Aerpro VE 2 Series Instruction Manual

VE
SERIES 2
INSTALL KIT FP9550GK & FP9550BK
INSTALLATION/USER MANUAL

Page 2
PLEASE READ BEFORE INSTALLATION
The system you are installing acts as a controller for your factory Heating/Cooling
system.
To ensure correct functionality, please conrm the factory system is functioning
correctly prior to installation.
This controller WILL NOT x any prior issues with the Heating/Cooling system in the
vehicle.
To conrm the factory system is operational, follow the steps below.
1. Check Fan speed control
2. Check the Vents change correctly
3. Check the system changes temperature correctly
4. Conrm Dual Zone separates temperatures correctly
5. Air conditioner
6. SWC (The steering controls must be working in the vehicle previously to work with
our control harnesses. They will not x previous underlying problems).
If the system is deemed to be operational, Please continue with your Installation
NOTE: Remove any Cd’s in the from the factory head unit before uninstalling
Installation Information
Product and Install Information
If you would like to nd more information on this product or download an up to date
digital copy of this manual, please visit the aerpro.com website and search for your
model or scan the QR code below.
FP9550GK An installation and setup video
is also available on our site
FP9550BK

Page 3
Use the following tools to make dismantling the car and the installation of the new facia
easier. NOTE: Do not use power tools, only use the tools recommended below
and do not over tighten screws as they may damage the facia kit. Also take care
in removing the vehicles trim as over time they may have become brittle.
Tools needed
4. Small Pick
6. Hacksaw or cutting blade5. Side Cutters
7. Cable Ties
3. Small Flat Head
Screwdriver
1. Panel Removers 2. Phillips Head Screwdrivers
8. Electrical Tape

Page 4
Product overview
The Aerpro FP9550GK/BK VE Series 2 Facia Installation Kit is Australian designed
and engineered and has been made for tting a double DIN aftermarket radio, CD or
DVD player to the original double DIN enclosure. The trims between these two models
varies as shown below and are model specic.
The Aerpro AWCGM1 wireless charging dock is also available for this installation
Optional accessory both variants (Sold separately)
FP9550GK FP9550BK

Page 5
1x Double DIN facia kit
1x Gunmetal trim panel (FP9550GK) or 1x Piano Black trim panel (FP9550BK)
1x Built-in HVAC and SWC unit
1x Universal SWC patch lead
1x Factory USB retention lead
1x Camera retention lead
1x Antenna adapter
1x Mounting kit
2x Support brackets
1x User/Install manual
Inclusions
FP9550GK FP9550BK
OR

Page 6
Dash Disassembly
Reset factory HVAC system
It is recommended that you re-calibrated the factory HVAC heater valves or ducting
positions before removal of the factory head unit. Press and hold the rear demister for
5 seconds until you hear the actuators re-calibrate. NOTE: Remove any Cd’s in the
from the factory head unit before uninstalling
Remove right side dash panel
Insert a panel remover and lever outwards

Page 7
Dash Disassembly
Remove right side trim
Insert a panel remover and lever outwards
Remove right side trim
Continue to the left side with the panel remover
FP9550GK FP9550BK

Page 8
Dash Disassembly
Remove left side panel
Insert a panel remover and lever outwards
Remove left side dash trim
Insert a panel remover and lever towards yourself working your way to the centre of
the dash FP9550GK

Page 9
Dash Disassembly
Remove glovebox
There are 2 x screws to remove from the bottom of the glove box
Remove glovebox
Unclip the panel underneath the glovebox to access glove box light and mounting
screws

Page 10
Dash Disassembly
Remove glovebox
Twist to remove the glove box light from the panel (Model dependent) and place trim
aside until reassembly
Remove glovebox
There are 2 x screws to remove at the bottom of the glovebox as indicated

Page 11
CAUTION
Glovebox may drop when screws are removed
Dash Disassembly
Remove glovebox
There are 5 x screws to remove from around the top of the glove box. Remove the
outer screw covers with the small at head screwdriver or pick
Remove glovebox
Once the glovebox is unscrewed, disconnect the connector at the rear to completely
remove the glovebox from the vehicle. The connector sits behind a metal plate with a
cutout to access the clip

Page 12
Dash Disassembly
Remove left side center console panels
The panels are held in with 1 plug and 2 inner clips. Release centre of plug and
remove. Pull the lower panel downwards and out. Then pull the top panel outwards
and downwards to release from the clips.
Remove left side center console trim
Once removed, place the panels aside for reassembly
Inner clips

Page 13
Dash Disassembly
Disconnect Antenna
Disconnect all antenna and USB connectors. Press down on the top of the connector
to remove from the head unit
Remove under steering wheel cover
Insert a panel remover and lever towards you to remove the trim, repeat this process
on the opposite side.

Page 14
Dash Disassembly
Remove under steering wheel cover
While unclipping, be sure to hold up the panel and not let it drop to protect the
headlight switch connection
Remove right side center console panels
The panels are held in with 1 plug and 2 inner clips. Release centre of plug and
remove. Pull the lower panel downwards and out. Then pull the top panel outwards
and downwards to release from the clips as done on the left side previously

Page 15
Dash Disassembly
Remove rear camera plug & quadlock
Unclip the rear camera connector below the quadlock
To remove the quadlock connector, press the sides marked with arrows inwards.
The lever will release then pull outwards to detach from the head unit.
Press the sides marked with arrows inwards Connector released

Page 16
Remove centre panel trim (Calais speaker shown)
Use pick tool or at headed screwdriver to lift panel or grille. Put aside for reassembly
Dash Disassembly
Remove centre panel trim top screws
Unscrew the 2 screws holding the main factory fascia in place

Page 17
Dash Disassembly
Main factory facia removal
Unscrew the left hand side screw holding the main factory fascia in place
Main factory facia removal
Unscrew the right hand side screw holding the main factory fascia in place

Page 18
Remove centre console trim
Apply the handbrake and place the gear shift in the neutral position. Using a panel
remover, lift the trim around the gear stick holding the window controls. Then carefully
lift the top by hand to release the retaining clips
Remove centre console trim
Unplug the 3 connectors attached to the centre console trim
Dash Disassembly

Page 19
Dash Disassembly
Remove pocket if applicable
Unscrew left and right hand side screws and remove
Remove pocket if applicable
Pull upwards and towards you to remove

Page 20
Dash Disassembly
Remove tray if applicable
Unscrew left and right hand side screws and remove
Remove tray if applicable
Pull upwards and towards you to remove
