S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

TP-S5

• TYPE:

S/M Code No. 09–992–326–40A

CASSETTE RECORDER

HJB,HJW(207)HJB,HJW(207)

D(S5)

YUBSC,YSC(530)

• BASIC TAPE MECHANISM:TN-9XR-107

TP-VS530

MODEL CODE:8ZHT7-0137(S)

SCHEMATIC DIAGRAM _1

ELECTRICAL MAIN PARTS LIST - 1 (TP-S5)

NOTE: The characters in the suffix column indicate the part usage.

S ......................OO..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

* 87-A91-158-010 SPKR,DIA 50 4OHM 1.0W A...................

C 105 87-010-184-080 0E CHIP CAPACITOR 3300P(K) A...................

C 104 87-010-186-080 0E CAP,CHIP 4700P A...................

C 109 87-015-674-010 0E CAP 22U-6.3V A...................

C 101 87-015-676-010 0E CAP,E 47-6.3 7L A...................

C 108 87-015-677-010 0E ELECTROLYTIC CAPACITOR, 100U 6 A...................

C 107 87-015-681-010 0E ELECTROLYTIC CAPACITOR, SRA16V A...................

C 106 87-015-695-010 0E CAP,E 1-50 7L A...................

C 103 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 102 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 110 87-010-186-080 0E CAP,CHIP 4700P A...................

C 119 87-010-187-080 0E CAP CHIP S5600P A...................

C 116 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 115 87-015-675-010 0E ELECTROLYTIC CAPACITOR, 6.3V-3 A...................

C 111 87-015-698-010 0E ELECTROLYTIC SRA 50V-4.7U A...................

C 114 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 113 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 118 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 155 87-015-676-010 0E CAP,E 47-6.3 7L A...................

C 153 87-015-908-010 0E CAP, 220-4V A...................

C 154 87-015-908-010 0E CAP, 220-4V A...................

C 152 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 151 87-A10-264-080 0E C-CAP,S 0.1-16ZF A...................

C 182 87-015-676-010 0E CAP,E 47-6.3 7L A...................

C 181 87-015-695-010 0E CAP,E 1-50 7L A...................

C 183 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 201 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 403 87-016-491-080 0E C-CAP,S 0.22-16 FZ A...................

C 402 87-A10-264-080 0E C-CAP,S 0.1-16ZF A...................

C 401 87-A10-264-080 0E C-CAP,S 0.1-16ZF A...................

D 101 87-A40-529-010 1A DIODE,1GWJ42 A...................

J 101 84-TM1-630-010 1A JACK,3.5 HSJ1493-05 A...................

J 103 84-TM1-630-010 1A JACK,3.5 HSJ1493-05 A...................

J 102 87-A60-319-010 0E JACK,DC DIA 2.75 A...................

SFR 202 87-A90-527-010 SFR,5K H VZ066L3 A...................

SW 102 87-031-816-010 1A SLIDE SWITCH A...................

SW 101 87-A90-305-010 SW,SL 2-2-2 (NC) A...................

SW 181 87-031-816-010 1A SLIDE SWITCH A...................

TH 202 87-A90-307-080 C-THMS,K39G220 A...................

VR 101 87-A90-314-010 VR,RTRY 10K H A...................

VR 201 87-A90-308-010 VR,RTRY 3KB XV81 A...................

C 301 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 303 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 302 87-016-462-080 0E C-CAP,S 1-16 F A...................

C 304 87-016-462-080 0E C-CAP,S 1-16 F A...................

* 82-TP3-609-010 1C ECM A...................

D 151 87-020-027-080 0E CHIP-DIODE 1SS184 A...................

D 305 87-017-827-070 0E C-LED,SEC 1201C RED A...................

D 304 87-017-827-070 0E C-LED,SEC 1201C RED A...................

D 301 87-017-828-070 0E C-LED,SEL 1401C GRN A...................

D 302 87-017-829-070 0E C-LED,SEC 1901C ORN A...................

D 401 87-020-339-080 0E CHIP DIODE,1SS226 A...................

IC 101 87-A20-399-010 1F IC,LA4168M A...................

IC 301 87-017-643-080 1B IC,MM1206XF A...................

Q 102 89-333-266-080 0E CHIP TR,2SC3326B A...................

Q 181 89-327-125-080 0E CHIP TR,2SC2712GR A...................

Q 182 89-333-266-080 0E CHIP TR,2SC3326B A...................

