Aiwa HS-TA183 User manual

S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
HS-TA183
• BASIC TAPE MECHANISM: 4ZM-2 P1NC • TYPE: YZ,YK,YVJ
S/M Code No. 09–982–243–6FP
STEREO RADIO CASSETTE PLAYER

ELECTRICAL MAIN PARTS LIST - 1
NOTE: The characters in the suffix column indicate the part usage.
KBNC ...................XX........................................G.............
VJ1B ...................XX.........................................H............
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-610-062-210 WIRE,B0-6-2 ABCDEFGHIJKLMNOPQRST
87-612-042-210 WIRE B2-4-2 ABCDEFGHIJKLMNOPQRST
C 5 87-010-502-040 CAP ELECT GAS 100/4 ABCDEFGHIJKLMNOPQRST
C 6 87-010-502-040 CAP ELECT GAS 100/4 ABCDEFGHIJKLMNOPQRST
C 1 87-A10-409-010 CAP,CER 1500P-25 K SR ABCDEFGHIJKLMNOPQRST
C 9 87-A10-409-010 CAP,CER 1500P-25 K SR ABCDEFGHIJKLMNOPQRST
C 2 87-A10-409-010 CAP,CER 1500P-25 K SR ABCDEFGHIJKLMNOPQRST
C 8 87-A10-410-010 CAP,CER 0.015-25 K SR ABCDEFGHIJKLMNOPQRST
C 7 87-A10-410-010 CAP,CER 0.015-25 K SR ABCDEFGHIJKLMNOPQRST
C 4 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFGHIJKLMNOPQRST
C 3 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFGHIJKLMNOPQRST
C 11 87-010-491-040 CAP,E 0.22-50 GAS ABCDEFGHIJKLMNOPQRST
C 12 87-010-491-040 CAP,E 0.22-50 GAS ABCDEFGHIJKLMNOPQRST
C 18 87-010-498-040 CAP,E 10-16 GAS ABCD.FGH.J.L.N.PQ.S.
C 15 87-010-503-010 CAP,E 220-4 GAS ABCDEFGHIJKLMNOPQRST
C 18 87-015-681-040 E/CAP 10-16 ....E...I.K.M.O..R.T
C 14 87-015-681-040 E/CAP 10-16 ABCDEFGHIJKLMNOPQRST
C 16 87-015-681-040 E/CAP 10-16 ABCDEFGHIJKLMNOPQRST
C 10 87-A10-409-010 CAP,CER 1500P-25 K SR ABCDEFGHIJKLMNOPQRST
C 19 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFGHIJKLMNOPQRST
C 13 87-A10-512-010 CAP,SC 0.01-25 M SR ...DEF.HIJKLMNOP.RST
C 17 87-A10-512-010 CAP,SC 0.01-25 M SR ABCDEFGHIJKLMNOPQRST
C 22 87-010-490-040 CAP, ELECT 0.1-50 ABCDEFGHIJKLMNOPQRST
C 20 87-010-494-040 CAP,E 1-50 GAS ABCDEFGHIJKLMNOPQRST
C 21 87-010-501-040 E/CAP GAS 47-4 ABCDEFGHIJKLMNOPQRST
C 30 87-A10-512-010 CAP,SC 0.01-25 M SR ABCDEFGHIJKLMNOPQRST
IC 1 87-A20-461-040 IC,MM1336DF ABCDEFGHIJKLMNOPQRST
J 1 85-HRL-623-010 JACK,3.5 ST BLK ABCDEFGHIJKLMNOPQRST
J 2 87-A60-122-010 JACK,DC 3.8 ABCDEFGHIJKLMNOPQRST
L 1 87-A50-167-010 COIL,RF CHOKE3.0UH ABCDEFGHIJKLMNOPQRST
Q 2 87-026-287-080 TR,DTC143ES ABCDEFGHIJKLMNOPQRST
Q 1 89-110-484-080 TR,2SA1048Y ABCDEFGHIJKLMNOPQRST
R 17 87-022-657-080 RES,K34G 0.68 ABCDEFGHIJKLMNOPQRST
SFR 1 87-024-197-010 SEMI-FIXED RESISTOR, 1K ABCDEFGHIJKLMNOPQRST
SW 3 87-A90-050-010 SW, SL 2-2-2 NS (BLK) ABCDEFGHIJKLMNOPQRST
SW 1 87-A90-133-010 SW LEAF LSA1120JAU ABCDEFGHIJKLMNOPQRST
SW 2 87-A90-216-010 SW SL 2-2-3 SK230 ABCDEFGHIJKLMNOPQRST
TH 1 87-026-256-090 THERMISTOR, HT-100 ABCDEFGHIJKLMNOPQRST
VR 1 83-HRC-609-010 VOL 20KAX2 ABCDEFGHIJKLMNOPQRST
C 502 87-010-490-040 CAP, ELECT 0.1-50 ABC...G.........Q...
