Aeronaut Santorini User manual

aero
naut
Order no. 3074/00
Trawler
Santorini

The wooden parts of the kit are provided with laser-cut and part numbers. The accompanying cuts can
be clearly assigned by using the parts list on the last pages. To solve the laser parts from the material
carriers, you cut the lands from which the laser parts are held in the material carrier, with a sharp craft
knife. then clean to achieve the dark edges of the laser parts with sandpaper to the radicals of the
lands to be removed, a good bonding of the components and, not least, a good appearance of the
model.
Check all components before bonding for correct position and work the parts necessary for something.
Make sure that all bonds are completely dry before you begin the next construction step.
Assembling the model should be in the order of construction stages according to these instructions.
always loosen only the parts of the material support that you need for the current construction step.
Please note the adhesive table below for the individual bonds. Before the boat is put into the water, it must Please note the adhesive table below for the individual bonds. Before the boat is put into the water, it must
be with boat varnish inside and painted outside so that the wood and the glued joints are waterproof.
Parts which are glued onto the spar varnish, 2-component adhesive connect to a. A sanding block (9
parts adhere to each other) and sandpaper are in the kit.
Trawler Santorini
Technical specifications
Length: about 510 mm
Width: about 170 mm
Height: about 205 mm
Scale: 1:15
Recommendations for the drive / RC hardware
Engine: Race 280 Order no. 7000/28
controller: Multi 25 Order no. 7019/71
Battery pack: 2S Po or 6 cells NiMh
servo: 1 Servo about 22 × 11 × 24 mm
Tips & Hints
Recommended adhesives
material adhesive Order No.
Wood / Wood Ponal Express 7638/10
Wood / metal stability Express 7646/02
For the construction we recommend our
aero-model pick-needles Order No. 7855/02
Please note the adhesive recommendations
Attention! Carefully follow the instructions of
the building instructions
Grind the holding webs of the parts
carefully, in order to obtain a clean
Bauergebnis. Disconnect the bridge
pieces with a sharp knife from the
wood. Do not break - that could
damage components!
Recommended primer
material item Order No.
Wood sealer 7666/02
Wood Spar varnish (for example, highlight)
16
26
10 mm
4 mm
10
11
Part 10 stick to part fourteenth Parts 11, 12 and 13 fitting exactly stick to parts
15th The marker should be placed on part 15 on the respective outer side.
The shaft tube 16 between the parts 11 and 12 adhere. The shaft
tube must survive mm at the rear of the 10th The rudder trunk 26
glue so that 4 mm it protrudes downward. Note: The small hole in
the shaft tube for greasing the shaft needs to show up.
1
2 + 3
15
14
10
11
12
13

The wooden parts of the kit are provided with laser-cut and part numbers. The accompanying cuts can be clearly assigned by using the parts list on the last pages. To
solve the laser parts from the material carriers, you cut the lands from which the laser parts are held in the material carrier, with a sharp craft knife. then clean the dark
edges of the laser parts with sandpaper, of the remains of the lands to be removed, a good bonding of the components and not least a good look
to achieve model. Check all components before bonding for correct position and work the parts necessary for something. Make sure that all bonds are completely dry
before using the
next construction step start. Assembling the model should be in the order of construction stages according to these instructions. always loosen only the parts of the material
support that you need for the current construction step. Please note the adhesive table below for each
Adhesions. Before the boat is put into the water, it must be with boat varnish inside and painted outside so that the wood and the glued joints are waterproof. Parts of theAdhesions. Before the boat is put into the water, it must be with boat varnish inside and painted outside so that the wood and the glued joints are waterproof. Parts of the
Boot lacquer to be glued, connected to a 2-component adhesive. A sanding block (9 parts adhere to each other) and sandpaper are in the kit.
Trawler Santorini
Technical specifications
Length: about 510 mm
Width: about 170 mm
Height: about 205 mm
Scale: 1:15
Recommendations for the drive / RC hardware
Engine: Race 280 Order no. 7000/28
controller: Multi 25 Order no. 7019/71
Battery pack: 2S Po or 6 cells NiMh
servo: 1 Servo about 22 × 11 × 24 mm
Tips & Hints
Recommended adhesives
material adhesive Order No.
Wood / Wood Ponal Express 7638/10
Wood / metal stability Express 7646/02
For the construction we recommend our
aero-model pick-needles
Order No. 7855/02
Please note the adhesive recommendations
Attention! Carefully follow
Notes the building instructions
Grind the holding webs of
Parts carefully, in order to obtain a clean Bauergebnis.
Disconnect the bridge pieces with a sharp knife from
the wood. Do not break - that could damage
components!
Recommended primer
material item Order No.
Wood sealer 7666/02
Wood Spar varnish (for example, highlight)
16
26
10 mm
4 mm
10
11
Part 10 stick to part fourteenth
Parts 11, 12 and 13 fitting exactly stick to parts 15th The marker should be
placed on part 15 on the respective outer side.
The shaft tube 16 between the parts 11 and 12 adhere. The shaft
tube must survive mm at the rear of the 10th The rudder trunk 26
glue so that 4 mm it protrudes downward.
Note: The small hole in the shaft tube for greasing the shaft
needs to show up.
1
2 + 3
15
14
10
11
12
13

