USER MANUAL
AND
TECHNICAL SPECIFICATIONS
SP0123 Cabinet
Document reference code: 4804 872 60014
Edition: 04

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
2
DOCUMENT HISTORY
Edition
Date
Page
Changes
03
06/08/2013
18
20
19
35
38
Reviewed:
2.4. EMC standards
2.7.1. CSA file number
Added :
2.5. RoHS statement
3.3.8. Mounting the internal batteries
4. Service & alarms
04
12/08/2013
19
Replace 2002/95/EC (RoHS_6/6) by RoHS 2011/65/EU

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
3
Table of Contents
1. GENERAL...............................................................................................................5
1.1. STATUS............................................................................................................5
1.2. POWER SUPPLY DESCRIPTION....................................................................5
1.2.1. Cabinet...................................................................................................... 5
1.2.2. Sub-rack.................................................................................................... 7
1.2.3. Battery..................................................................................................... 10
1.2.4. Mains absent signal................................................................................. 11
2. SPECIFICATIONS ................................................................................................12
2.1. MECHANICAL SPECIFICATIONS.................................................................12
2.1.1. Cabinet.................................................................................................... 12
2.1.2. Sub-rack.................................................................................................. 12
2.1.3. Cooling.................................................................................................... 13
2.2. ELECTRICAL SPECIFICATIONS ..................................................................14
2.2.1. Sub-rack.................................................................................................. 14
2.3. SAFETY STANDARDS ..................................................................................17
2.4. EMC STANDARDS ........................................................................................18
2.4.1. Typical test set-up ................................................................................... 18
2.4.2. Applicable Standards............................................................................... 18
2.5. ROHS............................................................................................................ 19
2.6. Environmental specifications..................................................................... 19
2.7. MARKINGS ....................................................................................................20
2.7.1 Type plate .................................................................................................20
2.7.2 WEEE marking..........................................................................................20
2.7.3 Safety markings ........................................................................................20
3. INSTALLATION ....................................................................................................21
3.1 UNPACKING THE CABINET ..........................................................................22
3.1.1 Opening the package ............................................................................... 22
3.2. UNPACKING THE ADDITIONAL SUB-RACK...............................................23
3.2.1. Opening the package .............................................................................. 23
3.3. INSTALLATION..............................................................................................24
3.3.1. Safety precautions................................................................................... 24

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
4
3.3.2. Tools and equipment required for installation.......................................... 24
3.3.3. Ventilation conditions............................................................................... 24
3.3.4. Mounting the sub-rack (Basic configuration) ........................................... 25
3.3.5. Mounting the additional sub-rack (optinal configuration) ......................... 27
3.3.6. Input connections .................................................................................... 33
3.3.7. Place the rectifiers................................................................................... 34
3.3.8. Mounting the internal batteries ................................................................ 35
4. SERVICE & ALARMS..........................................................................................38
4.1. NORMAL OPERATION..................................................................................38
4.1.1. Normal switching on/off procedure .......................................................... 38
4.2. SERVICE ACTIONS & ADJUSMENTS ..........................................................39
4.2.1. Voltage of the 48V bus ............................................................................ 39
4.2.2. Current measurement.............................................................................. 39
4.2.3.Temperature compensation..................................................................... 39
4.2.4. Alarm on the rectifiers.............................................................................. 39
4.2.5. Alarm on the distribution.......................................................................... 39

