Alpine ACTIVE VIEW HCE-C305R User manual

ACTIVE VIEW™ REAR CAMERA SYSTEM
HCE-C305R
• OWNER'S MANUAL
Please read before using this equipment. • MANUAL DE OPERACION
Lealo antes de utilizar este equipo.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by
registering your product now at the following address: www.alpine-usa.com/registration.
You will be informed of product and software updates (ifapplicable), special promotions, news about
Alpine,
and entered for a chance to win prizes.
Merci d'avoir achete ce produit Alpine. Nous vous invitons a consacrer
un moment ala protection de
votre achat en enregistrant votre produit des maintenant a l'adresse suivante:
www.alpine-usa.com/registration.
Vous serez tenu informe des mises a
jour des produits et des logiciels (le cas echeant), des promotions
speciales, de l'actualite d'Alpine, et vous aurez une chance de remporter des prix.
Gracias
por adquirir este producto Alpine. Con solo unos pocos pasos podni proteger su producto,
registnindolo a traves de la siguiente direccion: www.alpine-usa.com/registration.
Recibini informacion sobre nuevos productos y software, promociones especiales, novedades sobre
Alpine y participani en el sorteo de premios.
ALPINE ELECTRONICS MARKETING, INC.
1-7, Yukigaya-Otsukamachi, Ota-ku,
Tokyo 145-0067,
JAPAN
Phone: [phone]
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501,
U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road, Toronto,
Ontario M3J 2M9, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
YAMAGATA Co., Ltd.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone [phone]
ALPINE ELECTRONICS GmbH
Wilhelm-Wagenfeld-Str. 1-3,
80807
Munchen, Germany
Phone [phone]
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway,
Coventry CV4 9TW, U.K.
Phone [phone]
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B338 101 280)
98, Rue
de Ia Belle Etoile, Z.l. Paris Nord II,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone [phone]
2-6-34,Takashima, Nishi-ku, Yokohama-shi,
Kanagawa, 220-8515 Japan
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090Trezzano
Sui Naviglio (MI), Italy
Phone [phone]
ALPINE ELECTRONICS DE ESPANA, S.A.
Portal de Gamarra 36, Pabell6n, 32
01013 Vitoria (Aiava)-APDO 133, Spain
Phone [phone]
ALPINE ELECTRONICS (BENELUX) GmbH
Leuvensesteenweg 51 O-B6,
1930 Zaventem, Belgium
Phone [phone]
5
Designed by ALPINE Japan
Printed in Japan (Y)
68-23120Z51-A
(Y _AS)

Contents
Operating Instructions
WARNING
DANGER...........................................2
WARNING ........................................2
CAUTION .........................................3
NOTICE.............................................4
Feature
About Object Detection
Function..........................................5
Cautions Regarding Object Detection
Function.................................................. 6
About Selection
of Warning Objects...... 7
Display of Detected Object..............8
Warning Icon when No Object is
Detected................................................ 10
Moving object verification icon............ 10
Camera Image..................................10
About the rear camera guide................. 11
Error between the display and actual
road surface ..........................................
12
Warning Message Displays .................... 13
About Calibration ........................... 13
Camera Operation
Turning the Rear Camera On and
Off ..................................................14
Displaying the rear image by shifting the
gear lever...............................................
14
Changing the Rear Image
Configuration...............................14
Adjusting Alarm Volume ...............15
Adjusting Detection Sensitivity..... 15
Installation and Connections
Installation of the Rearview
Camera System ............................
16
Mounting the Rearview Camera ... 16
1. Preparation .......................................... 16
2. Installing the Rearview camera......... 17
3. Installing the Buzzer........................... 19
4. Installing the Switch ........................... 20
5. Installing the Control Unit................ 20
Special Instructions for Pickup Truck
Installations .......................................... 21
Connections.....................................22
System Example ..............................24
Connecting a product that has RCA
video input terminals .......................... 24
Confirmation .................................. 25
Calibration
Introduction.....................................26
What is Calibration?............................... 26
Setting Flowchart.................................... 26
Switching between "Calibration Mode"
and "Normal Use Mode"..................... 26
Preparation.......................................26
Accessory parts........................................ 26
Necessary tools........................................ 26
Necessary space for work.......................
27
Prepare the Car Body............................. 27
Affixing the calibration sheets.......27
About Operation in Calibration
Mode .............................................30
Performing Calibration ..................
31
Information
Specifications ................................... 35
In Case of Difficulty .......................35
LIMITED WARRANTY
l-EN

