Alto-Shaam 750-CTUS User manual

750-CTUS
HOT FOOD HOLDING CABINET
D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T,S P E C I F I C AT I O N S A R E S U B E C T TO C H A N G E W I T H O U T N O T I C E .
PRINTED IN U.S.A.#27 - 01/09
ITEM NO. _______________________
Cabinet has 22 gauge stainless steel exterior and French doors with two (2) positive latch door handles. It is
controlled by one (1) ON/OFF adjustable thermostat, 60° to 200°F (16° To 93°C); includes one (1) indicator light; and
one (1) holding temperature gauge to monitor inside air temperature. The cabinet is furnished with two (2) chrome
plated side racks spaced at 3" (76mm) centers to hold full-size sheet pans or can be furnished with optional chrome
plated wire shelves for holding half-size sheet pans and standard full-size pans (gastronorm).
■■MODEL 750-CTUS: Food holding cabinet with French doors and manual control
ADDITIONAL FEATURES & OPTIONS
●Casters or legs available
● HALO HEAT . . . a controlled, uniform heat source that
gently surrounds food for better appearance, taste, and longer
holding life.
● Holds food hot food hot . . . meat, poultry, fish, potatoes, casseroles,
vegetables, rolls, etc. for several hours.
●Close temperature tolerance and even heat application maintain ideal
serving temperatures throughout the cabinet.
●Manual control with adjustable thermostat:
— 60° to 200°F (16° to 93°C).
●Holding temperature gauge monitors inside air temperature.
●Non-magnetic stainless steel interior resists corrosion.
●Flexible installation:
— Counter-top
— Optional casters for mobility
— Optional legs for stationary placement
●Low energy use.


W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FA : 262.251.7067 800.329.8744 U.S.A. ONLY
www.alto-shaam.com

D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T, S P E C I F I C AT I O N S A R E S U B E C T TO C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A.
D I M E N S I O N S : H x W x D
EX TER IO R:
28-1/4" x 29-3/4" x 26-3/8" (718mm x 756mm x 670mm)
IN TER IO R COMPA RTM ENT:
20-7/8" x 26-7/8" x 21" (530mm x 683mm x 533mm)
CLEARANCE REQUIREMENTS
3-inches (76mm) at the back, 2-inches (51mm)
at the top, and 1-inch (25mm) at both sides INSTALLATION REQUIREMENTS
— Appliance must be installed level, and must not be installed in any
area where it may be affected by steam, grease, dripping water, high
temperatures, or any other severely adverse conditions.
— In order to maintain standards established by the National Sanitation
Foundation, all counter-mounted equipment must be sealed to the
counter with a NSF listed sealant, equipped with 6" (152mm) legs,
or have casters.
WEIGHT
NET 141 lb (64 kg)
SHIP 155 lb (70 kg)
CARTO N 34" X36" X30"
DIMENSIONS:(865mm x 914mm x 762mm)
O P T I O N S & A C C E S S O R I E S
■■Casters, 3" (76mm) 14227
■■Casters, 5" (127mm) 4007
■■Legs, 6" (152mm) 5205
■■Pan Grid, Stainless Steel, Wire PN-2115
■■Shelf, Chrome plated, Wire SH-2851
#27 - 01/09
38-7/8" (987mm)
2" (51mm)
29-3/4" (756mm)
24-3/8" (619mm)
28-1/4" (718mm)
27-3/4" (705mm)
Electrical Connection on bottom, 
1-5/8" (41mm) from back
6-1/4" (159mm)
For Casters 
or Legs
750-CTUS
HOT FOOD HOLDING CABINET
(H x W x D)
P R O D U C T \ PA N C A PA C I T Y
48 lb (22 kg) MAXIMUM
VOLUME MAXIMUM: 51 QTS. (57 LITERS)
FU LL-S IZ E SHEET PA NS:
Six (6) 18" x 26" x 1" (457mm x 660mm x 25mm)
HA LF-S IZ E SHEET PA NS:
*Twelve (12) 18" x 13" x 1" (457mm x 330mm x 25mm)
*WITH ADDITIONAL SHELVES
FU LL-S IZ E PANS :
*Six (6) 12" x 20" x 2-1/2" (530 x 325 x 65 mm) GN 1/1
*WITH ADDITIONAL SHELVES
— Includes two (2) side racks spaced at 3" (76mm) centers
ELECTRICAL
VOLTAGE PHASE CYCLE/HZ AMPS kW CORD & PLUG
120V 1 50/60 18.8 2.25 NEMA L5-30P
30A, 125V PLUG
208-240V
at 208 1 50/60 8.4 1.75 NEMA 6-15P
at 220 1 50/60 8.8 1.94 15A, 250V PLUG
at 240 1 50/60 9.4 2.25
230V (AGCY)1 50 9.4 2.17 CEE 7/7
16A, 25V PLUG
