Allen + Roth TPPER9137 User manual

5376015#METI
SOFT - TOP PERGOLA
MODEL #TPPER9137
ATTACH
YOUR RECEIPT HERE
AB24007
Español p. 17
Serial Number ___________
Purchase Date ___________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could
also contact us at [email protected].
ALLEN + ROTH and logo design are trademarks
or registered trademarks of LF, LLC.
All rights reserved.
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

TABLE OF CONTENTS
Package Contents ........................................................................................................................ 3
Hardware Contents ...................................................................................................................... 4
Safety Information ........................................................................................................................ 5
Preparation .................................................................................................................................. 5
Installation Instructions.................................................................................................................. 6
Care and Maintenance ................................................................................................................ 15
Warranty ....................................................................................................................................... 15
Replacement Parts List ............................................................................................................... 16
1 2 3 4 5 6
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

PACKAGE CONTENTS
DESCRIPTION T R A PT R A P
Post
Post
Arc Beam
Arc Beam
Beam
Beam
Connector
Connector
Connector
Arc Connector
Ferrule
Ferrule
A1
A2
B1
B2
C1
C2
E1
E2
E3
F1
F2
2
2
2
2
2
2
Top Beam
D14
2
2
7
4
7
Support Bar
Support Bar
Base Cover
Base
Sidewall Rod
Sidewall
Canopy
4
4
4
2
2
2
8
1
PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY
G
G1
H
I
J
K
L
N
M1
M2
F1
K
A1
L
A1
B1
F1
C1
B2
A2
G
A2
C2
D
N
N
D
E1
E2
E3
F2
G1
G
H
I
M1 M2
J
Canopy Holding Rod
Canopy Holding Rod
4
4
G1
1 2 3 4 5 6
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

M6 × 35 mm Bolt
Qty. + 2 Extra
Bolt
Qty. 4 + 1 Extra
Plastic Washer
Qty. 64 + 6 Extra
Cap
Qty.112+ 6 Extra
Ring
Qty. 20+ 2 Extra
Wrench
Allen Wrench
Qty. 1
tloBmm51×6M
Qty. 82 + 6 Extra
tloBmm51×6M
Qty. 8 + 1 Extra
Washer
Qty. 48 + 6 Extra
AA CC
GG
BB DD EE
JJ KKII
Stake
Qty. 12
LL
Qty. 1
HARDWARE CONTENTS (NOT TO SCALE)
M6 × 65 mm Bolt
Qty. 14 + 1 Extra
HH
FF
16
1 2 3 4 5 6
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

Please read and understand this entire manual before attempting to assemble or install the product.
. Three people are needed for assembly.
.
.
.
SAFETY INFORMATION
CAUTION
PREPARATION
WARNING:
KEEP ALL FLAME AND HEAT AWAY FROM THIS GAZEBO FABRIC.
The fabric may burn if left in continuous contact with any flame source.The application
of any foreign substance to the gazebo fabric may render the flame-resistant properties
ineffective.
Do not leave outside during high winds, heavy rains or snow. If high winds, heavy rains or snow
occurs, remove canopy and sidewall , clear snow load from roof, and check for damage
before continued use.
Before beginning assembly of product, make sure all parts are presented. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to assemble the product.
Estimated Assembly Time: 50 minutes
Tools Required for Assembly (included): Wrench
Tools Required for Assembly (not included):
Safety goggles Gloves Stepladder
Hard hat
1 2 3 4 5 6
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

A1
H
I
AA
HH AA HH
EE EE
A2
1Hardware Used
1.1. Insert the posts (A1/A2) into the base cover (H), then attach the bases (I) to the posts (A1/A2)
using bolts (AA) and washers (EE). Tighten with wrench (JJ). Place cap (HH) on the bolt heads.
1.2. Attach the connector (N) to the posts (A1/A2) by using the bolts (AA).
x24
x24
AA
EE
ASSEMBLY INSTRUCTIONS
HH AA EE
N
N
N
N
A1
A2
A1
A2
N
EE AA HH
HH AA EE
x1
JJ
x24
HH
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

ASSEMBLY INSTRUCTIONS
2.1.Insert the connectors (E1) to the beams (C1), secure with bolts (AA) and plastic washers (FF),
tighten with wrench (JJ). Place cap (HH) on the bolt heads.
2.2.Attach the ferrule (F1) to the beam assemblies (C1/E1).
2.3.Attach the beams (C2) to the beam assemblies (C1/E1/F1) and secure with bolts (AA) and
plastic washers (FF), tighten with wrench (JJ). Place cap (HH) on the bolt heads.
AA
FF
HH
C1
C1
C1 F1
E1
E1
C2
C2
C1 F1
AA
FF
HH
2Hardware Used
x6
x6
AA
FF
C2
C1 F1
AA
FF
HH
x1
JJ
x6
HH
123456
7 8 9 10 11 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

