ALIGATOR R15 eXtremo User manual

R15 eXtremo
Resistant mobile phone for 2 SIM cards
Quick Guide

Contents
Important instructions........................................................2
Your mobile phone............................................................6
Insert SIM + memory card and battery..............................7
Battery charging................................................................7
S itch On / Off..................................................................8
Making calls.......................................................................9
Keypad lock.......................................................................9
Volume...............................................................................9
Position of antennas........................................................10
Insert of text.....................................................................10
Telephone directory.........................................................11
Torchlight.........................................................................11
Speed dial........................................................................12
SOS function...................................................................12
Safety and ecology..........................................................12
Declaration of conformity.................................................13
We thank you for buying of this resistant mobile phone
ALIGATOR Before you start please read this quick guide ith
important instructions.
Important instructions
Although the phone is durable, treat your phone and its
accessories ith care, protect it from falling to the
ground, mechanical damage, dirt and extreme
temperatures. Especially protect the screen from bumps
and knocks! Never disassemble the phone or accessory!
2

Remember that even ith a durable phone the display
can crash damage!
Your phone is aterproof (not valid for salt ater),
provided that all covers of holes are properly fitted and
sealed. The maximum length of contact ith ater is 30
min. and the phone must not be submerged to depths
greater than 1m. Yet it has to be completely protected
against ater. In case of contact, respectively immersion
in ater, remove it from the ater as soon as possible
and let it dry.
When deploying all covers make sure that there is no dirt
on the seal caps , that they seal properly and are fully
deployed.
When the phone or its part got into contact ith ater,
dry it thoroughly before operating it. Especially dry all
caps, folds, crevices and holes for the speaker,
earphone and microphone. Never open the cover on the
back of the phone or at the connector after the phone
came into contact ith ater ithout being properly dried
out before.
In case of contact ith ater, do NOT tamper ith the
phone, press any buttons nor tamper ith hole caps.
Protect microphone, earphone and loud-speaker
openings from the dust of sharp objects
Do not s itch on and do not use the mobile phone in the
prohibited areas
3

Do not use the mobile phone hile driving the car
Do not use the mobile phone near the filling petrol station
Turn off the mobile phone al ays near explosives
Use al ays original batteries supplied by the producer
(danger of damage or explosion of the mobile phone)
SAR – mobile phone meets the prescription for maximal
emission of the electromagnetic radiation.
While making a call please keep the mobile phone at
least 2-3 cm a ay from the body to minimalise the
quantity of the el.magnetic radiation absorbed by your
body.
Handle your cell phone and accessories ith care ,
protect it from mechanical damage and impurity
Protect the mobile phone and accessories from the
extremely high temperatures
Do not put the battery at the fire and do not expose it to
the temperature over +60°C (danger of explosion or fire)
Protect the mobile phone and accessories from the fall to
the ground
Never put the mobile phone into parts !
Turn off the mobile phone near the sensitive medical
devices unless you are sure that the radio transmission
of the mobile phone does not influence its functions.
Mobile phone can affect the function of the electronic
cardiac pacemaker or other implanted apparatus –
please consult your medical doctor. In cases of
suspected violation turn off the phone immediately !
S itch off the cell phone al ays in the aicraft
Turn off the mobile phone al ays near explosives
Do not place the mobile phone or its holder in the car at
the place over the airbags
4

Keep it out of reach of the children and do not allo them
to play ith. It contains small parts that can be
suffocated or may hurt !
Soft are and hard are of the mobile phone are
continuously updated. The importer reserves the right to
alter the instruction manual or mobile phone functions
ithout a prior notice.
Your phone has a very po erful flashlight. So never
touch her in your eyes. Danger of glare or dazzle!
5

Your Mobile Phone
1. Earphone
2. Screen
3. Left function button
4. Button for calling
5. Connector for
charger and earphones
6. Numeric keypad
7. Navigation button
8. Right function button
9. Torchlight
10. Button to finish call
or S itch On
11. Button OK
12. Button * / SOS
13. Button 0 / torchlight
14. S itch of ringing /
vibration
6

lnsert SIM + Memory Cards and Battery
1. Unscre and remove the battery cover on the back side
of the phone
2. Insert carefully one or t o SIM cards at the slots under
the space for battery. Make sure that the SIM cards are
placed correctly ith the contacts to ards do n. The
battery must be removed hen placing of SIM cards.
3. Insert the MicroSD card at the slot
4. lnsert the battery
5. Put the cover back and tighten the supplied scre s.
Scre s must be tightened but make sure not to damage
the threads by an accessive force. You can use the
enclosed scre driver (optional accessories).
Battery Charging
The indicator of charging level is placed at the upper part of
the screen. In case the battery is discharged proceed as
follo s :
1. Connect the charger ith the electrical net ork
2. Open the cap of the connector on the bottom side
part of the phone
7

