ALIGATOR S5060 Duo 4-core IPS User manual

S5060 Duo 4-core IPS
Quick Guide

Contents
Before you start...................................2
DUAL SIM function..............................3
Important instructions........................3
Mobile controls...................................6
Insert battery and SIM cards...............7
S itch On / Off....................................8
Activation and screen unlock..............8
Select SIM for calls,SMS and internet. 9
Operating system Android™................9
Basic handling....................................10
Making calls.......................................14
Messages...........................................16
Selection of net ork.........................16
Photography......................................17
PC connection....................................18
Safety and ecology............................19
Declaration of conformity.................20
Google, Google Play and Android are
trademarks of Google Inc.
2

Before you start
Thank you for buying of our
ALIGATOR mobile phone . Before you
start please read carefully this
instruction manual.
DUAL IM Function
Your mobile phone can be operated
ith 1 or 2 SIM cards. If you insert only
one SIM card the mobile phone orks
as an ordinary mobile phone.
In case you insert 2 SIM cards at the
mobile phone both are active at the
same time. It means you can be called
on both SIM cards at the same time
ithout any s itch bet een them.
Both cards are on line.
Important instructions
Do not use the mobile phone at
the prohibited areas
3

Do not use the mobile phone
hile driving the car
Do not use the mobile phone
near the medical appliances
ithout having the confirmation
that the radio aves do not
influence its function.
Mobile phone can influence the
function of the cardiac
pacemakers or other implanted
appliances – please consult your
medical doctor
S itch off the mobile phone
al ays in the aircraft
Do not use mobile phone near
the petrol station. Al ays s itch
off the mobile phone near
explosives.
4

Use only the original batteries
supplied by the producer. Danger
of damage of the mobile phone
or explostion.
Do not thro the battery in the
fire nor expose it to the
temperatures over +60°C. Danger
of explosion or fire.
SAR – mobile phone meets all
prescriptions for maximal
emision of electromagnetic
radiation.
Please keep the mobile phone 2.5
cm a ay from the body hile
calling. You lo er by that the
quantity of electromagnetic
radiation absorbed by your body.
Handle the mobile phone ith
care, protect it from falling on
the ground, from mechanical
5

damage, impurity or high
temperatures. Never pick it to
pieces !
Do not place the mobile phone or
its holder in the area above the
airbag in the car
Keep it out of reach of children. It
contains small parts that could be
s ollo ed or may hurt.
Soft are and hard are of the
mobile phone are continuously
innovated. The importer reserves
the right to alter the instruction
manual or particular functions of
the mobile phone ithout a prior
notice.
Mobile controls
1. Button : Menu
6

2. Button : Main screen
3. Button : Back ards
4. Volume
5. Button : S itch On / Off
6. Earphones
7. Earphone connector
8. Front camera
9. Micro USB connector
7

Insert battery and IM card
Slip your nail at the slot under the
battery cover in the corner on the back
side of the mobile phone and carefully
pull do n the cover.
Insert firstly one or t o SIM cards at
the prepared slots. Insert SIM and also
MicroSD memory cards (if you have) as
per the picture instruction.
Insert the battery. Make sure that the
battery clicks smoothly into the slot in
the mobile phone.
Put the battery cover back. Place the
cover on the back side of the mobile
phone and press gently around the
circuit untill the cover clicks properly
on its place.
8

witch On / Off
To witch On - press the button (5).
Starting of the mobile phone can last
fe seconds.
To witch Off – press and hold the
button (5) till the indicator indo of
a s itch off appears on display.
Confirm it and the mobile phone ill
turn off.
Activation and screen unlock
The screen turns off automatically
after a certain time of inactivity. Turn
on / off the screen by a short press of
the button (5).
It is necessary to unlock the screen
after the activation. Put your finger on
a „Lock“ symbol and move it in the
up ard direction. The screen ill be
unlocked.
9

election of IM card for calls,
M and internet
Tap on the main screen, click ettings
and select IM card. No you can set
hich SIM card to be used for calls,
SMS and internet.
Attention! In the event that you insert
t o SIM cards at your phone, you
need to select hich SIM card ill be
used as the primary for sending of SMS
other ise Messenger for SMS ill NOT
function properly. These settings can
later be changed at any time, if
necessary, just before sending of SMS,
to select hich SIM should be used.
Operating system Android™
Your mobile phones is provided ith
the operating system Android™ . The
device is in reality a small personal
computer that can be connected ith
internet from hich you can do nload
10

