Scanner Power Supply Unit
CL-P115A/P148A
OPERATION MANUAL
AA05OM1203804-05
Original instructions

1
CL-P115A/P148A
About This Documentation
Thank you for purchasing our CL-P115A/P148A Scanner Power Supply Unit.
Please read this manual carefully to ensure correct use of the product. Keep the
manual handy after reading for future reference.
This document for the CL-P115A/P148A Scanner Power Supply Unit describes
installation and system specifications.
1. Note
•Company and product names in this manual are trademarks or registered
trademarks of their respective owners.
•Unauthorized reproduction of this manual in whole or part is prohibited.
•The contents of this manual are subject to change without notice.
•Every effort has been made to ensure the accuracy of this information. If you come
across oversights or errors, please notify your dealer.
•Be sure to read the user's manuals for any equipment used in conjunction with the
system (e.g., documentation for computer systems).
2. Symbols Used in this Manual
About This Documentation
Indicates instructions that must be followed to prevent hardware or software
damage or operating errors.
Indicates additional information on a particular topic.
Menus, icons, buttons,
windows, tabs Enclosed in brackets. Example: Click the [OK] button.
Keyboard keys Enclosed in angle brackets.
Example: Press the <Tab> key.
References Enclosed in quotes.
Example: Refer to "Chapter 8-3.2 Changing Passwords" (page 5).
CAUTION

㪘㪫㪫㪜㪥㪫㪠㪦㪥

Contents
2
CL-P115A/P148A
Contents
About This Documentation....................................................................... 1
1 Note...................................................................................................................... 1
2 Symbols Used in this Manual............................................................................... 1
Chapter 1 Special Precautions ............................................................ 3
1 Safety Precautions ............................................................................................... 3
2 Operating Precautions.......................................................................................... 6
3 For Disposal ......................................................................................................... 6
Chapter 2 Features.............................................................................. 7
Chapter 3 System Configuration.......................................................... 8
1 Overall Configuration............................................................................................ 8
2 Name and Functions of Each Section .................................................................. 9
Chapter 4 Installation......................................................................... 10
1 Unpacking .......................................................................................................... 10
2 Installation .......................................................................................................... 11
Chapter 5 Specifications.................................................................... 12
1 Basic Specifications ........................................................................................... 12
2 Accessories ........................................................................................................ 13
Chapter 6 Outline Drawing................................................................. 14

1. Safety Precautions
3
CL-P115A/P148A
Chapter 1 Special Precautions
1. Safety Precautions
Read these Safety Precautions thoroughly before use to ensure correct use of the
system.
•The precaution points indicated here are intended to ensure safe operation of the
system and prevent hazards or injury to users and other personnel.
They are important details relating to safety and must be read carefully.
•The indications have the following meanings.
Chapter 1 Special Precautions
Indicates that incorrect operation risks death or serious injury to personnel.
Indicates that incorrect operation may result in death or serious injury to
personnel.
Indicates that incorrect operation may result in injury to personnel or damage to
property.
Indicates prohibited actions and warns of actions not covered by the product warranty.
Indicates actions that must be performed by users.
The triangular symbol indicates details that supplement DANGER, WARNING, or CAUTION points.
DANGER
WARNING
CAUTION

1. Safety Precautions
4
CL-P115A/P148A
Never dismantle, repair, or modify the system. Doing so may result in electric
shock or fire.
Otherwise there is a risk of electric shock or fire. Do not attempt maintenance other than
that described in the Operation Manual.
Never burn, destroy, cut, crush or chemically decompose the system.
This product incorporates parts containing gallium arsenide (GaAs).
Do not damage power or connector cables.
Do not crush, twist, or pull cables. Damaged cables may result in electric shock, short-
circuiting, or fire.
Contact your dealer or us. if repair or replacement is necessary.
Connect securely using the specified cables.
Using cables with inadequate capacity or improper connections may result in fire or
electric shock.
Ground the Unit.
If the Unit is not grounded, you may get an electric shock when there is trouble or electricity
leaks.
Connect optical fibers securely.
Improper connection may result in burn injuries or fire.
Stop using the system if a problem arises.
If a problem occurs such as a burning smell, abnormal noise, overheating, or smoke
emission, continuing to use the system may result in electric shock or fire.
Contact your dealer or us immediately.
Wear protective work clothing.
Wear protective clothing such as gloves, long-sleeved clothing, and a leather apron.
Spatter will cause burn injuries if it lands on the skin.
DANGER
WARNING

