Alpine KTX-GM7-O User manual

Mobile Media Solutions
Perfect Fit For Select 2006-up GM Vehicles
Installation Manual
KTX-GM7-0
0
0
GM Trim Panel x 1
(Panel 7229) Power Harness x 1 On-Star/Steering Wheel Interface Module x 1
Left Bracket x 1
{Panel 7231) Right Bracket x 1
(Panel 7230) GM Antenna
Adapter Screws x 4
Introduction
This KTX-GM7-0 Perfect Fit installation kit is for Select 2006-up GM vehicles with or without the
Bose audio system. Included are all the parts needed
to install your Alpine INA-NAV-1 0, INA-
NAV-20, INA-W900, INA-W900BT,
or INA-W910 Audio Video Navigation system in Select 2006-up
GM vehicles. KTX-GM7-0 Perfect Fit installation kit also includes an interface module that allows
steering wheel remote control
of the Alpine system. Refer to the individual instruction sections of
this manual to remove your vehicle's factory radio and assemble the kit.
Caution! Disconnect your vehicle's negative battery terminal before the installation to
help prevent electrical damage. We recommend the use of a digital multimeter to check
vehicle wiring. Do not use a test light! A test light or grounded wire probe can cause
damage to the vehicle's computer and/or diagnostic systems. Avoid all factory airbag
wiring. Airbags can accidentally deploy causing serious injury or even death.
Notes:
• See
your vehicle's instructions for any special tools your installation might require.
• Read all instructions accompanying
your car stereo for properwiring and mounting
instructions.

Compatibility List
Buick
Enclave 2008-2011
Lucerne 2006-2011
GMC
Acadia 2007-2011
Savanna 2007-2011
Sierra 2007-2011**
Yukon 2007-2011
Hummer
Chevrolet
Avalanche 2007-2011
Equinox 2007-2009
Express
Van 2008-2011
Impala2006-2011
Monte Carlo 2006-2007
Silverado
2007-2011-
Suburban 2007-2011
Tahoe 2007-2011
Traverse 2009-2011
... . _ t:I£2. . QQ~:-~Q_o_~ --
Pontiac
Torrent 2008-2009
Factory Stereo Removal
Buick Enclave 2008-2011
Chevrolet Traverse 2009-2011
GMC Acadia 2007-2011
Saturn Outlook 2007-2009
1. Use a panel removal tool to carefully unsnap dash/radio bezel.
2. Unplug and remove panel.
Saturn
Outlook2007-2009
Suzuki
XL7 2007-2009
** This excludes
the 2007
"Classic" versi
ons which are
the same body style as th e
2006.
3. Extract (4) 7mm hex head screws securing the radio, unplug and remove radio.
Buick Lucerne
2006-2011
1. Use a panel removal tool to carefully unsnap the trim bezel around the radio and HVAC con-
trols.
2 ~ i:Xtrac£(3). 9/3:2 ··, - :. (mm hex head screws securing the HVAC controls to the dash. Disconnect
and remove.
3. Extract
(4) 9/32" -7mm hexhead screws securing the radio to the dash. Disconnect and
remove.
Chevrolet Avalanche
2007-2011
Chevrolet Tahoe 2007-2011
Chevrolet Suburban 2007-2011
GMC Sierra 2007-2011
GMC Yukon 2007·2011
1. Use a panel removal tool to carefully unsnap dash/radio bezel.
2. Extract (8) 9/32" hex head screws securing thefactory radio.
3. Lift away, disconnect, and remove.
4.
**See TechTip on Alpine Connected website formore information on the Tahoe
Chevrolet Equinox
2007-2009
Pontiac Torrent 2008-2009
1. Slidechrome ring down on shifterknob.
2. Remove allen head screw.
3. With panel removal
tool unsnap panel on console below window switches.
4. With panel removal
tool unsnap dash around radio. Shifterpanel includes AIC controls
and upper vents.
5. Disconnect all harnesses and remove.
6. Remove
(4) 7mm screws securing radio, disconnect, and remove.