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
5
1. GENERAL
Type
Description
SP0123/10
Cabinet equipped with one SP0123/00 sub-rack and one battery shelf
Input :
100-250 V 50-60 Hz 30 A Max or
Output :
2 x -54 V 2000 W at range 100-120 V or
2 x -54 V 4000 W at range 200-250 V
CAR1048TN
Rectifier module
AC IN: 200-250V - DC OUT: 54.1V –18.5A –1000W or
AC IN : 100-120V –DC OUT: 54.1V –9.3A –500W
4004 118 46151
Blind plate for rectifier empty slot
SP0123/00
Sub-rack with AC and DC distribution, slots for 4 rectifiers, mains cable, battery
cables , common for 110V and 230V rectifiers
SP0123/20
Kit containing one SP0123/00 sub-rack and accessories to mount this sub-rack in a
SP0123/10 cabinet
1.1. STATUS
Edition 03
1.2. POWER SUPPLY DESCRIPTION.
1.2.1. CABINET
GENERALITIES
The SP0123/10 is a cabinet housing one SP0123/00 sub-rack and its battery bank.
SP0123/00 is a power supply sub-racks able to work with or without battery. The
converter behaves as a quasi-resistive load seen from the low voltage mains it is
connected to.
The cabinet is provided with a front door with lock. The cabinet is divided in two
parts: a location looking like a 19 inches system able to contain one or two sub-
racks above and a battery location underneath.
The 19 inches location is 10U high and contains eight soldered M6 nuts in order to
fix two sub-racks and adapted plates. Two holes (diameter 17mm) are provided in
the rear side of the cabinet for mains cable of sub-racks.
If only one sub-rack is installed, the lowest position of the 19 inches location must
be used and the upper position must be closed by the delivered 3+5U plates (for
safety and cooling purpose).
In the other case of one cabinet equipped with two sub-racks, two 3U front plates
must be placed. Each of these 3U is fixed above each sub-rack with two M6 screws.
An optional Kit (SP0123/20) is necessary to upgrade a cabinet with one sub-rack with
one with two sub-racks.

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
6
The battery location is separated from the sub-racks by a metal sheet in order to
avoid gas from the batteries to enter in the rectifier’s area. However a 34 mm
diameter hole is foreseen for the battery and earth cables.
If two battery banks are installed, the optional battery shelf must be installed in order
to dispose the second battery bank (the first bank lays on the bottom sheet of the
cabinet).
A cable channel diameter 34 mm from front to rear side is provided above the
battery location in order to pass the load cables from front to the rear side of the
system.
6x M5 studs are soldered on the left side of the battery location. The earth wire of
each installed sub-rack must be fixed on one of these studs to earth the enclosure.
The cabinet is equipped with the necessary vents for air cooling on the rectifiers and
ventilation of the batteries.
CONNECTIONS
Mains
One or two mains input electrically independent are placed at the rear of the cabinet
- Approx. 1.5m long appliance wiring material cable
- section : 3x3.31mm² (AWG12)
- neutral wire marked with a “1”
- line wire marked with a “2”
- Earth wire in green and yellow colour
Loads
The 2 outputs are located at the rear of the cabinet.
Figure 1: BACK AND FRONT OF THE CABINET

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
7
1.2.2. SUB-RACK
GENERALITIES
The SP0123/00 (NC 9413 001 23001) is an 2U 19 inches sub-rack aimed at housing
up to four rectifiers CAR1048TN (1000W at 230Vinput / 500W at 110V input)
This sub-rack is designed to replace the PE3657/21.
Features:
- Single phase AC input protected by 30A breaker (single pole)
- 2x 30A DC outputs
- Battery LVD management
Ventilation is performed by rectifiers’ fans (front to back)
FRONT PANEL INDICATIONS
Rectifiers
- green led on continuously : normal operation
- green led on blinking : power derating
- red led on : dc fault (Vout < 40V)
Sub-rack
- 30 A mains breaker
- 60 A battery breaker (Bat)
- 30 A output breakers (2x)
- Green led (dc voltage present)
- Dry contact for “mains absent” signal (closes when mains disappear)
- Cable lock: tie-rap support
Figure 2: Sub-rack with 4 rectifiers
CONNECTIONS
Connections to the mains, batteries and protective earth are located at the rear of the
sub-rack. Signal and load connections are located on the front panel.
Mains- approx. 2m long appliance wiring material cable
- section : 3x3.31mm² (AWG12)
- neutral wire marked with a “1”
- line wire marked with a “2”

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
8
Loads
The 2 outputs are located on the front panel. They are available on 4 cage-
clamp connectors (4…6mm² stranded, 4…10mm² rigid, stripping length
15mm). Technical connection using the principle of direct insertion without
tools
Reference connector: Phoenix contact SPT 5/8-H-7,5-ZB
Figure 3: DC output connector
Positive and negative poles
The positives poles are connected to the chassis. The negative poles are
protected with the related breaker F1-F2.
Figure 4: connections available on the sub-rack
1
2
7
8
9
3 5
4 6