many useful applications (via Google
Play™ store).
Basic handling
Meaning of contact button
(1) to (3)
(1) Launched applications / Offer –
serves to display a list of recent
applications. After a long press
the menu items available on the
current screen or in a running
application ill display
(2) Main screen – short press serves
to return to the main screen.
Long press displays the Google
search.
(3) Backwards – serves to return by
one level back. (jump on the
preceding screen, closing of
offers or dialog indo s on the
screen, etc.)
11

ystem Control
Your phone is operated by using both
the buttons above, but mainly using
the touch screen.
Selecting items on the screen,
confirming dialogs and graphical
buttons on the screen are done by
tapping on them.
Google account
It is necessary to create the Google™
account hich can be set up in
follo ing simple steps:
1. Press the button ettings
2. Select in menu Accounts and
choose Add Account
3. Further follow instructions on
the screen .
12

Main screen
Same as on your PC the main screen of
the mobile phones offers you a
orking area. Your main screen is
devided into more pages that can be
displayed by moving of your finger to
the left/right direction.
You can place the short cuts of icons of
applications and links or idgets on
the main screen.
Widgets are mini-applications that
enable to display some other data
(clock, eather, charging level etc.)
Appplications
All installed applications can be
displayed by the button placed in the
middle of the lo er part of the main
screen.
13

In basic equipment of the mobile
phone you can find applications for
making call, sending messages and e-
mails or many other useful
applications.
There are thousands of various
applications suitable for Android
system but not all of them can ork
properly in your mobile phone.
Before buying of any ne application
please try first its gratis version if it
orks correctly in your mobile phone.
Information and display status
So called „status bar“ is placed in the
upper part of the screen. You may find
here the information about time,
battery level and signal strength but
also other useful information. For
example the information about ne
SMS, information about the system or
applications. Status bar can be moved
14

do n by your finger and rolled. You
ill get a detailed overvie about all
announcements and information
including the possibility of a quick
control of some mobile functions.
Mobile phone setup
All individual items of the telephone
set up are clearly arranged at the
settings menu.
Press the button Menu - select et up
and make the required changes.
Making calls
Dialling
Click on the earphone icon on the main
screen. A screen ith keypad for
number dialling ill be displayed.
You can enter the tel.number ith the
use of the keypad buttons. Similarly as
15

on the common telephone there are
the letters displayed on the buttons so
you can enter also the name.
The dialled number and all
corrresponding items of the telephone
directory ill be displayed after
entering of the letters on keys of the
screen.
At the bottom part of the screen you
can find the calling button ith a
symbol of the head-phone. You can
dial the number by its pressing and
make your call.
Answer and Reject the call
If somebody is calling you the
information about his telephone
number (if available) and a button ith
the receiver is displayed on the screen
16

to answer the call : move the button
to the right to ards the symbol of a
green receiver
to reject the call : move the button to
the left to ards the symbol of a red
receiver
Call flow / Finish of the call
The Screen shuts do n automatically
hen you hold the mobile near the
ear. After delaying the phone a ay
from the ear the screen is activated in
a fe moments.
Press the red button on the screen to
finish the call .
Messages
1. Click on the icon of Messages on
the lo er side of the main screen
or open the screen ith
17

applications and select the item
Messenger
2. A list of conversations containing
received and sent SMS and MMS
messages ill be displayed.
3. Select the icon „+“ at the lo er
right part of the screen
4. No you can insert the receiver
and the text of the message
5. To send the text message press
the arro button placed on the
right side of the text.
election of network
You can choose hether your phone
ill use 2G or 3G net ork.
Tap on the main screen on the icon
ettings and select Next in the
Wireless & networks section.
18

Next, select Mobile networks and
select Preferred network type for each
SIM card. No select item 2G or 3G.
Photography
Start the camera by tapping on the
camera icon. Point the camera at the
scene and tap the finger at the spot on
display that you need to focus or ait
a moment till the camera focuses on
the centre of the scene. Press the
shutter button on the display to
take a picture of the scene. The
camera ill automatically focus on the
central part of the image every fe
seconds if there is a change of the
scene.
To accelerate the sharpening of the
focus or another part of the image, tap
on the desired location on the screen.
19

Attention! Always do or wait for focus
and then press the shutter button
otherwise the images will be blurred.
Press the button to s itch the
front and rear camera.
Press the button to make video.
PC connection
You do not need any special drivers for
connection to the common PC (valid
for OS Windo s Vista, 7, event.
ne er). Follo these steps :
1. Connect the mobile phone ith
PC ith the enclosed cabel
2. Do nload the status bar and tap
the line ith the arning
"Connected as ...."
3. A connection mode offer is
opened. We recommend to use
the device mode for MTP media
20