1. Safety Precautions
5
CL-P115A/P148A
Chapter 1 Special Precautions
Keep away from water.
Subjecting electrical components to water may result in electric shock or short-circuiting.
Install in a firm location.
Otherwise there is a risk of injury if the system topples or falls from the installation
location.
Provide fire extinguishers.
Fire extinguishers must be provided in the welding work area in case of fire.
Inspect and maintain the system periodically.
Inspect and maintain the system periodically, repairing damaged parts and components
before use.
Keep connector plugs clean and insert fully.
There is a risk of overheating and fire if dust is allowed to accumulate or if plugs are not
fully inserted.
Hold the plug body when inserting or removing.
There is a risk of damage to the cable and electric shock or fire if the cable is pulled to
unplug.
Do not cover with blankets or sheets.
Do not cover the system with blankets or sheets while in use. Otherwise there is a risk of
over-heating and fire.
CAUTION

2. Operating Precautions
6
CL-P115A/P148A
2. Operating Precautions
(1) The system should be used in an ambient temperature range of 5°C to 40°C and
humidity 20% to 85% RH with no sudden temperature fluctuations. Avoid using the
system in the following locations.
•Locations with dust or oil mist present
•Locations subject to vibration or impact
•Locations in which chemicals are used
•Locations subject to high noise
•Locations susceptible to condensation
•Locations with high concentrations of CO2, NOx, or SOx
(2) The exterior of the system should be wiped clean using a soft or moist cloth. If the
exterior is particularly dirty, wipe clean using diluted detergent or alcohol.
(3) Do not drop foreign objects such as screws inside the system, as this may result in
failure of the system.
(4) Operate the system as described in the attached Operation Manual.
[Warning/Caution label details]
3. For Disposal
This product incorporates parts containing gallium arsenide (GaAs). At the time of
disposal, separate it from general industrial waste or domestic waste and carry out
the disposal in accordance with applicable laws and regulations.
Warning label of the charging unit
Location:
Near the power supply connector on the
rear surface

7
CL-P115A/P148A
Chapter 2 Features
The scanner power supply unit CL-P115A/P148A is the power supply unit for the laser
control unit CL-E100A series.
The CL-P115A supplies power to the laser control unit CL-E100A and the scanner
head unit CL-H201A.
The CL-P148A supplies power to the laser control unit CL-E100A and the scanner
head unit CL-H601A.
The CL-P115A/P148A has the following features.
•Compact body corresponding to 19-inch 1U rack
The outline is 482.6 x 547 x 320 (mm) and the weight is 5 kg. The CL-P115A/P148A
is 19-inch 1U rack size and can be installed anywhere.
•Applicable power supplies
The CL-P115A/P148A can be used with single-phase 200-240 V AC (50/60 Hz)
power supply.
•Applicable to ±15 V DC or 48 V DC scanner
The CL-P115A can be used with the scanner of ±15 V DC input. The CL-P148A can
be used with the scanner of 48 V DC input.
Chapter 2 Features

1. Overall Configuration
8
CL-P115A/P148A
1. Overall Configuration
Chapter 3 System Configuration
Computer
Laser equipment
Scanner head unit
Laser control unit
Scanner power supply unit
Optical fiber
LAN cable
Scanner
connecting
cable
Power cable for scanner
Power cable for
control unit
Laser
equipment
connecting
cable
Camera
connecting
cable
Camera unit

2. Name and Functions of Each Section
9
CL-P115A/P148A
Chapter 3 System Configuration
2. Name and Functions of Each Section
2.1. Front
(1) Power switch
Turn ON/OFF the power supply.
(2) POWER indicator (LED)
Lights up when the power to the equipment is ON.
Does not light up when the power to the equipment is OFF.
2.2. Rear
(1) Scanner power supply connector (screw diameter #4-40)
Connector of the power supply for the scanner head unit. The D-sub 15 pins
female is connected in the CL-P115A, and the D-Sub 3W3 type female is
connected in the CL-P148A.
(2) UNIT1 to 2 connectors (1829358/Phoenix Contact*)
Connects the laser control unit CL-E100A with the attached power cable for
control unit. Connect using 3.81-mm pitch 3-pole terminal block plug.
* The model number of connector is subject to change without notice. Depending on the part to be
changed, the mounting screw shape may change and a necessary tool may be different. For the
latest parts information, contact a nearest sales office.
(3) Power supply connector
IEC standard C14 type inlet. Connects the attached AC cord. A come-off
prevention part of the AC power (ACCD86AS) is equipped.
The POWER indicator lights up for a while even when the power switch is turned
off. Do not connect or disconnect the cable while the POWER indicator is lit since
the inside of the unit is in a charging state.
㻔㻝㻕 㻔㻞㻕
CAUTION
㻔㻝㻕 㻔㻞㻕 㻔㻞㻕 㻔㻟㻕

