Allen + Roth L-PG152PST-B User manual

PERGOLA
ITEM #0878763
MODEL #
L-PG152PST-B
Serial Number Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Friday.
AB 17781
ATTACH YOUR RECEIPT HERE
26
1
TM
Español p.19

2
PACKAGE CONTENTS
N
J
PQ
I1
I1
I2
I2
K3
K2
K2
K3
K1
L1
L2
K1
K1
O
M
J
A2
M
A2
H1
G2
B2 G1
H1
I1
H2 K2
K1
G2
G1
I2
D1
I2
D2 G2
K3
K1
K2
K3
L2
L1
H2
A1
G1
G2
C1
K1
I1
A1
C2 B1
M
E
E
F
O

3
PACKAGE CONTENTS
A1
A2
B1
B2
C1
C2
Post 1
Post 2
Top Arc Beam 1
Top Arc Beam 2
Top Beam 1
Top Beam 2
Top Beam 3
Top Beam 4
PART DESCRIPTION QUANTITY
2
2
2
2
2
7
7
2
2
4
4
2
2
2
2
4
4
2
2
4
2
2
2
Connector 1
Connector 2
Support Bar 2
Support Bar 3
Support Bar 4
Fabric Tube Connector
K3
L1
L2
M
Rail Tube Connector 3
Fabric Tube 1
Fabric Tube 2
Rail Tube
4
2
4
O
P
Q
Ferrule
Base Cover
Base
1N Canopy
Post Decoration
Beam Decoration
D1
D2
E
F
G1
I1
I2
J
Rail Tube Connector 1
K1
Rail Tube Connector 2
K2
G2
H1
H2
Support Bar 1

4
HARDWARE CONTENTS (not shown to size)
Qty. 98 + 11 spare Qty. 16 + 2 spare Qty. 132 + 14 spare Qty. 48 + 5 spare
AA BB KKII
M6 x 15 mm
Short Bolt
M6 x 12 mm
Bolt
M8 x 20 mm
SS Bolt
M6 x 15 mm
SS Short Bolt
M6
Washer
M6 SS
Washer
M6 x 56 mm
SS Middle Bolt M6
SS Nut
M6
Plastic Cap
Qty. 16 + 2 spare
CC DD GGHH
Qty. 16 + 2 spare Qty. 16 + 2 spareQty. 116 + 12 spare
Qty. 2
M6
Wrench
ZZ
Qty. 4
M6 x 70 mm
Long Bolt Φ8 x180 mm
Stake
Qty. 16Qty. 30 + 3 spare
Qty. 1
M8
Wrench
XXEE FF
JJ

SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or
install the product.
• Keep all children and pets away from assembly area. Children and pets should
be supervised while pergola is being assembled.
• This pergola is for domestic outdoor use.
• Install the pergola on level ground. Stakes are provided to secure the pergola to
the ground. Do not assemble the pergola on sandy, muddy or loose soil, as
stakes do not have enough holding strength in these types of soil. If you wish to
secure the pergola to a wood deck or concrete surface, use anchors suited to
these surfaces (anchors not included).
• Some parts may contain sharp edges. Wear protective gloves if necessary
during assembly.
• This unit is heavy. DO NOT assemble this item alone. Make sure there is
sufficient manpower for safe assembling or moving of the pergola.
• Check all nuts and bolts periodically for tightness and when required, tighten
them again.
• ALWAYS REMOVE the tent before experiencing heavy wind conditions, as
it is a semi-permanent construction and not designed to withstand harsh
weather, including high wind or heavy rain and snow.
• Keep all flame and heat sources away from the tent fabric. This tent is made
with fabric that meets CPAI-84 specifications for flame resistance. It is not
fire proof. The fabric will burn if left in continuous contact with any flame
source. The application of any foreign substance to the tent fabric may render
the flame-resistant properties ineffective.
WARNING
• DO NOT use or enter the pergola during harsh weather (e.g. thunderstorms,
high winds, hail, heavy snow, etc). In these conditions, it might tip over and
could cause serious injury to bystanders. Any damage or injury caused by
these conditions is not covered by the warranty.
• DO NOT install the pergola adjacent to trees a sloped roof. Snow and ice
may slide onto the pergola and cause it to collapse.
• DO NOT hang any weights on the roof frame.
• DO NOT use a ladder leaning against the pergola for climbing onto the roof.
• Keep away from heat or flame sources.
• If the pergola will not be used for a long period of time (e.g. during winter
time), disassemble and store it in a clean, dry environment.
CAUTION
5

PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare
parts with package contents list and hardware contents list. If any part is missing
or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 90 minutes
Tools Required for Assembly (included): Wrench.
Tools Required for Assembly (not included): Phillips screwdriver, hammer, and
ladders (no less than 8.2-feet tall).
4 people are needed for assembly. A safety helmet should be worn during
assembly.
6

7
ASSEMBLY INSTRUCTIONS
1. Insert the posts (A1, A2) into the base
covers (P), then attach the bases (Q) to the
posts (A1, A2) using bolts (AA) and
washers (BB). Tighten with wrench (ZZ).
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 16
x 16
M6 Wrench
ZZ x 1
1
AA BB
A1 A2
P
Q
A2
G1
A2
P
P
P
P
O
O
A1
A1
G1 C2
G2
B1
B2
C1
G1
G2
G1
G2
C2
B1
C1
B2

8
ASSEMBLY INSTRUCTIONS
•
2. Attach the post decorations (G1) to the
posts (A1, A2) using bolts (CC). Tighten
with wrench (XX). Note: Make sure to
install the post decorations (G1) facing
the same direction as seen in the image
at right to ensure the holes are properly
aligned with the posts.
2
AA
3-2. Insert the other ends of connectors 1
(E) to the top beams 2 (C2), secure
with bolts (AA) and washers (BB),
tighten with wrench (ZZ) and cover
bolts with plastic caps (DD).
3-1. Insert the connectors 1 (E) to the top
beams 1 (C1), secure with bolts (AA)
and washers (BB), tighten with wrench
(ZZ) and cover bolts with plastic caps
(DD).
3-1
Hardware Used
CC M8 x 20 mm SS Bolt
XX M8 Wrench
x 16
x 1
3-2
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 6
x 6
M6 Plastic Cap
DD x 6
M6 Wrench
ZZ x 1
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 6
x 6
M6 Plastic Cap
DD x 6
M6 Wrench
ZZ x 1
CC
AA
A1 A2
A1 A2
G1 G1
3-1
BB
DD
AA
C1
E
3-2
DD
AA
BBC1
C2
E
G1

9
ASSEMBLY INSTRUCTIONS
4. Attach the assembled top beams (C1, C2)
to the post decorations (G1) using bolts (II)
and washers (KK), tighten with wrench
(ZZ) and cover bolts with plastic caps (DD).
5-1. Insert the ferrule (O) to the top arc
beams 1 (B1), then attach the top arc
beams 1 (B1) with the connector 2 (F)
using bolts (AA) and washers (BB),
tighten with wrench (ZZ) and cover bolts
with plastic caps (DD).
5-2. Attach the top arc beams 2 (B2) with the
connector 2 (F) using bolts (AA) and
washers (BB), tighten with wrench (ZZ)
and cover bolts with plastic caps (DD).
11
5-2
11
5
11
4
11
6
11
5-1
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 6
x 6
M6 Plastic Cap
DD x 6
M6 Wrench
ZZ x 1
Hardware Used
II M6 x 15 mm SS
Short Bolt
KK M6 SS Washer
x 16
x 16
M6 Plastic Cap
DD x 16
M6 Wrench
ZZ x 1
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 6
x 6
M6 Plastic Cap
DD x 6
M6 Wrench
ZZ x 1
11
5
11
4
DD
KK
II
G1
A1
C2 C1
A2
B1
AA
BB
DD
11
6
11
5-1
F
O
11
5-2
B1
B2
F
O

10
ASSEMBLY INSTRUCTIONS
5-3. Move the ferrule (O) to the middle of
assembled top arc beams (B1, B2),
secure with bolts (AA) and washers (BB),
tighten with wrench (ZZ) and cover bolts
with plastic caps (DD).
7-25-3
6. Connect the assembled top arc beams
(B1, B2) with the beam decorations (G2)
through the holes of assembled top
beams (C1, C2) using bolts (HH),
washers (KK) and nuts (GG), tighten with
wrench (ZZ) and cover bolts with plastic
caps (DD).
12-1
8
12-1
6
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 4
x 4
M6 Plastic Cap
DD x 4
M6 Wrench
ZZ x 1
Hardware Used
GG M6 SS Nut
HH M6 x 56 mm SS
Middle Bolt
KK M6 SS Washer
M6 Plastic Cap
DD
M6 Wrench
ZZ
x 16
x 32
x 16
x 16
x 2
7-25-3
BB
AA
DD
B2
B1 O
12-1
8
12-1
6
DD
KK GG
G2 G1
C1 C2
B2 B1
HH
KK