Q 202 87-A30-288-040 0E C-TR,DTC114YKA A...................

ELECTRICAL MAIN PARTS LIST - 2 (TP-S5)

Q 203 87-A30-288-040 0E C-TR,DTC114YKA A...................

Q 201 87-A30-288-040 0E C-TR,DTC114YKA A...................

Q 404 87-026-422-080 0E C-TR,RN2304 A...................

Q 403 87-A30-144-080 0E C-TR,2SC4081 A...................

Q 401 89-341-165-080 0E CHIP TRANSISTOR 2SC4116GR A...................

Q 402 89-342-132-080 0E TR,2SC4213 A...................

TH 201 87-A90-855-080 0E C-THMS,SC20-3K102K A...................

ELECTRICAL MAIN PARTS LIST - 3 (TP-VS530)

NOTE: The characters in the suffix column indicate the part usage.

UBSC ...................XX..................................A...................

SC .....................XX...................................B..................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

* 87-A91-158-010 SPKR,DIA 50 4OHM 1.0W AB..................

C 105 87-010-184-080 0E CHIP CAPACITOR 3300P(K) AB..................

C 104 87-010-186-080 0E CAP,CHIP 4700P AB..................

C 109 87-015-674-010 0E CAP 22U-6.3V AB..................

C 101 87-015-676-010 0E CAP,E 47-6.3 7L AB..................

C 108 87-015-677-010 0E ELECTROLYTIC CAPACITOR, 100U 6 AB..................

C 107 87-015-681-010 0E ELECTROLYTIC CAPACITOR, SRA16V AB..................

C 106 87-015-695-010 0E CAP,E 1-50 7L AB..................

C 103 87-016-462-080 0E C-CAP,S 1-16 F AB..................

C 102 87-016-462-080 0E C-CAP,S 1-16 F AB..................

C 110 87-010-186-080 0E CAP,CHIP 4700P AB..................

C 119 87-010-187-080 0E CAP CHIP S5600P AB..................

C 116 87-010-197-080 0E CAP, CHIP 0.01 DM AB..................

C 115 87-015-675-010 0E ELECTROLYTIC CAPACITOR, 6.3V-3 AB..................

C 111 87-015-698-010 0E ELECTROLYTIC SRA 50V-4.7U AB..................

C 113 87-016-462-080 0E C-CAP,S 1-16 F AB..................

C 114 87-016-462-080 0E C-CAP,S 1-16 F AB..................

C 118 87-016-462-080 0E C-CAP,S 1-16 F AB..................

C 155 87-015-676-010 0E CAP,E 47-6.3 7L AB..................

C 153 87-015-908-010 0E CAP, 220-4V AB..................

C 154 87-015-908-010 0E CAP, 220-4V AB..................

C 152 87-016-462-080 0E C-CAP,S 1-16 F AB..................

C 151 87-A10-264-080 0E C-CAP,S 0.1-16ZF AB..................

C 182 87-015-676-010 0E CAP,E 47-6.3 7L AB..................

C 181 87-015-695-010 0E CAP,E 1-50 7L AB..................

C 183 87-016-462-080 0E C-CAP,S 1-16 F AB..................

C 201 87-016-462-080 0E C-CAP,S 1-16 F AB..................

C 403 87-016-491-080 0E C-CAP,S 0.22-16 FZ AB..................

C 402 87-A10-264-080 0E C-CAP,S 0.1-16ZF AB..................

C 401 87-A10-264-080 0E C-CAP,S 0.1-16ZF AB..................

D 101 87-A40-529-010 1A DIODE,1GWJ42 AB..................

J 103 84-TM1-630-010 1A JACK,3.5 HSJ1493-05 AB..................

J 101 84-TM1-630-010 1A JACK,3.5 HSJ1493-05 AB..................

J 102 87-A60-849-010 0E JACK,DC DIA 2.75 BLK AB..................

SFR 202 87-A90-527-010 SFR,5K H VZ066L3 AB..................

SW 102 87-031-816-010 1A SLIDE SWITCH AB..................

SW 101 87-A90-305-010 SW,SL 2-2-2 (NC) AB..................

SW 181 87-031-816-010 1A SLIDE SWITCH AB..................

TH 202 87-A90-307-080 C-THMS,K39G220 AB..................

VR 101 87-A90-314-010 VR,RTRY 10K H AB..................

VR 201 87-A90-308-010 VR,RTRY 3KB XV81 AB..................