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
9
Connector reference on above Fig.4
Description
1
LOAD CONNECTORS
2
ALARM CONNECTOR
3
OUTPUT 1 BREAKER
4
OUTPUT 2 BREAKER
5
BATTERY BREAKER
6
MAINS INPUT BREAKER
7
MAINS CABLE
8
POSITIVE AND NEGATIVE BATTERY CABLE
9
EARTH CABLE FOR BONDING

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
10
1.2.3. BATTERY
GENERALITIES
The battery connections are 6 AWG cables coming out from the rear side of
the sub-rack and terminated with M6 tags. These cables are approx. 1.5m
long. The red one is the positive pole and connected to the chassis of the
sub-rack. The black one is the negative pole and is protected by the battery
breaker.
Figure 5: battery cable at the rear of the sub-rack
A yellow/green 16mm² wire is provided to earth the cabinet in which the sub-
rack is mounted. It is approx. 0.9m long and is terminated with a M6 eye tag.
Figure 6: bonding cable at the rear of the sub-rack

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
11
1.2.4. MAINS ABSENT SIGNAL
This signal is available on the front panel (0.2…1.5mm² solid/ stranded,
stripping length 10mm).
Reference connector: Phoenix contact FFKDSA/H1-7.62
Figure 7: Location of the Mains absent signal connector

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
12
2. SPECIFICATIONS
2.1. MECHANICAL SPECIFICATIONS
2.1.1. CABINET
Height: 1250 mm
Width: 600 mm
Dept: 600 mm
Weight empty cabinet: 65 Kg
Weight empty sub-rack: 6.87 Kg
Weight rectifier: 1.16 Kg
Weight optional battery shelf: 7.5 Kg
Total of fully equipped cabinet without batteries is thus: 96 Kg
Maximal allowed weight of one battery bank: 200 Kg
Useful area of battery shelves:
Width: 520 mm
Depth: 550 mm
Height: 280 mm
Chassis colour: RAL 7012 (basalt grey)
Door colour: RAL 9002 (Grey White)
2.1.2. SUB-RACK
Sub-Rack Height max 2U
Sub-Rack Width 19"
Sub-Rack Depth max 293mm
Sub-Rack Depth all in 330 mm
Sub-Rack Weight "empty rack" 6.87kg
Sub-Rack Weight "rectifier" 1.16kg

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
13
2.1.3. COOLING
RECTIFIERS AND SUB-RACK
Cooling / Airflow Rectifier: Front to Rear
Fan: 1 per rectifier
Ventilation in Front of rectifier
Ventilation out Rear of rectifier
Air outlet on the top cover of sub-rack
CABINET
Forced cooling; fans in each of the sub-racks
Air inlet: front door
Air outlet: rear panel of the cabinet
Minimum distance between rear and any surface: 100 mm
Figure 8: front & rear view: ventilation
Battery ventilation

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
14
2.2. ELECTRICAL SPECIFICATIONS
2.2.1. SUB-RACK
INPUT SPECIFICATIONS
Characteristic
Rating / Description
Condition / Remarks
Voltage range
Reference
230 Vrms.
110 Vrms
High range (max power = nx1000W)
Low range (max power = nx500W)
Nominal
100 to 250 Vrms
Waveform distortion
± 3 %.
Stat. operating range
90 Vac-265 Vac
Both ranges
10 % and +6 % of nom. Value.
Range selection
Automatic
Power limitation done by the rectifier
Source frequency
Reference
50 Hz
60 Hz
High range
Low range
Nominal
50, 60 Hz
Range
47 –63.6 Hz
± 6 % of nominal value.
Mains turn off /
start up level
Turn off level
70 and 82 Vrms
Reference source voltage, nominal load.
Start up level
80 and 90 Vrms
Reference source voltage, nominal load.
Source current (*)

6.8 Arms.
180 Vac, nominal load.

7.0 Arms.
90 Vac, nominal load.
Typ.
5 Arms.
High range reference source voltage, nominal load
Typ.
6.8 Arms
Low range reference source voltage, nominal load
Consumption (Total
maximum input power
rectifier)

1240 VA.
Nominal load (high range)
Typ.
Typ.
1140 VA.
620 VA.
Reference source voltage, nominal load
(high range).
Reference source voltage, nominal load.
(low range)
Typ
55W
Input power of each rectifier –no output load
Consumption (Total
maximum input
power)
4580 VA
With 4 rectifiers at 230 Vac and Max output power
2510 VA
With 4 rectifiers at 110 Vac and Max output power
AC Ground leakage
current
>3.5 mA
Sticker High Current Leakage is placed
AC Ground leakage
(class)
Class_I IEC/UL60950
TT or TN mains
Input over-current
protection
30 A
Internal Breaker 30A long delay in ‘L’

