ALIGATOR A321 User manual

A321 – Quick Guide

Contents
Safety instructions.....................................3
Putting into operation................................4
Battery charging........................................5
Switch On / Off..........................................7
Mobile controls..........................................8
Ma ing calls............................................15
Contact list...............................................16
Photo contacts........................................18
SOS call and SMS..................................19
FM Radio................................................28
Setting of the phone................................28
Security....................................................29
Dual SIM setting.......................................30
Safety and ecology..................................31
Used electric device................................31
Battery liquidation....................................32
2

Safety instructions
Do not switch on and use the mobile
phone in the prohibited areas
Do not use the mobile phone while
driving the car
Turn off the mobile phone near the
sensitive medical device
Turn it off in the aircraft
Do not use the mobile phone near the
filling petrol station
Turn off the mobile phone always near
explosives
Use always original batteries supplied
by the producer (danger of damage of
explosion of the mobile phone)
Attention! Your mobile phone is NOT
waterproof !
3

Putting into operation
Insert SIM, memory cards and
battery
1. Insert your nail at the slot under the
battery cover on the bac side of the
phone and remove carefully the cover.
2. Insert 1 or 2 SIM cards (insert also
memory card if you have it).
3. Insert the battery. Three metal contacts
must lead to upper part of the mobile
phone. Battery must smoothly fit at the
battery holders in the mobile phone.
4. Finally put the battery cover bac .
A EN ION! Switch off the mobile
phone and disconnect the charger by
4

any manipulation with the battery,
memory card or SIM card. Use only
original battery supplied by the mobile
producer.
Battery charging
Be sure that the battery is placed at the
mobile phone. Connect the charger and the
charging will start automatically.
Mobile phone can be charged if it is in
switched on or switched off mode.
Charging level is indicated on the mobile
screen.
Discharged battery Fully charged
5

Mobile phone will warn you by an acoustic
signal and by message on the screen when
the battery is almost discharged. In this case
charge the battery as soon as possible.
Sometimes it happens that after the
battery is fully discharged phone will
not start charging the battery by
connecting the charger. In this case,
leave the phone connected to the
charger for several hours until the
battery starts charging.
Attention! If you leave the battery fully
discharged for a long time, it can lead to
its destruction, which is not covered by
warranty!
6

Switch On / Off
to SWI CH ON the phone - press and hold
the red button, till the phone turns on. (Now
you can be as ed to enter the PIN code in
case the PIN protection is activated).
to SWI CH OFF - press and hold the red
button, untill the mobile turns off.
Before Switching On be sure that the battery
is inserted and is charged.
7

Mobile controls
8

Description of the Mobile controls
No. Name Function
1
Right
functional
button
-starts contacts in
standby mode
-return from menu or
exit from current
function
-other functions
depending on
context (current
function is shown on
display above the
ey)
2
Left
functional
button
-displays message in
standby mode
-confirms selection
9

in menu or activates
selected function
(OK)
-other functions
depending on
context (current
function is shown on
display above the
ey)
3
Navigation
button
Up / Down
-press Up in standby
mode to display
phone menu
-press Down to
display photo
contacts
-move in menu and
in phone list
10

4 Red button
-long press to Switch
On / Off
-stop or reject a call
-return from the
menu or exit current
function on the main
screen
5Green
button
-press the buton to
answer the call
-displays call history
in standby mode
6 Button 0 -when writing
tel.number enables
to write „0“, when
writing text enables
to write „gap“
-long press to turn
11

on/off silent mode
„Meeting“
7 Button #
- inserts # when
writing numbers
- in text writing mode
toggles method of
character imput
8Button *
- inserts *,+, p, w
when writing
numbers
- in text writing mode
enables to insert
special characters
9
Keypad
lock
switch
-slide the switch Up to
loc eypad
-slide the switch Down
to unloc the eypad
12

10 Connector
MicroUSB
used to connect the
charger
11 Flashlight
powerful LED flashlight
is placed on top of the
phone
12 Earphone used to listen the call
13 Flashlight
switch
press and hold the
button to turn on/off the
flashlight
14 Stand
contacts
used for charging in a
stand
15 Earphone
connector
Used to connect
headphones / mini-
handfree
13

Icons on the screen
Battery charge level
Signal strenght
Alarm activated
Unread SMS message
Ringer Off - vibration
Missed call
14

Making calls
Dialling
Insert required phone number on the mobile
eypad and press the green button (5).
Mobile will start to dial required number.
If you have 2 SIM cards in your mobile
and both are activated, mobile phone will
as you which SIM card should be used for
calling.
By using of the button Up/Down (3) choose
the SIM card and confirm by button (OK)
If you have dialled by mistake a wrong
number, just press the right button „Delete“
(1) and the last digit will be deleted.
15

If you need to delete the whole number,
press the red button (4) and a whole number
is deleted.
For answering of the call press green
button (5).
For rejecting of the call, press red
button (4).
 Adjust the volume during a call by
pressing the Up / Down (3).
 For hands free during the call, press the
right button Sp rOn (1).
Contact list
you can store phone numbers at the phone
and assign a name to each number.
16

Contacts can be stored either on the SIM
card or at the phone memory.
Dialling from the contact list
The simplest way to display the contact list
is to press the right button (1). Now you can
type the first letter of the name you are
loo ing for. After that a contact list, sorted
alphabetically by name, appears.
Use the Up and Down button to select the
contact you want to call and press the green
button (5) to ma e a call.
When viewing the contact list, the
distinguishing icon appears to show if the
17

contact is stored on the SIM card or at the
mobile phone.
Photo contacts
This feature allows to save photos to the
eight selected contacts.
After pressing the down button (3) on the
main screen, these contacts are displayed
on the screen and can be easily dialed by
pressing the number that is displayed on
each photo.
Setting of photo contacts:
1. Select Contacts  Photo contacts
18

2. Use the Up / Down button (3) to select
the contact you want to set
3. Press the left button Edit (2)
4. Set the name, tel.number, picture and
ringtone
SOS call and SMS
Starting the emergency call and SMS
Press and hold the SOS button. An audible
alarm and a countdown begin, during which
you can interrupt the running emergency call
The phone will begin automatically to dial
the preset numbers from the list until it can
reach any of them. The phone repeats max.
3x to dial all preset numbers.
19

The phone also sends an emergency SMS
message with a preset text to all preset
phone numbers. (For TEXT setting : select
in menu SOS setting  SOS SMS)
After that the mobile phone remains in the
so-called “Emergency Mode”.
In the emergency mode, the phone will
automatically answer incoming calls and
automatically activates the handsfree -
spea erphone.
If you need to deactivate the SOS call and
alarm, resp.emergency mode, just press the
button OFF (1) and after that switch off and
restart the mobile phone again.
20