1. Unpacking
10
CL-P115A/P148A
1. Unpacking
1.1. Lifting and Transporting Container
1.2. Checking the Contents of Container
Verify that contents of the container agree with the following list.
Chapter 4 Installation
When moving the container, use a cart or ensure at least two people carry it.
Dimension Mass
(including contents)
Container for scanner
power supply unit and
accessories
Approx. 520 (H) x 650 (W) x 575 (D) mm Approx. 17 kg
Component Quantity
Scanner power supply unit 1
Power cable for scanner 1
Power cable for control unit 1
AC cord 1
Operation manual 1
CAUTION

2. Installation
11
CL-P115A/P148A
Chapter 4 Installation
2. Installation
2.1. Installation Requirements
The system should be used in an ambient temperature range of 5°C to 40°C and
humidity 20% to 85% RH with no sudden temperature fluctuations. Avoid using the
system in the following locations.
•Locations with dust or oil mist present
•Locations subject to vibration or impact
•Locations in which chemicals are used
•Locations subject to high noise
•Locations susceptible to condensation
•Locations with high concentrations of CO2, NOx, or SOx
Also, this unit is a 1U product of the EIA standard. When storing it in a rack, remove
the rubber foots at the bottom of the unit.
2.2. Connections
See "Chapter 3-1. Overall Configuration" (page 8) to connect the CL-P115A/P148A and
peripheral devices.
2.3. Ground Connection
Be sure to ground the power cable.
When the applicable power supply of the scanner head unit is ±15 V DC, the CL-
P115A is required. When 48 V DC, the CL-P148A is required.
For the ground to connect to, perform class D grounding work (Ministry of
Economy, Trade and Industry "Technical Standards for Electric Equipment").
CAUTION
CAUTION

1. Basic Specifications
12
CL-P115A
1. Basic Specifications
Chapter 5 Specifications
Item CL-P115A CL-P148A
Output Rated voltage +24 V DC ×2 (80 W in total),
±15 V DC ×1 (160 W)
+24 V DC ×2 (80 W in total),
+48 V DC ×1 (200 W)
Maximum output
current
5 A in total (24 V DC x2),
7 A (±15 V x1)
5 A in total (24 V DC x2),
4.4 A (48 V)
Input Voltage tolerance Single-phase, 200 to 240 V AC (180 to 250 V AC) (50/60 Hz)
Maximum power consumption 360 W 330 W
Ambient temperature 5°C to 40°C
Note: Contact us when using in ambient temperature below 5°C.
Ambient humidity 20% to 85% RH (with no condensation or freeze)
Temperature during storage -10°C to 60°C (with no condensation or freeze)
Humidity during storage 10% to 85% RH (with no condensation or freeze)
Vibration during transport (with
packaged) ASTM D 4728 Level2
Impact during transport (with packaged) ASTM D 4169-05 Level2
Protective class IP32
Electromagnetic
compatibility
standards
Immunity
Complied with the following:
IEC61000-4-2 (Electro-static immunity)
IEC61000-4-3 (Radiated field)
IEC61000-4-4 (Fast transient burst noise)
IEC61000-4-5 (Lightning surge)
IEC61000-4-6 (Conducted immunity)
IEC61000-4-8 (Magnetic field immunity)
IEC61000-4-11 (Dips/Interrupts)
Emission
Complied with the following:
EN55011 (Radiated disturbance)
EN55011 (Conducted disturbance)
Frequency variation ±3 Hz
External dimensions 430(W) mm × 320(D) mm × 44(H) mm (Not including projections)
Mass Approx. 5 kg
Altitude 2000 m or lower

2. Accessories
13
CL-P115A
Chapter 5 Specifications
2. Accessories
Item Model No. Quantity
Power cable for control unit AS1203962 1
AC cord AS1207613 1
Operation manual AS1203808(OM1203803,OM1203804) 1

14
CL-P115A/P148A
Chapter 6 Outline Drawing


 

Dimensions in mm