3. Connect the charger ith the mobile phone
4. When the battery is fully charged please
disconnect the charger from the mobile phone and
from the electrical net ork.
5. Close very carefully the cap of the connector and
press it on its place. In case you do not press it
carefully and control it, the ater can penetrate
inside of the mobile phone !
The mobile phone can be charged both in the switch on and
in switch off mode.
In case the battery is totally discharged (after a long time of
non-using), it can take even tens of minutes till the indicator of
charging level appears and till the mobile phone can be
switched on and started to be used.
Switch On / Switch Off
Press and hold the button (10) to switch on, to end the call or
to s itch off the mobile phone.
You can end the call or application event. you can return to
the main screen by a short press of this button (10).
In case the lock of the cell phone is activated please insert the
pass ord. The default password is 1234
Time and Date are set automatically if your operator supports
this option or you can set it manually.
8

Making Calls
Enter the tel.number ith the use of the keypad buttons and
press the button (4). In case 2 SIM cards are inserted you ill
be asked to choose hich one ill be used for calling.
Keypad Lock
To set up the automatic keypad lock select in menu :
Setup > Safety > Automatic keypad lock
You can lock the keypad by pressing of button (10) on the
main screen
To unlock the keypad please first press the left button (3)
follo ed by a button *.
You can call emergency number 2 even if the keypad is
locked.
Volume
Volume level of the headphones can be adjusted during the
call by pressing of the navigation button Up/Do n (7)
For handsfree activation / loud listening – during the call
press the button OK (12)
Warning : Exposing to an excessive noise can damage your
hearing. Listen to the music with reasonable volume level and
do not hold the device close to the ear, especially by using of
a loud-speaker !
9

Position of Antennas
Device is provided ith internal antennas for the reception
and transmission. Antennas are placed at the upper and
bottom part of the phone. Do not cover the places here the
antennas are placed.
While making a call please keep the mobile phone at least 2-3
cm a ay from the body to minimalise the quantity of the
el.magnetic radiation absorbed by your body.
Covered antennas may influence the intensity of transmission
and also the battery life.
Insert of Text
Keypad of the cell phone enables to enter not only the digits
but also the letters/characters.
In case of inserting of the characters each button offers to
rite several letters. For example the button „2“ can rite the
letters A, B and C. A gap can be ritten ith a button „0“.
You can insert the letter by repeated presses of a button,
everal times in quick succession till the correct letter on the
screen displays. For example : letter A is the first in line it
means you press only once the button 2. Letter C is the third
in line it means you press quickly the button 3 times.
1. With the button # you can s itch ( hen you rite text)
bet een the riting small and capital letters and digit
mode
2. With the button * you can insert the special characters
10

Telephone Directory
Numbers of your telephone contacts can be stored both at the
SIM card memory and at the memory of the cell phone.
Dialing numbers from your contact list
The simplest ay to display the list, press the right function
key "Contacts" (8). No you can enter the name you are
looking for. After that immediately a list of matching contacts
ill jump.
Move the button up and do n to select the contact you ant
to call and press the call button (4).
When vie ing the list, the icon (silhouette) appears by each
contact in case the contact is stored in the phone's memory.
When a contact is stored on the SIM card, the icon of a card
and a number of a SIM card appear.
Torchlight
Turn On/Off a Torchlight (9) positioned on top of the phone by
holding of the button 0(13). You can toggle each lamp mode
by repeatedly holding do n the button 0 (13).
ATTENTION! The flashlight is very po erful! Never point a
flashlight into the eyes, there is a risk of glare or even damage
to the eye! After inserting of the battery the lamp al ays lights
itsself ! Make sure that the light is not directed at anyone's eye
hile inserting a battery!
11

Speed Dial
Favourite functions can be assigned to one press of one of
the 4 directional sides of the navigation button (7). Such a
function ill start after the press of one of the direction.
For example : camera ill start to ork after pressing of the
directional button „up“ (set up from the production)
To change the settings, go to the menu:
Setting  Telephone  Speed Dial
SOS function
In case the SOS feature is enabled, you can:
press the * (12) button long to start the loud siren
press the * (12) t ice to start an emergency call on the
preset numbers. SMSs ith emergency text are also
sent to these numbers
To set the tel.numbers and texts, go to the menu:
Setting  SOS setting
Safety and Ecology
Used electric device
Mobile phone is an electronic appliance. It means
it must not be manipulated as a common
residential aste! Never throw the used electric
device away at the common municipal waste!!!
12

Hand over the used electric device to the respective collection
point hich provides the ecological liquidation. Please contact
your dealer to get more information ho to deal ith the used
products.
Battery liquidation
Used/old batteries and accumulators do not
belong to the common residential waste !!!
They may contain the substances dangerous to the
environment.
Hand over the battery to the respective collection point hich
provides the ecological liquidation. Please contact your
dealer to get more information ho to deal ith the used
products.
Handling with the used batteries in contradiction with
given instructions is illegal!
Declaration of Conformity
ADART COMPUTERS s.r.o. hereby declares that the type of
the radio device ALIGATOR R15 is in accordance ith the
directive 2014/53/EU.
Issued in Prague
Copyright © 2018
ADART COMPUTERS s.r.o.
.aligator.cz
13