2-EN
Operating Instructions
WARNING
~DANGER
This symbol means important instructions.
What to do in the case
of
an
extremely critical
situation wherein someone may suffer grave
or mortal injury.
DO NOT
PROCEED
TO
BACK
UP
YOUR
VEHICLE
WHILE
PEOPLE
ARE
IN
YOUR
VIEW
OR
THE
CAMERA'S
VIEW.
SERIOUS
INJURY
OR
DEATH
CAN
RESULT.
~WARNING
This symbol means important instructions.
Failure to heed
them
can result in serious
injury or death.
WHEN USING A
CAMERA
SYSTEM,
THE
DRIVER
MUST
VISUALLY
CHECK
ACTUAL
CONDITIONS AROUND
THE
VEHICLE.
MAKE
SURE
THERE
ARE
NO
PERSONS
OR
ANIMALS IN
THE
AREA
IN WHICH
YOU
ARE
MANEUVERING
OTHERWISE
YOU
COULD
INJURE
THEM.
A camera assists the driver by sending images to the screen
showing conditions in view
of
the camera. The camera uses
a wide-angle lens, therefore, there
is
a difference in distance
perspective between what
is
normally seen and what appears
on the screen. Also, the images shown by the rearview camera
are reversed, so
as
to appear the same
as
what
is
seen through
the rearview mirror.
The camera may not perform to full capability due to
variables such
as:
• weather conditions such
as
hard rain, snow,
fog
or
mud
• extremely high
or
low temperatures near camera
• slope
of
vehicle
and/or
roadway
• direct exposure to very bright light such
as
headlamp or
bright sunlight
• moving from very
dark
to very bright light and vice versa
such
as
in parking garages
or
tunnels
• extremely low light areas
• walls
or
objects that are located diagonally in relation to
the camera
• retracted mirrors that change camera viewing angle
•
open
doors
or
trunks
• changes to height
of
vehicle due to loading capacity
or
hydraulic suspensions
• objects located at the corner
of
the vehicle
WHEN USING
AN
OBJECT
SENSOR
SYSTEM,
THE
DRIVER
MUST
VISUALLY
CHECK
ACTUAL
CONDITIONS
AROUND
THE
VEHICLE.
MAKE
SURE
THERE
ARE
NO
PERSONS
OR
ANIMALS IN
THE
AREA
IN WHICH
YOU
ARE
MANEUVERING
OTHERWISE
YOU
COULD
INJURE
THEM.
The Object detection function assists the driver in checking
behind and around the vehicle but
is
not a substitute for using
your own eyes. The system may not perform to full capability
due to variables such
as:
• weather conditions such as hard rain, snow, fog
or
mud
• dense exhaust fumes obscuring the sensor
• extremely high or low temperatures near sensor
• slope
of
vehicle
and/or
roadway
• direct exposure to very bright light such as headlamp
or
bright sunlight
• moving from very dark to very bright light and vice versa
such
as
in parking garages
or
tunnels
• walls or objects that are located diagonally in relation to
the sensor
• open doors
or
trunks
• changes to height
of
vehicle due to load capacity
or
hydraulics
• speed
of
vehicle
and/or
approaching object
• objects moving perpendicular to vehicle at same speed
as
vehicle
• walls or objects that are located diagonally in relation to
the sensor
• large groups
of
moving objects, such
as
pedestrians in
crosswalk
• when an object and vehicle are not moving
• when an object approaches the vehicle from an angle
greater than 5 degrees
objects more
than
12
feet
or
3.7 meters behind vehicle
objects hidden by vehicle
narrow objects such
as
a cone
or
pole
objects located above the area that the sensor can scan
non-moving small objects that are low to the ground
approaching a flat wall, such
as
parking structure
or
guardrail
other vehicles traveling at speed in excess
of
24
mph
or
40km
• own vehicle traveling over 3
mph
or
5 km
CHECK
THAT
THE
CAMERA AND/OR
SENSOR
MOUNTING
IS
ATTACHED
SECURELY,
AND
THAT
THE
SCREWS
ARE
TIGHT
BEFORE
DRIVING.
Failure to do so may result in an accident.
WHEN INSTALLING
OR
CHECKING
A
CAMERA
AND/OR
OBJECT
SENSOR,
DO
SO
AFTER
PARKING
THE
CAR
IN
A
LEVEL,
SAFE
PLACE,
TURNING
OFF
THE
ENGINE, AND
APPLYING
THE
HAND
BRAKE.
Failure to do so may result in an accident.
WHEN INSTALLING
CAMERA
AND/OR
OBJECT
SENSOR,
BE
SURE
TO
USE
SPECIFIC
VEHICLE
CALIBRATION
KIT
OTHERWISE
IT WILL NOT
ACCURATELY
DISPLAY
IMAGES.
Failure to do so may result in an accident.
MINIMIZE
DISPLAY
VIEWING WHILE DRIVING.
Viewing the display may distract the driver from looking
ahead
of
the vehicle and cause an accident.
DO NOT
DISASSEMBLE
OR
ALTER.
Doing so may result in an accident, fire or electric shock.
KEEP
SMALL
OBJECTS
SUCH
AS
BOLTS
OR
SCREWS
OUT
OF
THE
REACH
OF
CHILDREN.
Swallowing them may result in serious injury. Ifswallowed,
consult a physician immediately.
USE
THE
CORRECT
AMPERE
RATING
WHEN
REPLACING
FUSES.
Failure to do so may result in fire or electric shock.

