ALIGATOR RX510 eXtremo User manual

RX510 eXtremo
Quick Guide

Google, Google Play and Android are trademarks of
Google Inc.
Contents
Before you start.................................................... 2
Dual SIM function................................................. 3
Im ortant instructions......................................... 3
Insert SIM cards.... ............................................... 7
Mobile controls.................................................... 8
Switch on …............................................................ 9
Tele hone reset................................................... 9
Activation and screen unlock …........................... 9
O erational system Android™........................... 10
Basic mani ulation .................................................. 10
Making calls …..................................................... 14
SMS Messages.................................................... 15
Choice of SIM for calling, SMS + Internet …........ 16
Choice of network by connection difficulties..... 16
Photogra hy ….................................................... 17
PC connection................................................... 17
Safety and ecology …............................................ 18
Declaration of conformity.................................. 19
Before you start
We thank you for buying of this resistant
mobile phone ALIGATOR.
2

Before you start, lease read this quick
guide with im ortant instructions.
D AL SIM function
Your mobile hone can o erate on 1 or 2 SIM
cards. If you insert only 1 SIM card, your
mobile hone works like a standard mobile
hone.
If you insert 2 SIM cards, both are working on
line at the same time and it is ossible to
make a call on either card.
Important instructions
 In s ite of the fact that the mobile hone
is very sturdy , handle the device with
care, rotect it against the fall on the
ground, mechanical damage,
contamination or extreme high
tem eratures. Protect the screen from
the hits or im acts ! Never ut the mobile
hone into arts. Never disassemble the
hone or accessory! Remember that even
3

by a durable hone the dis lay can crash
damage !
 Your hone is water resistant, assuming
that all the hole covers are ro erly fitted
and sealed. Yet if ossible, kee away from
water. In case of contact, res ectively
immersion in water, remove it from water
as soon as ossible and let it ro erly dry.
 When de loying all ca s be always sure
that the seal ca s are not dirty and that
the covers seal ro erly and are fully
de loyed.
 If the hone or its art gets into the contact
with water, dry it thoroughly before using. Mainly
dry all the folds, crevices and holes for the
s eaker, ear hone and micro hone. Never o en
the door (on the back of the hone) after the
hone has come into contact with water and
before the cover and its surroundings were
ro erly dried.
 I n case of contact with water, do not
tam er with the hone, do not ress any
keys and do not tam er with ca s o enings.
 Do not switch on and do not use the mobile
4

hone in the rohibited areas
 Do not use the mobile hone while driving the
car
 Turn off the mobile hone near the
sensitive medical device unless you are
sure that the radio transmission of the
mobile hone does not influence its
functions
 Mobile hone can influence the function
of the electronic cardiac acemaker or
other im lanted a aratus lease consult�
your medical doctor
 Turn off the mobile hone in the aircraft
 D o not use the mobile hone near the
filling etrol station, turn off the mobile
hone always near ex losives
 Use always original batteries su lied
by the roducer (danger of damage or
ex losion of the mobile hone)
5

 Do not ut the battery at the fire and
do not ex ose it to the tem erature
over +60°C (danger of ex losion or fire)
 SAR – mobile hone meets the
rescri tions for maximal emission of
the electromagnetic radiation
 While making a call lease kee the
mobile hone at least 2,5 cm away from
the body to minimalise the quantity of
the el. magnetic radiation absorbed by
your body
 D o not lace the mobile hone or its
holder in the car at the lace over the
airbag
 K ee it out of reach of the children and
do not allow them to lay with. It contains
small arts that they can suffocate or can
hurt !
 Failure to com ly with these
instructions may void the warranty on
the device
 Software and hardware of the mobile
hone are continuously u dated. The
im orter reserves the right to alter the
instruction manual or mobile hone
functions without a rior notice
6

lnsert SIM cards
Make sure that the mobile hone is
switched off. Loosen 2 screws on the back
side of the mobile hone and remove the
cover
Insert one or two SIM cards at the re ared
ositions. Pictures by the ositions show in
which way the SIM cards should be inserted.
The hone is equi ed with 2 slots for SIM
cards. Next to SIM cards you can also insert
a MicroSD memory card.
Finally ut the battery cover back and tighten
the screws. The screws must be ro erly
tightened to ensure a watertight seal, but
tighten them carefully not to cross the
thread.
If the ackage includes a screwdriver use
always the su lied screwdriver for
tightening of the screws.
Overtightening, breakage or other
mechanical damage of the screws are not
covered by warranty !
7

