FOREWORD
Si mple C o ntro l Cook & Ho l d ▪ O p er a to r’s Ma n ual ▪ MN -4 6 709 ▪ Rev 2 ▪ 3/2 1
3
FOREWORD
Enjoy your Alto-Shaam® Cook & Hold Oven!
Halo Heat®
Technology
Cook & Hold Oven
Precise, low-temperature cooking with Halo Heat technology perfected prime rib
for decades. Free up time with overnight cooking for corned beef, confit, and
even yogurt. Cook your food to perfection and hold for hours without
compromising food quality. No fans. No hood needed. Only big flavor and
savings.
Smoker Oven
The Alto-Shaam smoker oven can make a big impact on your operation. Use hot
or cold smoke to prepare anything from brisket to cheese. Cook your food to
perfection, and/or smoke it to perfection, then hold it for hours without
compromising food quality.
Extend Your Manufacturer’s Warranty
Register Register your Alto-Shaam appliance online. Registering your appliance ensures
prompt service in the event of a warranty claim.
Your personal information will not be shared with any other company.
alto-shaam.com/warranty
Alto-Shaam 24/7 Emergency Repair Service
Call Call 800-558-8744 to reach our 24-hour emergency service call center for
immediate access to local authorized service agencies outside standard business
hours. The emergency service access is provided exclusively for Alto-Shaam
equipment and is available throughout the United States through Alto-Shaam’s
toll free number.
Availability Emergency service access is available seven days a week, including holidays.

FOREWORD
Si mple C ontr ol Coo k & Ho l d ▪ O p era to r’s Manual ▪ M N- 46 7 09 ▪ Rev 2 ▪ 3/21
4
This page intentionally left blank.

TABLE OF CONTENTS
Si mple C o ntro l Cook & Ho l d ▪ O p er a to r’s Ma n ual ▪ MN -4 6 709 ▪ Rev 2 ▪ 3/2 1
5
TABLE OF CONTENTS
Manufacturer’s Information . . . . . . . . . . . . . . . . . . . . . . . . 2
Foreword 3
Enjoy your Alto-Shaam® Cook & Hold Oven! . . . . . . . . . . . . . . 3
Extend Your Manufacturer’s Warranty . . . . . . . . . . . . . . . . . . 3
Alto-Shaam 24/7 Emergency Repair Service . . . . . . . . . . . . . . . 3
Table of Contents 5
Safety 7
The Meaning of Signal Words . . . . . . . . . . . . . . . . . . . . . . . 7
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Labels 11
Label Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installation 15
Dimension Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Pre-Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
How to Receive the Appliance . . . . . . . . . . . . . . . . . . . . . . . 26
How to Unpack the Oven . . . . . . . . . . . . . . . . . . . . . . . . . . 27
How to Install the Oven. . . . . . . . . . . . . . . . . . . . . . . . . . . 28
How to Connect the Electrical Wiring . . . . . . . . . . . . . . . . . . . 34
How to Install the Drip Tray . . . . . . . . . . . . . . . . . . . . . . . . 37
How to Stack Two Ovens . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Operation 39
Control Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
How to Prepare the Oven for First Use . . . . . . . . . . . . . . . . . . 40
How to Use the Door Vents . . . . . . . . . . . . . . . . . . . . . . . . 41
How to Turn On and Turn Off the Oven . . . . . . . . . . . . . . . . . 42
How to Cook by Time (Optional Smoking) . . . . . . . . . . . . . . . . 43
How to Cook by Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
How to Hold at a Set Temperature . . . . . . . . . . . . . . . . . . . . 51
How to Prepare the Smoker Box for Smoking . . . . . . . . . . . . . . 52
How to Cold Smoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
How to Load Recipes from a USB Drive. . . . . . . . . . . . . . . . . . 55
How to Save Recipes to a USB Drive . . . . . . . . . . . . . . . . . . . 57
How to Create and Store a Recipe. . . . . . . . . . . . . . . . . . . . . 59
How to Cook Using a Recipe . . . . . . . . . . . . . . . . . . . . . . . . 61
How to Turn on or Turn off the Alert Function. . . . . . . . . . . . . . 63
How to Lock and Unlock the Controller. . . . . . . . . . . . . . . . . . 64
How to Change the Temperature Scale. . . . . . . . . . . . . . . . . . 65

TABLE OF CONTENTS
Si mple C ontr ol Coo k & Ho l d ▪ O p era to r’s Manual ▪ M N- 46 7 09 ▪ Rev 2 ▪ 3/21
6
How to Calibrate the Temperature Probe . . . . . . . . . . . . . . . . 66
How to Update Software with a USB Drive . . . . . . . . . . . . . . . 68
How to View the Software Versions. . . . . . . . . . . . . . . . . . . . 70
How to Set the Date and Time for HACCP Data (if equipped) . . . . . 72
How to Download HACCP Data (if equipped) . . . . . . . . . . . . . . 74
Maintenance 77
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
How to Clean the Oven. . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Troubleshooting 81
Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
What to do if a Power Interruption Occurs . . . . . . . . . . . . . . . 83
Warranty 85
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Declaration of Conformity 87