MAKETHE CORRECT CONNECTIONS.
When making connections to the vehicle's electrical system,
be aware
of the factory installed components (e.g. on-board
computer). Do not tap into these leads to provide power
for this unit.
When connecting the device to the fuse box,
make sure the fuse for the intended circuit
of the device has
the appropriate amperage. Failure to do so may result in fire
or damage to the unit
and/or the vehicle. When in doubt,
consult your Alpine dealer.
BEFORE WIRING, DISCONNECTTHE CABLE FROM THE
NEGATIVE BATTERY TERMINAL.
Failure to do so may result in electric shock or injury due to
electrical shorts.
DO NOT ROUTE ELECTRICAL CABLES NEAR HOT OR
MOVING PARTS.
Route the cables and wiring away from hot or moving parts,
and
fix them securely to avoid heat/mechanical damage to
the cable insulation, which may result in a short circuit, fire
or electric shock.
DO NOT SPLICE INTO ELECTRICAL CABLES.
Never cut away cable insulation to supply power to other
equipment. Doing so will exceed the current carrying
capacity
of the wire and result in fire or electric shock.
DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER
VEHICLE OPERATION, SUCH AS THE STEERING WHEEL
OR SHIFT LEVER.
Doing so may obstruct forward vision or hamper movement
etc. and results in serious accident.
DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING
HOLES.
When drilling holes in the chassis for installation, take
precautions so
as not to contact, damage or obstruct pipes,
fuel lines, tanks or electrical wiring. Failure to take such
precautions may result in fire.
DO NOT USE BOLTS OR NUTS IN THE BRAKE OR
STEERING SYSTEMS TO MAKE
GROUND CONNECTIONS.
Bolts or nuts used for the brake or steering systems (or any
other safety-related system), or tanks should NEVER be used
for installations or ground connections. Using such parts
could disable control
of the vehicle and cause fire etc.
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN
SURROUNDING OBJECTS.
Arrange wiring and cables in compliance with the manual
to prevent obstructions when driving. Cables
or wiring that
obstruct or hang up
on places such as the steering wheel, shift
lever, brake pedals, etc. can be extremely hazardous.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in fire,
electric shock or other injury.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so
may result in fire, etc.
WHEN USING A DRILLTO MAKE A HOLE, TAKE
PRECAUTIONS SUCH AS WEARING GOGGLES SO
FRAGMENTS
DO NOT GET INTO THE EYES.
Failure to do so may result in injury.
CALIBRATION REQUIRED.
If this camera system is not calibrated, its detection function
will not work properly.
It must be calibrated before use.
Calibration
is also necessary after remounting.
BE CAREFUL WHEN SETTING THE ALARM VOLUME.
Set the alarm volume to an audible level. Ifthe alarm cannot
be heard due to the volume
of the car radio, etc., it might
result in an accident.
BE AWARE OF DIFFERENCES IN DETECTION SENSITIVITY
LEVELS.
If the sensitivity level of the object detector is changed
from a high setting to a low setting, be aware
of differences
in detection levels. Objects that were detected under the
previous level will not be detected anymore, and this might
result in an accident.
BE AWARE OF THE OPERATING CONDITIONS OF THE
OBJECT DETECTION
FUNCTION.
The warning function only works when the gear lever is in
the reverse position (R). Using the detection feature with
reverse OFF may result in an accident.
DO NOT USE WITH A TOW TRUCK.
If reversed while connected to a tow truck, it will falsely
detect the tow truck. Also, it cannot detect objects near the
tow truck, which may result in an accident.
DO NOT JUDGE SITUATIONS BASED ONLY ON THE
WARNING OF THE OBJECT DETECTION
FUNCTION.
Warnings may not always be given even when vehicles or
people are in danger of being hit. This is due to many factors
such
as vehicle speed or distance from your vehicle.
DO NOT IGNORE OBJECT DETECTION FUNCTION
WARNINGS.
Ifan object detection warning occurs, check the surrounding
area thoroughly.
~CAUTION
This symbol means important instructions.
Failure to heed them can result in injury or
material property damage.
DO NOT ATTACH THE CAMERA AND/OR OBJECT SENSOR
MOUNTING TO FLUOROCARBON RESIN FINISHED CAR
BODIES OR GLASS.
Doing so could cause the strength of the camera mounting to
weaken, which could cause it to fall
of and cause accidents,
injury,
or damage to the car body.
DO NOT ATTACH THE CAMERA AND/OR OBJECT SENSOR
MOUNTING TO ANY SURFACE WHERE THE ENTIRE
ADHESIVE SURFACE
CANNOT BE APPLIED.
Doing so could cause the strength of the camera mounting to
weaken, which could cause it to fall
of and cause accidents,
injury,
or damage to the car body.
EXCEPT FOR THE CAMERA AND/OR OBJECT SENSOR, DO
NOT ATTACH ANY PARTS TO AREAS WHICH WILL GET
WET, OR WHERE THERE
IS A LOT OF HUMIDITY OR DUST.
Failure to do so may result in fire or damage.
USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM
SECURELY.
Be sure to use only the specified accessory parts. Use of other
than designated parts may damage this unit internally or may
not securely install the unit in place. This may cause parts to
become loose resulting in hazards or product failure.
3-EN