11
7. Attach the supports 2 (H2) to the posts 1
(A1) and the top beams 2 (C2) using bolts
(AA) and washers (BB), tighten with
wrench (ZZ) and cover bolts with plastic
caps (DD).
Repeat this step for attaching the supports
4 (I2) to the posts 1 (A1) and the top arc
beams 1 (B1), attaching the supports 1
(H1) to the posts 2 (A2) and the top beams
1 (C1), attaching the supports 3 (I1) to the
posts 2 (A2) and the top arc beams 2 (B2).
7
ASSEMBLY INSTRUCTIONS
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 32
x 32
M6 Plastic Cap
DD x 32
M6 Wrench
ZZ x 1
7
AA BB
DD
DD
C1
C2
B2B1
A1
H1
I1 I2 H2
A2
A1
G1
K1
H2
L1
L1
L2
L2
A2
A2
I2
N
M
O
P
P
P
M
I1
A1
K2
K2
K3

12
ASSEMBLY INSTRUCTIONS
8. Connect top beams 3 (D1) with top beams
4 (D2), then secure with bolts (AA) and
washers (BB).
14
9. Attach the assembled top beams (D1, D2)
to the assembled top arc beams (B1, B2)
using bolts (EE) and washers (BB).
9
10. Place the fabric tube connectors (J) onto
rail tubes (M) through the bottoms of the
rail tube (M).
10
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 14
x 14
M6 Wrench
ZZ x 1
Hardware Used
EE M6 x 70 mm
Long Bolt
BB M6 Washer
x 14
x 14
M6 Wrench
ZZ x 1
13
8
AA
D2
D1
BB
14
9
BB
BB
EE
EE
D1
D1
D2
D2
B2
B1
10
J
M

13
ASSEMBLY INSTRUCTIONS
12. Insert the rail tubes (M) to the rail tube
connectors 2 and 3 (K2, K3), then
secure them to posts (A1, A2) using
bolts (EE) and washers (BB). Tighten
with wrench (ZZ) and cover bolts with
plastic caps (DD).
12
11. Insert the rail tubes (M) to the rail tube
connectors 1 (K1), then secure them
to posts (A1, A2) using bolts (EE) and
washers (BB). Tighten with wrench (ZZ)
and cover bolts with plastic caps (DD).
11
13. Insert the fabric tubes 1 (L1) to the fabric
tubes 2 (L2), then secure with bolts (JJ)
and washers (BB). Tighten with wrench
(ZZ).
13
Hardware Used
JJ M6 x 12 mm Bolt
BB M6 Washer
x 4
x 4
M6 Wrench
ZZ x 1
Hardware Used
M6 Wrench
ZZ x 1
M6 x 70 mm Long Bolt
EE x 8
BB M6 Washer x 8
M6 Plastic Cap
DD x 8
Hardware Used
M6 Wrench
ZZ x 1
M6 x 70 mm Long Bolt
EE x 8
BB M6 Washer x 8
M6 Plastic Cap
DD x 8
12
DD
EE
BB
A1A2
K2 K3
M
11
DD
EE
BB
K1
J
M
A1(A2)
BB
K1
A2
A1
EE DD
M
J
L1
L2
BB
JJ
1313
L1
L2
BB
JJ

16
A1 A2
J
M
K3K2
14
ASSEMBLY INSTRUCTIONS
15. Attach the fabric tube connectors (J) to
the assembled tubes (L1, L2) using bolts
(AA) and washers (BB). Tighten with
wrench (ZZ) and cover bolts with plastic
caps (DD).
15
14. Place the canopy (N) on the top of the
pergola, then insert the assembled
tubes (L1, L2) into the hemline of the
canopy.
14
16. When pulling down canopy (N), make
sure it is secured in place with clasps on
the rail tube connectors (K2, K3) to the
rings of fabric tube connector (J).
16
Hardware Used
AA M6 x 15 mm Short Bolt
BB M6 Washer
x 8
x 8
M6 Plastic Cap
DD x 8
M6 Wrench
ZZ x 1
14
N
L2
L1
15
AA BB
DD J