C 501 87-010-498-040 CAP,E 10-16 GAS ABC...G.........Q...
C 503 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFGHIJKLMNOPQRST
SW 501 87-036-145-010 C-SW,SLIDE 1-1-3 ABC...G.........Q...
BPF 101 87-A90-336-010 FLTR,GFEB4 .......H............
BPF 101 87-A90-749-010 FLTR,GFMB5 ABCDEFG.IJKLMNOPQRST
C 107 87-010-491-040 CAP,E 0.22-50 GAS ABCDEFGHIJKLMNOPQRST
C 109 87-010-494-040 CAP,E 1-50 GAS ABCDEFGHIJKLMNOPQRST
C 108 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFGHIJKLMNOPQRST
C 105 87-A10-512-010 CAP,SC 0.01-25 M SR ABCDEFGHIJKLMNOPQRST
C 115 87-010-490-040 CAP, ELECT 0.1-50 ABCDEFGHIJKLMNOPQRST
C 114 87-010-490-040 CAP, ELECT 0.1-50 ABCDEFGHIJKLMNOPQRST
C 118 87-010-500-040 CAPE 33-4 ABCDEFGHIJKLMNOPQRST
C 116 87-010-503-010 CAP,E 220-4 GAS ABCDEFGHIJKLMNOPQRST
C 110 87-015-691-040 CAP,E0.1-50 SRA ABCDEFGHIJKLMNOPQRST
C 111 87-015-691-040 CAP,E0.1-50 SRA ABCDEFGHIJKLMNOPQRST
C 117 87-A10-411-010 CAP,CER 0.047-16 K SR ABCDEFGHIJKLMNOPQRST
C 119 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFGHIJKLMNOPQRST
C 120 87-015-694-040 E/CAP 0.47-50 ABCDEFGHIJKLMNOPQRST
CF 102 87-A90-812-010 FLTR,KIT ABCDEFGHIJKLMNOPQRST
CF 101 87-A90-840-010 FLTR,AM IF PFS455A6 ABCDEFGHIJKLMNOPQRST
IC 101 87-A20-851-040 C-IC,TA2111F ....E...I.K.M.O..R.T
L 2 87-005-730-080 COIL,10UH J SP02 ABCDEFGHIJKLMNOPQRST
L 104 87-A50-187-010 COIL,AM OSC270UH ABCDEFGHIJKLMNOPQRST
L 105 87-A90-425-010 IFT,MW(7L)-455 ABCDEFGHIJKLMNOPQRST
L 102 87-HRL-605-010 COIL,RF FM EX ABCDEFG.IJKLMNOPQRST
L 101 87-HRL-610-010 BAR-ANT,MWS1 ABCDEFGHIJKLMNOPQRST
L 102 87-HRM-605-010 COIL,RF FM V .......H............
L 103 87-HRM-606-010 COIL,OSC FM V .......H............
L 103 88-HRJ-604-010 COIL,OSC FM ABCDEFG.IJKLMNOPQRST
VC 101 87-011-246-010 TUN-CAP,7.5-20P ............MN..Q...
VC 101 87-A90-097-010 TUN-CAP,20-160 16X16 ABCDEFG.IJKL..OP.RST
VC 101 87-A90-415-010 TUN-CAP,40P-160P 16X .......H............
C 403 87-012-142-080 CAP, S 0.33-16 ABCDEFGHIJKLMNOPQRST
C 404 87-012-142-080 CAP, S 0.33-16 ABCDEFGHIJKLMNOPQRST
SW 401 87-036-124-080 C-SLIDE SWITCH 1-2-2 ABCDEFGHIJKLMNOPQRST
LED 1 87-017-827-070 C-LED,SEC 1201C RED ....E...I.K...O..R.T
LED 1 87-A40-321-080 C-LED,LT1D40A RED ............MN..Q...

