Soundoff Signal nERGY ETSA200R-PA User manual

ETSA200R(x)-PA 0618
1.800.338.7337 / www.soundoffsignal.com
IMPORTANT INFORMATION:
Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances. These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these devices to ensure compliance.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/sales-support.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. at 1.800338.7337 (press #4 to skip the automated message).
Questions or comments that do not require immediate attention may be emailed to [email protected].
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
• Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances.
These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these
devices to ensure compliance.
• DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to your vehicle
Owner’s Manual for the location of any air bag deployment zones.
• DO NOT connect this device to a strobe power supply. This product is self-contained and does not
require an external power supply.
Important Information:
INSTALLATION:
1. Securely mount the PA Pre-Amplier in a dry location
inside vehicle
2. Plug 4 wire cable into 4 pin connector on PA
Pre-Amplier
3. Plug microphone into 3 pin connector on PA Pre-
Amplier
4. Route 4 wire cable to 200R Siren Amplier
5. 4 Wire PA Pre-Amplier connections:
a. Black wire and shield: tap into black wire of 200R Siren
Amplier or connect to reliable ground near siren
amplier ground
b. Red wire: tap into 200R sire amplier orange wire
c. White wire: Connect to the White/Red wire of 200R
siren amplier
d. Green Wire:
i. If Radio Rebroadcast function is not required:
connect to the Grey wire of the 200R siren amplier
ii. If Radio Rebroadcast
function is required:
1. Connect Grey Wire of 200R siren amplier to
a common terminal of SPDT (single pole/
double throw) switch
2. Connect White wire from 4 wire cable to
the terminal of the switch which makes
contact with the common terminal when
switch is the off position
3. Connect the other terminal of the switch to
+10-16Vdc to activate Radio Rebroadcast
function when the switch is in the ON position
e. Orange/Black Wire:
1. Connect Orange/Black wire to ignition
switch. +Vdc is required on Orange/Black
wire for siren to operate.
6. Adjust the Audio Gain potentiometer on the PA Pre-
Amplier to obtain desired speaker output level for PA
function
7. Dip Switch conguration on PA Pre-Amplier
a. Dip Switch #1: ON Position
b. Dip Switch #2: OFF Position
200R SIREN w/PA PRE-AMP
PART NUMBERS:
ETSA200R-PA
ETSA200RA-PA
ETSA200RW-PA
Package Contents:
1 PA Pre-Amplier
1 Microphone w/Mounting Clip
& Hardware
1 4 Wire Cable
.
Tech Specs 200R SIREN W/PA PRE-AMP
Input Voltage: 10-16Vdc (Negative Ground)
Connectors:
1x 3 Pin Microphone (Ground, PTT Input, Audio in)
1x 4 Pin Audio (Ground, +V, Audio Out, PTT Output)
1x 8 Pin RJ45 CTRL PNL
1x 8 Pin RJ45 CENTRAL
Protection:
Reverse Polarity
Short Circuit
Over Current
Transient
Operating Temp: -40˚C to + 110˚F
Dimensions: 3.5” x 3.5” x .8”
Audio Frequency: 200Hz-10Khz
Standby Current: <5 mA
OPERATION:
Depressing the PTT switch on the PA
Microphone will activate the PA function
of the 200R Siren amplier. Releasing the
PTT switch on the PA Microphone will
disable the PA function and siren amplier
will return to previous function.
!
WARNING
Sirens produce loud sounds that
may damage hearing:
- Roll up windows.
- Wear hearing protection.
- Use only for emergency response.
- Avoid exposure to siren sound
outside of vehicle.
1.

ETSA200R(x)-PA 0618
1.800.338.7337 / www.soundoffsignal.com
IMPORTANT INFORMATION:
Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances. These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these devices to ensure compliance.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/sales-support.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. at 1.800338.7337 (press #4 to skip the automated message).
Questions or comments that do not require immediate attention may be emailed to [email protected].
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
2.
BATTERY
INSTALLER SUPPLIED
& INSTALLED 10A FUSE
SUPPLIED
SPLASH-PROOF
FUSEHOLDER W/10A
FUSE
ORANGE
TAN
BROWN
RED/BLACK
RED
ORANGE/BLACK
WHITE/BLACK
WHITE
BLUE
BLUE
GREY
WHITE/RED
YELLOW
VIOLET
BLACK
200R AMPLIFIER
TONE 1
TONE 2
MANUAL TONE INPUT
HORN TONE INPUT
IGNITION INPUT
HORN INPUT
HORN IN
PTT/RADIO REBROADCAST
PA AUDIO INPUT
PARK KILL INPUT
TONE SELECT
GROUND
SHIELDED CABLE
POWER
PTT
AUDIO
GROUND
PA PRE-AMP
RED
WHITE
GREEN
BLACK
PA
PA MICROPHONE
PA PRE-AMP WITHOUT RADIO
RE-BROADCAST REQUIRED
58/100 WATT
SPEAKER
GREEN GREEN/BLACK
NOTE: ORANGE/BLACK wire must be
connected to ignition for function.

ETSA200R(x)-PA 0618
1.800.338.7337 / www.soundoffsignal.com
IMPORTANT INFORMATION:
Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances. These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these devices to ensure compliance.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/sales-support.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. at 1.800338.7337 (press #4 to skip the automated message).
Questions or comments that do not require immediate attention may be emailed to [email protected].
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
PA PRE-AMP WITH RADIO
RE-BROADCAST REQUIRED
BATTERY
INSTALLER SUPPLIED
& INSTALLED 10A FUSE
SUPPLIED
SPLASH-PROOF
FUSEHOLDER W/10A
FUSE
ORANGE
TAN
BROWN
RED/BLACK
RED
ORANGE/BLACK
WHITE/BLACK
WHITE
BLUE
BLUE
GREY
WHITE/RED
YELLOW
VIOLET
BLACK
200R AMPLIFIER
TONE 1
TONE 2
MANUAL TONE INPUT
HORN TONE INPUT
IGNITION INPUT
HORN RING OUT
HORN RING IN
PTT/RADIO REBROADCAST
PA AUDIO INPUT
PARK KILL INPUT
TONE SELECT
GROUND
SHIELDED CABLE
POWER
PTT
AUDIO
GROUND
PA PRE-AMP
RED
WHITE
GREEN
BLACK
PA
PA MICROPHONE
RR
PTT
RED
GRN
GREEN
3.
RADIO
REBROADCAST
NOTE: Connect Orange/Black
wire to ignition switch. +Vdc is
required on Orange/Black wire for
siren to operate.