Factory Stereo Removal (Continued)
Chevrolet Express Van
2008-2011
GMC
Savanna
2007-2011
1.
Using a panel removal tool, carefully
pry
awayinstrument clusterpanel from dash.
2.
Disconnect electrical connectors and remove instrumentclusterpanel.
3. Remove
(3)
screws
that
secure the radio
to
the
dash cavity.
4. Disconnect electrical connectorsand remove radio.
Chevrolet Impala
2006·2011
1.
Using a panel removal tool, remove the trim around the radio.
2. Remove
(6)
7mm hex screws securing
the
factory radio. Lift away, disconnect, and
remove.
Chevrolet
Monte
Carlo
2006-2007
1.
Using a panel removal tool, remove the trim around the radio and climate controls.
2. Extract
(2)
phillips head screws securing the
HVAC
controls
to
the dash. Remove
HVAC
controls.
3. Extract
(4)
phillips head screws securing he radio
to
the
dash. Disconnectand remove.
Chevrolet Silverado
2007-2011
(Dash
type
1)
1. Remove
(2)
screws located above instrument gauge cluster.
2. Usinga panel removal tool,
pry
away instrument cluster
top
coverpanel.
3. Using a panel removal tool,
pry
away radio/HVAC control panel.
4. Remove screws securingthe radio.
Chevrolet Silverado
2007-2011
(Dash type 2)
1.
Using a panel removal tool,
pry
away radio/HVAC venttrim bezel.
2. Remove
(2)
screwssecuring lower
HVAC
control panel.
3. Remove
(2)
screws securing upperHVAC control panel.
4. Remove
(4)
screwssecuring the radio.
Hummer
H2
2008-2009
1. Using a panel removal tool,
pry
away radio/AC vent dash bezel.
2.
Disconnect electrical connectionsand remove radio/AC vent dash bezel.
3.
Remove
(4)
screws
that
secure the radio
to
the dash cavity.
4.
Disconnect electrical connectorsand remove radio.
Suzuki
XL
7
2007-2009
1. Using a panel removal
tool
unclip shifterleatherboot.
2.
Extract
(1)
screw securing the shi
fter
console panel.
3.
Using a panel removal tool, unsnap shifterconsole panel without removing,
lift
&
rotate
it
out
of
the
way.
4. Usnap trim bezel around radio with panel removal
tool
and remove.
5.
Extract
(4)
screws securing the radio, unplug, and remove controls.

Wiring Harness Diagram
INA-W900/
INA-W900BTI
INA-W910/
INA-NAV-10 I
INA-NAV-20
Audio
Video
Navigation
System
To
Orange/
White on
back
of
head unit
To
Head Unit
Power Connector
range/White
To
Steering Wheel Remote/
On-Star Control Module
The selector should
be
set
to
1 (default)
for
the
steering wheel controls
to
work
with
the
Alpine head unit. The steering
wheel controls are pre-programmed
and ready
for
plug-and-play use.
Notes:
The
port
is labeled
for
a
Bose
or
non-Bose system.
Choose accqrding
to
the
type
of system in
the
-vehicle.
Yellow/Black
To
Foot
Brake
(+)
at
switch above pedal
To
Parking
Brake
(-)
at
Blue/White rake in driver
kick
panel
To
aftermarket amplifier
remote turn on
• This
product
is not applicable
to
vehicles equipped with PREMIUM BOSE systems (Y91/Y92//Z75).
• This information can be found on equipment
code
sticker in the glove box.
• * No connection
for
INA-W91
0;
Bluetooth® module optional
for
INA-W900; KCE-250BT module included with
the
INA-W900BT.
Liability Disclaimer
Due
to
changes in design and manufacturing
that
may
occur
with
your
specific vehicle,
it
is important
that
you
do
not
rely solely on vehicle information contained in this installation
manual, such as dash disassembly, wire harness, and codes. Such information should be
confirmed with the vehicle manufacturer. Alpine Electronics, Inc. and its affiliated companies
is
not
responsible
for
damage
that
may
occur
to
you
or
your automobile during
the
installation
of
the Perfect Fit Kit.
If
you have any further questions, feel free
to
contact
Alpine Tech Support
at
1-800-NAV-HELP.
