Combitherm®
Combination O en/Steamer
COMBITOUCH™
SERIES
STEP BY STEP
COOKING GUIDE AND
OPERATION MANUAL
7.14es CombiTouch
7.14esG CombiTouch

INTRODUCTION ............................1
CONTROL ANEL IDENTIFICATION . . . . . . . . . . . 2-5
FACTORY DEFAULT SETTINGS . . . . . . . . . . . . . . . . 6
SAFETY RECAUTIONS......................7
O ERATIONMODES......................8-17
Steam ....................................8
Combination...............................10
Convection................................12
Retherm..................................14
Core Temperature robe . . . . . . . . . . . . . . . . . . . . . 16
Core Temperature - Delta-T . . . . . . . . . . . . . . . . . . . 17
AUXILIARY FUNCTIONS . . . . . . . . . . . . . . . . . . 18-19
reheating................................18
Gold-n-Brown™............................18
Cool-DownFeature .........................18
ReducedFanSpeed.........................19
Reduced ower............................19
Multi-shelfTimer............................19
SteamInjection ............................19
CombiSmoke™ Feature . . . . . . . . . . . . . . . . . . . . . . 20
CombiSmoke™ Function . . . . . . . . . . . . . . . . . . . . . 21
RE ROGRAMMED RECI ES . . . . . . . . . . . . . . 22-33
Using reprogrammed Recipes . . . . . . . . . . . . . . . . 22
Recipe rogramming........................23
reprogrammed Bakery Recipes . . . . . . . . . . . . . . . 24
reprogrammed Convenience roduct Recipes. . 25-26
reprogrammed Fish & Seafood Recipes . . . . . . . . . 27
reprogrammed Meat Recipes . . . . . . . . . . . . . . 28-29
reprogrammed Miscellaneous Recipes . . . . . . . . . . 30
reprogrammed oultry Recipes . . . . . . . . . . . . . . . 31
reprogrammed Vegetable Recipes . . . . . . . . . . 32-33
CLEANING & MAINTENANCE. . . . . . . . . . . . . . . 34-38
CleaningMenus............................34
reventive Maintenance . . . . . . . . . . . . . . . . . . . . . . 35
Food Trolley Cleaning . . . . . . . . . . . . . . . . . . . . . . . 35
rotecting Stainless Steel Surfaces . . . . . . . . . . . . . 36
CleaningAgents............................36
CleaningMaterials..........................36
Daily Gasket Cleaning . . . . . . . . . . . . . . . . . . . . . . . 37
robe Usage and Cleaning. . . . . . . . . . . . . . . . . . . . 37
Daily Oven Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . 37
Daily Steam Generator Flush . . . . . . . . . . . . . . . . . . 37
Regular Decalcification. . . . . . . . . . . . . . . . . . . . . . . 37
MonthlyCleaning...........................37
Combitherm Oven Cleaner recautions . . . . . . . . . . 38
Steam Generator Flush . . . . . . . . . . . . . . . . . . . . . . 38
Decalcification.............................38
TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . 39-44
Emergency Operation Mode . . . . . . . . . . . . . . . . 39-40
ErrorCodes.............................41-44

I N T R O D U C T I O N
1
COMBITOUCHTM CONTROL
The Combitherm CombiTouch control features a simple,
graphics-based control panel that commands all the oven
functions. Access up to 250 of your recipes that are
identified by your own uploaded pictures. Manual
cooking by time and temperature also are easily done with
the CombiTouch control.
Intuitive interface - The Alto-Shaam CombiTouch offers a
simple interface that commands all
of the Combitherm’s cooking
functions. As the name implies, it
is fully operable by touch.
Graphic controls - The highly
visual graphic-based control
overcomes language barriers while
the simple, logical procedures
ensure that correct steps are
followed every time.
An excellent memory - Access up
to 250 of your recipes that are
identified by your own uploaded
pictures. The Combitherm with
CombiTouch also comes standard
with more than 100 pre-
programmed recipes and photos,
covering most commonly prepared food items.
Standard HACCP - The Combitherm with CombiTouch
includes a standard downloadable HACCP functionality.
Six levels of Gold-n-Brown™ - Six precise and consistent
browning levels are available with the CombiTouch. The
exclusive Gold-n-Brown feature gives the operator the
ability to achieve the ideal cooking environment for the
ideal finish.
Superior baking - The new two-
speed reversing fan provides
excellent and consistent baking
results. A moisture injection
feature provides perfect sheen and
crust on breads and pastry items.
Multi-shelf timers - Track cooking
time of either seven or 10 different
food items (depending on oven
size) in the same oven with multi-
shelf timers. Time is tracked in
minutes and seconds.
On-board diagnostics - The
CombiTouch system includes on-
board diagnostic functionality
with results displayed right on the
touch screen.
Reduced energy setting - CombiTouch features
an interactive control display with reduced energy setting.
STEAM MODE
COMBINATION MODE
CONVECTION MODE
RETHERM MODE
ECOSMART®TECHNOLOGY
The Alto-Shaam CombiTouch Combitherm
combination oven/steamer employs
Ecosmart operating efficiencies in the
design and application of all operating
and programming functions. Ecosmart
operational characteristics include the use of a water
barrier to close the oven compartment to the outside
air. While maintaining a non-pressurized
atmosphere, the primary purpose of the Ecosmart
system is to prevent the steam and heat generated
within the oven compartment from freely escaping
to the outside.
The Ecosmart design displaces the air within the
cooking compartment and achieves a higher level of
steam saturation that offers quick-steaming at
temperatures above 212°F (100°C).
This guide is provided as an operational aid with
step-by-step instructions of the basic functions of
the Combitherm oven, along with the many other
additional features of the control.