* 82-TP3-609-010 1C ECM AB..................

D 151 87-020-027-080 0E CHIP-DIODE 1SS184 AB..................

D 304 87-017-827-070 0E C-LED,SEC 1201C RED AB..................

D 401 87-020-339-080 0E CHIP DIODE,1SS226 AB..................

D 402 88-HC6-612-080 C-DIODE,RB411D AB..................

IC 101 87-A20-399-010 1F IC,LA4168M AB..................

Q 102 89-333-266-080 0E CHIP TR,2SC3326B AB..................

Q 181 89-327-125-080 0E CHIP TR,2SC2712GR AB..................

Q 182 89-333-266-080 0E CHIP TR,2SC3326B AB..................

Q 203 87-A30-288-040 0E C-TR,DTC114YKA AB..................

Q 202 87-A30-288-040 0E C-TR,DTC114YKA AB..................

Q 201 87-A30-288-040 0E C-TR,DTC114YKA AB..................

Q 403 87-A30-144-080 C-TR,2SC4081 AB..................

Q 404 89-333-266-080 0E CHIP TR,2SC3326B AB..................

Q 401 89-341-165-080 0E CHIP TRANSISTOR 2SC4116GR AB..................

Q 402 89-342-132-080 0E TR,2SC4213 AB..................

ELECTRICAL MAIN PARTS LIST - 4 (TP-VS530)

TH 201 87-A90-855-080 0E C-THMS,SC20-3K102K AB..................

MECHANICAL PARTS LIST - 1 (TP-S5)

NOTE: The characters in the suffix column indicate the part usage.

S ......................OO..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-HT7-001-010 LID,CASS A...................

8Z-HT7-002-010 FRAME,CENTER A...................

8Z-HT7-003-010 CABI,REAR A...................

8Z-HT7-004-010 GRILLE,MIC A...................

8Z-HT7-005-010 PANEL,MIC A...................

8Z-HT7-006-010 WINDOW,CASS A...................

8Z-HT7-007-010 LID,BATT A...................

8Z-HT7-010-010 GRILLE,SPEAKER A...................

8Z-HT7-012-010 FOOT,RUBBER A...................

8Z-HT6-010-010 BTN,PLAY A...................

8Z-HT6-011-010 BTN,REC A...................

8Z-HT6-012-010 BTN,FF A...................

8Z-HT6-013-010 BTN,REW A...................

8Z-HT6-014-010 BTN,STOP A...................

8Z-HT7-008-010 KNOB,SL PAUSE A...................

8Z-HT7-009-010 KNOB,SL SLSS A...................

87-067-271-010 0E SCREW VFT2+1.7-4 A...................

87-067-769-010 0E VT2+1.7-8(3) BLK A...................

87-264-521-310 V+1.7-1.6 CR A...................

87-351-508-310 VT2+1.4-3.5 BLK A...................

87-354-529-310 0E VT2+1.7-4 A...................

87-B10-234-010 QT2+1.4-3 BLK A...................

87-HT8-211-010 VT2+2-18 S-SCREW BLK A...................

87-040-196-010 1H COUNTER A...................

87-HT8-202-010 HLDR,COUNTER A...................

87-HT8-203-010 SPR-P,CASS A...................

87-HT8-204-010 LEVER,REC ACTUATOR A...................

87-HT8-205-010 LEVER,REC SAFETY A...................

87-HT8-208-010 SPR-T,LID CASS A...................

87-HT8-209-010 SPR-E,REC SAFETY A...................

87-HT8-210-010 BELT,COUNTER A...................

8Z-HT7-201-010 HLDR,MIC A...................

8Z-HT7-202-010 COVER, SPEAKER A...................

8Z-HT7-203-010 LEVER,PAUSE A...................

8Z-HT7-204-010 COVER, MIC A...................

8Z-HT7-205-010 BAT-CONTACT,(+) A...................

8Z-HT7-206-010 BAT-CONTACT,(-) A...................

MECHANICAL PARTS LIST - 2 (TP-VS530)

NOTE: The characters in the suffix column indicate the part usage.

UBSC ...................XX..................................A...................

SC .....................XX...................................B..................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-HT7-004-010 GRILLE,MIC AB..................

8Z-HT7-005-010 PANEL,MIC AB..................

8Z-HT7-007-010 LID,BATT AB..................

8Z-HT7-010-010 GRILLE,SPEAKER AB..................

8Z-HT7-012-010 FOOT,RUBBER AB..................

