STAGE 21: THE RIGHT LEG (III)
STAGE 22: THE RIGHT RIBS & THE LEG (II)
STAGE 23: THE RIGHT RIBS & THE LEG (III)
STAGE 24: THE RIGHT RIBS & THE LEG (IV)
STAGE 25: THE RIGHT RIBS &
THE RIGHT FEMUR (I)
STAGE 26: THE RIGHT RIBS &
THE RIGHT FEMUR (II)
STAGE 27: THE RIGHT RIBS &
THE RIGHT FEMUR (III)
STAGE 28: THE RIGHT RIBS &
THE RIGHT FEMUR (IV)

2PB
WARNING: Some parts are assembled using magnets. These magnets can cause serious injury if they are
swallowed. Keep away from children. If you suspect a magnet has been swallowed, seek medical help
straight away.
All parts belong to a kit. Collectors item for adults.
Not suitable for children under 14.
Some parts may have sharp edges, please handle them with care.
The installation of electronic parts must always be carried out by an adult. When replacing batteries, use
the same type of batteries.
Please ensure that the battery compartment is securely fastened before you use the model.
Used batteries should be recycled.
Please make sure to check with your local authority how batteries should be disposed of in your area.
Batteries can present a choking danger to small children and may cause serious harm if ingested. Do not
leave them lying around and keep any spare batteries locked away at all times.
Before you start...
!
To help you get the best out of building the Xenomorph, we’ve prepared a modellers checklist
with hints, tips and advice from our expert. The information below is aimed at making your
build as enjoyable and professional as possible right from the start.
Make sure you have good ventilation when using adhesives and to replace
caps firmly.
Always use the correct adhesives and always follow manufacturers guidance.
Apply glue sparingly and use a cocktail stick to apply so that you don’t use too
much nor apply the glue too heavily.
Work in a well lit area. Use an anglepoise lamp or similar on your work bench to ensure you
have good light whenever you’re at work.
Organise storage – stackable, labeled containers like old clean takeaway or ice-cream plastic
tubs with lids are perfect. Small parts which may not be needed until a later stage should be
kept in clear plastic and labeled bags.
Use masking tape to hold parts temporarily in place.
Only use the correct size screwdriver that fits the screw head firmly.
Cut parts from a sprue (framework) with side cutters or a craft knife. Side cutters tend to be
easiest.
Use a magnet to help find screws that have fallen on the floor.
Leave parts in the paper bags supplied until they are needed. You can write a note of the stage
and part on the paper bag too.
If a screw is tight, try turning a half turn forwards followed by a quarter turn backwards. Also, it
can sometimes help to temporarily fit a screw into its hole before assembling the parts.
But most of all, enjoy your build!

3PB
ASSEMBLY GUIDE
In this stage you will continue to assemble parts of the Xenomorph’s right leg.
STAGE 21: THE RIGHT
LEG (III)
21-1
21-2
21-3
21-4
PARTS SUPPLIED
Ref. Name Qty.
21-1 Right Tibia 1
21-2 Connectors 4
Ref. Name Qty.
21-3 Magnets 8
21-4 2.3x6mm screws 10*
*A spare screw is supplied in case of loss or damage.

4PB
STAGE 21: THE RIGHT LEG (III)
1
2
21-1
16-1
15-1
14-1
21-4
20-3
20-4
3
21-1
20-3
16-1
15-1
Take the Right Tibia assembly
20-3 which was worked on in
the last stage. Tibia part 21-1 is
joined to this using the previously
fitted Connector 20-4, as shown.
Secure in place with a 2.3x6mm
screw 21-4.
Next, take the Right Calf
assembly 14-1 which was
last worked on in stage 16
and remove the inner parts
15-1/16-1.
The Tibia assembly 15-1/16-1 is
now joined to the assembly 20-3/
21-1. There is a tab with a hole at
the end of part 15-1 (circled) which
fits over a peg on part 20-3 (arrow).

5PB
STAGE 21: THE RIGHT LEG (III)
4
5
21-2
21-4
21-4
21-2
21-2
21-4
21-4
21-2
21-1
20-3
15-1
16-1
Fit the four Connectors
21-2 which will hold the
assemblies 15-1/16-1
and 20-3/21-1 together.
Secure each Connector
21-2 in place with two
2.3x6mm screws 21-4.

