Alpha Data XRM2-CLINK-R-GIGE User manual

XRM2-CLINK-R-GIGE
User Manual
Revision: V1.0

XRM2-CLINK-R-GIGE
User Manual
© 2014 Co yright Al ha Data Parallel Systems Ltd.
All rights reserved.
This ublication is rotected by Co yright Law, with all rights reserved. No art of this
ublication may be re roduced, in any sha e or form, without rior written consent from Al ha
Data Parallel Systems Ltd.
Head Office
Address: 4 West Silvermills Lane,
Edinburgh, EH3 5B , UK
Telephone: [phone]
Fax: [phone]
email: [email protected]
website: http://www.alpha-data.com
US Office
3507 Ringsby Court Suite 105,
enver, CO 80216
[phone]
[phone] toll free
[email protected]
http://www.alpha-data.com
All trademarks are the ro erty of their res ective owners.

XRM2-CLINK-R-GIGE
User Manual
Table Of Contents
1 Introduction ...................................................................................................................................... 1
2 Installation ........................................................................................................................................ 3
2.1 Handling instructions ..................................................................................................................... 3
3 S ecification .................................................................................................................................... 3
3.1 Connectors .................................................................................................................................... 3
3.2 Mating Cableform .......................................................................................................................... 3
3.2.1 SDR connector .......................................................................................................................... 3
3.2.2 RJ-45 connector ........................................................................................................................ 3
3.2.3 Miscellaneous ............................................................................................................................ 3
3.3 rder Code .................................................................................................................................... 3
4 Related Documents ......................................................................................................................... 3
5 Design Exam les ............................................................................................................................. 4
6 Pinout ................................................................................................................................................ 4
6.1 Samtec pinout ................................................................................................................................ 4
6.2 RS232 thru-hole header ................................................................................................................ 7
List of Tables
Table 1 Camera Link Connector 1 (Base Configuration) ................................................................................ 4
Table 2 LE Indicators ................................................................................................................................... 5
Table 3 RGMII PHY Interface ......................................................................................................................... 6
Table 4 RS232 Interface ................................................................................................................................. 6
Table 5 RX input ............................................................................................................................................. 7
Table 6 TX output ........................................................................................................................................... 7
List of Figures
Figure 1 XRM-CLINK-R-GIGE Photo ............................................................................................................... 1
Figure 2 XRM-CLINK-R-GIGE Block iagram ................................................................................................. 1
Figure 3 XRM-CLINK-R-GIGE Features .......................................................................................................... 2
Figure 4 Ethernet PHY status LE S ................................................................................................................ 2

XRM2-CLINK-R-GIGE
User Manual
Page Intentionally left blank

XRM2-CLINK-R-GIGE
User Manual
1 Introduction
Figure 1 : XRM-CLINK-R-GIGE Photo
The XRM-CLINK-R-GIGE provides a RGMII 1000/100/10 Ethernet PHY, RS232 transceiver, and mini Cameralink
interfaces for the Alpha ata’s FPGA based platforms.
Figure 2 : XRM-CLINK-R-GIGE Block Diagram
The XRM-CLINK-R-GIGE is designed to allow the deployment of systems that require Gigabit Ethernet capability
(for example GigE-Cameralink) and mini Cameralink connectivity.
Page 1Introduction
ad-ug-01288_v1_0. df

XRM2-CLINK-R-GIGE
User Manual
Figure 3 : XRM-CLINK-R-GIGE Features
Figure 4 : Ethernet PHY status LEDS
Page 2 Introduction
ad-ug-01288_v1_0. df

XRM2-CLINK-R-GIGE
User Manual
2 Installation
The XRM-CLINK-R-GIGE is designed to plug in to the front panel connector (SAMTEC QSH series) on the
FPGA base card. The retaining screws should be tightened to secure the XRM-CLINK-R-GIGE.
The XRM-CLINK-R-GIGE is designed to be used with Virtex 7 series cards and I/O voltages are set accordingly
Note:This operation should not be performed while the host PMC/XMC or PCI card is powered up.
2.1 Handling instructions
Observe precautions for preventing damage to components by electrostatic discharge. Personnel handling the
board should take SS precautions.
Avoid flexing the board.
3 S ecification
3.1 Connectors
S R connector 3M part number 12226-8250-00FR
Standard RJ-45 connector
3.2 Mating Cableform
3.2.1 SDR connector
S R cable assembly 3M part number 1SF26-L120-00C-XXX, where XXX= length in centimetres.
S R to M R cable assembly 3M part number 1MF26-L560-00C-XXX, where XXX= length in centimetres.
3.2.2 RJ-45 connector
Standard RJ-45 Cat 5e/6 cable.
3.2.3 Miscellaneous
RS232 transceiver controlled from FPGA implementing 3-wire interface. Connection via 3-pin 1.0 mm thru-hole
header.
3.3 Order Code
XRM-CLINK-R-GIGE
For further information please contact Alpha ata.
4 Related Documents
Camera Link Specification v1.1 (Automated Imaging Association)
CameraLink Technology Brief Available from http://www.baslerweb.com
Xilinx E K documentation. http://www.xilinx.com/ise/embedded_design_prod/platform_studio.htm
Page 3Related Documents
ad-ug-01288_v1_0. df

