aidapt VR164 Manual

NB. This equipment must be installed
by a competent person.
VR164 Linton Commode
VR166 Linton Commode w/Footrests
VR167 Footrests (Pair)
Weight Limit: 190kg 30 stone)
UU Do not UU exceed the weight limit stated –
doing so could put the user at UU risk UU .
Linton Mobile Commode & Footrests
Fixing and Maintenance Instructions
1. Assembly
The commode is provided to you packed in cube form. Please examine all components for any visible
damage before use. If you see any damage or suspect a fault, please contact your supplier immediately.
In this case, please do not use your product as it may compromise the safety of the user.
The package (VR 64) contains the following components:
•The main frame with four brake castors attached
•White commode plastic aperture seat (attached to the main frame)
•Grey commode seat cover
•A pair of detachable arms
•Detachable back
•One pair of Footrests (VR 66 and VR 67 only)
Please read the following installation instructions carefully:
. Remove all contents from the box
.2 Place the assembled base on a level floor
.3 At the rear of the commode you will see two black threaded wheel nuts; undo the wheel nuts so
that the locking holes are clear
.4 Place the two back legs into the locating holes on the back edge of the commode frame
.5 Secure the back by turning the black lock nuts until you feel the nut biting against the back leg.
.6 Do no over tighten
1.7 Do not use tools as it is only necessary to have the back secured finger tight
.8 Place the two detachable arms into the four locating holes featured two each side of the
commode
09/ / 0
548

2. Footrests if supplied)
Footrests are supplied separately to the main commode. Please examine your footrests for any visible
damage before use. If you see any damage or suspect a fault, please contact your supplier immediately.
UUIn this case, please do not use your product as it may compromise your safety.
2. Remove the commode footrests from their packaging
2. You will see on each of the front legs of the commode main frame about
50 mm high from the castor 2 retaining lugs either side
2. Take the footrests and align the holes in the inverted ‘U’ section with the lugs and lower down into
place.
2. Rotate the footrests towards the commode so that they clip into place.
3. Composition
The frame is made from chromium-plated mild steel. You must not, under any circumstances, use any
abrasive cleaners or cleaners which attack chromium plating.
4. Use of the commode
When moving always lift the commode by placing you hands on the tubular metal frame beneath the blow
moulded seat.
•Do not allow children or unauthorised persons to play with or use the commode.
•Do not rock back and forth or sideways when using the commode as this will cause excessive stress
and possible damage and failure which may cause injury.
•Do not use the commode outside the home or on uneven surfaces (such as in the garden) as this
will cause stress to the legs and possible damage which may cause injury.
•Do not place fingers or foreign objects into any of the exposed tubular sections as this can lead to
serious injury.
•When operating the brake mechanism, do not stamp on the lever as this may cause damage to the
mechanism and possible failure.
5. Cleaning
Simply hose down/wash or pressure wash with a mild detergent solution, ensuring that all detergents are
washed off thoroughly. Wipe the commode thoroughly dry, paying particular attention to all joints and
abutments.
It is recommended that all joints, abutments and castors are then sprayed with a water dispersing agent
such as WD-40 after cleaning, this will give your Linton Commode greater longevity and avoid premature
rusting.

6. Height Adjustment
UUNB. Before attempting to adjust the height of your commode, always ensure that the commode
pail is removed.
To adjust the height of your Linton, carefully lay the commode on its side. Remove all the e-clips and
adjust all four legs equally to the desired height.
Re-insert the e-clips ensuring that each one passes through the frame and the correct hole in the
extension leg.
Return the commode to the upright position and make sure that all wheels are sitting evenly on the
floor. UU
Never extend the legs in a manner that the commode is slanting this will compromise the safety of
the user.
7. Commode Bucket
To remove the commode bucket, simply slide the bucket out from the chrome runners at the rear of the
commode. Cover the top of the bucket to avoid splashing, carefully dispose of the contents into a
proper sluice or WC. Never use an open drain, sink or basin. This could cause a serious health risk.
Clean out the residue with a suitable disinfectant and refit to the commode after use.
8. Reissue
If you reissue or are about to reissue this product, please thoroughly check all components for their
safety. This includes:
•PAT test for electrical items
•Tightness of all nuts/bolts/castors and other screw-in/bolt-in/push-in components
•Also check all upholstery for security, splits, etc.
If in any doubt, please do not issue or use, but immediately contact your supplier for service support.
8. Maintenance
Please make a safety check of the product at regular intervals or if you have any concerns.
