Alinco DJ - C7 T User manual

DJ – C7 T/E
Service Manual
CONTENTS S
SPECIFICATIONS
General…..……………………………..…….……
Transmitter…….……………………..……………
Receiver….………………………………..………
CIRCUIT DISCRIPTION
1) Receiver System……….……………………….
2) Transmitter System……………………………..
3) M38268MCL069GP (XA1023)……..…………
SEMICONDUCTOR DATA
1) NJM2070M (XA0210)…………………………
2) TC4W53FU (XA0348) ………………………..
3) XC62HR3302MR (XA0519)..…………………
4) BA4510FV (XA0537)…..……………………..
5) NJM2904V (XA0573)…..……………………..
6) TK10931V (XA0666)…..………………………
7) BU9831F (XA0882)……………………………
8) uPC2771TB (XA0953)…………………………
9) uPC2757TB (XA0976).….……………….…….
10) BR24L32FV (XA1008)………………………...
11) BD4930FVE (XA1009)…..…………………….
12) MB15A01PFV1 (XA1010)……………….……
13) XC6383A701MR (XA1012).…………………..
14) MM1438BW (XA1013).………………….……
15) TC75S51FU (XA1014)………………………...
16) Transistor, Diode and LED Outline Drawing…..
17) LCD Connection (A48A002X)…………….…..
EXPLODED VIEW
1) Front View…………….………………………..
2) Rear View……………………….………….…..
2
2
2
3-5
6
7-9
10
10
10
10
11
11
11
12
12
12
12
13
13
14
14
15
16
17
18
PARTS LIST
MAIN Unit..……………………………………….
KEY Unit…………..………………………………
BATTERY Unit..…………………………….…….
PTT Unit…………………………………………..
ROTARY ENCODER Unit………………………..
Mechanical Parts…………………………………..
Packing Parts………………………………………
ADJUSTMENT
1) Required Test Equipment..……………………...
2) Entering and Releasing the Adjustment Mode….
PC BOARD VIEW…………………………..
SCHEMATIC DIAGRAM………………...
BLOCK DIAGRAM………………………...
19-22
22-23
23
23
23
23
23
24
25-28
29-33
34-35
36
ALINCO, INC.
www.ALINCO.ru

2
SPECIFICATIONS
General
Type DJ – C7T DJ-C7E
VHF 144.000 – 147.995MHz 144.000 – 145.995MHz
Transmitter Range UHF 420.000 – 449.995MHz 430.000 – 439.995MHz
WFM 88.100 – 1.7.995MHz 87.500 – 107.995MHz
VHF 108.000 – 173.995MHz 144.000 – 145.995MHz
Receiving Range
UHF 380.000 – 511.995MHz 430.000 – 439.995MHz
Modulation F3E
Operating temperature -10 °C ~ 60°C (+14°F ~ +140°F)
Frequency stability -7 ~ +3 ppm
Antenna impedance 50ohm unbalanced (SMA)
Supply Voltage 3.7 – 6.0VDC (External)
Ground method Negative ground
DC6.0V: VHF Approx. 0.28A, UHF Approx. 0.32A
Transmit 3.7V(EBP-58N): VHF Approx. 0.25A, UHF Approx. 0.30A
Receive Approx. 70mA
Current drain
Battery Save Approx. 19mA
Dimensions (Projection exclusive) 58 (w) x 96 (h) x 14.5 (d) mm
Weight Approx. 102g (EBP-58N inclusive)
Transmitter
Type DJ-C7T DJ-C7E
DC6.0V Approx. 0.5W
Output power EBP-58N equipped Approx. 0.3W
Modulation System Variable reactance frequency modulation
Maximum Frequency Deviation +/- 5kHz
Spurious Emission - 60 dB c or less
Microphone impedance Approx. 2kohm
Receiver
Type DJ-C7T DJ-C7E
Receiver circuit Double conversion super-heterodyne
1st 50.85MHz (FM/AM), 10.7MHz (WFM)
Intermediate frequency 2nd 450MHz (FM/AM)
Sensitivity (12dB SINAD)
144.000 – 147.995MHz
420.000 – 449.995MHz
-15dBu or less
144.000 – 145.995MHz
430.000 – 439.995MHz
-15dBu or less
Audio output power 100mW or more (Max) / 90mW or more (8ohm, 10 % THD)
Spurious response 60 dB or less
Squelch sensitivity Approx. - 18 dBu or less
! NOTE: All specifications are subject to change without notice or obligation.
