GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports (Supports Wake
on LAN)
I/O ports
2 x RS-232 COM (RS-422/485)*
2 x USB 2.0 / 2 x USB 3.0
2 x Gigabit Ethernet (RJ-45)
1 x VGA & HDMI
Audio Line-out x 1, Mic-in x 1
Stereo Speaker 1 W x 2
Bus expansion Full-size MiniPCIe/mSATA
Mounting VESA 100 x 100 mm
Dimensions (W x H x D) 389.81 x 240.12 x 45.20 (mm)
Weight 4.85 kg (10.67 Ib)

UTC-515/520/532 User Manual 4
OS Support Windows Embedded 7, Windows Embed-
ded 8, Embedded Linux 3.0
Environmental
Specifications
Operating Temperature 0 ~ 40 °C (32 ~ 104 °F)
Relative Humidity 10 ~ 95% @ 40° C non-condensing
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC/ Safety CE, FCC, UL, CCC CB,BSMI
Front Panel Protection IP65/ NEMA4 Compliant
Power Supply
Input Rating 12 V/5 A (60 W ITE Adapter)
Power consumption Typical 40W
Max. 50W
LCD Display
Size/Type 15.6" TFT LCD
Max.Resolution 1366 x 768
Max. Color 262 K
Pixel Pitch (um) 248.25 (H) x 248.25 (V)
Brightness (cd/m2) 300
View Angle 170°/160°
Touch Screen
Option (PE/RE/GE)
Type
Projected Capacitive. Antimicrobial Corn-
ing® Gorilla® Glass / Analog Resistive 5-
wires / Glass Panel
Light Transmission 90% ± 2% / 80% ± 5% / 90%
Controller USB Interface / USB Interface / -

5 UTC-515/520/532 User Manual
Chapter 1 General Information
1.2.3 UTC-520A/B/C
Processor System
CPU
AMD® G-Series
T40E Dual-core
1.0 GHz (UTC-
520A)
Intel Atom Dual
Core D2550 1.8
GHz (UTC-520B)
Intel Core™ i7
3517UE 1.7 GHz
(UTC-520C)
Chipset T40E + A50M
Intel Atom D2550
+ Intel NM10 Intel QM77
L2 Cache 512 KB 1 MB 1 MB (L3, 4MB)
Memory
1 x SO-DIMM
DDR3 1066 MHz
up to 4 GB
1 x SO-DIMM
DDR3 1066 MHz
up to 4 GB
1 x SO-DIMM
DDR3/DDR3L
1333/1600 MHz
up to 8 GB
SSD Support 1 x CFast Support 1 x CFast
HDD 1 x 2.5 internal SATA HDD bay
Network
(LAN) 2 x Gigabit Ethernet ports
I/O Ports
3 x RS-232 COM
(RS-422/485)*
3 x RS-232 COM
(RS-422/485)*
2 x RS-232 COM
(RS-422/485)*
4 x USB 2.0 4 x USB 2.0 2 x USB 2.0, 2 x
USB 3.0
2 x Gigabit
Ethernet (RJ-45)
2 x Gigabit
Ethernet (RJ-45)
2 x Gigabit
Ethernet (RJ-45)
1 x VGA & HDMI 1 x VGA & HDMI 1 x VGA & HDMI
Audio Line-out x 1,
Mic-in x 1
Audio Line-out x
1, Mic-in x 1
Audio Line-out x
1, Mic-in x 1
Stereo
Speaker 3 W x 2
Bus
Expansion Full-size MiniPCIe/mSATA
Dimensions
(W x H x D) 517.64 x 313.51 x 43.50 (mm) (20.38" x 12.34" x 1.71")
Weight 8 kg (17.6 lb)
OS Support
Windows XP/
XPE/ Embedded 7
Embedded Win-
dows 8
Embedded Linux
3.0
Embedded Win-
dows 7 32bit
Embedded Win-
dows 8
Embedded Linux
3.0
Windows XP/
XPE/ Embed-
ded 7
Environmental
Specifications
Operating
Temperature 0 ~ 40° C (32 ~ 104° F)
Relative
Humidity 10 ~ 95% @ 40° C non-condensing
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC CE, FCC, UL, CCC, BSMI
Front Panel
Protection IP65/ NEMA4 Compliant
Power
Input Rating
12 V/5 A
(60 W ITE
Adapter)
12 V/7 A
(84 W ITE
Adapter)
Power
consumption
Typical 32W
Max. 40W
Typical 45W
Max. 65W