4-EN
HAVE THE WIRING
AND
INSTALLATION DONE
BY
EXPERTS.
The wiring and installation
of
this unit requires special
technical skill
and
experience.
To
ensure safety, always
contact the dealer where you purchased this product to have
the work done.
ARRANGE THE WIRING SO
IT
IS
NOT
CRIMPED OR
PINCHED
BY
A SHARP METAL EDGE.
Route the cables
and
wiring away from moving parts (like
the seat rails)
or
sharp
or
pointed edges. This will prevent
crimping
and
damage to the wiring.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury
or
damage to the
product. Return it to your authorized Alpine dealer
or
the
nearest Alpine Service Center for repairing.
CHECK
WIRING
WHEN
ATTACHING.
Double-check your wiring to ensure all connections are
correct
and
secure. Also, do not apply unnecessary force to
the harness. This can result in battery failure, performance
failure, connector damage,
or
wire breakage.
NOTICE
• About Care
of
Device
Do not assert any excess pressure to the camera, object
sensor
or
the mounting,
as
this could cause the device's
direction to shift,
or
the device mounting to come off.
•
To
prevent the camera lens, object sensor,
mounting
and
cords from changing color
or
shape,
or
from deteriorating,
wipe with a chemical-free, damp cloth.
•
When
washing the vehicle, do not use an automatic car
wa
sher, or high-pressure washer. Doing so could cause
the camera
and/or
object sensor to come off, damage to
the device cords, or may allow water to enter the camera
and/or
object sensor.
Be
sure to disconnect the cable from the
(-)
battery post
before installing your HCE-C305R. This will reduce any
chance
of
damage to the unit in case
of
a short circuit.
•
Be
sure to connect the color coded leads according to the
diagram. Incorrect connections may cause the unit to
malfunction
or
damage to the vehicle's electrical system.
• When making connections to the vehicle's electrical
system, be aware
of
the factory installed components (e.g.
on-board
computer). Do not tap into these leads to provide
power for this unit.
When
connecting the HCE-C305R to
the fuse box, make sure the fuse for the intended circuit
of
the HCE-C305R has the appropriate amperage. Failure to
do so may result in damage to the unit
and/or
the vehicle.
When
in
doubt, consult your Alpine dealer.
• In some cases, to attach the device, a hole
must
be drilled
in the car body, requiring use
of
touch-up paint (retail
product) for rust-prevention, and should be prepared
beforehand.
• Route the cables and wiring away from hot or moving
parts,
and
fix
them
securely to avoid heat/mechanical
damage to the cable insulation, which may result in short-
circuit, fire
or
electric shock.
• About Calibration Settings
Obstacle detection performance adjustment and guidance
mark settings configuration require that the camera
installation information be entered. Ifthe camera
information
is
not entered, correct detection results may
not be provided. Therefore, be sure to perform calibration.
When
the camera
is
reinstalled or when the vehicle
is
changed,
be
sure
to
perform
readjustment.
• About Rear Camera
The rear camera
of
this camera system
is
a dedicated
product. Do not connect it to other cameras.
• About Power Connection
Connect a reverse input cable (orange/white) to the
power cable
of
the rear lamp. For details, consult a dealer
purchased the camera,
or
car dealer.
• Connect this
to
a power
cable
of
the
rear
lamp,
but not
to
the
positive (
+)
of
the
rear
lamp signal
cabl
e.
•
Do
not use a mobile phone and wireless device near the
camera.
• Doing so may result in noise on the screen
or
malfunction.
It
is
recommended to use a mobile phones or wireless
devices away from the camera.
• About Camera Installation Location
Before installing, make sure there
is
a enough space to be
able to install the camera.
Ifpossible, install the camera in the center
of
the
bumper
or
other fitting. Ifthe camera
is
installed at a distance left
or
right
of
center, the image may differ from the real view.
• Choose the mounting locations for the control unit, camera
and
buzzer carefully. This location must be able to support
the product weight when
mounted
by the supplied screws.
Otherwise, damage to the vehicle may result.

Feature
This camera system displays a live video
of
the area
behind
the vehicle. A separately installed
monitor
is
required to view this video.
When
the vehicle
is
placed in reverse, besides video, the system also detects
various objects (such
as
other cars
or
people) moving
behind
the vehicle. There
is
a visual and audible
warning given for each object detected.
There are
4
different display configurations for the rear view.
About Object Detection Function
This camera system detects objects from the camera image
and
warns drivers with a display
and
an
alarm.
The object detection function
is
useful in the following situations:
•
When
you reverse the car to exit a parking space at a shopping mall, this function helps to detect cars
that are driving from the right
or
the left and gives an audible warning.
•
When
you reverse the car to exit your garage toward the street, this function helps to detect cars that
are driving down the street
and
gives an audible warning.
• Objects moving awayfrom vehicle
are
not detected.
•
You
can
adjust the volume
of
the warning
beeps.
Refer
to
"Adjusting Alarm Volume"
(page
15).
•
You
can
adjust the sensitivity
to
objects. Refer
to
"Adjusting Detection Sensitivity"
(page
15).
5-EN

6-EN
Cautions Regarding Object Detection Function
This camera system
is
designed to help
the
driver make safe driving decisions. It must
not
replace a thorough, visual inspection around
the
vehicle by the driver, before proceeding.
• This system cannot detect every object within
range
of
coming
in
contact with your
vehicle.
• This camera distorts object size and distance from the
vehicle.
We
are
not responsible for any accidents caused
by
driver misjudgement
or
conclusions based
on
objects
seen
or
unseen
by
this system.
This system uses the camera's image to detect moving objects. Therefore, only objects seen by the camera
are detectable.
There be times when a false warning
is
given with no moving object in the display. In
other
cases, no
warning at all
is
given although moving vehicles are visible in the display.
In addition, a warning may
not
be given
or
may
be
delayed in the following cases
or
for the following
objects.
• Object out
of
the
camera's scope
Your vehicle
x·--·
0
• Objects approaching from directly behind
• When both the vehicle and objects
are
motionless
-Motionless objects
are
difficult
to
detect. Therefore, there may
be
cases
where a warning
is
notgiven or the
distance
is
not
correct.
Be
sure
to
perform a visual
check.
• Roadpaint (for example, crosswalks),
tire
chocks,
curbstones
• Thin objects (for example,
cones
and poles)
• Low objects (for example, infants, children and small bicycles/tricycles)
•
Large
objects (for example, concrete block walls andguardrails)
• Objects not within
3.
7
m behind the vehicle
• Objects approachingfrom a
slope

