FACTORY INSTALLED OPTIONS
●eft-hand door swing is standard.
■■➥Specify right-hand door as a
special order.
• HA O HEAT . . . a controlled,
uniform heat source that gently
surrounds food to provide a better
appearance, taste, and longer holding life.
• Uses one-third to one-half the energy of conventional
holding equipment.
• Motionless air inside cabinet prevents transfer of
flavors, retains more product moisture, and
preserves color.
• Close temperature tolerance, along with even heat
distribution, maintains an ideal serving temperature
throughout the cabinet.
• Roll-In Pan Cart (trolley) is designed for maximum
capacity and is completely interchangeable with the
Combitherm®Combi Oven/Steamer model 20•20 and
the Alto-Shaam®QuickChillerTM QC-100.
• Available in a stationary or mobile cabinet design.
D U E T O O N G O I N G P R O D U C T D E V E O P M E N T , S P E C I F I C A T I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A. #93 - 05/08
20•20MW
20•20W
CO MPA NI ON H OL DI NG C AB IN ET W IT H RO LL -IN C AR T
ITEM NO. _______________________
MODEL 20•20MW
(SHOWN WITH RIGHT-HAND DOOR)
MODEL 20•20W ROLL-IN PAN CART ROLL-IN PLATE CART
ANSI/NSF 4
Insulated Halo Heat companion holding cabinet features 20 gauge stainless steel construction. The cabinet is controlled with one (1)
ON/OFF power switch and an adjustable, electronic thermostat which includes a heat indicator light, temperature set button, and
temperature increase and decrease buttons. The thermostat has a range of 60° to 200°F (16° to 93°C) and includes a digital display
indicating the air temperature within the cabinet. The door has a heavy duty rotary handle with standard left-hand hinging.
Each holding cabinet includes one (1) Roll-In Pan Cart (trolley) which features removable handle, pan support rails to hold
full-size pans, and ten (10) wire shelves for sheet pans. Cart includes four (4) swivel casters with brake.
■■MODEL 20•20MW: Mobile holding cabinet supported by four (4) heavy duty casters
■■MODEL 20•20W: Stationary holding cabinet supported by four (4) heavy equipment legs
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FA : 262.251.7067 800.329.8744 U.S.A. ONLY
www.alto-shaam.com

W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FA : 262.251.7067 800.329.8744 U.S.A. ONLY
www.alto-shaam.com
P R O D U C T \ P A N C A P A C I T Y
480 lbs (218 kg) MAXIMUM
VO UME MAXIMUM: 300 QUARTS (284 ITERS)
FU -SIZE PANS: Forty (40) 20" x 12" x 2-1/2" MAXIMUM
GN 1/1: Forty (40) (530mm x 325mm x 65mm)
GN 2/1: Twenty (20) (650mm x 530mm x 65mm)
FU -SIZE SHEET PANS: Ten (10) 18" x 26" x 1" (20 with
added shelves)
Roll-in Pan Rack (UN-27970)
—Ten (10) stainless steel wire shelves
—Twenty (20) pan support rail positions
2-5/8" (67mm) vertical spacing between rails
21-3/16" (538mm) horizontal width between rails
W E I G H T 2 0 •2 0 M W 2 0 •20W
NET: 495 lb (225 kg) 495 lb (225 kg) EST.
SHIP: 730 lb (331 kg) 730 lb (331 kg) EST.
CRATE DIMENSIONS:(H XW XD)
80" X44" X50"
(2032mm x 1118mm x 1270mm)
DIMENSIONS: (H XW XD)
EXTERIOR: 73-5/8" x 35" x 42-1/16"
(1869mm x 888mm x 1068mm)
ROLL-IN PAN CART: (TROLLEY)
All stainless steel construction
-Twenty (20) pan support rail positions
2-5/8" (67mm) vertical spacing between rails
21-3/16" (538mm) horizontal width between rails
-Four (4) casters (swivel with brake)
-One (1) removable push handle
-Ten (10) stainless steel wire shelves
INSTALLATION REQUIREMENTS
●Applance must be installed level.
●The appliance must not be installed in any area where it
may be affected by steam, grease, dripping water, high
temperatures, or any other severely adverse conditions.
DUE TO ONGOING PRODUCT DEVE OPMENT, S P E C I F I C A T I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A.#93 - 05/08
C L E A R A N C E R E Q U I R E M E N T S
3" (76mm) at the back, 2" (51mm) at the top,
and 1" (25mm) at both sides
E L E C T R I C A L
VOLTAGE PHASE CYCLE/HZ AMPS kW CORD & PLUG
208-240 (U )1 50/60 17.1 4.1
208 1 50/60 14.8 3.1
240 1 50/60 17.1 4.1
230 1 50/60 17.0 3.9 NO CORD OR P UG
NNEEMMAAL6-30P
30A-250V Plug
35" (888mm)
42-1/16" (1068mm)
67-11/16" (1719mm)
39-1/4" (996mm)
42-1/16" (1068mm)
65" (1651mm)
73-5/8" (1869mm)
8-5/8" (218mm)
32-13/16" (833mm)
ELECTRICAL
CONNECTION
5-5/8" (143mm)
FROM TOP
WITH CASTERS OR LEGS
23-3/8" (593mm)
28-1/8" (714mm)
65-11/16"(1669mm)
33-5/16" (846mm)
O P T I O N S & A C C E S S O R I E S
■■Preheat Sealing Strip 5007925
■■Roll-In Pan Cart (fits QC-100, 20•20ES & 20•20ESG) UN-27970
■■Roll-In Plate Cart (fits 20•20ES & 20•20ESG)
65-1/2" X30-5/16" X39-9/16"
(1663mm x 770mm x 1004mm)
2-11/16" (69mm) SPACING
HO DS 114 10-12" (254-305mm) DIAMETER P ATES
UN-27971
■■Roll-In Plate Cart (fits 20•20ES & 20•20ESG)
65-1/2" X30-5/16" X39-9/16"
(1663mm x 770mm x 1004mm)
3-1/2" (89mm) SPACING
HO DS 78 10-12" (254-305mm) DIAMETER P ATES
UN-28311
■■Shelf, Stainless Steel Wire SH-22473
COMPANION HOLDING CABINET 20•20MW
20•20W
