aFe Power 46-20299-B User manual

advanced FLOW engineering
Instruction Manual P/N: 46-20299-B
Make: Ford Model: F-150 Raptor Year: 2017-2020 Engine: V6-3.5L (tt) EcoBoost

Label Qty. Description Part Number
A 1 Tube, Cold Side 05-60771B
B 1 Coupling, Silicone Hump: 3"ID x 2-1/4" 05-01245
C 1 Coupling, Silicone Elbow: 3-1/2"ID x 45 05-60556
D 1 Adaptor 05-60373
E 1 Plug, Hex Head Socket: 1/8" NPT 03-50029
F 1 O-Ring 05-60626
G 2 Clamp, #052 03-50008
H 2 Clamp, #048 03-50007
I 1 Screws, Socket Head Cap: M6 03-50241
J 1 Washer, M6 03-50177
Tools Needed: 6mm & 8mm Allen wrenches, 7mm & 8 mm sockets or nut drivers, T30 Torx socket
or driver, 13mm & 15mm sockets, ratchet, grease and thread sealant.
Note: Legal in California for use on race vehicles only. The use of this device on vehicles used on
public streets or highways is strictly prohibited in California and others states that have adopted
California emission regulations.
• Please read the entire instruction manual before proceeding.
• Ensure all components listed are present.
• If you are missing any of the components, call customer support at 951-493-7185.
• Ensure you have all necessary tools before proceeding.
• Do not attempt to work on your vehicle when the engine is hot.
• Disconnect the negative battery terminal before proceeding.
• Retain factory parts for future use.
Page 2

aFepower.com
Page 3
C
A
B
H H G G
D I
E J
F

Refer to Figure A for Steps 1-6
Step 1: Park vehicle on level ground and engage parking brake.
Step 2: Remove intake Y-pipe by loosening the three clamps using a 7mm socket or nut driver and
disconnecting the sensor. (Figure A).
Step 3: Disconnect the vent tube by squeezing the retaining clip and pushing it through to release it,
then gently pull it off the intercooler tube. (Figure B).
Step 4: Disconnect the wire harness from the sensor and the factory intercooler tube. (Figure B).
Step 5: Remove the sensor for reuse in your new aFe intercooler tube, using a Torx socket. (Figure B).
Step 6: Loosen the clamp at the throttle body connection, using a 7mm socket or nut driver and
separate the coupling from the throttle body. (Figure B).
Page 4
REMOVAL
Figure A

Refer to Figure B for Steps 7-12
Step 7: Under the vehicle you will need to remove the six bolts securing the skid plate to the truck.
Step 8: Once the skid plate is removed disconnect the pressure relief valve tube on the driver side of the
vehicle right above the intercooler tube connection by twisting it a ¼ turn counter-clock wise,
then gently pulling it back to separate it from the canister and twisting the entire tube out of the
way.
Step 9: On the driver side of the vehicle loosen the clamp using a 7mm socket or nut driver that is
securing the cold side intercooler tube to the 3-1/2" rubber hose and disconnect the hard plastic
tube from the rubber coupling.
Step 10: Once the rubber hose is disconnected remove the tube from the top of the vehicle.
Step 11: Use a small screwdriver to remove the wire retaining clip at the lower intercooler tube
connection on the driver side of the vehicle.
Step 12: Pull the lower tube connection apart and remove the lower half of the intercooler tube from the
vehicle.
aFepower.com
Page 5
3
1
1
2
REMOVAL
Figure B

Refer to Figure C for Steps 13-14
Step 13: Place the small silicone coupling over the small end of the aFe intercooler tube with one of the
smaller supplied clamps and install the 1/8” NPT plug into the fitting.
NOTE: Be sure to use thread sealant on the threads prior to instillation.
Step 14: Install the sensor from Step 5 into the aFe intercooler tube with the small screw provided, using
an allen wrench.
Page 6
INSTALL
Figure C

Refer to Figure D for Steps 15-17
Step 15: Install the factory retaining clip into the groove on the outside of the supplied aluminum adaptor
(Figure A).
Step 16: Install the supplied O-ring into the groove on the inside the aluminum adaptor (Figure A).
NOTE: Lube the O-rings for the adaptor and the sensor from Step 5 with a small amount
of grease, prior to installation, to prevent the O-ring from tearing.
Step 17: Place the large 45° silicone coupling the intercooler adaptor along with the large clamps
(Figure B).
Page 7
INSTALL
Figure D
15
16
aFepower.com

