Alpine APF-X300VW User manual

R
FOR CAR USE ONLY/NUR FÜR AUTOMOBILGEBRAUCH/POUR APPLICATION AUTOMOBILE
UNIQUEMENT/SOLO PARA USO ENAUTOMÓVILES/PER IL SOLO UTILIZZO INAUTOMOBILE
CAN Interface for VW
APF-X300VW
Cars with RNS, RCD, MIB-PQ
Quick Reference Guide
Kurzreferenz
Guide de Référence Rapide
Guia de Referencia Rapida
Guida Rapida

GND
BATT
ACC
CAN Interface
Antenna Power (12Volt)
REMOTE
AVN Power
Connector
CAN I/F
Connector
UART
Connector
CAN
Connector
DIN Antenna
AVN Unit
(DVD/ TV Tuner)
Quadlock
AUX INPUT
CONNECT2 I/F
CAMERA
SPEED
SENSOR
Connect
MIB-PQ
adapter
RNS/ RCD →2016
MIB-PQ 2016 →
Connections/Anschlüsse/ Raccordements/
Conexiones/ Collegamenti

OK
Button Tuner CD/USB Incoming/
Active Call
Vol + Vol + Vol +
Vol – Vol – Vol –
-Folder Up -
-Folder Down -
Seek Up Track Up -
Seek Down Track Down -
Short Source Source -
Long Voice Command
to Phone Voice Command to Phone -
Short - - Off Hook
Long - - On Hook/Reject
Taste Radio CD/USB Eingehender/
AktiverAnruf
Vol + Vol + Vol +
Vol – Vol – Vol –
-Ordner auf -
-Ordner ab -
Suchlauf auf Track auf -
Suchlauf ab Track ab -
Kurz Quelle Quelle -
Lang Sprachbefehl an
Telefon Sprachbefehl an Telefon -
Kurz - - Abnehmen
Lang - - Auegen/
Ablehnen
Touche Radio CD/USB Appel entrant/
actif
Vol + Vol + Vol +
Vol – Vol – Vol –
-Dossier suiv. -
-Dossier préc. -
Recherche avant Piste suiv. -
Recherche arr. Piste préc. -
Court Source Source -
Long Commande vocale
du téléphone Commande vocale du téléphone -
Court - - Décrocher
Long - - Raccrocher/
rejeter
Botón Radio CD/USB Llamada
entrante/activa
Vol + Vol + Vol +
Vol – Vol – Vol –
-Subir carpeta -
-Bajar carpeta -
Búsqueda hacia
arriba Canción superior -
Búsqueda hacia
abajo Canción inferior -
Corta Fuente Fuente -
Larga Comando de voz
para teléfono Comando de voz para teléfono -
Corta - - Descolgar
Larga - - Colgar/Rechazar
Tasto Radio CD/USB Chiamata in
arrivo/attiva
Vol + Vol + Vol +
Vol – Vol – Vol –
-File su -
-File giù -
Ricerca su Brano su -
Ricerca giù Brano giù -
Breve Sorgente Sorgente -
Lunga Comando vocale
al telefono Comando vocale al telefono -
Breve - - Accettazione della chiamata in
arrivo
Lunga - -
Chiusura della
chiamata in
corso/riuto della
chiamata in arrivo
EN: The functions can dier depending on the vehicle
equipment.
DE: Die Funktionen können je nach Fahrzeugausstat-
tung abweichen.
FR: Les fonctions peuvent varier en fonction de l’équipe-
ment du véhicule.
ES: Las funciones pueden variar dependiendo del equi-
po del vehículo.
IT: Le funzioni possono variare a seconda dell’equipag-
giamento del veicolo.