Mobile controls
1. Button „Menu“
2. Button „Main screen“
3. Button „Backwards“
4. Volume
5. Button „Switch On / Off“
6. E ar hon e
7. E ar hone connector
8. Front camera
9. Micro USB connector
10. Button „Camera“

Switch on
To Turn On – ress the button On/Off (5)
and wait for a while till the mobile hone is
on.
The setu wizard is dis layed by the first
start. Choose your language and follow the
instructions on the screen.
To Turn off - ress and hold the hone
button (5) until the dis lay shows the
window asking to shut down. Then confirm
it and the mobile hone switches off.
Mobile phone reset
In case the hone does not res ond or if
you need to reset it, ress and hold the
On/Off button (5) until the hone
reboots.
Activation and screen unlock
The screen will be Switched Off after a certain
time of inactivity. You can Switch On/Off the
screen by a short ress of the button (5).

Generally it is necessary to unlock the screen
after the activation. Put the finger on symbol
„Lock“ on the screen and move it U , left (for
calling) or to the right (camera).The screen
will be unlocked.
Android™ system
Your mobile hone is rovided with the
Android o erating system. The mobile hone
is in fact a small ersonal com uter which
can be connected to internet and in which
you can install a lot of various a lications
free of charge (viaGoogle Play™ store).
Basic manipulation
Meaning of the touch buttons (1) až (3)
(1) Launched applications/Menu – serves
to dis lay a list of recently o ened
a lications. After a long ress dis lays
the menu of items available on the
current screen or in a running
a lication

(2) Main screen – short ress for return to
the main screen, long ress hel s to
dis lay the Goggle search.
(3) Back – serves to move back by one
ste /level (or to go to the receding
screen, to close the o tions, dialog
windows on the screen etc.)
System control
Your mobile hone can be controlled by
the above mentioned buttons but mainly
with the use of the touch screen.
Just click on the selected item to confirm
the item on the screen, to confirm the
dialog windows or gra hical buttons on
the screen.
Google account
You need to have adjusted Google
account for the ro er use of the system.
The account can be created very easily :
1. Click on the icon Settings
2. Select the o tion Accounts + select Add
account
3. Further follow the instructions on the screen

Main screen
Same as on your PC you have available a
main screen on the mobile hone. The main
screen is devided into several ages that can
be dis layed by moving of your finger to the
left/right direction. You can lace shortcuts
of a lications and links or widgets on the
main screen.
Widgets are mini-a lications that enable to
dis lay some data, control elements like
watches, weather, charging controll etc.
Applications
All installed a lications can be dis layed by
the button laced in the centre of the bottom
art of the main screen.
In the basic equi ment of the mobile hone
there are a lications for making calls,
sending SMS, emails but also for other useful
and entertaining a lications.
There are thousands of various a lications
suitable for Android system but not all of
them can work ro erly in your mobile
hone.

Before buying of any new a lication lease
try first its gratis version if it works correctly
in your mobile hone.
Information and display of status
So called status bar is laced in the u er art
of the screen. You may find here the
information about time, battery level and
signal but also other useful information. For
exam le the information about new SMS,
information about the system or a lications.
Status bar can be moved down by your finger
or rolled. You will get a detailed overview
about all announcements and information
including the ossibility of a quick control of
some mobile functions.
Mobile phone setup
All items of the tele hone set u are clearly
arranged at the settings menu.
Press the button Setup on the home age
and make desired changes.

Making calls
Dialing
Click on the ear hone icon on the main
screen. Screen with key ad for number
dialling will be dis layed. Ta the keyboard
icon at the bottom of the screen to dis lay
the keyboard.
You can enter the tel.number with the use of
the key ad buttons. Similarly as on the
common tele hone there are the letters
dis layed on the buttons so you can enter
also the name. The dialled number and all
corres onding items of the tel.directory will
be dis layed after entering of the letters on
the keys of the screen.
At the bottom art of the screen you can
find the calling button with a symbol of the
head- hone. You can dial the number by its
ressing and make your call.
Answer and reject the call
If somebody is calling you the information
about his tele hone number and a button

with the receiver is dis layed on the screen (if
available)
To answer the call : move the button to
the right towards the symbol of a Green
receiver
To reject the call : move the button to
the left towards the symbol of a Red
receiver
When working with your hone the call alert
a ears as a dialog box with buttons for
admission ("Answer") or rejection of the call
("Close").
Call flow and finish of the call
The screen will automatically switch off
when the mobile hone is attached to the
ear. After the delay from the ear the screen
will switch on within few seconds.
The call can be finished by ressing of the
Red button on the screen.
SMS messages
1. Click on the icon of Messages on the lower
side of the main screen or o en the screen
with a lications and select the item
Sending messages

