Agora Models Lamborghini MIURA Manual

The “Automobili Lamborghini” and “Automobili Lamborghini Bull and Shield” trademarks, copyrights,
designs and models are used under license from Automobile Lamborghini S.p.A, Italy.
STAGE 75: INSTALLING THE FUEL PUMPS AND
THE FRONT FRAME REINFORCEMENT PLATES
STAGE 76: FITTING THE DASHBOARD
AND FRONT FRAME INTO THE BODY AND
INSTALLING THE CIRCUIT BOARD
STAGE 77: CONNECTING THE WIRING AND
FITTING THE COCKPIT INTO THE BODY
STAGE 78: FITTING THE REAR FRAME AND
INSTALLING THE UPPER TIE RODS
STAGE 79: ATTACHING THE LEFT
AND RIGHT DOORS
STAGE 80: BUILDING THE BONNET
REINFORCEMENT STRUCTURE 1
STAGE 81: BUILDING THE BONNET
REINFORCEMENT STRUCTURE 2
STAGE 82: ASSEMBLING THE HEADLIGHTS
Pack 10
BUILD INSTRUCTIONS

AGORAMODELS LAMBORGHINI MIURA
2
Spare screws are included with each part. Occasionally, you may be instructed to keep spare or
unused screws for a later stage. Keep these spares in a safe place and label them correctly.
Please make sure you don’t mix up the screws. They look quite similar, but the threads do vary
slightly. Using the wrong screws may damage the parts.
When securing parts together using multiple screws, fit each screw loosely to ensure all the
parts are correctly aligned before gently tightening them firmly, but not overtight, in the order
in which you placed them.
The screwdriver can be magnetized by stroking it with a magnet (fridge magnet, etc.) enabling
it to hold the screws and make assembly easier.
If a screw is tight going into a metal part, do not force it as you may shear the head off. Remove
it and put a tiny smear of Vaseline, soap or light oil on the thread. That will lubricate it and make
it easier to drive home.
During the course of this build, you will receive many pieces that you will assemble immediately
– following the instructions in the corresponding stage – and other pieces that you should store
safely to one side, for use in future assembly stages.
Left and Right! When building your Lamborghini, the left or right hand side refers to each side
as you are sitting in the car.
WARNING: Some parts are assembled using magnets. These magnets can cause serious injury
if they are swallowed. Keep away from children. If you suspect a magnet has been swallowed,
seek medical help straight away.
Advice from the experts
!

AGORAMODELS LAMBORGHINI MIURA
3
XXX
Name
Fuel pump (1)
Fuel pump bracket
Fuel pump (2)
Front frame reinforcement plate (right)
Fitting x2
Front frame reinforcement plate (left)
Long tube x2
Short tube x4
STAGE 75 PARTS LIST
In this stage you’ll fit the front
reinforcement plates onto the
frame, then construct and install
the fuel pumps.
Fuel pump (1)
Stage 75: Installing the Fuel Pumps and the Front
Frame Reinforcement Plates
Fuel pump (2)
Front frame reinforcement plate (right) Front frame reinforcement plate (left)
Fuel pump bracket
Long tube x2
Fitting x2
Short tube x4

AGORAMODELS LAMBORGHINI MIURA
4
1
3
2
4
Take the two front frame reinforcement plates and lay them on your
work surface as shown. To distinguish the left plate from the right,
note the number of holes – the right one has four, the left one has five.
Repeat on the other side of the frame to fit the right reinforcement
plate in place.
Take the front frame assembly. On the left-hand side, next to the spare
wheel, there are two rectangular holes (red arrows) as well as a small
break (blue arrow) in the frame: these are the three fixing points for
the left reinforcement plate. Insert the plate into position by fitting
the three plugs of the piece into the fixing points of the frame. We
recommend starting with fitting the plate into the small break first,
then pressing it into the rectangular holes.
Take one of the fuel pumps and the fuel pump bracket. Press the
pump into the bracket, by inserting the rectangular pins of the
bracket (circled) into the hole of the pump. Fit the second fuel pump
in the same manner. Ensure that the parts are oriented as shown in
the inset photo, with the pins on the back of the bracket (blue arrow)
on the right while the flat ends of the fuel pumps (red arrows) are
oriented upwards.
Right Left
Stage 75: Installing the Fuel Pumps and the Front
Frame Reinforcement Plates

AGORAMODELS LAMBORGHINI MIURA
5
5
7
6
8
Next take the two fittings along with the long and short tubes and lay
them on your work surface oriented as shown. Fit the long tubes onto
the ends of the Y-shaped fittings and the short tubes onto the split
branches of the fittings (red arrows).
Push one pair of the short tubes onto the top pins of the fuel pumps
(red arrows). The other pair fits onto the bottom pins as shown.
To get a good fit, try twisting the tubes between your thumb and
finger as you press them onto the fitting.
You can now mount the fuel pump bracket onto the right-hand frame
reinforcement plate. To do this, insert the pins of the pump bracket
into the two holes on the plate (red arrows). Note that the rounded
ends (blue arrows) of the fuel pumps are oriented upwards.
Stage 75: Installing the Fuel Pumps and the Front
Frame Reinforcement Plates