UTC-515/520/532 User Manual 6
LCD Display
Size/Type 21.5" TFT LCD with LED backlight
Max.
Resolution 1920 x 1080
Max. Color 16.7 M
Pixel Pitch
(mm) 248.25 (H) x 248.25 (V)
Brightness
(cd/m2) 250 (Optional 400)
View Angle 178°/178°
Touch Screen
Option (PE/RE/GE)
Type Projected Capacitive. Antimicrobial Corning® Gorilla®
Glass / Analog Resistive 5-wires / Glass Panel
Light
Transmission 90% ± 2% / 80%± 5% / 90%
Controller USB Interface / USB Interface / -

7 UTC-515/520/532 User Manual
Chapter 1 General Information
1.2.4 UTC-520D/E
Processor
System
CPU Intel® Celeron J1900
(UTC-520D)
Intel® Core™ i5-4300U
(UTC-520E)
Intel® Core™ i3-4010U
(Available)*
Intel® Celeron 2980U
(Available)*
Base
Frequency 2 GHz (Quad-Core) 1.9 GHz (Dual-Core)
Cache L2 Cache 2MB L3 Cache 3MB
Memory 1 x SO-DIMM DDR3L 1333
MHz up to 8 GB
1 x SO-DIMM DDR3L 1333 /
1600 MHz up to 8 GB
HDD
1 x 2.5 internal SATA HDD bay 1 x 2.5 internal SATA HDD bay
Network
(LAN) 2 x Gigabit Ethernet ports (Supports Wake on LAN)
I/O ports
2 x RS-232 COM
(RS-422/485)*
2 x RS-232 COM
(RS-422/485)*
3 x USB 2.0 / 1 x USB 3.0 2 x USB 2.0 / 2 x USB 3.0
2 x Gigabit Ethernet (RJ-45) 2 x Gigabit Ethernet (RJ-45)
1 x VGA & HDMI 1 x VGA & HDMI
Audio Line-out x 1, Mic-in x 1 Audio Line-out x 1, Mic-in x 1
Stereo
Speaker 3 W x 2
Bus
Expansion Full-size MiniPCIe/mSATA
Mounting
VESA 100 x 100 mm
Dimensions
(W x H x D) 517.64 x 313.51 x 43.50 (mm)
Weight 8 kg (17.6 lb)
OS Support Windows Embedded 7, Windows Embedded 8, Embedded
Linux 3.0
Environmental
Specifications
Operating
Temperature 0 ~ 40 °C (32 ~ 104 °F)
Relative
Humidity 10 ~ 95% @ 40° C non-condensing
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC/ Safety CE, FCC, UL, CCC CB,BSMI
Front Panel
Protection IP65/ NEMA4 Compliant
Power Supply
Input Rating 12 V/5 A (60 W ITE Adapter) 12 V/7 A (84 W ITE Adapter)
Power
Consumption
Typical 40W
Max. 50W
Typical 45W
Max. 65W

UTC-515/520/532 User Manual 8
LCD Display
Size/Type 21.5" TFT LCD
Max.
Resolution 1920 x 1080
Max. Color 16.7M
Pixel Pitch
(um) 248.25 (H) x 248.25 (V)
Brightness
(cd/m2) 250 (Optional 400)
View Angle 178°/178°
Touch Screen
Option (PE/
RE/GE)
Type Projected Capacitive. Antimicrobial Corning® Gorilla® Glass
/ Analog Resistive 5-wires / Glass Panel
Light
Transmission 90% ± 2% / 80% ± 5% / 90%
Controller USB Interface / USB Interface / -