XRM2-CLINK-R-GIGE
User Manual
5 Design Exam les
Example UCF, H L files and Application software are available from Alpha ata for for purchasers of this card.
6 Pinout
6.1 Samtec inout
The pin numbers in the section should be used with the usermanual or S K for a board it is being attached to to
create a UCF. Example UCFs may also be available on request from [email protected]
Signal Name irection Samtec pin S R pin (Con. 1)
xclk_p in 89 9
xclk_n in 91 22
x_p<0> in 64 25
x_n<0> in 62 12
x_p<1> in 68 11
x_n<1> in 66 24
x_p<2> in 72 10
x_n<2> in 70 23
x_p<3> in 74 8
x_n<3> in 76 21
.
cc_p<1> out 88 5
cc_n<1> out 86 18
cc_p<2> out 83 17
cc_n<2> out 81 4
cc_p<3> out 63 3
cc_n<3> out 61 16
cc_p<4> out 87 15
cc_n<4> out 85 2
.
ser_tfg_p in 82 6
ser_tfg_n in 84 19
ser_tc_p out 80 20
ser_tc_n out 78 7
Table 1 : Camera Link Connector 1 (Base Configuration)
Page 4 Pinout
ad-ug-01288_v1_0. df

XRM2-CLINK-R-GIGE
User Manual
Signal Name irection Samtec pin Notes
led<0> out 2 Blue
led<1> out 4 Green
led<2> out 6 Red
led<3> out 8 Blue
led<4> out 10 Green
led<5> out 12 Red
Table 2 : LED Indicators
Page 5Pinout
ad-ug-01288_v1_0. df

XRM2-CLINK-R-GIGE
User Manual
Signal Name irection Samtec pin Notes
gige_mdio inout 22 Management data
gige_mdc out 20 Management data clock. Max.
freq 8.3MHz
gige_reset_l out 30 Active low reset
gige_clk125 in 110 125MHz clock source
gige_crs in n/a Carrier sence
gige_col in n/a Collision
gige_int_l in 28 Active low interrupt
gige_tx_ctl out 9 RGMII tx control
gige_txc out 40 RGMII tx clock.
125MHz/25MHz/2.5MHz
gige_txd<0> out 1
RGMII tx data
gige_txd<1> out 3
gige_txd<2> out 5
gige_txd<3> out 7
gige_rxd<0> in 13
RGMII tx data
gige_rxd<1> in 15
gige_rxd<2> in 17
gige_rxd<3> in 19
gige_rx_ctl in 21 RGMII rx control
gige_rxc in 38 RGMII rx clock
125MHz/25MHz/2.5MHz
Table 3 : RGMII PHY Interface
Signal Name irection Samtec pin Notes
tx out 101 RS232 compatible output
rx in 103 RS232 compatible input
ready in 94 Active high
force_on out 98 Active high enable for RS232
interface
force_off out 100 Active low dissable
Table 4 : RS232 Interface
Page 6 Pinout
ad-ug-01288_v1_0. df

XRM2-CLINK-R-GIGE
User Manual
6.2 RS232 thru-hole header
Pin Function irection
1 tx out
2 gnd n/a
3 rx in
The tables below show the electrical characteristics of the RS232 connection under typical operating conditions.
RX Inputs Min Tpy Max Units
Input Voltage Range -25 .25 V
Input Threshold Low 0.6 1.2 .V
Input Threshold High n/a 1.5 2.4 V
Input Hysteresis n/a 0.5 .V
Input Resistance 3 5 7 kOhms
Table 5 : RX in ut
TX Outputs Min Tpy Max Units
Output Voltage Swing ±5 n/a ±5.4 V
Output Resistance 300 n/a 10M Ohms
Output Short-Circuit
Current n/a n/a ±60 mA
Output Leakage
Current n/a n/a ±25 uA
Table 6 : TX out ut
Page 7Pinout
ad-ug-01288_v1_0. df

XRM2-CLINK-R-GIGE
User Manual
Revision History
ate Revision Nature of Change
Jul-2014 1.0 First release.
