aFe Power GT MOMENTUM 50-70087D User manual

Cold Air Intake System
Instruction Manual P/N: 50-70087D / 50-70087R______________________________
Make: Audi
Model: Q3
Year: 2019-2022
Engine: L4-2.0L (t) 45 TFSI

Page 2
• Please read the entire instruction manual before proceeding.
• Ensure all components listed are present.
• For technical support please call 951-493-7185.
• Ensure you have all necessary tools before proceeding.
• Do not attempt to work on your vehicle when the engine is hot.
• Retain factory parts for future use.
Label
Qty.
Description
Part Number
A1
1
Air Filter (Pro 5R)
24-91103
A2
1
Air Filter (Pro DRY S)
21-91103
B
1
Housing
05-5070087B2
C
1
Intake Tube
05-5070087B1
D
1
Coupling, Silicone Reducer
05-01528
E
1
Grommet, 1” ID
03-50139
F
1
Fitting, Smog Pump
05-01096
G
1
Clamp, #044
03-50019
H
1
Clamp, #048
03-50007
I
3
Grommet, Mounting
03-50647
J
1
Nipple, Brass ¼”
03-50194
K
1
Inlet Trim
05-01657
L
1
Plug, Silicone
05-01482
Installation will require the following tools:
7mm & 8mm nut drivers, ½” deep socket and driver
Warranty Information available at https://afepower.com/contact#warranty
Emissions Disclaimer: This product is not currently CARB exempt and is not available for purchase in
California or for use on any vehicle registered with the California Department of Motor Vehicles.

Page 3

Page 4
Refer to Figure A for Step 1
Step 1: Remove the engine cover 1 .
REMOVAL
Figure A
1

Page 5
Refer to Figure B for Steps 2-5
Step 2: Using a 7mm nut driver, loosen the clamp 2 at the factory turbo inlet.
Step 3: Disconnect the CCV line 3 from the side of the factory filter housing.
Step 4: Disconnect the smog pump fitting 4 from the factory filter housing.
Step 5: Remove the factory filter housing and intake tube by pulling straight up off the mounting grommets.
REMOVAL
Figure B
4
2
3

Page 6
Refer to Figure C for Steps 6-7
Step 6: Install the supplied reducer coupling 5 and #044 clamp 6 with the smaller side on your turbo inlet
and tighten using an 8mm nut driver.
Step 7: Place the #048 clamp 7 loosely around the open end of the coupler.
INSTALL
Figure C
7
6
5

Page 7
Refer to Figure D for Step 8
Step 8: Install the 3 supplied silicone grommets 8 into the bottom of your aFe POWER filter housing.
Figure D
INSTALL
8

Page 8
Refer to Figure E for Step 9
Step 9: Install the supplied silicone inlet trim 9 onto the inlet of your aFe POWER filter housing.
INSTALL
9
Figure E

Page 9
Refer to Figure F for Step 10
Step 10: Install your aFe POWER filter housing into the vehicle by sliding the front inlet onto the OE scoop,
then rotating the housing down onto the mounting points.
INSTALL
Figure F

Page 10
Refer to Figure G for Steps 11-12
Step 11: Install the supplied 1” ID grommet 10 into the opening on your aFe POWER intake tube, then
press the supplied aluminum fitting 11 into the grommet. Make sure the fitting is fully seated in the
grommet for a good seal.
Step 12: Install the supplied ¼” hose nipple 12 into the threaded fitting on the bottom of the intake tube.
Use a ½” deep socket and driver to tighten the fitting. *This is an NPT syle fitting –some threads will still
be exposed when the fitting it fully tightened. Do not overtighten the fitting or you risk stripping the insert
out of the plastic*
INSTALL
Figure G
11
12
10

Page 11
Refer to Figure H for Step 13
Step 13: Install your aFe POWER air filter into the filter housing by firmly pressing it into the opening until
the small tabs are locked on the inside. Leave the clamp loose on the filter opening.
INSTALL
Figure H

Page 12
Refer to Figure I for Step 14
Step 14: Install your aFe POWER intake tube assembly first into the opening on the air filter, then rotate it
downwards into the open end of the coupler at the turbo inlet. Use an 8mm nut driver to tighten all
clamps.
INSTALL
Figure I

Page 13
Refer to Figure J for Steps 15-16
Step 15: Reconnect the smog pump hose 13 to the fitting on the side of your aFe POWER intake tube.
Step 16: Connect the CCV hose 14 to the barbed fitting on the bottom of your aFe POWER intake tube.
INSTALL
Figure J
14
13

Page 14
Refer to Figure K for Step 17
Step 17: (Optional) Use the provided plug 15 to close the additional air inlet if you want to completely seal
the filter housing. Best performance is obtained without the plug.
Figure K
INSTALL
15

Page 15
Refer to Figure L for Steps 18-19
Step 18: Reinstall your engine cover.
Step 19: Check that all components are tight and secure. Your installation is now complete. Thank you for
choosing aFe POWER!
NOTE: Check all clamps, and connectors are secure after 100-200 miles
Figure L
INSTALL