9 UTC-515/520/532 User Manual
Chapter 1 General Information
1.2.5 UTC-532A/C
Processor
System
CPU AMD® G-Series T40E Dual-
core 1.0 GHz (UTC- 532A)
Intel Core™ i7 3517UE 1.7
GHz (UTC-532C)
Chipset T40E + A50M Intel QM77
L2 Cache 512 KB 1 MB (L3, 4 MB)
Memory 1 x SO-DIMM DDR3 1066
up to 4GB
1 x SO-DIMM DDR3/DDR3L
1333/1600 MHz up to 8 GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports
I/O Ports
3 x RS-232 COM (RS-422/
485)*
2 x RS-232 COM (RS-422/
485)*
4 x USB 2.0 2 x USB 2.0, 2 x USB 3.0
2 x Gigabit Ethernet (RJ-45) 2 x Gigabit Ethernet (RJ-45)
1 x VGA & HDMI 1 x VGA & HDMI
Audio Line-out x 1, Mic-in x 1 Audio Line-out x 1, Mic-in x 1
Stereo Speaker 3 W x 2
Bus
Expansion Full-size MiniPCIe/mSATA
Dimensions
(W x H x D) 785.64 x 480.24 x 62.50 mm
Weight 1 8 kg (39.6 lb)
OS Support
Windows XP/ XPE/ Embedded 7
Embedded Windows 8
Embedded Linux 3.0
Environmental
Specifications
Operating
Temperature 0 ~ 40 °C (32 ~ 104 °F)
Relative
Humidity 10 ~ 95% @ 40° C non-condensing
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC CE, FCC, UL, CCC, BSMI
Front Panel
Protection IP65/ NEMA4 Compliant
Power
Input Rating 100-240V, 3.15A Max. 50 ~ 60 Hz
Power
Consumption
Typical 95W
Max. 105W
LCD Display
Size/Type 32" TFT LCD with LED backlight
Max.Resolution 1920 x 1080
Max. Color 16.7 M
Pixel Pitch
(mm) 0.36375 (H) x 0.36375 (W)
Brightness
(cd/m2) 300
View Angle 178°/178°
Touch Screen
(PE/GE)
Type Projected Capacitive Touch Panel (Pcap. Flat Glass) /
Glass Panel (No touch function)
Light
Transmission 90% ± 2% / 90%
Controller USB Interface / -

UTC-515/520/532 User Manual 10
1.2.6 UTC-532D/E
Processor
System
CPU Intel® Celeron J1900
(UTC-532D)
Intel® Core™ i5-4300U
(UTC-532E)
Intel® Core™ i3-4010U
(Available)*
Intel® Celeron 2980U
(Available)*
Base Frequency 2 GHz (Quad-Core) 1.9 GHz (Dual-Core)
Cache 2 MB 3 MB
Memory 1 x SO-DIMM DDR3L 1333
MHz up to 8 GB
1 x SO-DIMM DDR3L 1333 /
1600 MHz up to 8 GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports
I/O Ports
2 x RS-232 COM
(RS-422/485)*
2 x RS-232 COM
(RS-422/485)*
3 x USB 2.0 / 1 x USB 3.0 2 x USB 2.0, 2 x USB 3.0
2 x Gigabit Ethernet (RJ-45) 2 x Gigabit Ethernet (RJ-45)
1 x VGA & HDMI 1 x VGA & HDMI
Audio Line-out x 1, Mic-in x 1 Audio Line-out x 1, Mic-in x 1
Stereo Speaker 3 W x 2
Bus
Expansion Full-size MiniPCIe/mSATA
Dimensions
(W x H x D) 785.64 x 480.24 x 62.50 mm
Weight 18 kg (39.6 lb)
OS Support Windows Embedded 7, Windows Embedded 8, Embed-
ded Linux 3.0
Environmental
Specifications
Operating
Temperature 0 ~ 40 °C (32 ~ 104 °F)
Relative
Humidity 10 ~ 95% @ 40° C non-condensing
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC CE, FCC, UL, CCC, BSMI
Front Panel
Protection IP65/ NEMA4 Compliant
Power
Input Rating 100-240V, 3.15A Max. 50 ~ 60 Hz
Power
Consumption
Typical 95W
Max. 105W
LCD Display
Size/Type 32" TFT LCD with LED backlight
Max.Resolution 1920 x 1080
Max. Color 16.7 M
Pixel Pitch (mm) 0.36375 (H) x 0.36375 (W)
Brightness
(cd/m2) 300
View Angle 178°/178°

11 UTC-515/520/532 User Manual
Chapter 1 General Information
1.3 Dimension
1.3.1 UTC-515
Dimensions: 390 x 240 x 45 mm
VESA Mounting: 100 x 100 mm
Touch Screen
(PE/GE)
Type Projected Capacitive Touch Panel (Pcap. Flat Glass) /
Glass Panel (No touch function)
Light
Transmission 90% ± 2% / 90%
Controller USB Interface / -
139.91100
49.06
100
VESA Hole
M4 depth=5mm
389.81
40
45.20
240.12
139.91100
49.06
100
VESA Hole
M4 depth=5mm

UTC-515/520/532 User Manual 12
1.3.2 UTC-520
Dimensions: 518 x 314 x 44 mm
VESA Mounting: 100 x 100 mm
517.64
313.51
40
43.50
517.64
208.82
308.82
395.67
101.96
201.96
420
73.36
VESA Hole
M4 Depth=5mm
208.82
308.82
395.67
101.96
201.96
420
73.36
VESA Hole
M4 Depth=5mm
