1200-UP SERIES
LOW TEMPERATURE HOT HOLDING CABINETS
D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T,S P E C I F I C AT I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A. #39 - 7/07
ITEM NO. _______________________
W164 N9221 Water Street • P Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PH NE: 262.251.3800 • 800.558.8744 U.S.A./CANADA FAX: [phone] • 800.329.8744 U.S.A.NLY
WEBSITE: www.alto-shaam.com
®
FACTORY INSTALLED OPTIONS
●Reach-in compartment is standard.
■■➥ Specify pass-through doors as a special
order. Pass-thro ug h cab ine ts canno t h ave
all d o o rs h inge d o n th e sa e sid e .
●Right-hand door swing is standard.
■■ ➥ Specify left-hand door as a special order.
■■Window Door [5005142].
NOT EN ERGY STAR RATED.
●Side Rack Model.
■■As an alte rnative to unive rsal p a n slid e s, th is
unit can b e o rd e re d a s a “sid e rack ” o d e l
w h ich is e q uip p e d w ith tw o (2) sid e rack s and
th re e (3) ch ro e p late d w ire sh e lve s. It w ill
acco o d ate full and h alf size US h o te l a nd
Euro p e an gastro no r p a ns o r sh e e t p a ns o n th e
sid e rack s.
ADDITIONAL FEATURES
●Optional HACCP Documentation software
provides the ability to monitor, store, and
print all relevant data through a Windows®
based PC.
●Optional HACCP with itchen Management
web-based software provides the ability to
program, control, monitor, and store all
relevant data.
● HALO HEAT…a controlled, uniform heat source that gently surrounds food
for better appearance, taste, and longer holding life.
●Holds hot food hot...meat, poultry, fish, potatoes, casseroles, vegetables, rolls, etc.
●Dual purpose — both a holding cabinet and dough proofer.
●Universal rack design accommodates standard full-size (gastronorm) pans or
full-size sheet pans.
●Can be converted with side racks to accommodate shelves for full size gastronorm
pans or full size sheet pans.
●Non-magnetic stainless steel interior resists corrosion.
●Casters provide easy mobility.
●Antimicrobial handle retards the growth of illness-causing pathogens.
ELECTRONIC CONTROL OPTION
■■Solid state electronic control option simplifies temperature setting and has
a clear, easy-to-read LED display and includes our patented SureTemp™
heat recovery system. SureTemp™ reacts immediately to compensate for
any loss of heat whenever the door is opened.
■■Electronic control is also available with six independent multiple timers for
each compartment to facilitate “first-in, first-out” concept.
1234 56
1234 56
ANSI/NSF 4
Double compartment holding cabinet with 22 gauge stainless steel doors with magnetic catch. Each compartment has
one (1) ON/OFF adjustable thermostat, 60° to 200°F (16° to 93°C); one (1) indicator light; and one (1) holding
temperature gauge to monitor inside air temperature. Each compartment is equipped with two (2) stainless steel side
racks designed to accommodate standard full-size pans, and three (3) chrome plated wire shelves for full-size sheet pans.
Cabinet includes one (2) set of 5" (127mm) heavy duty casters, two rigid and two swivel with brake.
■■MODEL 1200-UP/STD: Double compartment holding cabinet with a .040" stucco aluminum exterior casing.
■■MODEL 1200-UP/HD: Double compartment holding cabinet with heavy duty 20 gauge stainless steel
exterior casing.
.

D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T , S P E C I F I C AT I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A.
D I M E N S I O N S : H x W x D
EXTERI R:
75-11/16" x 26" x 30-1/2" (1922mm x 659mm x 773mm)
INTERI R EACH C MPARTMENT:
28-7/8" x 22-1/4" x 26-1/2" (733mm x 565mm x 673mm)
C L E A R A N C E R E Q U I R E M E N T S
3-inches (76mm) at the back, 2-inches (51mm)
at the top, and 1-inch (25mm) at both sides
I N S TA L L AT I O N R E Q U I R E M E N T S
Appliance must be installed level. It must
not be installed in any area where it may be
affected by steam, grease, dripping water,
high temperatures, or any other severely
adverse conditions.
W E I G H T (EST.)