14
15
15
34.1
34.2 34.2
35.1
34
5
Now part 14 stick to part 10 and 15 on the parts
11,12 and 13, to complete part to the keel.
4
Solder the capacitor between the two
terminals and one cable per
connection.
6
The motor 34 with the screws 35 and washers
35.1 Screw on frame 5th
5
1
2
3
4 5
6
7 8th
Xieren the top frame 1 on a flat building board fi and the frames 2
attach to. 8
7
1
8th The keel to the frames and front stuck in the top frame. 1 The keel throughout8th The keel to the frames and front stuck in the top frame. 1 The keel throughout
slide in the recess of the top frame, so that the frames are correctly aligned.
The parts in all corner joints glue.

14
15
15
34.1
34.2 34.2
35.1 34 5
Now part 14 to part 10 and part 15 on stick
the parts 11,12 and 13 to the keel to
to complete.
4
The capacitor between the two terminals
and one cable
Solder per connection.
6
The motor 34 with the screws 35 and washers
35.1 Screw on frame 5th
5
1
2
3
4 5
6
7 8th
Xieren the top frame 1 on a flat building board fi and the frames 2
attach to. 8
7
1
8th The keel to the frames and front stuck in the top frame. 1 The keel throughout8th The keel to the frames and front stuck in the top frame. 1 The keel throughout
slide in the recess of the top frame, so that the frames are correctly aligned.
The parts in all corner joints glue.

18
15
23
24
The false edges 15.1 and 15.2 glue on both sides of the keel 15th
The lines at the keel must remain visible. Note: The part numbers on
the parts 15.1 and 15.2 must be upside down.
The Kimmleiste 18 put forward in the Kiel 15th Part 18 sticking into the keel
15 and in the joists and secured with staples.
9
22
24
glue together the boatstand
from parts 22, 23 and 24th
10
15.2
15.1
19
4
18
1
8th
The bottom 19 ay fl on the frames, align the rear of the keel and the
rudder trunk and secure to frame 8 with a clamp. Secure the bottom
of frame 4 with a needle so that it does not slip. Press the ground
with staples down on the frames and secure with masking tape at the
bending bar 18 and the frame first
11
15.1
15.2

18
15
23
24
The false edges 15.1 and 15.2 glue on both sides of the keel 15th The lines at the keel must remain visible. Note: The part numbers on the parts 15.1 and 15.2
must appear on the head. The Kimmleiste 18 put forward in the Kiel 15th Part 18 sticking into the keel 15 and in the joists and secured with staples.
9
22
24
glue together the boatstand from parts 22, 23 and 24th
10
15.2
15.1
19
4
18
1
8th
The bottom 19 ay fl on the frames, align the rear of the keel and the
rudder trunk and secure to frame 8 with a clamp. Secure the bottom
of frame 4 with a needle so that it does not slip. Press the ground
with staples down on the frames and secure with masking tape at the
bending bar 18 and the frame first
11
15.1
15.2

5
28
30
34
stuck the shaft of the propeller 28 through the shaft tube. Assemble
the motor shaft and the shaft with the hose 30th The shafts must be
in alignment. The shaft 28 with the propeller and the hose 30 is
again removed.
12
10 Glue the bow 10 in
the keel and secure with a
clamp.
13
20
The side panels 20 front insert into
the bow 10 and get back with a
clamp. If everything fits, stick part
20 and secure with masking tape.
See next stage of construction.
14
20
10
20

5
28
30 34
stuck the shaft of the propeller 28 through the shaft tube. Assemble the motor shaft and the shaft with the hose 30th The shafts must be in alignment. The shaft 28
with the propeller and the hose 30
Remove again.
12
10
Glue the bow 10 in the keel and
secure with a clamp.
13
20
The side panels 20 front insert into
the bow 10 and get back with a
clamp. If everything fits, stick part
20 and secure with masking tape.
See next stage of construction.
14
20
10
20

39
40
39
40
Glue the cockpit rim of the parts
39 and 40th
16
21
If the bond has dried, the stick
mirror 21 from the rear.
15
20.1
20.1
21.1
21.1
20.1 parts of glue on the inside with UHU adhesive to the
hull sides. With clips or tape backup so that they rest on
the parts 20 altogether. Tip: Deck 25 can be temporarily
used for secure positioning of the parts 20.1.
After that Glue part 21.1.
17