Refer to Figure E for Steps 18-20
Step 18: Install the intercooler tube from the top of the vehicle.
Step 19: Install the aluminum adaptor onto the intercooler and then onto the intercooler tube, be sure
that the clip snaps all the way into the groove on the intercooler.
Step 20: Up top, install the throttle body coupling onto the throttle body with the last clamp.
Page 8
INSTALL
Figure E

Refer to Figure F for Steps 21-23
Page 9
Step 21: Reinstall the relief valve tube from Step 8.
Step 22: Ensure intercooler tube is not resting on any plastic or metal surfaces then tighten all clamps.
Step 23: Reinstall factory skid plate.
INSTALL
Figure F
aFepower.com

Refer to Figure G for Steps 24-27
Page 10
Step 24: Up top, reconnect the vent tube onto the aFe intercooler tube and lock it with the retaining clip.
Step 25: Reconnect the sensor from Step 4.
Step 26: Reinstall intake y-pipe and the tighten clamps.
Step 27: Reconnect the sensor in the intake tube. Install is now complete.
Thank you for choosing aFe Power. Enjoy!
Figure G
INSTALL

aFepower.com
To purchase any of the items above, view airflow charts, dyno graphs, photos, and video; please go to aFepower.com.
Intercooler w/ Tube
P/N: 46-20292-B P/N: 46-70152-WL (w/ Oil)
46-70152 (Blk, Mch)
46-70150 (RAW)
P/N: 49-43091-B (Blk. Tips)
49-43091-P (Pol. Tips)
P/N: 49-43045-B (Blk. Tips)
49-43045-P (Pol. Tips)
Rear Diff. Cover Cat-Back Exhaust System Side-Exit Exhaust System
P/N: 77-43023
SCORCHER GT Module
P/N: 51-73115 (PDS)
54-73115 (P5R)
Cold Air Intake System
Page 11

Page 12
Page left blank intentionally.

Page left blank intentionally.
Page 13

Page 14
Page left blank intentionally.

aFepower.com
Warranty
General Terms:
• aFe warrants their products to be free from manufacturer’s defects due to workmanship and material.
• This warranty applies only to the original purchaser of the product and is nontransferable.
• Proof of purchase of the aFe product is required for all warranty claims.
• Warranty is valid provided aFe instructions for installation and/or cleaning were properly followed.
• Proper maintenance with regular inspections of product is required to insure warranty coverage.
• Damage due to improper installation, abuse, unauthorized repair or alteration is not warranted.
• Incidental or consequential damages or cost, including installation and removal of part, incurred due to failure of aFe
product is not covered under this warranty.
• All warranty is limited to the repair and/or replacement of the aFe part. To request Return Goods Authorization
(“RGA”), email [e-mail] or call [phone]. Upon receipt of the RGA, you must return the product
to the address provided in the RGA, freight prepaid and accompanied with a dated proof of purchase and the RGA.
 Uponreceiptofthedefectiveproductanduponvericationofproofofpurchase,aFewilleitherrepairorreplacethe
defective product within a reasonable time, not to exceed thirty days.
ProductCategory P/NPrex Warrantyduration
Direct OE Replacement Filters 10, 11, 30, 31, 71, 73 Life of the vehicle
Racing Filters 18 1 year
Universal 21, 24, 72 2 years
Air Intake Systems 50, 51, 54, 55, 75 2 years
Exhaust Systems 49 2 years
Intercoolers & Intercooler Tubes 46-2 2 years
Intake Manifolds 46-1 2 years
Differential Cover 46-7 Life of the vehicle
Exhaust Manifolds 46 2 years
Throttle Body Spacers 46-3 2 years
Fluid Filters 44 90 days
Pre-Filters 28 2 years
Heavy Duty OE Replacement 70 2 years
PowerSports OE Replacement 81, 87 2 years
PowerSports Intake Systems 85 2 years
No other warranty expressed or implied applies nor is any person or advanced FLOW engineering authorized to assume any other
warranty. Some States do not allow the exclusion or limitation of incidental or consequential damages or do not allow limitations on
howlonganimpliedwarrantylasts,sotheabovelimitationsorexclusionsmaynotapplytoyou.Thiswarrantygivesyouspecic
legal rights, and you may also have other rights which vary from State to State.
Page 15

advanced FLOW engineering, inc.
252 Granite Street Corona, CA 92879
TEL: [phone] • TECH: 951.493.7185
E-Mail:[e-mail] P/N: 06-80924