1200-UP/STD 1200-UP/HD
NET 276 lb (125kg) 301 lb (137kg)
SHIP 315 lb (142kg) 350 lb (159kg)
CARTON H x W x D 85" x 30" x 35" EST.
DIMENSIONS:(2159mm x 762mm x 889mm)
O P T I O N S & A C C E S S O R I E S
■■Bumper, Full Perimeter 5004861
■■Casters, 3-1/2" (89mm) RIGID (EACH) CS-25674
■■Casters, 3-1/2" (89mm) SWIVEL W/BRA E (EACH)CS-25675
■■Door Lock with ey L -22567
HACCP Network Options (ELECTRONIC CONTROL ONLY)
REFER T SPECIFICATI N #9015 F R APPLICABLE PART NUMBERS
■■HACCP Documentation
■■HACCP with itchen Management
■■Legs, 6" (152mm) Flanged (SET OF FOUR) 5004863
■■Pan Grid, chrome plated, wire PN-2115
➥PAN INSERT 18" x 26" (457mm x 660mm x 25mm)
■■Probe, Internal Temperature (ELECTRONIC CONTROL)AVAILABLE
Universal Angle Configuration
■■Pan Slides, Chrome Plated SR-24447
■■Pan Slides, Stainless Steel SR-24762
Side Rack Configuration
■■Side Rack, Chrome Plated SR-22445
■■Side Rack, Stainless Steel SR-23739
■■Shelf, Stainless Steel SH-23738
■■Shelf, Chrome Plated SH-2733
■■Water Reservoir Pan 1775
■■Water Reservoir Pan Cover 1774
#39 - 7/07
W164 N9221 Water Street • P Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PH NE: 262.251.3800 • 800.558.8744 U.S.A./CANADA FAX: [phone] • 800.329.8744 U.S.A. NLY
WEBSITE: www.alto-shaam.com
®
75-11/16" (1922mm)
72-7/8" (1851mm)
6-13/16" (172mm)
78-3/4" (2000mm)
26"(659mm)
30-1/2"(773mm)
26-1/2"(672mm)
3-5/16"(83mm)
53-5/16" (1353mm)
33-7/8" (860mm)
with bumper
electrical
pass-thru
28-3/16"
(716mm)
with bumper
1200-UP SERIES
LOW TEMPERATURE HOT HOLDING CABINETS
P R O D U C T \ PA N C A PA C I T Y (P E R C O M PA R T M E N T )
192 lbs (87kg) MAXIMUM
VOLUME MAXIMUM: 120 QUARTS (152 LITERS)
—WITH PAN SLIDES PR VIDED:—WITH ADDT'L PAN SLIDES:
FULL-SIZE PANS:GASTR N RM 1/1:
Eight (8) 20" x 12" x 2-1/2" (530mm x 325mm x 65mm) up to 16 Pans
Eight (8) 20" x 12" x 4" (530mm x 325mm x 100mm) up to 10 Pans
Eight (8) 20" x 12" x 6" (530mm x 325mm x 150mm)
FULL-SIZE SHEET PANS:
Four (4) 18" x 26" x 1" up to 16 Pans
UNIVERSAL PAN SLIDES - 1-3/4" (44mm) CENTERS w ith ad d itio nal sh e lv e s
—WITH PTI NAL SIDE RACKS F R SHELVES
FULL-SIZE PANS:GASTR N RM 1/1:
Sixteen (16) 20" x 12" x 2-1/2" (530mm x 325mm x 65mm)
Ten (10) 20" x 12" x 4" (530mm x 325mm x 100mm)
Eight (8) 20" x 12" x 6" (530mm x 325mm x 150mm)
230 208 - 240 120
E L E C T R I C A L
VOLTAGE PHASE CYCLE / HZ AMPS K W
at 120 1 60 16.0 2.0
at 208 1 50/60 7.2 1.5
at 240 1 50/60 8.3 2.0
at 208 1 50/60 14.4 3.0
at 240 1 50/60 16.0 4.0
at 230 1 50 7.8 1.8
NEMA 5-15P,
20A-125V PLUG
NEMA 6-15 P ,
15A-250
VPLUG
(USA ONLY)
CEE 7/7,
220-230VPLUG
NO CORD
NO PLUG
