Allen + Roth MCLEAN GSS00405A User manual

MCLEAN HANGING
DAYBED
Thank you for purchasing this allen + roth product. We’ve created these easy-to-follow instructions to ensure you spend your time enjoying the product
instead of putting it together. But, if you need more information than what is provided here, please visit Lowes.com, search the item number and refer to the
Guides & Documents tab on the product’s page.
ITEM#4140545
MODEL#GSS00405A
Printed in China
FEELING CONFIDENT? START YOUR NEXT PROJECT
• Visit www.lowes.com for more information.
Please read and understand this entire manual before attempting to assemble, operate or install the product.
SAFETY INFORMATION
If you have any questions or problems, please call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list.
If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 30 minutes
NO ADDITIONAL TOOLS REQUIRED
CARE AND MAINTENANCE
• Before using, clean the product completely with a soft, dry towel.
• When not in use, wipe free of any dirt or loose objects, wash with a mild solution of soap and water, rinse and dry completely.
• Do not use strong detergents or abrasive cleaners.
• Store the product in a cool, dry location away from sunlight.
ALLEN + ROTH and logo design are trademarks
or registered trademarks of LF, LLC. All rights
reserved.
You could also contact us at [email protected] or visit www.lowespartsplus.com.
WARRANTY
This warranty is extended to the original purchaser and applies to defects in materials and workmanship of your patio furniture provided your furniture is
maintained with care and used only for personal, residential purposes.
Frames are warranted to be free from defects in material or workmanship for a period of one (1) years.
Cushions, straps and/or wicker weaves are covered for a period of one (1) year against defects in material or workmanship.
SAFETY INFORMATION
• Use and carry this item with care and apply touch-up paint (not included) when necessary.
• This outdoor furniture is designed and made for personal non-commercial use.
• This item should not be used as a toy or a tool.
• Do not locate the product near any heat source.
CAUTION
WARNING
• Tighten each bolt firmly and properly. Do not completely tighten screws until all screws are started.
• Some parts may contain sharp edges. Wear protective gloves as necessary.
• Children under the age of 16 should not be engaged in the assembly, removal or disassembly of the product.
• Children under the age of 10 should be supervised by a competent adult while using this furniture.
• Please keep children out of the assembly area during assembly.
• This swing is heavy, and may require two adults for safe assembly.
• Never use this product as a support. Do not shake, lean, or climb on the product at any time.
• Do not overtighten any of the bolts as this may damage the threads.
• Repeated assembly can weaken the locking ability of the washers.
• Periodically check all bolted connections on the furniture to make sure they are tight and secure.
• Retain these instructions for future reference.
• Paint on this product might peel off if it is hit or used improperly.
CAUTION
WARNING: MAXIMUM WEIGHT CAPACITY: 250 LBS PER SEAT.
Not intended for commercial use. Proper use of this swing is for three person seating only. Do not stand on swing or use as a step ladder.
For optimum safety, use on even surface only! Improper use of this product or failure to use or assemble as directed may result in injury.
SM21544

PACKAGE CONTENTS
HARDWARE CONTENTS
2
1
3
QUICK REFERENCE GUIDE
QUICK REFERENCE GUIDE
Note: Hardware not shown actual size.
INSTALLATION OVERVIEW
INSTALLATION OVERVIEW
3
A
4
56
A
x 1
B
DE
CHG
F
x 1
x 1
x 1 x 1
x 4
x 2
x 1
AA BB CC DD EE FF GG HH
x 6
x 4
x 4
x 4
x 4
x 4
x 1 x 1
ASSEMBLE ON A SOFT SURFACE, SUCH AS A CARPET, TO AVOID SCRATCHING THE PRODUCT.
A
B
AA
A
C
AA
Hand tighten AA. Do not tighten until all bolts have been installed. Hand tighten AA. Do not tighten until all bolts have been installed.
Hand tighten BB, CC, DD, EE . Once all bolts have been installed and
hand tightened, go back and tighten firmly with wrench.
H
FG
A
DE
BB
CC
EE
DD
I
x 4
I
5 6
7
FF
3/8 ”
2.75”
WARNING: EYE HOOKS (PART FF) MUST BE ANCHORED IN
CEILING JOISTS. SERIOUS INJURY CAN OCCUR IF EYE HOOKS
ARE NOT PROPERLY INSTALLED.Drill four (4) 3/8 " pilot holes into
ceiling joists at the proper position. Holes should be 79.1" apart in
width and 34.5" apart in depth. Ceiling joists must be at least 2.75" H
and 2.17" W. Screw eye hook (FF) into pre-drilled holes.
2.17”
I
FF
21.65”
6”
Step 1
Step 2
Step 3
Step 4
Step 5
WARNING: FAILURE TO PROPERLY TIE KNOT CAN RESULT IN
SERIOUS INJURY.Using two people to help, lift swing up and tie
knot following steps 1-5 above.
Proper distance from the ground is indicated above.
Ground
14.17 ” ~15.75”
18.11 ” ~19.68 ”
34.5” 79.1”