2. A list of conversations containing received
and sent SMS and MMS messages will be
dis layed.
3. Select the icon New message on the left
bottom side of the screen.
4. Now you can insert the receiver of the text
message.
5. To send the text message ress the
arrow button laced on the right side
of the text.
Choice of SIM card for calling, SMS
and Internet
Click on Settings/Setup icon on the main
screen and choose the item SIM Cards. You
can choose which SIM card will be used for
calls, SMS and internet/data access.
Choice of network by difficulty with
connectivity
You can choose whether your hone will use a
2G network, 3G or 4G, res ectively you can
switch between them automatically.
If you have roblems with access to calls or
you can not be called des ite showing

sufficient signal, restart mobile hone and
ossibly tem orarily disable the 4G network
connection:
Ta on the main screen and select Settings
icon in the Wireless connection &
networks click Next.
Next select the Mobile networks and select
referred network ty e for each SIM card.
Now select GSM / WCDMA auto (2G / 3G)
or GSM only (2G only).
Photography
Start the camera by ta ing the camera icon
or ress and hold the side button (10). Aim
the camera at the scene and ta your finger
on the screen to the oint that you want to
focus.
After focusing the scene you can take a
icture by ressing the shutter button on
the side of the dis lay. Attention! Always
erform focus or wait for automatic focus and
then ress the shutter button otherwise the
images may be blurred.
PC connection
For connection to the common PC you do

not need any s ecial drivers (Vista, 7, event.
newer). Follow these ste s :
1. Connect the mobile hone with PC with the
enclosed cabel
2.Drag the status bar down and click on the line
„Connected as...“
3.Menu of the connection mode will be o ened.
We recommend to use the device mode for media
MTP.
4.Subsequently, the hone will connect to a PC as
a "Media device"
Internal storage in your hone and inserted
MicroSD card will be connected to a com uter in
the file “Com uter”, in section “Portable
Devices” and under the name “ALIGATOR RX510.
Connection can be cancelled by disconnecting of
the cable.
Safety and ecology
sed electric device
Mobile hone is an electronic a liance. It means
it must not be mani ulated as a common
residential waste. Never throw the used device
away at the common municipal waste!!!
Hand over the electric devices to the res ective
collection oint which rovides the ecological
liquidation.

Battery liquidation
sed/old batteries and accumulators do not
belong to the common residential waste !!!
Hand over the battery or electric devices to
the res ective collection oint which
rovides the ecological liquidation. Please
contact your dealer to get more information
how to deal with the used roducts. Do not
ut the battery at the fire and do not ex ose
it to the tem erature over +60°C (danger of
ex losion or fire)
Handling with the used batteries in
contradiction with given instructions is
illegal!
0700
Declaration of conformity
No. 6/6/2016
Issued in acco rdance with the rescri tion : EU R&TTE,
1999/5/EC
Product: Mobile Phone for GSM, WCDMA and LTE
network
Model: ALIGATOR RX510

Im orter: ADART COMPUTERS s.r.o., Sokolovská 161,
180 00 Praha 8, Reg.No.: 25074547
Evaluated roduct is a mobile hone intended to be used and
stored in standard conditions. The im orter declares that the
roduct is for its use safe and during the roduction there
are taken control and other measurements securing the
confirmity of the roduct with the basic requirements and
technical documentation. Relevant harmonized norms have
been a lied to evaluate the conformity.
The tests of confirmity were carried out and the rotocol
made by authorised erson: PHOENIX TESTLAB GmbH,
Königswinkel 10, 32825 Blomberg, Germany.
The roduct bears the Euro ean conformity mark CE 0700 in
accordance with the rescri tions of the EU.
Issued in Prague, dne 6.6.2016:
ADART COMPUTERS s.r.o.