•
If
multiple pedestrians crossing.
If
multiple pedestrians continuously approaching.
•
When
the object moves at the same speed as the vehicle
• Motionless objects when the vehicle moves very slowly
• Object moving at an extremely low speed
•
When
objects disappear
from
the camera's scope because
of
exhaustgases, rain, fog, snow, or
mud
• False detection because
of
exhaustgases, rain, snow, or road surface reflections
•
When
the vehicle moves
at
speeds equal to or more than 5
mph
(5
kmlh)
•
When
the object moves
at
speeds equal to or more than
25
mph
(40
km!h)
•
When
the detection range becomes narrower because the camera's scope
is
interrupted by the vehicle's body
•
When
tires are changed or the vehicle
is
loaded with heavy objects after calibration
• A particularly dark location
at
night
• A lightflashing near the vehicle or its own hazard lampsflashing.
•
When
light hits the camera directly
(If
a license plate lamp has been customized to be brighter than normal, etc.)
•If
the vehicle
is
tilted
• Reflection
of
light on the road surface while driving the vehicle
• Moving object that starts moving near the vehicle
•
If
the vehicle shadow shows up in the camera image
•
If
the headlights
of
another car reflect on the body
of
the vehicle
to
the side
About Selection
of
Warning Objects
If
multiple objects are detected, a
warning
is
given for
the
most
critical object in
both
the
right
and
left
images.
An
alarm
sounds
for
the
nearest object
on
either
the
right
or
left side.
The
warning
objects are selected according to
the
"arrival time"
to
the
vehicle. Therefore, objects at
higher
speeds are recognized as
high
priority
from
a longer distance. Even
when
a moving object at
lower speeds (for example, pedestrians) is closer
to
the
vehicle,
another
moving
object with a
shorter
arrival
time
(for example, a car)
is
preferentially displayed
if
such
an
object
is
detected.
For example:
There
is
a
pedestrian
moving
towards
your
vehicle at 2.5
mph
(4
km/h)
and
a car
from
your
vehicle
approaching
at
12
mph
(20
km/h).
The
car will reach
your
vehicle earlier.
In
this case, a
warning
is given for
the
car.
Your vehicle
12
mph (20 km/h)
Arrival
time
is
shorter
'---y----'
2.5
mph (4 km/h)
Arrival
time
is
longer
Pedestrian
Car
7-EN

B-EN
Display
of
Detected Object
The display
when
an object
is
detected differs
depending
on
image configurations.
• When there
are
lots
of
objects present,
such
as
in
a
crowd
of
people, the outerframe light will blink
as
a
warning. Individual objects will not
be
detected.
• Because this camera system detects objects based
on
a Panorama View
image,
warnings
can
occur even
if
an
object
does
not show
on
the Ground View I Rear
View
screen.
• Panorama View Display
Indications
A small box appears
on
an object that enters the
camera's view.
The
box follows the object moving
through
the display.
• The box represents the objects approximate position
relative
to
your
vehicle.
There may
be
times when
the box
does
not appear
or
does
notfollow the object
accurately.
When an object
is
detected,
the
screen
is
enclosed by a red frame (first
time
only).
An
alarm also starts
to
sound.
•
The system boxes
off
the
object in red.
The warning ends when the object comes
directly behind the vehicle. No warning also
occurs when
the
object moves away from
the
vehicle.
• Rear View Display Indications
A
triangle
mark
appears
on
the leftmost
or
rightmost side
of
the screen, indicating that an
object is approaching from a side. After the object
appears
on
the screen, a small box appears at the
approximate location.
When an object
is
detected,
the
screen
is
enclosed by a red frame (first
time
only).
An
alarm also starts
to
sound.
If
the
object comes into
the
warning area, a
red triangle arrow appears.

When the object comes into the screen, the
system boxes off the obstacle in red.
The
warning ends when the object comes
directly behind the vehicle. No warning also
occurs
when the object moves away from the
vehicle.
• Ground View Display Indications
A triangle mark appears on the leftmost or
rightmost side of the screen, indicating that an
object is approaching from a side.
When an object is detected, the screen is
enclosed
by a red frame (first time only). An
alarm also starts
to sound.
If the object comes into the warning area, a
red
triangle arrow appears.
The
warning ends when the object comes
directly behind the vehicle. No warning also
occurs
when the object moves away from the
vehicle.
• The Ground View displays only a small area.
Even if no warning occurs, make sure to check the
surrounding area thoroughly.
• Corner View Display Indications
The direction from which a detected object is
approaching is indicated on the left or right side
of the screen.
The left or right side screen frame (whichever
side
the object is detected) blinks red.
The
warning ends when the object comes
directly behind the vehicle. No warning also
occurs
when the object moves away from the
vehicle.
9-EN

10 -EN
Warning Icon when NoObject is
Detected
The system detects an object only when the gear
lever
is in the reverse position (R).
•Ifa rear camera image is displayed without placing
the gear lever in the reverse position (when you
call a rear camera image from the menu screen for
example), object detection
is not active.
When object detection is not active, an icon
appears at the upper left
of the screen.
Warning icon
Moving object verification icon
This icon displays when the system is determining
if an object nearby the vehicle is moving or
stationary. Warnings are delayed slightly while
this icon
is beingdisplayed.
•
The moving object verification icon may be displayed
even
if vehicle speed increases.
Camera Image
With HCE-C305R, you can select and switch
image configurations.
The guidelines display varies with the image
configuration.
For details
on how to switch image
configurations, refer to "
Camera Operation" (page
14)
•
The guidelines shown here are for illustrative
purposes
only. The guidelines in the actual image
will
be different.
--------------~ ,------- ~--~
Panorama View:
Displays a general perspective of what is behind
the car. Use this when you want to view a wider
than normal area behi nd the car.
RearView:
Displays what is directly behind the car. Use this
when reversing into a parking space, for example.
f.::.:_
;£--
,, ,,