• The steel components for this pergola are treated with rust inhibiting paint that
protects it from rusting. However, due to the nature of steel, surface oxidation
(rusting) will occur if these protective coatings are scratched. This is not a defect
and thus not covered by the warranty.
• To minimize this condition, it is recommended to use care when assembling and
handling the product to prevent scratching the paint. Should any scratch or
damage occur, it is recommended to cover the scratch immediately with rust
inhibiting paint (not included). Surface rust can also be easily removed with a
very light application of regular cooking oil. If surface oxidation (rusting) occurs
and if no preventive measure is taken, the oxidation may start dripping onto the
deck or patio and cause damaging stains, which may be difficult to remove.
This can be prevented if the above-mentioned measures are taken to keep the
product from oxidizing.
• Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts.
• Keep instruction manual for future reference.
• Keep the original packaging to store the pergola.
ONE-YEAR LIMITED WARRANTY
workmanship of your item provided the item is maintained with care
and used only for personal, residential purposes.
The manufacturer warranty for this item, is to be free of defects in material and
workmanship for a period of one year. If any defect is found, please call our
customer service department at 1-866-439-9800 for help. The manufacturer will
not cover transportation or delivery costs or compensate the individual or any
outside party for assembling or disassembling the product. This warranty gives
you certain rights, and you may have other rights that vary from state to state.
CARE AND MAINTENANCE
15
ASSEMBLY INSTRUCTIONS
17. Lift the base covers (P) and secure the
assembled pergola to the ground with
stakes (FF). Your pergola is now fully
assembled.
17
Hardware Used
FF Φ8 x180 mm Stake x 16
17
FF FF FF
P
A1 A2
Q

For replacement parts, call our customer service department at 1-866-439-9800,
8 a.m. - 8 p.m., EST, Monday - Friday.
REPLACEMENT PARTS LIST
16
A1 B1
B2A2
C1 C2
D1
G1
H1 H2 I1
I2
G2
D2
E
J K1
L1
L2 M
O P Q
K3
K2
F
N

17
REPLACEMENT PARTS LIST
AA BB KKII
CC DD GGHH
ZZXXEE FF
JJ
PART
AA
II
BB
KK
CC
HH
M6 x 15 mm Short Bolt
M6 x 15 mm SS Short Bolt
M6 Washer
M6 SS Washer
M8 x 20 mm SS Bolt
M6 SS Nut
DESCRIPTIONPART#
DD
GG
H02015C11
H02015C31
H19001C11
H19001C31
H04020C31
H02056C31
P91204A07001
H14001C31
Φ8 x180 mm Stake
M6 x 70 mm Long Bolt H02070C11
P12401A01001
EE
FF
M6 Wrench
M8 Wrench H00002C12
H00001C12
XX
ZZ
M6 x 12 mm Bolt H02012C11JJ
M6 x 56 mm SS Middle Bolt
M6 Plastic Cap

Production Number：xxxxxxxx
18
Printed in China
REPLACEMENT PARTS LIST
A1
A2
B1
B2
C1
C2
Post 1
Post 2
Top Arc Beam 1
Top Arc Beam 2
Top Beam 1
Top Beam 2
Top Beam 3
Top Beam 4
PART
Connector 1
Connector 2
Support Bar 2
Support Bar 3
Support Bar 4
Fabric Tube Connector
K3
L1
L2
M
Rail Tube Connector 3
Fabric Tube 1
Fabric Tube 2
Rail Tube
Post Decoration
Beam Decoration
D1
D2
E
F
G1
I1
I2
J
Rail Tube Connector 1
K1
Rail Tube Connector 2
K2
G2
H1
H2
Support Bar 1
P11119A01123
P11035B01122
P11036B01122
P11120A01123
P11037A01122
P12709A01122
P12710A01122
P11038A01122
P11407A01122
P12902A01122
P10007A01122
P11408A01122
P11816A01122
P11814A01122
P11815A01122
P11409A01122
P12812A01122
P12813A01122
P12814A01122
P12811A01122
O
P
Q
Ferrule
Base Cover
Base
P10903A01122
P11510A01122
P11610A01122
NCanopy P00102N12042
P12810A01122
P12809A01122
P11817A01122
DESCRIPTIONPART#

19
TM
Número de serie Fecha de compra
¿Preguntas, problemas, piezas faltantes?
ADJUNTE SU RECIBO AQUÍ
PÉRGOLA
ARTÍCULO #0878763
MODELO #
L-PG152PST-B
Antes de volver a la tienda, llame a nuestro
Departamento de Servicio al Cliente al 1-866-439-9800, de lunes a viernes de 8 a.m. a 8 p.m.,
hora estándar del Este.

20
CONTENIDO DEL PAQUETE
N
J
PQ
I1
I1
I2
I2
K3
K2
K2
K3
K1
L1
L2
K1
K1
O
M
J
A2
M
A2
H1
G2
B2 G1
H1
I1
H2 K2
K1
G2
G1
I2
D1
I2
D2 G2
K3
K1
K2
K3
L2
L1
H2
A1
G1
G2
C1
K1
I1
A1
C2 B1
M
E
E
F
O