ELECTRICAL MAIN PARTS LIST - 2
NOTE: The characters in the suffix column indicate the part usage.
Z1BC ...................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-610-062-210 WIRE,B0-6-2 ABCDEFG.............
87-612-042-210 WIRE B2-4-2 ABCDEFG.............
C 5 87-010-502-040 CAP ELECT GAS 100/4 ABCDEFG.............
C 6 87-010-502-040 CAP ELECT GAS 100/4 ABCDEFG.............
C 9 87-A10-409-010 CAP,CER 1500P-25 K SR ABCDEFG.............
C 2 87-A10-409-010 CAP,CER 1500P-25 K SR ABCDEFG.............
C 1 87-A10-409-010 CAP,CER 1500P-25 K SR ABCDEFG.............
C 8 87-A10-410-010 CAP,CER 0.015-25 K SR ABCDEFG.............
C 7 87-A10-410-010 CAP,CER 0.015-25 K SR ABCDEFG.............
C 3 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFG.............
C 4 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFG.............
C 12 87-010-491-040 CAP,E 0.22-50 GAS ABCDEFG.............
C 11 87-010-491-040 CAP,E 0.22-50 GAS ABCDEFG.............
C 18 87-010-498-040 CAP,E 10-16 GAS ABCDEFG.............
C 15 87-010-503-010 CAP,E 220-4 GAS ABCDEFG.............
C 14 87-015-681-040 E/CAP 10-16 ABCDEFG.............
C 16 87-015-681-040 E/CAP 10-16 ABCDEFG.............
C 10 87-A10-409-010 CAP,CER 1500P-25 K SR ABCDEFG.............
C 19 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFG.............
C 13 87-A10-512-010 CAP,SC 0.01-25 M SR AB..................
C 17 87-A10-512-010 CAP,SC 0.01-25 M SR ABCDEFG.............
C 22 87-010-490-040 CAP, ELECT 0.1-50 ABCDEFG.............
C 20 87-010-494-040 CAP,E 1-50 GAS ABCDEFG.............
C 21 87-010-501-040 E/CAP GAS 47-4 ABCDEFG.............
C 30 87-A10-512-010 CAP,SC 0.01-25 M SR ABCDEFG.............
IC 1 87-A20-461-040 IC,MM1336DF ABCDEFG.............
J 1 85-HRL-623-010 JACK,3.5 ST BLK ABCDEFG.............
J 2 87-A60-122-010 JACK,DC 3.8 ABCDEFG.............
L 1 87-A50-167-010 COIL,RF CHOKE3.0UH ABCDEFG.............
Q 2 87-026-287-080 TR,DTC143ES ABCDEFG.............
Q 1 89-110-484-080 TR,2SA1048Y ABCDEFG.............
R 17 87-022-657-080 RES,K34G 0.68 ABCDEFG.............
SFR 1 87-024-197-010 SEMI-FIXED RESISTOR, 1K ABCDEFG.............
SW 3 87-A90-050-010 SW, SL 2-2-2 NS (BLK) ABCDEFG.............
SW 1 87-A90-133-010 SW LEAF LSA1120JAU ABCDEFG.............
SW 2 87-A90-216-010 SW SL 2-2-3 SK230 ABCDEFG.............
TH 1 87-026-256-090 THERMISTOR, HT-100 ABCDEFG.............
VR 1 83-HRC-609-010 VOL 20KAX2 ABCDEFG.............
C 502 87-010-490-040 CAP, ELECT 0.1-50 ..CDEFG.............
C 501 87-010-498-040 CAP,E 10-16 GAS ..CDEFG.............
C 503 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFG.............
SW 501 87-036-145-010 C-SW,SLIDE 1-1-3 ..CDEFG.............
BPF 101 87-A90-749-010 FLTR,GFMB5 ABCDEFG.............
C 107 87-010-491-040 CAP,E 0.22-50 GAS ABCDEFG.............
C 109 87-010-494-040 CAP,E 1-50 GAS ABCDEFG.............
C 108 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFG.............
C 105 87-A10-512-010 CAP,SC 0.01-25 M SR ABCDEFG.............