Ground View:
Displays
an
down
to
the
lower
section
of
the
car.
Use
this
to
determine
the
car's position in
relation
to
the
curb, etc.
Corner View:
Displays a divided image left and
right
of
center.
Use
this mainly
when
checking
the
left and
right
directional
view
.
• No guidelines appear in Corner View.
• The rearview camera image
is
reversed to have the
same
perspective as the rearview mirror. However,
due to the camera'sfisheye lens, there
is
a distortion
of
the actual distance
as
it appears in the display.
• Images
may
not
be clearly displayed in thefollowing
conditions. This
is
normal.
-In
the dark (nighttime, etc.)
-The temperature near the lens
is
high or
low.
-The camera has water droplets on it or the
humidity
is
high (rainy day, etc.).
-Foreign substances (dirt, etc.) are on or
around
the
camera.
-Sun light or the light
of
a headlamp directly enters
the camera lens.
• The guidelines in the display
may
not
always
correspond to actual distances
from
objects being
viewed. Factors such as road surface,
number
of
passengers, load weight, suspension adjustments,
etc. can affect the accuracy
of
the display. Always use
visual inspection to verify safe driving conditions
of
your
surroundings.
About
the
rear camera guide
• Indication mark meaning
When
you put the car in reverse gear, the monitor
switches to the rear camera view. Guidelines
appear to help in determining distances to
surrounding objects (vehicles, walls, etc.).
CD
Car width extension marks (red, yellow
and green in order
of
proximity)
The marks
are
extensions
of
the
vehicles
width.
They provide guidance
when
backing
into
a parking space.
®
Distance guidelines
The horizontal lines represent
the
distance
from
the
rear
of
the
car (from
the
rear end
of
the
bumper).
• The lines
do
not
move
in synchronization
with
the
steering wheel.
•
Each
line represents a distance
of
0.5
m or
20" (red), 1 m or 39" (yellow) and 2 m or 79"
(green) behind
the
vehicle.
• Depending on the condition
of
the car or road
surface, the range
of
vision
may
vary.
• The camera's range
of
vision has a limit. Objects
near both ends
of
the
bumper
and
objects
under
the
bumper
may
be
out
of
sight
of
the camera.
• The rear camera image
may
have a tint which
is
different
from
the actual surroundings.
•
Depending
on the
car,
the guidance
may
deviate to
the right or left. This
is
not
a malfunction.
11-EN

12-EN
• Distance guidelines
The distance guidelines represents the distance to
the road surface, so you cannot judge the distance
to an object based
on these marks.
<Screen>
;:..
,
I
1-
1
I
I
c
---7---8
----:-- A {about
20" {O.Sm})
<Positions of A, 8 and C>
about 39" {1m)
In the display, according to the distance
guidelines,
the truck seems to be parked
about 39"
(1 m) away (at position 8).1n fact,
however,
if you reversed to position A, you
would collide with
the truck.
In
the display, positions A, 8 and Cseem to
be located in order of proximity. However,
position A and
Care the same distance, and
8
is further awaythan positions A and C.
• The car width extension mark represents the distance
to the road surface, so when an object on the road
surface
is displayed on the screen, the mark does not
represent the actual distance to the object.
• In thefollowing conditions, screen visibility
may be
impaired. This
is not a malfunction.
- When it is dark (at night, etc.).
-
When the temperature around the camera lens is
high or low.
- When water drops adhere to the camera, or when
the
humidity is high (such as rainy weather, etc.).
- When foreign bodies (such as mud, etc.) adhere to
the camera or its peripheral area.
-
When sunlight or headlights directly strike the
camera lens.
Error between the display and
actual road surface
Under the following conditions, errors are
produced between the display guidelines
and the
actual road surface. (The illustrations represent a
case when the camera
is installed in the standard
position.)
• When there is a steep upward
slope behind the car (example)
<Screen>
]'"''"'
i
j
I-
I
I
I-
I
I
I
Distance guidelines
<Situation of the car>
Actual distance
~1.
fB -\
\
~
\ \ \
Actual distance
Error Error
The distance guidelines represents the
distance to a flat road surface. Therefore in
the
case of an upward slope behind the car,
the distance guidelines appear further from
the vehicle than their actual position. For
example,
if there is an object on the upward
slope,
it may appear further away than its
actual position.
Also, an error may occur between
the
guidance and the actual path of the car on
the road surface.

• When there is a steep downward
slope behind
the car (example)
<Screen>
;==·
f
J-
1
I
I-
-I
I
I
<Situation of the car>
'!\
~
\ \
~
\
Error
\ \ -
Error
In the case of a downward slope behind
the
car, the distance guidelines will appear
further away than the actual distance.
If there is an object on the downward slope,
it mayappear closer than its actual position.
Also, an error may occur between the
guidance and the actual path
of the car on
the road surface.
Warning Message Displays
This camera system displays warning messages in
the upper part
of the screen.
•Ifthe connected navigation/monitor also displays a
warning message, its message will appearfirst.
About Calibration
In order to effectively identify approaching
objects, it
is necessary to configure the guidance
and install data. This data
is entered during the
Calibration mode and ensures the most consistent
detection results.
For details on how to configure the calibration
settings, refer to "Calibration" (page 26).
• A message appears on the screen if the system has
not been calibrated.
13-EN

