Agilent TS-5400
Functional Test System
Series IIB
Agilent E6171B
Measurement Control Module
User’s Manual
*E6171-90032*
*E6171-90032**E6171-90032*
*E6171-90032*
Manual Part Number E6171-90032
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Notices
© Agilent Technologies, Inc. 1994 - 2003
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement and written consent from Agi-
lent Technologies, Inc. as governed by
United States and international copyright
laws.
Documentation History
All Editions and Updates of this manual and
their creation date are listed below. The
first Edition of the manual is Edition 1. The
Edition number increments by 1 whenever
the manual is revised. Updates, which are
issued between Editions, contain replace-
ment pages to correct or add additional
information to the current Edition of the
manual. Whenever a new Edition is cre-
ated, it will contain all of the Update infor-
mation for the previous Edition. Each new
Edition or Update also includes a revised
copy of this documentation history page.
Edition 1 (E3750-90000) (prelim)July 1994
Edition 2 (E6171-90000) (prelim)June 1995
Edition 3 (E6171-90001)February 1996
Edition 4 (E6171-90002)May 1996
Edition 5 (E6171-90022)June 2000
Edition 6 (E6171-90032) August 2003
Manual Part Number
E6171-90032
Printed in USA
Agilent Technologies, Inc.
1601 California Street
Palo Alto, CA 94304 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warran-
ties, either express or implied, with
regard to this manual and any infor-
mation contained herein, including
but not limited to the implied warran-
ties of merchantability and fitness for
a particular purpose. Agilent shall not
be liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or perfor-
mance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of
a U.S. Government prime contract or sub-
contract, Software is delivered and
licensed as “Commercial computer soft-
ware” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as
defined in FAR 2.101(a) or as “Restricted
computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use,
duplication or disclosure of Software is
subject to Agilent Technologies’ standard
commercial license terms, and non-DOD
Departments and Agencies of the U.S. Gov-
ernment will receive no greater than
Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Govern-
ment users will receive no greater than
Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
Caution
A Caution notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that,
if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
Caution notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and met.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety and Support Information 3
Safety Summary
The following general safety
precautions must be observed
during all phases of operation of
this system. Failure to comply
with these precautions or with
specific warnings elsewhere in
this manual violates safety
standards of design,
manufacture, and intended use
of the system. Agilent
Technologies, Inc. assumes no
liability for the customer's
failure to comply with these
requirements.
General
This product is provided with a
protective earth terminal. The
protective features of this
product may be impaired if it is
used in a manner not specified
in the operation instructions.
WARNING: DO NOT OPERATE
IN AN EXPLOSIVE ATMOSPHERE
Do not operate the system in the
presence of flammable gases or
flames.
If the equipment in this system
is used in a manner not
specified by Agilent
Technologies, the protection
provided by the equipment may
be impaired.
Cleaning Instructions
Clean the system cabinet using a
soft cloth dampened in water.
WARNING: DO NOT REMOVE
ANY SYSTEM COVER
Operating personnel must not
remove system covers. Component
replacement and internal
adjustments must be made only by
qualified service personnel.
Equipment that appears damaged or
defective should be made
inoperative and secured against
unintended operation until they can
be repaired by qualified service
personnel.
Environmental Conditions
Unless otherwise noted in the
specifications, this system is
intended for indoor use in an
installation category II,
pollution degree 2 environment.
It is designed to operate at a
maximum relative humidity of
80% and at altitudes of up to
2000 meters. Refer to the
specifications tables for the ac
mains voltage requirements and
ambient operating temperature
range.
Before applying power
Verify that all safety precautions
are taken. Note the external
markings described in “Safety
Symbols and Regulatory
Markings” on page 4.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4 Safety and Support Information
Ground the System
To minimize shock hazard, the
system chassis must have a
hard-wired connection to an
electrical protective earth
ground. The system must also be
connected to the ac power mains
through a power cable that
includes a protective earth
conductor. The power cable
ground wire must be connected
to an electrical ground (safety
ground) at the power outlet. Any
interruption of the protective
grounding will cause a potential
shock hazard that could result in
personal injury.
Fuses
Use only fuses with the required
rated current, voltage, and
specified type (normal blow,
time delay). Do not use repaired
fuses or short-circuited fuse
holders. To do so could cause a
shock or fire hazard.