6PB
6
7
21-3
21-3
21-3
14-1
14-1
15-1
20-3
21-1
16-1
Take the Outer Calf Skin 14-1 and
glue four Magnets 21-3 firmly into
the circular recesses as shown on
the left. It doesn’t matter which
way round the magnets are fitted.
Place the assembly 15-1/
16-1/20-3/21-1 over the
calf assembly 14-1.
STAGE 21: THE RIGHT LEG (III)

7PB
STAGE 21 IS COMPLETE
8
21-3
21-3
21-3
20-3
21-1
Further parts including a set of
magnets have been fitted to the
right leg.
Four magnets are now fitted into
the circular recesses in parts
20-3/21-1, as shown above.
When fitted correctly, they should
be attracted to the magnets
underneath on the Calf Skin 14-1.
When certain that the magnets are
correctly orientated, glue in place.
STAGE 21: THE RIGHT LEG (III)

8PB
Ref. Name Qty.
22-1 Calf Protector 1
22-2 Right Rib 1
Ref. Name Qty.
22-3 Pipe A1 1
22-4 2.3x6mm screws 4*
ASSEMBLY GUIDE
In this stage you will continue to work on the right ribs
and leg of the Xenomorph.
STAGE 22: THE RIGHT
RIBS & THE LEG (II)
22-1
22-3 22-4
22-2
PARTS SUPPLIED
*A spare screw is supplied in case of loss or damage.

9PB
STAGE 22: THE RIGHT RIBS & THE LEG (II)
1
2
3
22-2
22-3 (A1)
22-1
22-4
22-2
20-2
19-3
19-2
Take the rib support assembly
19-3 which was worked on in pack
3 - stage 20. Fit the raised screw
socket on Right Rib 22-2 into the
corresponding hole on rib support
19-3, as shown.
Turn the assembly over and
x Right Rib 22-2 in place
with a 2.3x6mm screw 22-4.
Put the assembly aside.
Next, take the Calf Protector 22-1
and the Pipe A1 22-3. The tabs
on the pipe are arranged so that
the pipe will only fit correctly one
way round. After test-fitting, apply
a little glue to the tabs and fix
firmly in place.

10 PB
STAGE 22: THE RIGHT RIBS & THE LEG (II)
STAGE 22 IS COMPLETE
4
22-4
4-6
22-4
22-1
ANOTHER RIB HAS BEEN CONNECTED
AS WELL AS FURTHER WORK ON THE
CALF PROTECTOR.
Take the Calf Protector 4-6, which was
assembled in pack 1 - stage 4, along with
Calf Protector 22-1. Align the holes at
one end of part 4-6 over the raised screw
sockets on part 22-1, as shown. Secure
the parts together using two 2.3x6mm
screws 22-4.

11 PB
ASSEMBLY GUIDE
In this stage you will continue to work on the right ribs and leg of the Xenomorph.
STAGE 23: THE RIGHT
RIBS & THE LEG (III)
23-1 23-2
23-3
23-5 23-6
23-4
PARTS SUPPLIED
Ref. Name Qty.
23-1 Right Rib 1
23-2 Right Rib 1
23-3 Pipe A2 4
Ref. Name Qty.
23-4 Ball Joint 1
23-5 2.3x6mm screws 11*
23-6 2.3x4mm screws 3*
*A spare screw of each type is supplied in case of loss or damage.

12 PB
STAGE 23: THE RIGHT RIBS & LEG (III)
12
3
23-6 23-6
23-2
20-2
19-3
14-1
15-1
20-3
21-1
16-1
23-1
23-2
Place the two Ribs 23-1
and 23-2 on the work
surface. Study the diagram
and note how a peg at
the end of 23-2 fits into
a socket in 23-1. Fix the
two parts together using a
2.3x4mm screw 23-6.
Now take the assembly
constructed in stage 21 and
separate the inner parts 15-1/
16-1/20-3/21-1 from the
outer skin 14-1.
Take the rib support assembly 19-3
which was worked on in the last stage.
Fit the raised screw socket on Rib 23-2
into the hole in support 19-3 and secure
in place with a 2.3x4mm screw 23-6.
Put the assembly to one side until it is
needed in the next stage.

13 PB
STAGE 23: THE RIGHT RIBS & THE LEG (III)
4
5
20-3
15-1
16-1
18-1
23-5
20-3
15-1
16-1
21-1
23-5
23-5
23-5
23-5
17-1
21-1
23-4
4-1
4-2
Take time to make sure that
all of the parts are correctly
aligned and fix firmly
together with ten 2.3x6mm
screws 23-5.
Next take the second tibia assembly
4-1/4-2/17-1/18-1 which was worked
on in pack 3 - stage 18. Fit the Ball Joint
23-4 into the slot at the end of part
4-1 and 18-1. Check the orientation to
ensure a good fit. This assembly is now
covered with the other half of the tibia
15-1/16-1/20-3/21-1. There are
raised screw sockets on the assembly
4-1 which fit into matching recesses on
assembly 16-1.