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
15
Characteristic
Rating / Description
Condition / Remarks
Input over-voltage
protection
285V +/-5V
Value specified by the rectifier specification
Hold-Up time 48V
10 ms
Power factor

0.99
Reference source voltage, nominal load.

0.95
Any allowed input voltage, nominal load
Power Factor
Correction
IEC 1000-3-2
Class A
Efficiency
At 25°C
Typ
90 %.
High range reference source voltage, nominal load
Typ
85 %.
Low range reference source voltage, nominal load
Relative harmonics of
mains current
According to
IEC 1000-3-2, Class A
Inrush current (*)
According to
Per ETS 300 132
Max. peak
20 A.
Cold and hot start.
Typ. duration
10 ms.
Energy reserve
Ref. voltage at 0° sinewave, nominal load.
Holdup time 
Drop time 
10 ms
10 ms
Output voltage stays above 48V.
(*): per rectifier
Mains conductors marking
N = "1" / L = "2" / Earth = "Y/G"
Mains cables length
2 m
Mains cables section
3 x 3.31mm² / AWG12
Mains cables end
Ferrule
Mains cable free end
Phase –brown wire –40mm
Neutral –blue wire –40mm
PE –yellow-green wire - 90mm
Mains cables "Anchorage
fixed at the rear of the sub-rack
Earth cables safety length
Must be longer than the "L" & "N"
PE is the last to be detached

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
16
OUTPUT SPECIFICATION
Characteristic
Output
Condition / Remarks
Output voltage
Nom.
54
V
Ref. load
18.5
A
Per rectifier (high power)
Ref. load
9.3
A
Per rectifier (low power)
Adjustment error
0.2
%
Factory preset (53.9 –54.1)
Drift
-
%
Overvoltage prot.
Trip level (typ)
59.5
V
Reset by switching mains input

60
V
Under voltage prot.
40.5
Vdc
Control range

40.5
V
With monitoring

58
V
Output current (*)
Min.
0
A
Nom.
18.5
A
High input range
Nom.
9.3
A
Low input range
Output current (sub-rack)
Min.
0
A
Nom.
….
A
High input range
Nom.
….
A
Low input range
Current limit (*)
Imax

20.9
A
High input range

25
A
(Constant power limit between 48V and 58V)

12
A
Low input range

17
A
(Constant power limit between 42V and 58V)
Short circuit current

30
A
Limited by breaker located in distribution
Output power (*)
Nom.
1000
W
High input range
Nom.
500
W
Low input range
 Source effect 

0.1
%
Source var.: 230V 15%
 Load effect 

2
%
Load change 10…90%
Dynamic operation
Min. load
0.5
A
Load variation Iout
5
A
dIout/dt
0.5
A/µs
Overshoot / undershoot 
1
V
Recovery time 
4
ms
Turn on delay time
Mains on delay time ≤
2500
ms
Full input voltage rangeRef. output

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
17
Thermal protection
Power thermal derating protection
Smart power limitation according to the ambient temperature (2.5% per °C
between 55°C to 70°C in high input voltage range and full power up to 70°c in
low input voltage range)
Thermal Shutdown protection
Inside each rectifier module, when internal temperature has reached
threeshold
Ripple and noise
Peak to Peak
<= 500
mV
Bandwith : 10 Hz –20MHz.
True rms
<= 50
mV
Wideband noise
ETS 300 132-
Psophometric
<= 2
mV
RMS
Flat/Unweighted
<=10
mV
RMS
2.3. SAFETY STANDARDS
WARNING: this system is intended for installation by a Qualified Service Personal
with other equipment and must not be operated as stand-alone product.
The CE marking applies to the Low Voltage Directive 2006/95/EC.
When correctly installed this system complies with EN 60950-1 with the provision that
the installer is responsible for protection against contact with live parts.
Applicable standards
EN 60950-1:2006+A11:2009 + A1 :2010 + A12 :2011
Safety of information Technology Equipment
IEC 60950-1:2005 + A1:2009
Safety of information Technology Equipment
CAN/CSA- C22.2 No. 60950-1-07+Am1:2011
Information Technology Equipment –Safety –Part 1: General Requirements
UL 60950-1, Second Edition +Am1:2011
Information Technology Equipment –Safety –Part 1: General Requirements
Characteristic
Rating / Description
Conditions / Remarks
Earth leakage current
Max. value in
TT/TN configuration, 5 rect.
IT configuration, 5 rect.
> 3.5 mA
Sticker is placed on the sub-rack and shows a
warning message:
“High leakage current”
Electric strength
Input –ground
4250 V (DC)
Output connected to ground
Output –ground
0 V
Output connected to ground
Input –output
4250 V (DC)
Output connected to ground