C 103 88-254-232-010 CAP CERA 27P NPO AB..................
C 114 87-010-490-040 CAP, ELECT 0.1-50 ABCDEFG.............
C 115 87-010-490-040 CAP, ELECT 0.1-50 ABCDEFG.............
C 118 87-010-500-040 CAPE 33-4 ABCDEFG.............
C 116 87-010-503-010 CAP,E 220-4 GAS ABCDEFG.............
C 111 87-015-691-040 CAP,E0.1-50 SRA ABCDEFG.............
C 110 87-015-691-040 CAP,E0.1-50 SRA ABCDEFG.............
C 117 87-A10-411-010 CAP,CER 0.047-16 K SR ABCDEFG.............
C 119 87-A10-509-010 CAP,SC 1000P-25 K SR ABCDEFG.............
C 120 87-015-694-040 E/CAP 0.47-50 ABCDEFG.............
CF 102 87-A90-812-010 FLTR,KIT ABCDEFG.............
CF 101 87-A90-840-010 FLTR,AM IF PFS455A6 ABCDEFG.............
L 2 87-005-730-080 COIL,10UH J SP02 ABCDEFG.............
L 104 87-A50-187-010 COIL,AM OSC270UH ABCDEFG.............
L 105 87-A90-425-010 IFT,MW(7L)-455 ABCDEFG.............
L 102 87-HRL-605-010 COIL,RF FM EX ABCDEFG.............
L 101 87-HRL-610-010 BAR-ANT,MWS1 ABCDEFG.............
L 103 88-HRJ-604-010 COIL,OSC FM ABCDEFG.............
VC 101 87-011-246-010 TUN-CAP,7.5-20P ......G.............
VC 101 87-A90-097-010 TUN-CAP,20-160 16X16 ABCDEF..............
C 404 87-012-142-080 CAP, S 0.33-16 ABCDEFG.............
C 403 87-012-142-080 CAP, S 0.33-16 ABCDEFG.............
SW 401 87-036-124-080 C-SLIDE SWITCH 1-2-2 ABCDEFG.............
LED 1 87-A40-321-080 C-LED,LT1D40A RED ......G.............

MECHANICAL PARTS LIST - 1
NOTE: The characters in the suffix column indicate the part usage.
KBNC ...................XX........................................G.............
VJ1B ...................XX.........................................H............
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
86-HRM-005-110 WINDOW,TUN ABCDEFGHIJKLMNOPQRST
86-HRM-009-110 POINTER,TUN ABCDEFGHIJKLMNOPQRST
87-HRL-005-010 LID,BAT ...DEFGHIJ....OP.RS.
87-HRL-024-010 CABI,REAR YZC ......G.............
87-HRL-035-010 CABI,REAR ...DEF.HIJ....OP..S.
87-HRR-002-110 PANEL,SBASS B ............MN..Q...
87-HRR-004-110 PLATE,IND B ............MN..Q...
87-HRR-020-010 FRAME,CENTRE GRAY ...DEFGHIJ....OP.RS.
87-HRR-034-010 LID,CASS SIL ............MN......
87-HRR-035-010 CABI,REAR SIL ..........KLMN......
87-HRR-036-010 FRAME,CENTRE J034 A.........KLMN..Q..T
87-HRR-037-010 LID,BATT SIL A.........KLMN..Q..T
87-HRR-041-010 LID,CASS YZ SIL ................Q...
88-HRL-001-010 LID,CASS YU ...D................
88-HRL-002-010 PANEL,SBASS ABCDEFGHIJKL..OP.RST
88-HRL-004-010 LID,CASS YZ ......G.............
88-HRL-005-010 LID,CASS YJ ....EF..IJ....OP.RS.
88-HRL-006-010 LID,CASS YV .......H............
88-HRL-008-010 LID,CASS YJ SIL ..........KL.......T
88-HRL-017-010 LID,CASS YZ SIL A...................
88-HRL-018-010 LID,CASS YZ MTLV .B..................
88-HRL-019-010 LID,CASS YZ MTLG ..C.................
88-HRL-024-010 CABI,REAR YZ SIL A...............Q...
88-HRL-025-010 CABI,REAR YZ MTLV .B..................
88-HRL-026-010 CABI,REAR YZ MTLG ..C.................