Operator Safety Information
MODULE CONNECTORS AND
TEST SIGNAL CABLES
CONNECTED TO THEM
CANNOT BE OPERATOR
ACCESSIBLE: Cables and
connectors are considered
inaccessible if a tool (e.g.,
screwdriver, wrench, socket,
etc.) or a key (equipment in a
locked cabinet) is required to
gain access to them.
Additionally, the operator
cannot have access to a
conductive surface connected to
any cable conductor (High, Low
or Guard).
ASSURE THE EQUIPMENT
UNDER TEST HAS
ADEQUATE INSULATION
BETWEEN THE CABLE
CONNECTIONS AND ANY
OPERATOR-ACCESSIBLE
PARTS (DOORS, COVERS,
PANELS, SHIELDS, CASES,
CABINETS, ETC.): Verify there
are multiple and sufficient
protective means (rated for the
voltages you are applying) to
assure the operator will NOT
come into contact with any
energized conductor even if one
of the protective means fails to
work as intended. For example,
the inner side of a case, cabinet,
door, cover or panel can be
covered with an insulating
material as well as routing the
test cables to the module’s front
panel connectors through
non-conductive, flexible conduit
such as that used in electrical
power distribution.
Safety Symbols and
Regulatory Markings
Symbols and markings on the
system, in manuals and on
instruments alert you to
potential risks, provide
information about conditions,
and comply with international
regulations. Table 1 defines the
symbols and markings you may
encounter.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety and Support Information 5
Tab le 1 Safety Symbols and Markings
Safety symbols
Warning: risk of electric shock.
Caution: refer to accompanying documents.
Alternating current.
Both direct and alternating current.
Earth (ground) terminal
Protective earth (ground) terminal
Frame or chassis terminal
Terminal is at earth potential. Used for measurement and control
circuits designed to be operated with one terminal at earth potential.
Switch setting indicator. O = Off, | = On.
Standby (supply); units with this symbol are not completely
disconnected from ac mains when this switch is off. To completely
disconnect the unit from ac mains, either disconnect the power cord, or
have a qualified electrician install an external switch.
Regulatory Markings
The CE mark is a registered trademark of the European Community.
The CSA mark is a registered trademark of the Canadian Standards
Association.
The C-tick mark is a registered trademark of the Spectrum Management
Agency of Australia. This signifies compliance with the Australian EMC
Framework regulations under the terms of the Radio Communications
Act of 1992.
ISM 1-A This text indicates that the product is an Industrial Scientific and
Medical Group 1 Class A product (CISPR 11, Clause 4).
N10149
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6 Safety and Support Information
Service and Support
Any adjustment, maintenance,
or repair of this product must be
performed by qualified
personnel. Contact your
customer engineer through your
local Agilent Technologies
Service Center.
Agilent on the Web
You can find information about
technical and professional
services, product support, and
equipment repair and service on
the Web:
http://www.agilent.com
Click the link to Te st &
Measurement. Select your
country from the drop-down
menus. The Web page that
appears next has contact
information specific for your
country.
Agilent by Phone
If you do not have access to the
Internet, call one of the numbers
in Table 2.
Tab le 2 Agilent Call Centers and Regional Headquarters
United States and Canada: Test and Measurement Call Center
[phone] (toll-free in US)
Europe: (41 22) 780 8111
Japan: Measurement Assistance Center
(81) 0426 56 7832
Latin America: 305 269 7548
Asia-Pacific: (85 22) 599 7777
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7
Declaration of Conformity
According to ISO/IEC Guide 22 and EN 45014
Manufacturer's Name: Agilent Technologies
Loveland Manufacturing Center
Manufacturer's Address: 815 14th Street S.W.
Loveland, Colorado 80537
Declares, that the product:
Product Name: Agilent Technologies E617B Measurement Control Module
Model Number: Agilent E6171B
Product Options: All
Conforms to the following Product Specifications:
Safety: IEC 61010-1 (1990)+A2:1995/EN61010-1:1993+A2:1995
CSA C22.2 #1010.1 (1992)
UL 3111
EMC: CISPR 11:1990/EN55011 1991: Group 1, Class A
EN50082-1:1992
IEC 61000-4-2:1995/: 4kV CD
IEC 61000-4-3:1995/: 3V/m
IEC 61000-4-4:1995/: 1 kV Power line
Supplementary Information: This product complies with the requirements of the Low Voltage Directive 73/23/
EEC (inclusive 93/68/EEC). This product also wherewith complies with the protection requirements of: The EMC
Directive 89/336/EECand carries the "CE" marking accordingly. Attestation isprovided according to article 10(2)
of the Directive by a Technical Construction File.
