Allegion Olivari PT Series User manual

*47280190*
47280190
2 Install spindle with spring, side 1.
a
bc
3 Install spring cage, side 1.
a
b
c
d
Arrow matches
down rotation of lever
Insert mounting post
thru #3 position of
spring cage as shown
3
3
4 Install spindle/spring/spring cage, side 2.
(reverse angle)
a
Insert spindle
and spring.
Arrow
matches
down
rotation
of lever.
Insert mounting post
thru #3 position of
spring cage as before.
Long post feeds into short post on
opposite side and vice versa as shown
below.
Door
edge
long
short long
short
3
3
c
b
5 Hand thread screws into mounting posts on opposite side,
then fully tighten.
Flush with
channel
Flush with
channel
(reverse
angle)
PT9000 Series, Rose Installation Instructions
PT-Series Mortise Trim
Door Handing
IMPORTANT! Check lock handing before installation.
If necessary to change handing:
1. Pull out the latch and rotate 180°.
2. Handing screw must be installed on the interior side of the chassis. If necessary, move
the screw to the opposite side.
Handing screw
(install on interior side)
Pull and
rotate 180°
1 Install lock chassis and lightly tighten screws.
LDo not fully tighten chassis mounting screws at this time.
Ø ⁷⁄₈" (22)
for Thumbturn
Non-Standard
prep
4⁷⁄₁₆" x 6¹⁄₆" x 1"
(113 x 154 x 25mm)
Parts
H
J
G
F
C
I
K
B
E
A D
Required Supplied
Phillips
screwdriver
3mm
hex key
2.5mm
hex key (thumbturn only)
installation
aid
Tools
L
N
M
Q
P
Optional
thumbturn
O R
Parts
A Spindles (2)
B Springs (2)
C Left hand spring cage
D Right hand spring cage
E Mounting posts (2)
F Mounting screws (2)
G Surface mount screws (4)
H Left hand lever/rose
I Right hand lever/rose
J Set screws (2)
K 3mm hex key
Optional Thumbturn Parts
L Spindle
M Surface mount screws (4)
N Rose
O Nylon bushing
P Thumbturn
Q Set screw
R 2.5mm hex key

© Allegion 2020
Printed in U.S.A.
47280190 Rev. 02/20-a
10Install thumbturn, if applicable.
a. Install spring cage.
align mounting
holes to centerlines
on door
(reverse angle)
inserts into
door hole
a
b. Secure spring cage with surface mount screws.
b
c. Install rose as shown.
d. Snap it into place.
Slot at
bottom
Plastic
washer Snaps in
place
c d
e. Install thumbturn.
f. Tighten set screw.
Tighten
set screw
2.5mm
hex key
e
f
11For thumbturn, install emergency privacy button.
12Check thumbturn operation.
Conrm smooth operation. With door locked, cycling inside lever should rotate thumbturn
to vertical unlocked position and retract deadbolt.
Rotate
inside
lever
13Tighten screws.
Fully tighten mortise lock chassis mounting screws.
14Install armor front.
6 Check lever operation.
Conrm smooth operation with no sticking.
If not operating smoothly, perform these steps:
a. Slightly loosen spring cage mounting screws.
b. Conrm function by cycling lever.
c. Temporarily slide lever onto spindle. Conrm lever is horizontal with no lever droop.
d. Retighten spring cage mounting screws.
7 Install surface mount screws.
8 Install lever/rose.
Tighten set screw
with 3mm hex key
Set screw
backed out
a
Set screw
on underside
Press
against lever
Notch
With notch at bottom,
press against lever while
turning rose slightly
counter-clockwise to
align with grooves on
spring cage, then turn
rose 1/4 turn clockwise
to lock lever in place.
Release lever.
HINT: Use supplied
band to more easily
turn the rose.
Groove
b
c
d
band
9 Repeat previous step to install rose/lever on opposite side of
door.