AGORAMODELS LAMBORGHINI MIURA
6
9 10
On the frame, below the two pumps, there are two holes into which
the ends of the long pipes are inserted. Insert the loose end of the
lower long tube into the hole highlighted in the photo with an arrow.
You may wish to remove then place the tube in hot water first to bend
it into shape.
Insert the end of the upper long tube into the other hole as shown.
STAGE COMPLETE
Stage 75: Installing the Fuel Pumps and the Front
Frame Reinforcement Plates

AGORAMODELS LAMBORGHINI MIURA
7
XXX
Name
Upper tie rod x2
Circuit board
Steering joint
Type Q screws x2
Type A screws x15
Type B screws x8
STAGE 76 PARTS LIST
You’ll need the dashboard and the
central body assemblies for this stage.
After fitting the dashboard in place,
you’ll fix the circuit board for the
model’s electronics. You’ll then attach
the front frame and body together.
The upper tie rods supplied with this
stage can be stored away for now until
they are needed later in this Pack.
Type Q x2
Stage 76: Fitting the Dashboard and Front Frame
into the Body and Installing the Circuit Board
Upper tie rod x2
Steering joint
Circuit board
Type A x15
Type B x8

AGORAMODELS LAMBORGHINI MIURA
8
1
2 3
For this stage you will need the central body and dashboard assembled previously.
Turn the the body upside down. Inside the front, under the
windscreen area, there are three drilled columns on each side: the two
innermost columns (arrows) are for installing the dashboard.
Turn the dashboard upside down. Opposite the steering wheel there
are two slots (arrows) for fixing it to the body.
Stage 76: Fitting the Dashboard and Front Frame
into the Body and Installing the Circuit Board

AGORAMODELS LAMBORGHINI MIURA
9
4
6
5
7
Take the dashboard and position it inside the central part of the body,
taking care to match up the drilled columns and the fixing slots
highlighted in steps 2 and 3 (arrows). You may find it necessary to
slightly widen the body in order to fit the dashboard in place.
Secure the right-hand side of the dashboard with a Type A screw.
Use a Type A screw to secure the left-hand side of the dashboard. You
may wish to leave the screw slightly loose until the other side (step 6)
has been tightened.
Check that the dashboard is fitted flush all the way round.
TYPE A
TYPE A
Stage 76: Fitting the Dashboard and Front Frame
into the Body and Installing the Circuit Board

AGORAMODELS LAMBORGHINI MIURA
10
8
9 10
Next take the circuit board. Make sure to handle the circuit board carefully as you install it, holding it by the
edges when necessary. Remove all the protective caps from the connectors as shown.
Retrieve the front frame assembly and place it upside down on your
work surface as shown. There is a large rectangular opening in the
center with four perforated columns (circled) inside for fixing the
electronic board.
Place the circuit board in the recess inside the front frame assembly.
Make sure to orient the card so that the connectors numbered 5 to 8
are facing the rear of the assembly (arrow).
Stage 76: Fitting the Dashboard and Front Frame
into the Body and Installing the Circuit Board

AGORAMODELS LAMBORGHINI MIURA
11
11
13
12
14
Fix the circuit board to the assembly using 4x Type B screws.
The slots fit into the drilled columns located next to the ones used to
secure the dashboard (arrows).
Next locate the four connection points on the front frame assembly
(arrows) which are used to secure it to the body.
Fit the front frame assembly into the body as shown. It may be
necessary to widen the body in order to fit the front frame – be careful
not to apply too much force to any of the plastic areas of the model.
You may wish to file excess black paint from the faces of the side
connections (arrows) where they contact the body.
TYPE B TYPE B
Stage 76: Fitting the Dashboard and Front Frame
into the Body and Installing the Circuit Board

AGORAMODELS LAMBORGHINI MIURA
12
15
17
16
18
Make sure that the holes in the base of the door hinge housings
(arrow) line up on both sides of the components.
Once you have ensured that the front assembly of the chassis is
positioned correctly, you can fix everything with four Type A screws.
Start inserting the first one in the slot on the driver’s side, located next
to the dashboard fixing point.
Also check that the front frame assembly is properly seated by
checking alignment with the edge of the body, as shown by the
dashed line.
Drive the second Type A screw into the passenger side slot.
TYPE A
TYPE A
Stage 76: Fitting the Dashboard and Front Frame
into the Body and Installing the Circuit Board

AGORAMODELS LAMBORGHINI MIURA
13
19 20
Continue to fix the assemblies together with a third Type A screw in
the outer hole at the base of the driver’s side door hinge housing. The
screw should sit flush inside the recess.
Finish fixing the front frame with the fourth Type A screw in the outer
hole on the passenger’s side.
TYPE A
TYPE A
21 22
Now take the steering joint and a Type Q screw. Check the front wheel hubs are parallel to the direction of travel and
that the steering wheel is also in the neutral position – the ends of the
steering columns should look like those in the image. Connect the two
steering columns together by pressing the pin of one into the hole of
the other (arrow).
Stage 76: Fitting the Dashboard and Front Frame
into the Body and Installing the Circuit Board