Technical File Number: 95-0900-002-TCF Rev. C Dated: 28 June, 1999
A Technical Report/Certificate has been issued by the following appointed Competent Body, namely,
KEMA Registered Quality Nederland B.V.
Utrechtseweg 310, 6812 AR Arnhem
6800 ET Arnhem, The Netherlands
Certificate Number: 71301-KRQ/EMC 97-4165 Dated: February 18, 1997
June 28, 1999
For Compliance Information ONLY, contact:
Australian Contact: Product Regulations Manager, Agilent Technologies Australia Ltd., 31-41 Joseph Street, Blackburn,
Victoria 3130, Australia
European Contact: Your local Agilent Technologies Sales and Service Office or Agilent Technologies GmbH,
Department HQ-TRE, Standards Europe, Herrenberger Straße 130, D-71034 Böblingen (FAX: +49-
7031-14-3143)
USA Contact: Product Regulations Manager, Agilent Technologies Company, P.O. Box 301, Mail Stop BU212,
Loveland, CO 80537
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8
Notes:
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents 9
Contents
Declaration of Conformity............................................................................................7
Chapter 1
Getting Started .............................................................................................................11
Introduction.................................................................................................................11
Warnings and Cautions...............................................................................................13
Setting the Address Switch......................................................................................... 14
Installing in a VXI Mainframe.................................................................................... 14
Chapter 2
Understanding the Agilent E6171B Measurement Control Module .......................15
Introduction.................................................................................................................15
Description of Features...............................................................................................15
16 X 5 Instrument Multiplexer ............................................................................17
Trigger Multiplexer .............................................................................................17
Isolated V/I Source ..............................................................................................20
ARB Features ......................................................................................................21
Analog Comparator ............................................................................................. 21
General-Purpose Timer ....................................................................................... 21
Digital Trigger .....................................................................................................23
Programmable Attenuator ................................................................................... 24
Connecting DUT Ground to Chassis Ground .....................................................25
Interrupts .............................................................................................................25
Power-on State ....................................................................................................26
Software Reset ....................................................................................................26
Chapter 3
Adjusting the Agilent E6171BE6171B
Measurement Control Module ...................................................................................27
Using This Chapter.....................................................................................................27
Adjusting the VI Pots..................................................................................................27
Other Adjustments......................................................................................................27
Appendix A
Agilent E6171B Measurement Control
Module Specifications ..................................................................................................29
General........................................................................................................................ 29
External Instrument Multiplexer...............................................................................29
Voltage Source (Low Voltage)...................................................................................30
Voltage Source (High Voltage) .................................................................................. 30
Current Source (Low Voltage) ...................................................................................30
Current Source (High Voltage)...................................................................................31
Step Up Transformer .................................................................................................31
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10 Contents
Hi-Voltage Attenuator ................................................................................................ 31
MCM Trigger Subsystem ...........................................................................................32
End-of-Life Detection.................................................................................................33
Replacement Strategy .................................................................................................34
Appendix B
Register Definitions .....................................................................................................35
Addressing the Registers ............................................................................................ 35
16 Address Space Outside the System Controller ...............................................35
Register Offset ..................................................................................................... 36
Register Descriptions.................................................................................................. 37
Manufacturer Identification Register ..................................................................37
Device Type Register ..........................................................................................37
Status/Control Register .......................................................................................37
General-Purpose Timer Register .........................................................................40
DAC Control Registers ....................................................................................... 40
V/I Clamp, Attenuator Knee, and DAC & Amplifier Selector Register ............41
Relay Registers ....................................................................................................44
Trigger Configuration Registers ..........................................................................48
IRQ Register ........................................................................................................51
Programming the Registers.........................................................................................52
Using the IRQ Register .......................................................................................52
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started 11
Chapter 1
Getting Started
Introduction
The Agilent E6171B Measurement Control Module is an instrument
multiplexer and voltage/current source module designed for automotive
electronic test applications. Key features of the module include:
•An isolated voltage source.
•An isolated current source with a programmable voltage limit.
•A 16 X 5 instrument multiplexer that multiplexes four analog buses
plus Device Under Test (DUT) common.
•Multiplexing for eightexternal triggers and eightVXIbus TTL triggers
to and from each other or to and from the DUT.
