AKG LC User manual

Handheld Microphone
LC “Light Condenser”
Vocals
Recording
Live Sound
Sound/AV company
•Slender and elegant silhouette
•PB 1000 Presence boost adapter for increased intelligibility
•Condenser vocal microphone for onstage use
•XLR connector module with 24-carat gold plated pins for optimized connectivity
•24-carat gold plated transducer case for optimum conductivity and resistance to
corrosion and humidity
•Spring steel wire-mesh grill for extreme ruggedness incl. reliable control of pops and wind noise
•Internal elastic suspension
This professional condenser vocal microphone will make your voice cut through the loudest mix - on any
stage. Its cardioid polar pattern ensures maximum gain before feedback and has been optimized for use
with in-ear monitor systems. LC is custom-designed with piano black painting to address the aesthetic
preferences of special performances: a slim line premium condenser microphone.
Delivering an extremely accurate, detailed and natural sound, the AKG LC features an XLR connector
module with 24-carat gold plated pins for optimized connectivity, as well as resistance to corrosion and
humidity. Additionally, the LC features a spring steel wire-mesh grill for extreme ruggedness offering
reliable control of pops and wind noise while an artist is on stage.
The resulting LC microphone features a frequency range of 60 to 20,000 Hz and premium 24-carat gold
plated transducer case for optimum conductivity. Offering a slender and elegant silhouette, the
lightweight unit has a subtle piano black finish to visually complement any performance.
L C

Handheld Microphone
o
Specifications
Polar pattern cardioid
Frequency range 60 to 20,000 Hz
Sensitivity 4 mV/Pa (-52 dBV)
Max. SPL for 1%/3% THD 140/145 dB SPL
Equivalent noise level 25 dB-A
Signal/noise ratio (A-weighted) 69 dB
Impedance/load Impedance ≤200 ohms
Recommended load impedance: >2000 ohms
Powering: 9 to 52 V phantom power to DIN 45596
Current consumption: typ.3 mA
Finish Piano Black
Dimensions length: 185 mm (7.3 in.);
diameter: 34 mm (1.3 in.)
Net/shipping weight: 260 g (9.2 oz.)/ 620 g (1.4 lbs.)
Standard accessories: Microphone bag, SA 45, PB 1000
Optional accessories: B 18, H 30, H 50, SA 44, SA 61, ST 1, ST 45,
ST 46, ST 305, W 23, W 1000
Item number L C
Order Number 3133A00030