3. Attach the sidewall rod (J) to the beam (C1/C2), secure with bolts (AA) and plastic washers (FF),
tighten with wrench (JJ). Place cap (HH) on the bolt heads.
J
AA
FF
F1
HH
AA
FF
HH
C1
C1
J
J
J
J
C2
C2
C2
J
ASSEMBLY INSTRUCTIONS
3Hardware Used
x8
x8
AA
FF
x1
JJ
x8
HH
123456
78 9 10 11 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

4.1.Insert arc connectors (E2) to the arc beams (B1), secure with bolts (AA) and plastic washers (FF),
tighten with wrench (JJ). Place cap (HH) on the bolt heads.
4.2.Attach the ferrule (F1) to the beam assemblies (B1/E2).
4.3.Attach the arc beams (B2) to the arc beam assemblies (B1/E2/F1) and secure with bolts (AA)
and plastic washers (FF), tighten with wrench (JJ). Place cap (HH) on the bolt heads.
B1
B1
E2
E2
F1
F1
B1
AA
FF
HH AA
FF
HH
F1
B1
B2
B2
AA
FF
HH
AA
FF
HH
ASSEMBLY INSTRUCTIONS
4Hardware Used
x8
x8
AA
FF
x1
JJ
x8
HH
123456
7 8 9 10 11 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

5.1. Connect the assembled arc beams (B1/B2) to posts (A1/A2) through the holes on the posts
using bolts (BB) on a flat, non-abrasive surface. Tighten all bolts with Allen Wrench (LL).
5.2. Attach the supports bar (G1) to the beams (B1/B2) with bolt (CC/EE), connect the other
end of the supports bar (G1) to the connector (N) with bolt (CC/EE), then tighten with wrench (JJ).
Place cap (HH) on the bolt heads. Stand the assembled structure of posts (A1/A2) and arched
beams (B1/B2) up with two people.
BB
LL
A1
A1
A1
A2
A2
A2
B1
B1 B1
B2
B2
B2
HH
CC
EE
JJ
BB
LL
ASSEMBLY INSTRUCTIONS
5Hardware Used
x8
x1
x8
x8
x8
x1
EE
B1 B2
G1
G1
G1
G1
G1
N
CC
HH
123456
78910 11 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

EE HH
AA
CC
C2
C1
A1 A2
B1 B2
6.1. Attach the beams (C1/C2) to the posts (A1/A2), secure with bolts (AA) and washers (EE),
tighten with wrench (JJ). Place cap (HH) on the bolt heads.
6.2. Attach the supports bar (G) to the beams (C1/C2) with bolt (CC/EE), connect the other end
of the supports bar (G) to the connector (N) with bolt (CC/EE), then tighten with wrench (JJ).
Place cap (HH) on the bolt heads.
B1 B2
C1
EE
CC
HH
C2
G
G
G
G
N
G1
G1
G1
G1
G1
6Hardware Used
x16
x16
x8
AA
EE
ASSEMBLY INSTRUCTIONS
x1
JJ
x16
HH
B1
B1 B2
B2
C1
C1
C2
C2
A1
A1
A2
A2
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

ASSEMBLY INSTRUCTIONS
7. Insert connectors (E3) to the top beams (D), secure with bolts (AA) and plastic washers (FF). Attach
the ferrule (F2) and the top beams (D) to the beam assemblies (D/E3) and secure with bolts (AA)
and plastic washers (FF), tighten with wrench (JJ). Place cap (HH) on the bolt heads.
D
D
F2 E3 E3
D
D
F2
HH
AA
FF
7Hardware Used
x28
x28
AA
FF
x1
JJ
x28
HH
D
F2
D
AA
FF
HH
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

ASSEMBLY INSTRUCTIONS
8. Attach the assembled top beams (D) to the arc beams (B1/B2) using bolts (DD) and plastic
washers (FF), tighten with wrench (JJ). Place cap (HH) on the bolt heads.
Note: Don’t attach the assembled top beams (D) to the holes on the outside of the arc
beams (B1/B2).
B1 B2
DD
FF
HH
D
DD
DD
D
D
8Hardware Used
x14
x14
FF
x1 JJ
x14
HH
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

9. Connect canopy holding rod (M1) and canopy holding rod (M2), insert the assembed
canopy holding rod (M1/M2) into the canopy (K), then secure the rod onto the arc beam (B1/B2)
with the bolt (GG).
x4
GG
K
GG
K
ASSEMBLY INSTRUCTIONS
9Hardware Used
M1
M2
K
M1 M2
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