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
18
2.4. EMC STANDARDS
The CE marking applies for the EMC Directive 2004/108/EC (Equipment intended
exclusively for professional purposes) with the provision that the installer takes the
necessary mitigation measures described in the present manual (typical set-up).
2.4.1. TYPICAL TEST SET-UP
Test set-up:
- one sub-rack in one cabinet
- four rectifiers in the sub-rack
- load: 48A
- air cooled resistive loads placed outside the cabinet
Note:
The proposed test set-up does not need to be considered as the only possible
solution to achieve conformity of the final product with the specified EMC
requirements. The final user has to evaluate compliance of the final product.
2.4.2. APPLICABLE STANDARDS
EN EMC Generic Standards for Emission
EN61000-6-3:2007
Emission standard for residential, commercial and light-industrial environments
EN61000-3-2:2006 + A1:2009 + A2:2009
Limits for harmonic current emission (equipment input current ≤16A per phase)
EN61000-3-3:2008
Limitation of voltage changes, voltage fluctuations and flicker in public low-voltage supply
systems, for equipment with rated current ≤16 A per phase and not subject to conditional
connection
EN55022:2010
Information technology equipment - Radio disturbance characteristics - Limits and methods of
measurement
EN EMC Generic Standards for Immunity
EN61000-6-1:2007 –Immunity for residential, commercial and light-industrial environments
EN55024:2010 –Information technology equipment –Immunity characteristics –Limits and
methods of measurement

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
19
C/US EMC Standards
FCC 47 CFR Part 15 - Subpart B
Conducted and radiated emission - Class B
IC ICES-003 Issue 5
Conducted and radiated emission - Class B
2.5. ROHS
The equipment is in conformity with 2011/65/EU RoHS directive.
2.6. ENVIRONMENTAL SPECIFICATIONS
The operational conditions are:
Temperature range (cabinet): 0°C to 45°C.
Temperature range (sub-rack): 0°C to 55°C.
Relative humidity range: 20 to 80%.
Atmospheric pressure 70 to 110 KPa.
Altitude max 3000m above sea level.
The storage and transport conditions are:
Temperature range: -40 to 85°c.
Relative humidity range: 10 to 95%.
Atmospheric pressure: 70 to 110 KPa.
Environment: Pollution level 2 (EN60950)
Compliant to RoHS 2011/65/EU
According to ETS 300–019–1–1 CLASS T1–2 for storage.
According to ETS 300–019–1–2 CLASS T2–2 for transportation.
Reliability
MTBF 22 years for sub-rack without rectifiers
34 years for each rectifier, fan not included
According to Bellcore TR332, 1997, ground fixed, 25°C ambient temperature

User Manual - ref code: 4804 872 60014 - Edition: 04 - 39 pages
20
2.7. MARKINGS
2.7.1. TYPE PLATE
Each cabinet is marked with its own type-plate mentioning
Alpha Technologies systems
Part number
Revision number
Input rating
Output rating
Date of manufacturing
Approvals marking
Safety markings
Furthermore others labels are applied on the system to remind the user of reading
the installation manual before operating on the system.
2.7.2. WEEE marking
The WEEE symbol is printed on the type plate of the sub-rack (9413 001 23001) and
cabinet (9413 001 23101):
Recycle this product in the nearest recycling centre.
2.7.3. SAFETY markings
- Leakage current : indication on the rear of the system :
High leakage current
Earth connection essential
before connecting supply
- Electrical shock : indication on the rear of the system :
CAUTION :
See installation instructions before
connecting supply and batteries
