Airaid 302-370 User manual

Installation Instructions
302-370 702-466 SynthaMax Dry Media Filter - Black
Component Identication
2013-18 RAM 1500
2019 RAM 1500 Classic
V6-3.6L
For Part Numbers:
Full color instructions can be viewed on our web site at Airaid.com. If you need any assistance please call 1-800-498-6951 to speak with
a representative in our Customer Service Center before returning the product.
See Airaid.com for CARB status on each part for a specific vehicle
NOT LEGAL FOR SALE OR USE ON ANY POLLUTION
CONTROLLED MOTOR VEHICLE IN CALIFORNIA OR
STATES ADOPTING CALIFORNIA EMISSION PROCEDURES.
1. Turn o the ignition and disconnect the negative
battery cable.
NOTE: Disconnecting the negative battery cable
erases pre-programmed electronic memories. Write
down all memory settings before disconnecting the
negative battery cable. Some radios will require
an anti-theft code to be entered after the battery is
reconnected. The anti-theft code is typically supplied
with your owner’s manual. In the event your vehicles
anti-theft code cannot be recovered, contact an
authorized dealership to obtain your vehicles anti-
theft code.
TO START:
A
B
C
D
C
H
G
F
E
I
J
I
M
L
N
N
P
L
N
M
M
M
M
L
N
K
L
K
O
Q
R
S
Description Qty. Part # Description Qty. Part # Description Qty. Part #
A VENT; 1/2" BARB TO QUICK 1 82629
B HOSE CLAMP #6 MINI 1 08407
C HOSE CLAMP #52 2 08610
D HOSE; 3-1/4" ID X 2"L 1 08690
E HOSE; 1/2"ID X 12"L 1 087031
F VENT; STRT 1/2" HOSE, 1/4" 1 080022
G GROMMET; 1" OD, 1/2" ID, 1/2" 1 08064
HINTAKE TUBE 1 KIT27622TK
I HOSE CLAMP #56 2 08620
J HOSE; 3-1/2"ID X 2-1/2"L HUMP 1 08699
KEDGE TRIM (55") 1 102480
L BOLT; M6 X 1.00" 12MM, SS 6 07794
M WASHER, M6 SPLIT LOCK ZINC 6 1-3025
N WASHER; 6MM FLAT, SS 6 08269
O HEAT SHIELD 1 073173
P SCOOP 1 073174
Q ADAPTER; UNIVERSAL, 6",3.5" 1 21512-1
R HOSE CLAMP #104 1 08697
S AIR FILTER 1 702-466
2. Disconnect the Inlet air temperature sensor electrical
connection and loosen the hose clamp securing the
intake plenum to the throttle body.
3. Disconnect the crank case vent from the intake
plenum.
4. Loosen the hose clamp securing the intake hose to the
factory air box.
5. Lift up the intake plenum to dislodge it from the
mounting grommets and then remove the plenum from
the vehicle.
6. Lift the air box assembly o of the mounting studs
and then remove the air box from the vehicle.
NOTE: AIRAID recommends that customers do not
discard factory air intake.

Continued...
7. Install the fresh air intake scoop onto the heat shield
and secure with the provided hardware.
8. Cut the provided edge trim into two sections. One
section will be 29” long; the other section will be 23.5”
long.
9. Install the two sections of edge trim onto the heat
shield and fresh air intake scoop as shown. The 29”
section will be installed onto the heat shield and the
23.5” section will be installed onto the fresh air intake
scoop.
10. Remove one of the rubber mounting grommets from
the factory air box.
11. Install the factory rubber mounting grommet into the
AIRAID heat shield as shown.
12. Install the air lter adapter into the heat shield and
secure with the provided hardware.
13. Install the air lter onto the lter adapter and secure
with the provided hose clamp.
14. Remove the two factory air box mounting bracket
bolts shown.
NOTE: These bolts will be reused in the next step.
15. Set the heat shield into position on the factory air
box mounting bracket and then secure with the factory
bolts removed on step #14.
16. Install the provided coupling hose (08699) onto the
lter adapter and secure with the provided hose clamp.
17. Install the provided coupling hose (08690) onto the
throttle body and secure with the provided hose clamp.
18. Install the provided grommet into the intake tube.
19. Remove the inlet air temperature sensor from the
factory intake plenum.
20. Install the inlet air temperature sensor into the
grommet installed into the intake tube.
NOTE: Remove the factory sealing O-ring from the
sensor before installation.
21. Install the provided vent tting into the intake tube
as shown.

AIR-I30370
REV 9/19/18
See Airaid.com for CARB status on each part for a specific vehicle
NOT LEGAL FOR SALE OR USE ON ANY POLLUTION
CONTROLLED MOTOR VEHICLE IN CALIFORNIA OR
STATES ADOPTING CALIFORNIA EMISSION PROCEDURES.
Thank you for purchasing the Airaid Intake System. Contact Airaid @ [phone] 8:00 AM - 5:00 PM MST weekdays for questions regarding t or instructions that are
not clear to you. Your Airaid Intake System was carefully inspected and packaged. Check that no parts are missing, or were damaged during shipping. If any parts are missing,
contact Airaid. The air lter element is protected from direct exposure to water and debris; care should be taken not to drive through deep water.
WATER INGESTION IS THE DRIVERS RESPONSIBILITY! The air lter is reusable and should be cleaned periodically.
FILTER IDENTIFICATION
702-466 Airaid SynthaMax Dry Media - Black
Synthamax Air Filters do not require oil. Service
air lter as needed by cleaning with common
non-petroleum all-purpose household cleaner
and water. Simple Green®, Formula 409® or
equivalent works great. Apply cleaner to outside of
air lter and allow to soak. Then ush lter clean
from the inside out with a garden hose and repeat
steps if necessary. Do not apply high pressure
water or air to clean lter. Allow lter to air dry
and reinstall.
Airaid. 1455 Citrus St., P.O. Box 1329, Riverside, CA. 92502 1-800-498-6951 [email protected] www.airaid.com
For your Oiled media lter we oer the
Airaid Tune Up Kit!
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
26. Double check your work!
Make sure there is no foreign material in the intake path.
Make sure all clamps, hoses, bolts, and screws are tight.
Double check the hood clearance!
Reconnect the negative battery cable!
Continued...
22. Install the intake tube assembly into the coupler hose
at the lter adapter and then into the coupler hose at the
throttle body. Adjust the tube for best t and then secure
with the provided hose clamps.
23. Reconnect the inlet air temperature sensor electrical
connection.
24. Install the provided quick disconnect tting into
the provided crank case vent hose and secure with the
provided hose clamp.
25. Install the crank case vent hose assembly onto the
tting installed into the intake tube and then connect the
quick disconnect tting into the factory connector as
shown.