•An analog comparator, with programmable thresholds, whose output
connects to the trigger multiplexer.
•A programmable high-voltage attenuator.
•A amplifier with programmable gain that can amplify the output of an
Agilent E6173A Arbitrary Function Generator module (formerly the
Agilent Z2471A) via a step-up transformer to provide output for
simulating VRS (Variable Reluctance Sensors) signals.
•A Programmable IRQ.
•A programmable general-purpose timer whose output also can be used
to generate interrupts, trigger delays, and pacing.
Note The Agilent E6171A and E6171B are functionally equivalent. The module
was updated to the "B" version to improve overall manufacturability and
calibration.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12 Getting Started
Note that the Measurement Control Module has four LEDs on its front
panel. They are:
Accessed This LED flashes when the module is accessed.
Failed When lit, this LED indicates either the module
failed to power-up correctly or the VCC is noisy.
When the module is powered-up, this LED remains
lit until the VXIbus backplane is initialized.
IRQ When lit, this LED indicates that an IRQ has been
asserted. This LED flashes periodically during
normal operation and during reset.
Interlock When lit, this LED indicates the safety interlock
feature is enabled, which can be used to prevent
access to dangerous high voltages.
Figure 1-1. Measurement Control Module LADD Switch Access
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started 13
Warnings and Cautions
WARNING SHOCK HAZARD. Only service-trained personnel who are
aware of the hazards involved should install, remove, or
configure the switch module. Before you remove any installed
module, disconnect AC power from the mainframe and from
other modules that may be connected to the modules.
Do not defeat the Agilent E6171B Measurement Control Module
Interlock feature with jumpers.
An interlocked safety cover is recommended to prevent
operator access to electric shock hazard voltages and currents
that may be applied to the unit under test.
Voltages greater than 30 Vrms, 42 Vpk, or 60 Vdc are
considered hazardous voltages. Current greater than 8 A or
energy greater than 150 VA is also considered hazardous.
AVERTISSMENT NE pas neutraliser le verrouillage de l'appareil de mesure
E6171B.
Un couvercle des sécurité à verrouillage est recommandé afin
de protéger l'opérateur des chocs électriques causés par des
tensions ou des courants qui peuvent ètre appliqués à
l'appareil à l'essai. Les tensions superieures a 30 V (eff.), 42 V
(crete) ou 60 V (c.c.) sont dangereuses. Un courant supérieures
à 8 A ou une énergie supérieure à 150 V-A sont dangereux.
Caution STATIC ELECTRICITY. Static electricity is a major cause of
component failure. To prevent damage to the electrical
components in the switch module, observe anti-static
techniques whenever removing a module from the mainframe
or whenever working on a module.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14 Getting Started
Setting the Address Switch
The logical address switch is factory set at 3. You may need to change the
setting the during module installation. Valid addresses are from 1 to 254.
Figure 1-1 shows the module and the location of the address switches.
Installing in a VXI Mainframe
The Agilent E6171B Measurement Control Module can be installed in any
available mainframe slot except slot 0. The jumper cable that connects the
Agilent E6171B to the first Agilent E6172A 32-Pin Matrix Module requires
the two modules to be adjacent. See Figure 1-2.
Figure 1-2. Placement of the Agilent E6171B Measurement Control Module in a VXI Mainframe
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Understanding the Agilent E6171B Measurement Control Module 15Chapter 2
Chapter 2
Understanding the Agilent E6171B
Measurement Control Module
Introduction
Figure 2-1 shows a simplified block diagram of the Agilent E6171B in a
typical Agilent TS-5400 Family application. THe application includes one
Agilent E6172A 32-Channel Pin Matrix module and four other test
instruments.
Description of Features
The Measurement Control Module contains:
•A 16 X 5 matrix of dry reed relays used to multiplex instruments.
•An isolated—i.e., “floating”—dual-range voltage and current source
that also can be used as an amplifier for the Agilent E6173A Arbitrary
Waveform Generator Module (formerly Agilent Z2471A), and
optionally, high-voltage transformer output.
•A trigger multiplexer that provides access for external equipment
triggers to the VXIbus TTL triggers and Device Under Test (DUT).
•An analog comparator whose output is routed to the trigger
multiplexer.
•A general-purpose timer that can run in one-shot or free running
modes. Besides being used for general timing applications, its output
can be routed to any of seven interrupt lines and used for triggering,
generating delays, or pacing.