A1
H
KK KK
I
A2
KK
10.1.Put the sidewall (L) onto the sidewall rod (J) by the rings (II), then secure it onto the
posts (A1/A2).
10.2.Lift the base covers (H) and secure the assembled pergola to the ground with stakes (KK).
Your pergola is now fully assembled.
A1 A2
L
J
II
x20
II
ASSEMBLY INSTRUCTIONS
10 Hardware Used
x12
KK
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

CARE AND MAINTENANCE
WARRANTY
1 YEAR WARRANTY FOR FRAME AND FABRIC.
•WHAT IS COVERED
We provide warranty to the original purchase for 1 year for frame and fabric from the date of purchase,
and the fabric and frame will be replaced at no charge due to manufacturing defects.
•WHAT IS NOT COVERED
We do not reimburse for transportation costs. This warranty does not cover the damage caused by commercial
use, acts of nature, fire, freezing, and abusive use. Discoloration or fading of the finish or fabrics as a result
of chemicals or spills is not covered.
Contact the Customer Service Team at 866-439-9800.
•For cleaning, use a mild detergent solution, rinse with water, and allow to air dry.
Do not use acetone, abrasive, or other special detergents as they would be harmful to the product’s finish.
•Due to the nature of steel, surface oxidation (rusting) will occur if this protective coating is scratched.
This is a natural process. To minimize this condition, it is recommended that care be taken when assembling
and handling the product in order to prevent the paint from being scratched.
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

REPLACEMENT PARTS LIST (NOT TO SCALE)
PART DESCRIPTION PART #
AA 6
BB 1
CC 2
DD 1
EE 6
HH 6
II 2
M6 x 15 mm Bolt
M6 x 15 mm Bolt
M6 x 35 mm Bolt
M6 x 65 mm Bolt
Washer
PART DESCRIPTION PART #
FF 6
GG 1
Plastic Washer
Bolt
Cap
Ring
M6 × 35 mm Bolt
Bolt
Plastic Washer
Cap
Ring
tloBmm51×6M
tloBmm51×6M
Washer
AA CC
GG
BB DD EE
II
M6 × 65 mm Bolt
HH
FF
Printed in China
For replacement parts, call our customer service department at 866-439-9800, 8 a.m. - 8 p.m., EST,
Monday - Sunday. You could also contact us at [email protected].
123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34

123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34
5376015#OLUCÍTRA
PÉRGOLA CON
CUBIERTA BLANDA
MODELO #TPPER9137
ADJUNTE EL RECIBO AQUÍ
Número de serie ___________
Fecha de compra ___________
ALLEN + ROTH y el diseño del logotipo son
marcas comerciales o marcas registradas de
LF, LLC. Todos los derechos reservados.
¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a
nuestro Departamento de Servicio al Cliente al 866-439-9800, de lunes a domingo
de 8 a.m. a 8 p.m., hora estándar del Este. También puede ponerse en contacto
con nosotros en [email protected].

123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34
ÍNDICE
...................................................................................................................eteuqapledodinetnoC 20
Aditamentos .................................................................................................................................... 21
Información de seguridad ................................................................................................................ 22
Preparación .....................................................................................................................................22
23............................................................................................................nóicalatsniedsenoiccurtsnI
Cuidado y mantenimiento ..............................................................................................................33
Garantía ........................................................................................................................................ 33
Lista de piezas de repuesto ......................................................................................................... 34

123456
7891011 12
13 14 15 16 17 18
19 20 21 22 23 24
25 26 27 28 29 30
31 32 33 34
CONTENIDO DEL PAQUETE
DESCRIPTION T R A PR A P
Poste
Poste
Viga de arco
Viga de arco
Viga
Viga
Conector
Conector
Conector
Conector de arco
Casquillo
Casquillo
A1
A2
B1
B2
C1
C2
E1
E2
E3
F1
F2
2
2
2
2
2
2
Viga superior
D14
2
2
7
4
7
Barra de soporte
Barra de soporte
Cubierta de la base
Base
Varilla de la pared lateral
Pared lateral
Toldo
4
4
4
2
2
2
8
1
PIEZA
G
G1
H
I
J
K
L
N
M1
M2
F1
K
A1
L
A1
B1
F1
C1
B2
A2
G
A2
C2
D
N
N
D
E1
E2
E3
F2
G1
G
H
I
M1 M2
J
Varilla de sujeción del
toldo
Varilla de sujeción del
toldo
4
4
G1
DESCRIPCIÓN CANTIDAD PIEZA DESCRIPCIÓN CANTIDAD