START SCREEN
1 CLEANING MODE
2 DOWNLOAD/U LOAD FILES
3 SETTINGS
4 SERVICE MODE
( ASSWORD ROTECTED)
O P E R AT I N G I N S T R U C T I O N S
2
CONTROL PANEL IDENTIFICATION
1. Cleaning Mode
Four (4) cleaning levels are available: rinse, light,
normal, and heavy-duty cleaning.
2. Download/Upload Files
Download all preprogrammed recipes (factory default
and user-programmed), photos and HACCP to a USB
memory device. See next page for more information.
3. Settings
Change factory default settings. See next page for more
information.
4. Service Mode (password protected)
This mode is only available to qualified service
technicians.

O P E R AT I N G I N S T R U C T I O N S
CONTROL PANEL IDENTIFICATION
3
O P E R AT I N G I N S T R U C T I O N S
SETTINGS SCREEN
1 FAHRENHEIT OR CELSIUS
3 NUMBER OF SHELVES FOR
MULTI-SHELF TIMER
4 MULTI-SHELF TIMER FORMAT
5 DEFAULT MEMO
6 SOUND SETTINGS 7 TOUCH SCREEN BRIGHTNESS
9 RETURN TO REVIOUS SCREEN
8 MOVIES
UPLOAD/DOWNLOAD SCREEN
1 U LOAD HOTOS 2 HACC
3 DOWNLOAD RECI ES
2 TIMER FORMAT
4 U LOAD RECI ES
1. Upload Photos
Upload photo files to oven for
user-programmed recipes
2. HACCP
3. Download Recipes
Download recipes from a USB
thumb drive to unit
4. Upload Recipes
Upload all recipes from unit to a
USB thumb drive
1. Fahrenheit or Celsius Function
Choose temperature format.
2. Timer Format
Display HOURS:MINUTES:SECONDS or
HOURS:MINUTES in timer.
3. Multi-shelf Timer umber of Shelves
Choose the default number shelves in the oven to be
used by the multi-shelf timer.
4. Multi-shelf Timer Format
Display MINUTES:SECONDS or MINUTES only
in timer.
5. Default Memo
Reverts all settings to factory defaults. Clears all user-
input times and temperatures except those in
programmed recipes.
6. Sound/Alarm Settings
Change alarm sounds and volume.
7. Touchscreen Brightness
Adjust brightness of touchscreen.
8. Movies
Access instructional cooking and service videos.
9. Return to Previous Screen
Return to previous screen when finished
adjusting settings.