14 PB
6
7
20-3
22-1
20-3
4-6
17-1
21-1
14-1
15-1
16-1
4-4
14-1
STAGE 23: THE RIGHT RIBS & THE LEG (III)
Fit the outer skin 14-1
on top of the tibia
assembly, as shown.
The Outer Skin 4-4 will
also need to be fitted if
previously removed.
Turn over the right tibia assembly.
The calf protector assembly
4-6/22-1, which was prepared in
stage 22 is fitted into the recess on
the assembly 17-1/20-3, as shown.
There are four raised screw sockets
on the calf protector 4-6/22-1
which push-fit into corresponding
holes in 17-1/20-3. Note that the
protector is placed over the ridges
on the sides of skin parts 4-4 and
14-1. The skin assemblies 4-4/
14-1 and the calf protector
4-6/22-1 are only fitted temporarily
at present as they will need to be
removed again in a later stage.

15 PB
STAGE 23 IS COMPLETE
8
23-3 (A2)
4-4
MORE OF THE RIGHT LEG HAS
BEEN ASSEMBLED ALONG WITH
WORK ON THE RIB CAGE.
STAGE 23: THE RIGHT RIBS & THE LEG (III)
Turn the tibia assembly
over again as shown
on the right. Check the
fit of the tabs on Pipe
A2 23-3 in the slots in
the Calf Piece 4-4 and
secure in place with a
little glue.

16 PB
ASSEMBLY GUIDE
In this stage you will continue to work on the right ribs and
leg of the Xenomorph.
STAGE 24: THE RIGHT
RIBS & THE LEG (IV)
24-1
24-2
24-3
24-4
24-5
PARTS SUPPLIED
Ref. Name Qty.
24-1 Right Rib 1
24-2 Pipe A3 1
24-3 Pipe A4 1
Ref. Name Qty.
24-4 Pipe A5 1
24-5 2.3x6mm screws 2*
*A spare screw is supplied in case of loss or damage.

17 PB
STAGE 24: THE RIGHT RIBS & THE LEG (IV)
1
24-5
22-2
24-1
19-3
2
24-2 (A3)
4-4
Take the rib support assembly
19-3 from the last stage. Fit the
raised screw socket at one end of
Rib 24-1 into its corresponding
hole in support 19-3. Fix in place
with a 2.3x6mm screw 24-5.
Take the right leg
assembly which was
worked on in stage
23 along with Pipe A3
24-2. After test-fitting,
apply a little glue to the
tabs on Pipe A3 24-2
and firmly secure in
place on Skin 4-4.

18 PB
STAGE 24: THE RIGHT RIBS & THE LEG (IV)
STAGE 24 IS COMPLETE
4
3
24-3 (A4)
24-4 (A5)
4-4
4-4
ANOTHER RIB HAS BEEN
ADDED AND MORE PIPES
FITTED TO THE RIGHT LEG.
Repeat the previous step
to attach Pipe A4 24-3
in the position shown on
the Calf Skin 4-4.
Check the orientation of
Pipe A5 24-4 by test-
fitting and glue the pipe
in place.

19 PB
ASSEMBLY GUIDE
In this stage you will continue to work on the Xenomorph’s right ribs and start the
assembly of the right femur.
STAGE 25: THE RIGHT RIBS
& THE RIGHT FEMUR (I)
25-1 25-2
25-3
25-5 25-625-4
PARTS SUPPLIED
Ref. Name Qty.
25-1 Right Rib 1
25-2 Right Rib 1
25-3 Right Femur 1
Ref. Name Qty.
25-4 Connector 1
25-5 2.3x6mm screws (1 spare) 2
25-6 2.3x4mm screws (1 spare) 3

20 PB
STAGE 25: THE RIGHT RIBS & THE RIGHT FEMUR (I)
2
1
25-6
25-6
19-3
25-2
23-1
25-2
25-1
Rib parts 25-1 and 25-2
are joined together with a
2.3x4mm screw 25-6. Note
how a locating peg on Rib
25-2 fits into a raised hole
in Rib 25-1.
Take the rib support assembly 19-3,
which was worked on in the last stage
and fit the raised screw socket on Rib
25-2 into the corresponding hole in
part 19-3. Fix in place with a 2.3x4mm
screw 25-6.