AGORAMODELS LAMBORGHINI MIURA
14
23
Fit the steering joint over the other pin of the steering column (arrow), then secure it in place using a Type
Q screw. Test the steering by turning the wheel – if the steering doesn’t engage, try tightening the screws
in the silver washers, or loosen them if the wheels don’t move. The steering wheel may turn a small amount
both left and right before the columns begins to turn the wheels.
STAGE COMPLETE
Stage 76: Fitting the Dashboard and Front Frame
into the Body and Installing the Circuit Board
TYPE Q

AGORAMODELS LAMBORGHINI MIURA
15
XXX
Name
Bonnet inner bulkhead
Bonnet side crossbar
Bonnet side crossbar
Bonnet central crossbar
Type B screws x3
STAGE 77 PARTS LIST
With the circuit board in place,
you’ll start to connect up the
electronic wiring for the model.
You’ll also need the cockpit
assembly, which will be fixed in
place and its wires connected up.
The parts supplied with this stage
can be kept aside until they are
needed later in this Pack.
Stage 77: Connecting the Wiring and Fitting the
Cockpit into the Body
Bonnet inner bulkhead
Bonnet side crossbar
Bonnet central crossbar
Type B x3
Bonnet side crossbar

AGORAMODELS LAMBORGHINI MIURA
16
1 2
Take the indicator switch coming from the steering wheel column,
which has a black plug with a yellow pad. Pass it under the
crossmember of the frame (dashed line).
Insert the plug into connection 1 on the circuit board (arrow). We
recommend using tweezers to push the plug firmly into place – be
careful to align the plug correctly with the pins of the circuit board
connection so as not to bend them.
Connection
Number
Function Plug
Colour
Pad Print
Colour
Supplied in
Stage N°
1 Indicator switch Black Yellow 46
2 Horn switch Black Blue 46
3 Accelerator switch Black White 44
6 Engine switch Black 42
7Instrument panel LEDs White 7
8 Dashboard LED White Yellow 46
13 Brake switch Black Green 44
14 Left door switch White 5
15 Right door switch White Blue 52
16 Interior light White Red 49
CONNECTION SCHEME
In this stage you will begin to connect the cables to the circuit board of the model. The table above shows
a summary of the connections including the number of the connector on the circuit board in which it is
inserted, the function for which it is intended, the colour of the plug and the pad printing (if there is one),
as well as the number of the stage with which it was supplied.
Stage 77: Connecting the Wiring and Fitting the
Cockpit into the Body

AGORAMODELS LAMBORGHINI MIURA
17
5 6
Take the instrument panel LED wire, which is white with red/black
cables, and route it under the crossmember.
Plug the instrument panel LED into connection 7 (arrow).
3 4
Take the horn switch (black plug, blue panel) coming from the
steering wheel column and pass it under the crossmember in the
same way.
Plug the horn switch into connection 2 (arrow).
Stage 77: Connecting the Wiring and Fitting the
Cockpit into the Body

AGORAMODELS LAMBORGHINI MIURA
18
9 10
Retrieve the cockpit assembly and place it on your work surface. There
are two holes on the front for fixing it to the body (arrows).
At the rear of the cockpit, below the headrests, there are two more
holes for fixing (arrows).
7 8
Take the dashboard LED wire (white plug, yellow panel) and route it
under the crossmember.
Plug the dashboard LED into connection 8 (arrow).
Stage 77: Connecting the Wiring and Fitting the
Cockpit into the Body

AGORAMODELS LAMBORGHINI MIURA
19
13 14
Before pushing the front of the cockpit into position, ensure the wires
protruding from the pedal housing are flat against the cockpit wall
as shown (arrows). The connections are delicate – take care when
inserting the cockpit the wires don’t snag or bend out of place.
Push the front of the cockpit down until the holes highlighted in step
9 align with the connection points highlighted with the red arrows in
step 11.
11 12
Orient the body assembly on your work surface as shown and locate
the four connection points for fitting the cockpit (arrows).
Align the cockpit with the body as shown. Insert the holes below the
headrests highlighted in step 10 underneath cross frame firewall and
over the two connection points highlighted by the blue arrows in
step 11. Route the wires of the cockpit under the crossmember. If you
wish, you can disconnect the plugs in connectors 7 and 8 and reroute
the wires through the rectangular hole (circled) before pushing the
cockpit into place.
Stage 77: Connecting the Wiring and Fitting the
Cockpit into the Body

AGORAMODELS LAMBORGHINI MIURA
20
17 18
Use another Type A screw (supplied with Stage 76) to secure the
right-hand side of the cockpit in the same manner.
Take the plug of the accelerator switch (black plug, white panel).
15 16
Fix the cockpit in place at the rear using 2x Type B screws (supplied
with Stage 76).
Use a Type A screw (supplied with Stage 76) to secure the left-hand
side of the cockpit at the front. We recommend using the screwdriver
supplied with Stage 2. Press down carefully on the cockpit floor to
ensure the screw finds purchase with the hole underneath.
TYPE B
TYPE A
TYPE A
Stage 77: Connecting the Wiring and Fitting the
Cockpit into the Body