88-HRL-028-010 LID,BATT MTLV .B..................
88-HRL-030-010 LID,BATT MTLG ..C.................
88-HRL-034-010 FRAME,CENTRE GRE ..C.................
88-HRL-035-010 FRAME,CENTRE VIO .B..................
88-HRL-041-010 CABI,REAR YJF .................R..
88-HRL-042-010 CABI,REAR YJF SIL ...................T
86-HRM-006-010 KNOB,RTRY TUN ABCDEFGHIJKLMNOPQRST
87-HRL-014-010 KNOB,SL EGS ......G.............
87-HRR-003-210 KNOB,SL SBASS B .............N..Q...
87-HRR-003-210 KNOB,SL SBASS B ............M.......
88-HRL-003-010 KNOB,SL SBASS ABCDEFGHIJKL..OP.RST
88-HRL-031-010 KNOB,SL EGS SIL A...............Q...
88-HRL-032-010 KNOB,SL EGS MTLV .B..................
88-HRL-033-010 KNOB,SL EGS MTLG ..C.................
87-HRR-038-010 LBL,SPEC YHC .............N......
87-HRR-042-010 LBL,SPEC YZ ................Q...
88-HRL-011-010 LBL,SPEC YU ...D................
88-HRL-012-010 LBL,SPEC YZ ABC...G.............
88-HRL-013-010 LBL,SPEC YJ ..................S.
88-HRL-014-010 LBL,SPEC YV .......H............
88-HRL-015-010 LBL,SPEC YL .....F...J.L...P....
87-067-691-010 SCREW VT+1.7-6 ABCDEFGHIJKLMNOPQRST
87-067-732-010 TAPPING SCREW, VT1.4-3 ABCDEFGHIJKLMNOPQRST
87-B10-044-010 V+1.7-6.5 ABCDEFGHIJKLMNOPQRST
81-HK9-208-210 SPR-P,CASS A ABCDEFGHIJKLMNOPQRST
86-HRF-201-010 SH LED ............MN..Q...
86-HRM-202-010 BAT-CONTACT,(+) ABCDEFGHIJKLMNOPQRST
86-HRM-203-010 BAT-CONTACT,(-) ABCDEFGHIJKLMNOPQRST
86-HRM-205-010 SPR-T,CLICK ABCDEFGHIJKLMNOPQRST
87-HRM-201-010 PLATE,HEAD GRAY ...DEFGHIJ....OP.RS.
87-HRR-206-010 PLATE,HEAD J034 A.........KLMN..Q..T
88-HKB-204-010 PLATE,HEAD J266G ..C.................
88-HKB-205-010 PLATE,HEAD J240B .B..................

MECHANICAL PARTS LIST - 2
NOTE: The characters in the suffix column indicate the part usage.
Z1BC ...................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
86-HRM-005-110 WINDOW,TUN ABCDEFG.............
86-HRM-009-110 POINTER,TUN ABCDEFG.............
87-HRL-005-010 LID,BAT ..C.................
87-HRL-024-010 CABI,REAR YZC ..C.................
87-HRR-002-110 PANEL,SBASS B ......G.............
87-HRR-004-110 PLATE,IND B ......G.............
87-HRR-020-010 FRAME,CENTRE GRAY A.C.................
87-HRR-036-010 FRAME,CENTRE J034 ...D..G.............
87-HRR-037-010 LID,BATT SIL ...D..G.............
87-HRR-041-010 LID,CASS YZ SIL ......G.............
88-HRL-002-010 PANEL,SBASS ABCDEF..............
88-HRL-004-010 LID,CASS YZ ..C.................
88-HRL-010-010 LID,CASS YJ LGRE A...................
88-HRL-016-010 LID,CASS YJ MTLG .B..................
88-HRL-017-010 LID,CASS YZ SIL ...D................
88-HRL-018-010 LID,CASS YZ MTLV ....E...............
88-HRL-019-010 LID,CASS YZ MTLG .....F..............
88-HRL-022-010 CABI,REAR YJ LGRE A...................
88-HRL-023-010 CABI,REAR YJ MTLG .B..................
88-HRL-024-010 CABI,REAR YZ SIL ...D..G.............
88-HRL-025-010 CABI,REAR YZ MTLV ....E...............