O P E R AT I N G I N S T R U C T I O N S
CONTROL PANEL IDENTIFICATION
4
1 OWER ON KEY
2 STEAM MODE
6 TEM ERATURE
7 TIME
8 ROBE TEM ERATURE
9 REHEAT
12 REDUCED OWER MODE
16 GO TO REVIOUS SCREEN
10 COOL DOWN
15 FAN S EED
20 MULTI-SHELF TIMER
19 FIND RECI E
17 CLEANING MODE
18 ADD RECI E
11 START/STO ICON
13 GOLD-N-BROWN MODE
4 CONVECTION MODE
5 RETHERM MODE
3 COMBINATION MODE
14 SMOKING MODE (O TIONAL)
21 DELTA-T (ONLY VISIBLE
IN CERTAIN MODES)
1 OWER OFF KEY

MAIN MENU ICONS
1. Power O key
Activates power to the oven and automatically fills the
steam generator equipped models with water that will
heat to a stand-by mode temperature of 188°F (77°C).
2. Steam Mode
The oven will operate in the steam mode at a
temperature range of 85°F to 250°F (30°C to 121°C).
• Automatic steaming at 212°F (100°C) factory-set
default.
• Quick steaming between 213°F and 250°F (101°C
and 121°C).
• Low temperature steaming between 85°F and 211°F
(29°C and 99°C).
3. Combination Mode
Selection key for cooking with a combination of steam
and convection heat. Can be set between 212°F to 485°F
(100°C and 252°C).
4. Convection Mode
Selection key for convection cooking without steam at a
temperature range of 85°F to 485°F (29°C to 252°C).
5. Retherm Mode
Food rethermalization or reheating mode will operate
with automatic steam injection at a temperature range
of 245°F to 320°F (120°C to 160°C).
6. Temperature
Used to set the required cooking temperature, to recall
the set cooking temperature, or to check the actual oven
temperature.
7. Time
Used to set the required cooking time or recall the set
cooking time.
8. Core Temperature
Used to set the required internal product temperature,
to recall the internal product temperature set by the
operator, or to display the current internal temperature
of the product.
9. Preheat Mode
Preheats the oven cavity to a temperature set by user.
10. Cool Down Mode
Lowers temperature of the oven cavity at an
accelerated pace to temperature set by user.
11. Start/Stop
Initiates all cooking mode functions and programmed
procedures stored in memory. Stops an activated
cooking mode or programmed procedure currently in
progress.
AUXILIARY FUNCTION ICONS
12. Reduced Power Mode
Used to reduce kitchen power peaks and energy
consumption.
13.
Gold- -Brown Mode
This indicator will illuminate when the browning
function is set by the operator in a timed or
programmed cooking cycle in any mode. Level 1
provides least amount of browning, level 6 the most.
14. Smoking Mode (optional)
This indicator will illuminate when the smoking
function is set by the operator in a timer, probe or
programmed cooking cycle in either convection mode
or combination mode.
15. Fan Speed
This indicator will illuminate whenever the operator
sets a reduced fan speed to protect products affected
by high-velocity air movement.
16. Return to Previous Menu
17. Cleaning Mode
Four (4) cleaning levels are available: rinse, light,
normal, and heavy-duty cleaning.
18. Add Recipe
Used to create, change, duplicate, and delete programmed
menus.
19. Find Recipe
Access a menu list of all stored cooking programs.
20. Multi-shelf Timer
Use separate timers for one or more shelves in the
oven compartment.
20. Steam Injection (not shown on illustration)
Press to add moisture in any cooking mode. Steam will
inject into the cavity as long as the icon is touched.
21. Delta-T Core Temperature (only visible in certain
modes) Cook by probe. Mode automatically adjusts
cooking temperature in proportion to the internal
temperature of the product.
O P E R AT I N G I N S T R U C T I O N S
5
CONTROL PANEL IDENTIFICATION

COMBITOUCH FACTORY DEFAULT SETTINGS
COOKING MODE OVEN TEM ERATURE CORE TEM ERATURE COOKING TIME
Steam 212°F
(100°C)
160°F
(70°C) 25 minutes
Combination Steam 350°F
(175C)
160°F
(70°C) 60 minutes
Convection 350°F
(175°C)
160°F
(70°C) 30 minutes
Retherm 275°F
(135°C)
160°F
(70°C) 5 minutes
Preheat 350°F
(175°C) N/A N/A
Cool Down 212°F
(100°C) N/A N/A
Delta T 120°F
(50°C)
170°F
(75°C) N/A
6
O P E R AT I N G I N S T R U C T I O N S