•A DUT-referenced measurement system (a path through relays that
connects DUT ground to system or chassis ground).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16 Understanding the Agilent E6171B Chapter 2
Figure 2-1. Conceptual Overview of a Measurement Control Module with Agilent E6172A Modules
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Understanding the Agilent E6171B Measurement Control Module 17Chapter 2
16 X 5 Instrument
Multiplexer As many as sixteen external inputs to the MeasurementControl Module can
be connected to any of the four analog columns or to the common DUT
ground that exit this card via the ABus1-ABus4. You can use these inputs as
follows:
•Because the Agilent E1411 DMM is used to measure the output of the
V/I source, the DMM must always be connected to external inputs 1-4
as DVM Hi, DVM Lo, Isource Hi, and Isource Lo, respectively.
•The Measurement Control Module provides special routing for signals
from the Agilent E6173A Arbitrary Function Generator Module,
which must always be connected to external inputs 5 & 6, Hi and Lo,
respectively.
•If a digitizer, such as the Agilent E1429A, is used in the system, it
should be wired to row 7 through 10.
•Finally, row 11 and 12 are set aside for a counter, such as the Agilent
E1333A counter.
•The external inputs 13 through 16 are undefined and can be used with
any additional instruments.
•Row 17-19 is not available, and rows 20 through 32 have assigned
uses already.
The Agilent E6171B can route any of the 16 external instruments as well as
any of its internal resources (V/I source, analog comparator, digital trigger,
and attenuator) to the five measurement buses and then to one or more
Agilent E6172A 32-Pin Matrix Modules.
Trigger Multiplexer The trigger multiplexer lets you interconnect various combinations of
external triggers, VXIbus trigger lines, and the output from the analog
comparator on the Measurement Control Module. This helps with complex
DUT trigger scenarios with VXI instruments. You can simultaneously
connect two independent trigger paths.
Figure 2-2 is a simplified block diagram of the trigger MUX-DEMUX
arrangement. The sources and destinations of the triggers are shown in
greater detail in Figure 2-3.
Figure 2-2. Block Diagram of Trigger MUX-DEMUX Arrangement
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

18 Understanding the Agilent E6171B Chapter 2
By default, external trigger outputs and the digital trigger output are pulled
up to 5 volts. However, the digital trigger output can be pulled up to 30 volts
via external source and pull-up resistors for DUT triggering. The digital
trigger output from the trigger multiplexer can be connected to any of the
columns on ABus1-ABus4. The digital trigger output and comparator input
“float” to the DUT common.
You can connect more than one trigger source and trigger destination per
trigger path to provide synchronization between devices. For example, a
trigger source on the DUT could connect to both a counter and the external
trigger port on a DVM and use only one path in the trigger multiplexer.
Figure 2-3 shows a conceptual diagram of the bus structure in the trigger
multiplexer. Arrows indicate whether the various lines connected to the
trigger buses are inputs, outputs, or bi-directional.
Table 2-1. Trigger Sources and Destinations
Trigger Sources (inputs) Trigger Destinations (outputs)
8 external triggers
(on front panel of module)
8 VXIbus TTL triggers
output from analog comparator
output from general-purpose timer
software programmable trigger
8 external triggers
(on front panel of module)
8 VXIbus TTL triggers
digital trigger output
timer start
software poll
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Understanding the Agilent E6171B Measurement Control Module 19Chapter 2
The trigger multiplexer contains two trigger buses, nominally known as
TRIG1 and TRIG2, used to route signals. Any of the eight, bi-directional
TTL-level triggers at the VXIbus backplane can connect to either of the
trigger multiplexer's buses and can be used as trigger sources or trigger
destinations. The connections are made electronically through an
“open-collector” bus. If any selected input is low, then the bus is low.
Otherwise, the bus is high. In a similar fashion, any of the eight external
trigger lines available on the module's front panel can connect to either of
the two multiplexer buses.
The routing and configuration of all sixteen of the lines described above is
controlled by writing control data to the various Trigger Configuration
Registers (see Appendix B).
There are three other trigger sources you can connect to the trigger buses.
The first, “timer output” in the diagram, is an output from the
general-purpose timer. Its routing to TRIG1 or TRIG2 is controlled by bits
1 and 4 of the Other Trigger Resources Register (see Appendix B). The
Figure 2-3. Bus Structure of the Trigger Multiplexer
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