88-HRL-026-010 CABI,REAR YZ MTLG .....F..............
88-HRL-028-010 LID,BATT MTLV ....E...............
88-HRL-029-010 LID,BATT LGRE A...................
88-HRL-030-010 LID,BATT MTLG .B...F..............
88-HRL-034-010 FRAME,CENTRE GRE .B...F..............
88-HRL-035-010 FRAME,CENTRE VIO ....E...............
86-HRM-006-010 KNOB,RTRY TUN ABCDEFG.............
87-HRL-014-010 KNOB,SL EGS ..C.................
87-HRR-003-210 KNOB,SL SBASS B ......G.............
88-HRL-003-010 KNOB,SL SBASS ABCDEF..............
88-HRL-031-010 KNOB,SL EGS SIL ...D..G.............
88-HRL-032-010 KNOB,SL EGS MTLV ....E...............
88-HRL-033-010 KNOB,SL EGS MTLG .....F..............
87-HRR-042-010 LBL,SPEC YZ ......G.............
88-HRL-012-010 LBL,SPEC YZ ..CDEF..............
88-HRL-013-010 LBL,SPEC YJ AB..................
87-067-691-010 SCREW VT+1.7-6 ABCDEFG.............
87-067-732-010 TAPPING SCREW, VT1.4-3 ABCDEFG.............
87-B10-044-010 V+1.7-6.5 ABCDEFG.............
81-HK9-208-210 SPR-P,CASS A ABCDEFG.............
86-HRF-201-010 SH LED ......G.............
86-HRM-202-010 BAT-CONTACT,(+) ABCDEFG.............
86-HRM-203-010 BAT-CONTACT,(-) ABCDEFG.............
86-HRM-205-010 SPR-T,CLICK ABCDEFG.............
87-HRM-201-010 PLATE,HEAD GRAY A.C.................
87-HRR-206-010 PLATE,HEAD J034 ...D..G.............
88-HKB-204-010 PLATE,HEAD J266G .B...F..............
88-HKB-205-010 PLATE,HEAD J240B ....E...............

NOTE: The characters in the suffix column indicate the part usage.
KBNC ...................XX........................................G.............
VJ1B ...................XX.........................................H............
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-B40-064-010 LBL,L ALCO ...........L.N......
87-B40-186-010 LBL,COLOR M METAL GRN ..C.................
87-B40-188-010 LBL,COLOR M METAL VLT .B..................
87-B40-193-010 LBL,OUTER METAL GRN ..C.................
87-B40-195-010 LBL,OUTER METAL VLT .B..................
88-HRL-852-010 CTN,OUTER WYUBBNC ...D................
88-HRL-853-010 CTN,INNER WYUBBNC ...D................
88-HRL-856-010 CTN,PRINTED YKBNC ......G.............
88-HRL-857-010 CTN,INNER YZBNC ......G.........Q...
88-HRL-858-010 CTN,OUTER YZBNC ....................
88-HRL-862-010 CTN,PRINTED YL1BNC .........J..........
88-HRL-863-010 CTN,PRINTED 180YH1SNC .............N......
88-HRL-864-010 CTN,PRINTED YJ1BNC ..................S.
88-HRL-865-010 CTN,INNER YJ1BNC .........J.L.N....S.
88-HRL-866-010 CTN,OUTER YJ1BNC ....................
88-HRL-868-010 CTN,OUTER YL1BNC ....................
88-HRL-869-010 CTN,PRINTED YVJ1BNC .......H............
88-HRL-870-010 CTN,INNER YVJ1BNC .......H............
88-HRL-871-010 CTN,OUTER YVJ1BNC ....................
88-HRL-872-010 CTN,PRINTED YZ1BNC ABC.................
88-HRL-873-010 CTN,INNER YZ1BNC ABC.................
88-HRL-874-010 CTN,OUTER YZ1BNC ....................
88-HRL-875-010 CTN,OUTER YH1SNC ....................
88-HRL-877-010 CTN,PRINTED YH1SNC ...........L........
88-HRL-878-010 CTN,PRINTED 180YZSNC ................Q...
88-HRL-883-010 CTN,PRINTED YJ1BNF .................R.T
88-HRM-858-010 CTN,INNER YL1BBNC .....F.........P....