14-EN
Camera 0 eration
Operation is carried out by pressing the switch,
or
shifting the gear lever.
The following settings may be required depending
on
the connected navigation/monitor.
• Rear camera connection: ON setting
Setting
to
ON
is
required
to
display
the
camera
image on the navigation/monitor.
• Camera guidelines display: OFF setting
This camera system
has
its own, calibrated
guidelines. It
is
not
necessary
to
display
the
guidelines found in the
navigation/monitor
system being used.
• Refer also
to
the owners
manual
of
the product
to
connect.
Turning
the
Rear Camera On
and
Off
Displaying
the
rear image by
shifting the gear lever
1
Shift
the
gear
lever
to
the
reverse
position (backing up).
The video image behind the car and the
audible warnings depends
upon
the
gear
shift position.
2
If
you shift
the
gear lever
to
a position
other
than reverse (backing up),
the
monitor
returns
to
the
previous screen.
• Refer also
to
the
Owners
Manual
of
the connected
monitor/navigation system.
• Be sure
to
also check behind
and
around the car
visually.
Use
the camera image
to
assist in showing
conditions behind
and
around the
car.
• Depending on where the
unit
is
installed, actual
conditions
may
differ
from
the displayed image.
Changing
the
Rear Image
Configuration
1
Press
VIEW.
The image configuration changes every
time
VIEW
is
pressed.
Rear View
Panorama View
CornerView
Ground View

Adjusting Alarm Volume
The audible warning has 3 selectable volume
levels.
The default is the "Middle" setting.
1 Press and hold SET. for at least 1 second.
The volume adjustment screen appears.
2 Press SET. to switch to a desired volume
level.
Pressing the button toggles the volume level.
[ .. )»~Low- .. ))~Middle- .. )))High J
3 Press and hold SET. for at least 1 second.
The sensitivity adjustment screen appears.
4 To return to the normal mode, press and
hold SET. for at least 1 second again.
• The buzzer volume can be altered accidentally. Use
with the appropriate volume level.
Adjusting Detection
Sensitivity
Object detection has 2 selectable sensitivity levels.
The default is "High:'
1 Press and hold SET. for at least 1 second.
The volume adjustment screen appears.
2 Press and hold SET. for at least 1 second
again.
The sensitivity adjustment screen appears.
3 Press SET. to switch to a desired
detection sensitivity level.
Pressing the button toggles the detection
sensitivity level.
• ((l•J)) High - [(l•J)] Low ~
Low: Detects mainly
moving objects.
Almost no motionless objects
are
detected.
High: Detects
moving objects and
motionless objects.
4 To return to the normal mode, press and
hold SET. for at least 1 second.
• For details on the detection function, refer to
"Cautions Regarding Object Detection Function"
(page 6).
15-EN

16-EN
Installation and
Connections
Be
sure to disconnect the cable from the
(-)
battery post
before installing your HCE-C305R. This will reduce any
chance
of
damage to the unit in case
of
a short circuit.
•
Be
sure to connect the color coded leads according to the
diagram. Incorrect connections may cause the unit to
malfunction or damage to the vehicle's electrical system.
•
When
making connections to the vehicle's electrical
system, be aware
of
the factory installed components (e.g.
on-board computer). Do not tap into these leads to provide
power for this unit.
When
connecting the HCE-C305R to
the fuse box, make sure the fuse for the intended circuit
of
the HCE-C305R has the appropriate amperage. Failure to
do so may result in damage to the unit
and/or
the vehicle.
When
in doubt, consult your Alpine dealer.
• Route the cables and wiring away from hot
or
moving
parts, and
fix
them securely to avoid heat/mechanical
damage to the cable insulation, which may result in short-
circuit, fire
or
electric shock.
•
When
fixing the control unit, camera, and alarm to the
vehicle with screws, attaching to weak spots may damage
vehicle parts.
•
If
the camera
is
not mounted securely, shifting positions
will cause deterioration
of
detection performance.
• The cable may break due to stress caused when opening
and closing the
door/trunk
of
the vehicle.
• Ifthe control unit becomes wet, the electrical circuitry may
short out.
• Attaching with double stick tape may leave a
mark
on
the
vehicle interior.
• This camera system
is
meant to be used as a rear camera.
It
cannot
be used
as
a front
or
side camera.
• This camera system cannot be used
as
a corner sensor.
• The camera
is
designed specifically for use with this
system. The system cannot be used with a different camera.
• This product cannot be installed in
or
used with anything
other than a car (in other words, it cannot be used with
motorcycles, mobility vehicles,
or
electric wheelchairs
or
as
a household security camera, etc.).
Installation
of
the
Rearview
Camera System
Installing the Rearview camera (page 17)
Installing the buzzer and operation switch
(page 19)
Checking the installation location
of
the
control unit (page 20)
Connect the device (page 22)
Perform calibration (page 26)
Fixing the control unit
Mounting
the
Rearview
Camera
1. Preparation
1 Check accessory parts.
CD
Rearview camera
(SO
em)
®
Control
unit
0
®
Power cable @
RCA
extension
cable
(3m)
=
00
[§]
(Solderless
connector)
®
Camera extension cable
®
Velcro fastener
(Bm) (Control
unit)
0
Self-Tapping screw
®
Camera
mounting
(Control
unit)
bracket
(M4x8)
~
X4
®
Hex screw
@)
Hexagonal
wrench
~
~
X2
@
Self-Tapping screw (Base
@
Switch (3m)
for
attaching
the
camera)
(M3x8)
X4