39
40
39
40
Glue the cockpit rim of the parts 39 and 40th
16
21
If the bond has dried, the stick mirror 21 from the rear.
15
20.1
20.1
21.1
21.1
20.1 parts of glue on the inside with UHU adhesive to the
hull sides. With clips or tape backup so that they rest on
the parts 20 altogether. Tip: Deck 25 can be temporarily
used for secure positioning of the parts 20.1.
After that Glue part 21.1.
17

41
42
42
41
42
42
The strips 41 to the outer upper edge of
the ledges 42 at the inner edge. They
yield the substructure for the handrail.
Prime the whole body inside and out
with sealer. Shaft 28 and inserting
check that the hull is waterproof with
the propeller.
Then remove the shaft again and
paint the hull in the desired color.
18
41
28
30
paint
36
36
37
37
38
38
The Au fl agen 36, 37 and 38
to paint and glue in the hull.
19
paint
Paint the handrail 43 and stick.
43
20

41
42
42
41
42
42
The strips 41 to the outer upper edge of the ledges 42 at the inner edge. They yield the substructure for the handrail. Prime the whole body inside and out with
sealer. Shaft 28 and inserting check that the hull is waterproof with the propeller. Then remove the shaft again and paint the hull in the desired color.
18
41
28 30
paint
36
36
37
37
38
38
The Au fl agen 36, 37 and 38 of
painting and in the hull
Glue.
19
paint
Paint the handrail 43 and stick.
43
20

25
44
Adjust the deck 25 before the gluing and ensure that it fully ying fl on
deck frame first The deck 2 times prime, then paint with clear
varnish and glue. Cover 44 of painting and stick. Skirting board 27
paint and glue to the fuselage.
Note: The rounded end of the skirting board facing forward.
21
27
44
45
46
46
47
48
49
50
46.1
The construction of the wheelhouse of the parts 45 -
Are stuck together 47th
stick 50 - the parts of the 48th
22
23

25
44
Adjust the deck 25 before the gluing and ensure that it fully ying fl on deck frame first The deck 2 times prime, then paint with clear varnish and glue. Cover 44 of
painting and stick. Skirting board 27 paint and glue to the fuselage. Note: The rounded end of the skirting board is facing
front.
21
27
44
45
46
46
47
48
49
50
46.1
The construction of the wheelhouse of the parts 45 -
Are stuck together 47th
stick 50 - the parts of the 48th
22
23

51
52
53
53
54 55
56
45
paint the building, the window frames 54-56 paint
and glue. The discs 54.1 -
Glue 56.1.
The frame 51 + 52 and the bottom 53 below the
bottom stick 45th
24
25
57
57
58
59
In the roof 57 the handrail from the parts 58
+ Stick and paint 59th The roof only stick on the
control house, after the equipment 61 to 65 are
mounted.
26

51
52
53
53
54 55 56
45
paint the building, the window frames 54-56 paint and glue. The discs 54.1 -
Glue 56.1.
The frame 51 + 52 and the bottom 53 below the bottom stick 45th
24
25
57
57
58
59
In the roof 57 the handrail from the parts 58
+59 glue and paint. The roof only stick on the
control house, after the equipment 61 to 65 are
mounted.
26

64
65
61 62
63
stick to the steering wheel 61 part 62nd The axis 60 of the
rear glue in the steering wheel and the axis 60 in part 46.1.
The Instsrumentengehäuse 63 bend, cut out the valves (on
the last page), waterproof paint, and glue. turn the monitor 64
and stick to the foot 65 with part of the 49th
60
46.1
49
27
66
66
66
Glue the fan trays 66th
28
67
67
68
69
69
70
70
In part 67 on both sides of the
position lamps turn as shown.
The sunroof of the parts 67 - to solder
70th
Watch out
no solder may get into the groove of part 67 to the
position lamp.
29
30

64
65
61 62
63
stick to the steering wheel 61 part 62nd The axis 60 of the rear glue in the steering wheel and the axis 60 in part 46.1. The Instsrumentengehäuse 63 bend, cut out the valves
(on the last page), waterproof paint, and glue. turn the monitor 64 and stick to the foot 65 with part of the 49th
60
46.1
49
27
66
66
66
Glue the fan trays 66th
28
67
67
68
69
69
70
70
In part 67 on both sides of the
position lamps turn as shown.
The sunroof of the parts 67 - to solder
70th
Watch out
no solder may get into the groove of part 67 to the
position lamp.
29
30

71
72
73 74
75 76
77
78
The cross beams 71-74 öten fl.
The tubes 75, 76, 78 and the bulb holder 77 öten fl.
The position lamps downward turn.
79
68
The pipe 79 for the flagpole obliquely rearward soldering
part on 68th
31
32
33
80
80
81
81
80
81
82
82
82
82
83
83
43
The tubes stuck in the holes of the handrail 43 82, these are provided on the underside about 2 mm above. Below the
handrail 43, the tubes are slightly squashed 82 so that the wires 83 have a stroke. The holder 81 turn for the rescue rings
and öten fl on the cross strut 80th The cross-bar 80 attach to the wires 83rd
110 mm
34