8Z-HT9-001-010 LID,CASS AB..................

8Z-HT9-002-010 FRAME,CENTER AB..................

8Z-HT9-003-010 CABI,REAR AB..................

8Z-HT9-007-010 WINDOW,CASS AB..................

8Z-HT6-010-010 BTN,PLAY AB..................

8Z-HT6-011-010 BTN,REC AB..................

8Z-HT6-012-010 BTN,FF AB..................

8Z-HT6-013-010 BTN,REW AB..................

8Z-HT6-014-010 BTN,STOP AB..................

8Z-HT7-008-010 KNOB,SL PAUSE AB..................

8Z-HT7-009-010 KNOB,SL SLSS AB..................

87-067-271-010 0E SCREW VFT2+1.7-4 AB..................

87-067-769-010 0E VT2+1.7-8(3) BLK AB..................

87-264-521-310 V+1.7-1.6 CR AB..................

87-351-508-310 VT2+1.4-3.5 BLK AB..................

87-354-529-310 0E VT2+1.7-4 AB..................

87-B10-234-010 QT2+1.4-3 BLK AB..................

87-HT8-211-010 VT2+2-18 S-SCREW BLK AB..................

87-040-196-010 1H COUNTER AB..................

87-HT8-202-010 HLDR,COUNTER AB..................

87-HT8-203-010 SPR-P,CASS AB..................

87-HT8-204-010 LEVER,REC ACTUATOR AB..................

87-HT8-205-010 LEVER,REC SAFETY AB..................

87-HT8-208-010 SPR-T,LID CASS AB..................

87-HT8-209-010 SPR-E,REC SAFETY AB..................

87-HT8-210-010 BELT,COUNTER AB..................

8Z-HT7-201-010 HLDR,MIC AB..................

8Z-HT7-202-010 COVER, SPEAKER AB..................

8Z-HT7-203-010 LEVER,PAUSE AB..................

8Z-HT7-204-010 COVER, MIC AB..................

8Z-HT7-205-010 BAT-CONTACT,(+) AB..................

8Z-HT7-206-010 BAT-CONTACT,(-) AB..................

ACCESSORIES LIST - 1 (TP-S5)

NOTE: The characters in the suffix column indicate the part usage.

S ......................OO..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-HT7-851-010 COVER,SLIDE S A...................

8Z-HT7-901-010 IB,D A...................

87-042-186-110 2M RB-105 D A...................

87-047-153-110 1C BAT,NB-3A PH A...................

87-PD3-050-010 1B STRAP,HAND A...................

ACCESSORIES LIST - 1 (TP-VS530)

NOTE: The characters in the suffix column indicate the part usage.

UBSC ...................XX..................................A...................

SC .....................XX...................................B..................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-HT9-903-010 IB,YU(3L)C A...................

8Z-HT9-904-010 IB,YHJ(ECC)C ....................

8Z-HT9-906-010 IB,YL(3L)C ....................

8Z-HT9-907-010 IB,EZ(EGF)C .B..................

8Z-HT9-908-010 IB,EZ(SID)C .B..................

8Z-HT9-909-010 IB,EZ(PHNCZ)C .B..................

87-PD3-050-010 STRAP,HAND AB..................

This manual suits for next models

Popular Cassette Player manuals by other brands

Ahuja

Ahuja CPA-360 Operation manual

Sony

Sony Pressman TCS-60DV Specifications

Philips

Philips AQ6485/14 Product information

Sony

Sony TCM-200DV - Cassette Recorder operating instructions

Nakamichi

Nakamichi BX-300 Service manual

Panasonic

Panasonic RQ-E25V operating instructions

Yamaha

Yamaha MT8X Operation manual

Sherwood

Sherwood Newcastle D-480 operating instructions

Manta

Manta MA408 user manual

GPO

GPO W0162B user guide

Marantz

Marantz CP230 Service manual

Sony

Sony HST-471 Service manual

Sharp

Sharp JC-AV1 Operation manual

Pioneer

Pioneer CT-W103 Service manual

Sony

Sony CFS-B15 - Am/fm Stereo Cassette Recorder operating instructions

Sony

Sony WMFS220 - Portable Sports AM/FM Cassette... operating instructions

Sanyo

Sanyo MCD-ZX700F Service manual

Sony

Sony Pressman TCM-465V operating instructions

Aiwa TP-S5 User manual

Popular Cassette Player manuals by other brands