O P E R AT I N G I N S T R U C T I O N S
7
NOTE: Automatic steam venting is a standard safety
feature built into all Combitherm oven
models. This feature vents all steam from the
oven compartment immediately before
cooking time expires or set probe temperature
is reached.
This function is provided in all programmed
and timed production when operating in any
Steam, Combination, Convection, and
Retherm cooking mode. Automatic steam
venting does not function if the oven door is
opened before time expires or when the oven
has been set to continuous operation.
NOTE: Use authorized combitherm oven cleaner only.
unauthorized cleaning agents may discolor or
harm interior surfaces of the oven. Read and
understand label and material safety data sheet
before using the oven cleaner.
FOR OPERATOR SAFETY
NOTE AND OBSERVE ALL SAFETY PRECAUTIONS
LOCATED THROUGHOUT THIS GUIDE
CAUTION
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN IN
OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
D A N G E R
AT NO TIME SHOULD THE INTERIOR
OR EXTERIOR BE STEAM CLEANED,
HOSED DOWN, OR FLOODED WITH
WATER OR LIQUID SOLUTION OF
ANY KIND. DO NOT USE WATER JET
TO CLEAN.
SEVERE DAMAGE OR
ELECTRICAL HAZARD
COULD RESULT.
WARRANTY BECOMES VOID IF
APPLIANCE IS FLOODED
DO NOT USE THE ATTACHED HAND-HELD
HOSE TO SPRAY ANYTHING OTHER THAN THE
INTERIOR OF THE COMBITHERM O EN
COMPARTMENT.
DO NOT USE THE SPRAY HOSE ON THE
SURFACE OF A HOT COOKING COMPARTMENT.
ALLOW THE O EN TO COOL TO A MINIMUM OF
150°F (66°C).
HOT STEAM CAUSES BURNS
ROTATE THE DOOR HANDLE TO THE FIRST
OPEN ROTATION POSITION ONLY. WAIT
UNTIL THE STEAM IS VENTED BEFORE FULLY
OPENING THE DOOR.
DO NOT HANDLE PANS CONTAINING LIQUID OR
SEMILIQUID PRODUCTS POSITIONED ABO E
THE EYE LE EL OF THE OPERATOR. SUCH
PRODUCTS CAN SCALD AND CAUSE SERIOUS
INJURY.
IMPORTANT SAFETY PRECAUTIONS

STEAM MODE
The Steam mode provides the operator with the ability to
steam, poach, or blanch. This mode will automatically
steam at the boiling point of water; quick-steam above the
boiling point for faster cooking results; or low temperature
steam, below the boiling point, for more delicate products
such as pâté, mousse, seafood, or custard.
PRESS ON BUTTON TO POWER OVEN ON.
PRESS THE STEAM MODE ICON.
Automatic Steam temperature of 212°F (100°C) will
appear in the display. The last set time or oven
control default setting for time will appear in the
display.
PRESS THE START ICON TO STEAM AT THE
DISPLAYED SETTINGS.
TO CHA GE THE DISPLAYED SETTI GS:
TOUCH THE DISPLAYED TEMPERATURE.
The cooking temperature will appear at the top of the
temperature selection window. Type in desired
temperature or use up and down arrows to adjust
temperature. When finished, touch the green checkmark
key to confirm change.
• Automatic Steaming 212°F (100°C)
• Quick steaming 213°F to 250°F (101°C to 121°C)
• Low temperature Steaming 85°F to 211°F (29°C to 99°C)
TO COOK BY TIME:
TOUCH THE DISPLAYED TIME.
The cooking time will appear at the top the time selection
window. Type in desired time period or use up and down
arrows to adjust time. When finished, touch the green
checkmark key to confirm change.
Or, to set Continuous Operation mode, type in --:-- and
touch the green checkmark key to confirm.
TO COOK BY PRODUCT CORE TEMPERATURE:
TOUCH THE PROBE ICON.
The previously set core temperature or oven control
default setting will appear highlighted within the oven
display. Touch the displayed core temperature. The
internal product core temperature will appear at the top of
the temperature selection window. Type in desired
internal product core temperature or use up and down
arrows to adjust temperature. When finished, touch the
green checkmark key to confirm change.
Attach removable probe before activating core
temperature function, and insert into product.
PRESS THE GREEN START ARROW ICON TO
BEGIN COOKING IN STEAM MODE.
• The temperature and remaining cooking time will
appear in the display.
• If cooking by probe, the actual internal product
temperature will appear next to the icon during
operation. To change the set value for core temperature,
press the temperature next to the icon and make
changes as required.
When the cooking time has expired or the operator set
internal temperature has been reached, an alarm will
sound indicating the end of the operating mode.
• To stop the buzzer, press the red stop key or open
the oven door.
TO STOP COOKING PROGRAM AT ANY TIME,
PRESS RED STOP BUTTON.
8
O P E R AT I N G I N S T R U C T I O N S