@
Switch
adhesive
sheet
@
Buzzer
@
Buzzer
extension
cable
(3m)
@)
Buzzer adhesive
sheet
D
@
Cord
clamp
(Camera
extension
cable)
xs
@
Waterproofing
pad
adhesive sheet
®
Calibration
sheet
(1000
x
200
mm)
@
Cord
clamp
(Switch)
X3
@
Mounting
(Buzzer)
~
@
Self-Tapping screw
(Buzzer)
(M6
x 1
0)
®
Cord
clamp
(Buzzer)
X3
@
Waterproofing
pad
@
Calibration
sheet
(2039 x
100
mm)
X2
2. Installing
the
Rearview camera
1
Attach
the
camera
CD
to the camera
mounting
bracket®
using the hex
screws@.
8
tAngle
adjustment
screw
Make
sure
that
the
ALPINE logo
of
the
camera
is
facing up.
2 Determine a mounting location for the
camera.
When choosing the location, make sure
that
the camera and bracket
won't
come
in
contact
with
any part
of
the
vehicle. Check
the
contact
points after making
the
angle
adjustments
to
the
camera.
The location should be flat
to
provide the
self-adhesive on
the
base
to
make
good
surface contact. Also, ensure access
to
both
of
the angle-adjustment screws for proper
tightening
using the supplied hex wrench.
• Recommended installation
location
See the following table
to
determine the attachment angle
Install
the
camera
so
that
this rounded
part
is
clearly visible then viewed from
the
side
of
the
vehicle.
17-EN

18-EN
<Attachment angles>
Camera height Angle (degrees)
inch
mm
(from horizontal plane)
51.2 1300
40-59
47.2 1200
38-
57
43.3 1100
35-55
39.4 1000
33-
52
35.4 900
30-49
31.5 800
27-46
27.6 700
24-42
23.6 600
21
-38
19.7 500
18-
33
17.7 450
16-
30
• If
the
unit
is
not installed within the designated
angle,
calibration cannot
be
executed
correctly.
• Camera installation height
Lowest: 430
mm
(16.
9")
Highest
1300
mm
(51
.
2")
• Largest left and right offset
400
mm
(
15.7")
from the center
of
the vehicle
both
in the left
and
right directions
• Depth
A
maximum
of
300
mm
(
11.8")
from the tip
of
the rear
bumper
'
---
____
,______
• Install
the
camera
as
outward
as
possible
to
ensure
the detection
range
of
180°.
• Provide enough
clearance
for proper trunk and door
closure
without making contact with
the
camera.
Also,
ensure that the camera
cable
is
not being
pinched
or
damaged.
• Attach the camera
in
a position where it
does
not
touch the license plate.
• Make sure there
are
no
objects protruding between
the camera and bumper (wipers, rear-side
racks,
etc.).
•
Do
not install the camera near the
reverse
lamp.
• If
any part
of
the
vehicle body blocks
the
camera
coverage
area,
detection
of
that
area
will not
be
possible.
3
Installing the camera and the camera
mounting bracket
to
the
car.
•
• Attaching the Camera
Make
sure
that
the
ALPINE logo
of
the
camera
is
facing up.
(1) Drill a 13 mm (1/2") hole at the
mounting location for the camera
cable. Drill 2.5 mm (3/32") holes for
mounting the bracket. Apply touch-up
paint
as
necessary.
(2) Make sure the mounting surface
is
clean
of
debris, dirt, etc.
(3) Attach the camera to the mounting
bracket®
with the supplied
adjustment
screws.
(4) Make sure the camera
is
facing directly
behind the vehicle. It's horizontal
viewing angle should be at 90° to
the rear bumper. Adjust its vertical
viewing angle to about 45° to the
ground behind the vehicle.
(5) Pull the camera cable inside the car
through the 13 mm (1/2") hole made
in step
(1
).
(6) Peel
off
the protective sheet covering
the adhesive strip on the
bracket@.
Attach the bracket to the surface just
cleaned.
• If
mounting
to
plastic,
use
a self-tapping screw
to
attach the camera bracket@.

4 Secure
the
camera
cable. Attach
the
waterproof
pad
@ with
the
waterproof
pad
adhesive
sheet@,
and
secure
any
slack
cable
around
the
waterproof
pad
@
using
the
cord
clamp@.
• Ensure the cable does
not
get caught in the trunk,
rear door(s) or
any
hinges.
• The cable shouldgo on the outside
of
car hinges
and
harness covers.
•
After
completing wiring, open
and
close the
trunk
and
the rear doors several times
to
confirm the cable
is
not
getting caught or rubbing anywhere.
3.
Installing
the
Buzzer
1
Attach
the
buzzer@
with
the
supplied
double-faced
adhesive
tape@)
or
screw
@.
• Before attaching the buzzer, wipe
off
any
dust, oil,
etc., on the attaching surface with a suitable cleaning
cloth (sold separately).
• Attach the
buzzer
in a location where driving
is
not
hindered.
• Locations that are subject to high temperatures can
cause warping. Do
not
install in areas that receive
direct sunlight, such as the dashboard.
• This
is
not
a water resistant device. Do
not
get the
unit
wet. Also, install so that the cablefeed opening
is
facing downwards to avoid water drops on the cable
falling into the alarm unit.
•
If
the alarm hole
is
closed off,
sound
output
may
become unstable. Do
not
place anything within 10
mm
of
the alarm hole.
• Attaching with
the
double-face
adhesive
tape
(
1)
Peel off
the
protective
sheet
on
one
side,
and
apply
it
to
the
back
of
the
buzzer.
(2)
Peel off
the
protective
sheet
on
the
other
side
and
apply
to
the
desired
location in
the
car
(under
a
seat,
etc.).
If necessary, secure the cable
with
the
supplied cord
clamp®.
• Attaching with
the
screws
(
1)
Assemble
the
buzzer@
and
its
mounting
bracket@.
(2)
Install it in
the
desired
location in
the
car
(under
the
seat,
etc.) with
the
supplied
self-tapping
screw@.
If necessary, secure the cable
with
the
supplied cord
clamp®
.
19-EN