88-HRM-859-010 CTN,OUTER YL1BBNC .....F.........P....
87-056-177-010 LIST,FACILITY-A3 ABC...GH..KLMN..QRST
88-HRL-901-010 IB,YU (ESF)-C ...D................
88-HRL-903-010 IB,YL (ESP)-C .....F...J.....P....
88-HRL-904-010 IB,YJ (ESC)-C ...........L......S.
88-HRL-905-010 IB,Y (EGFSID)-C ......G.............
88-HRL-906-010 IB,YV (ERPOHCZ)-C .......H............
88-HRL-907-010 IB,YJ (ESC) TA180-C .............N......
88-HRL-909-010 IB,YZF (EF)-C ABC.................
88-HRL-910-010 IB,Y (EGFSI) TA180-C ................Q...
88-HRL-911-010 IB,Y (EDPOHCZ)TA180-C ................Q...
88-HRL-912-010 IB,YL (ESP)-I ....E...I.....O.....
88-HRL-913-010 IB,YJ (ESC)-I ..........K......R.T
88-HRL-916-010 IB,YJ (ESC) TA180-I ............M.......
84-447-019-310 CLIP,BELT ABCDEFGHIJKLMNOPQRST
87-B30-080-010 HEADPHONE,HP-M009(F) ...D..G.......OPQ...
87-B30-145-010 HEADPHONE,HP-M029(T) ABC.EF.HIJKLMN...RST
IC 101 87-A20-851-040 C-IC,TA2111F ABCD.FGH.J.L.N.PQ.S.
LED 1 87-017-827-070 C-LED,SEC 1201C RED ABCD.FGH.J.L...P..S.
ACCESSORIES / PACKAGE LIST - 1

ACCESSORIES / PACKAGE LIST - 2
NOTE: The characters in the suffix column indicate the part usage.
Z1BC ...................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-B40-186-010 LBL,COLOR M METAL GRN .B...F..............
87-B40-187-010 LBL,COLOR M LIGHT GRN A...................
87-B40-188-010 LBL,COLOR M METAL VLT ....E...............
87-B40-193-010 LBL,OUTER METAL GRN .B...F..............
87-B40-194-010 LBL,OUTER LIGHT GRN A...................
87-B40-195-010 LBL,OUTER METAL VLT ....E...............
88-HRL-864-010 CTN,PRINTED YJ1BNC AB..................
88-HRL-865-010 CTN,INNER YJ1BNC AB..................
88-HRL-866-010 CTN,OUTER YJ1BNC ....................
88-HRL-872-010 CTN,PRINTED YZ1BNC ..CDEF..............
88-HRL-873-010 CTN,INNER YZ1BNC ..CDEF..............
88-HRL-874-010 CTN,OUTER YZ1BNC ....................
88-HRL-879-010 BD,PRINTED 180YZBSNC ......G.............
88-HRL-886-010 COVER,TOP VERTICAL ......G.............
88-HRL-887-010 COVER,BOT VERTICAL ......G.............
88-HRM-862-010 CTN,INNER YZBBNC ......G.............
88-HRM-863-010 CTN,OUTER YZBBNC ......G.............
87-056-177-010 LIST,FACILITY-A3 ABCDEFG.............
88-HRL-904-010 IB,YJ (ESC)-C AB..................
88-HRL-905-010 IB,Y (EGFSID)-C ..CDEF..............
88-HRL-908-010 IB,Y (EDPOHCZ)-C ..CDEF..............
88-HRL-910-010 IB,Y (EGFSI) TA180-C ......G.............
88-HRL-911-010 IB,Y (EDPOHCZ)TA180-C ......G.............
84-447-019-310 CLIP,BELT ABCDEFG.............
87-B30-080-010 HEADPHONE,HP-M009(F) ......G.............
87-B30-145-010 HEADPHONE,HP-M029(T) ABCDEF..............
IC 101 87-A20-851-040 C-IC,TA2111F ABCDEFG.............
LED 1 87-017-827-070 C-LED,SEC 1201C RED ABCDEF..............

X:23 W:95
Y:8.7 H:5.1
Helvetica 12 No track
14.4 100%
Left align
SCHEMATIC DIAGRAM _1 (MAIN : EZ)

PrintedinSingapore
Tokyo Japan
4
9630472
