Amada DC25 User manual

990-661 REV F
SERIAL DATA
COMMUNICATIONS
FOR USE WITH DC25, HF25 AND UB25
(version 2)
OPERATION MANUAL

SERIAL DATA COMMUNICATIONS
ii 990-661
Copyright © 2001 – 2021 AMADA WELD TECH INC.
The engineering designs, drawings and data contained herein are the
proprietary work of AMADA WELD TECH and may not be reproduced,
copied, exhibited or otherwise used without the written authorization of
AMADA WELD TECH.
Printed in the United States of America.
REVISION RECORD
Revision EO Date Basis of Revision
A 18987 10/01 Original Release.
B 19214 02/02 Software Upgrade.
C 19673 07/03 Software Upgrade, Inclusion of HF25.
D 42861 11/13 Updated to Miyachi America name and logo.
E 45829 12/19 Update Company Name (Amada Weld Tech) + Updated content.
F 46300 04/21 See ECO for Details

SERIAL DATA COMMUNICATIONS
990-661 iii
FOREWORD
Thank you for purchasing an AMADA WELD TECH Power Supply. This manual describes the details of
serial data communications with the DC25, HF25 and UB25 Linear DC Power Supplies.
Upon receipt of your equipment, please thoroughly inspect it for shipping damage prior to its installation.
Should there be anydamage, please immediatelycontact the shipping companyto file a claim, and notifyus
at:
AMADA WELD TECH INC.
1820 South Myrtle Avenue
Monrovia, California 91016
Phone: [phone]
FAX: [phone]
E-mail: [e-mail]
For additional information, and updated technical bulletins called Nuggets, log on to our website:
www.amadaweldtech.com
We have made every effort to ensure that the information in this manual is accurate and adequate. The
contents of this manual are subject to change without notice. Should questions arise, or if you have
suggestions for improvement of this manual, please contact us at the above location/numbers.
AMADA WELD TECH is not responsible for any loss or injury due to improper use of this product.

SERIAL DATA COMMUNICATIONS
iv 990-661
Contents Page
Chapter 1. Description
Description …..........................................................................................................................................1-1
Chapter 2. Communications Syntax
Data and Display Formats .......................................................................................................................2-1
Status Message Codes ............................................................................................................................. 2-2
Communication Set-up ...........................................................................................................................2-6
Communication Role .......................................................................................................................2-6
Baud Rate .........................................................................................................................................2-7
RS-232/485 Select ...........................................................................................................................2-7
I.D. Number .....................................................................................................................................2-7
Appendix A. RS-232 and RS-485 Connections ............................................................................... A-1
Appendix B. Serial Data Communications Programming Codes ...................................................B-1

SERIAL DATA COMMUNICATIONS
990-661 v
LIMITED WARRANTY
GENERAL TERMS AND CONDITIONS FOR THE SALE OF GOODS
1. Applicability.
(a) These terms and conditions of sale (these “Terms”) are the only terms which govern the sale of the goods (“Goods”) by Amada Weld Tech Inc. (“Seller”) to the
buyer identified in the Sales Quotation and/or Acknowledgment (as each defined below) to which these Terms are attached or incorporated by reference
(“Buyer”). Notwithstanding anything herein to the contrary, if a written contract signed by authorized representatives of both parties is in existence covering the
sale of the Goods covered hereby, the terms and conditions of said contract shall prevail to the extent they are inconsistent with these Terms.
(b) The accompanying quotation of sale (the “Sales Quotation”) provided to Buyer, and/or sales order acknowledgement (“Acknowledgement”) and these Terms
(collectively, this “Agreement”) comprise the entire agreement between the parties, and supersede all prior or contemporaneous understandings, agreements,
negotiations, representations and warranties, and communications, both written and oral. For clarification, after the Acknowledgement is received by Buyer, the
order for Goods is binding and cannot be cancelled by Buyer for any reason and the full purchase price amount set forth in the Acknowledgement shall be due
and payable by Buyer to Seller pursuant to the payment schedule set forth in the Acknowledgement unless otherwise agreed to in writing by Seller. All terms and
conditions contained in any prior or contemporaneous oral or written communication which are differentfrom,or in addition to, the terms and conditions in this
Agreement are hereby rejected and shall not be binding on Seller, whether or not they would materially alter this Agreement. These Terms prevail over any of
Buyer’s terms and conditions of purchase regardless whether or when Buyer has submitted its purchase order or such terms. Fulfillment of Buyer’s order does
not constitute acceptance of any of Buyer’s terms and conditions and does not serve to modify or amend these Terms. Notwithstanding anything herein to the
contrary, all orders for Goods must be for a minimum purchase price of $100 or such orders will be rejected by Seller.
2. Delivery.
(a) The Goods will be delivered within a reasonable time after Seller provides Buyer the Acknowledgment, subject to availability of finished Goods. Seller will
endeavor to meet delivery schedules requested by Buyer, but in no event shall Seller incur any liability, consequential or otherwise, for any delays or failure to
deliver as a result of ceasing to manufacture any product or any Force Majeure Event. Delivery schedules set forth in the Acknowledgment are Seller’s good faith
estimate on the basis of current schedules. In no event shall Seller be liable for special or consequential damages resulting from failure to meet requested
delivery schedules.
(b) Unless otherwise agreed in writing by the parties in the Acknowledgement, Seller shall deliver the Goods to the Seller’s plant in Monrovia, CA, USA (the
“Shipping Point”) using Seller’s standard methods for packaging and shipping such Goods. Buyer shall take delivery of the Goods within three (3) days of Seller’s
written notice that the Goods have been delivered to the Shipping Point. Buyer shall be responsible for all loading costs (including freight and insurance costs)
and provide equipment and labor reasonably suited for receipt of the Goods at the Shipping Point. Seller shall not be liable for any delays, loss or damage in
transit.
(c) Seller may, in its sole discretion, without liability or penalty, make partial shipments of Goods to Buyer, if applicable. Each shipment will constitute a separate
sale, and Buyer shall pay for the units shipped whether such shipment is in whole or partial fulfillment of Buyer’s purchase order.
(d) If for any reason Buyer fails to accept delivery of any of the Goods on the date fixed pursuant to Seller’s notice that the Goods have been delivered at the
Shipping Point, or if Seller is unable to deliver the Goods at the Shipping Point on such date because Buyer has not provided appropriate instructions, documents,
licenses or authorizations: (i) risk of loss to the Goods shall pass to Buyer; (ii) the Goods shall be deemed to have been delivered; and (iii) Seller, at its option, may
store the Goods until Buyer picks them up, whereupon Buyer shall be liable for all related costs and expenses (including, without limitation, storage and
insurance).
3. Non-delivery.
(a) The quantity of any installment of Goods as recorded by Seller on dispatch from Seller’s place of business is conclusive evidence of the quantity received by
Buyer on delivery unless Buyer can provide conclusive evidence proving the contrary.
(b) Seller shall not be liable for any non-delivery of Goods (even if caused by Seller’s negligence) unless Buyer gives written notice to Seller of the non-delivery
within three (3) days of the date when the Goods would in the ordinary course of events have been received.
(c) Any liability of Seller for non-delivery of the Goods shall be limited to (in Seller’s sole discretion) replacing the Goods within a reasonable time or adjusting the
invoice respecting such Goods to reflect the actual quantity delivered.
4. Shipping Terms. Unless indicated otherwise in the Acknowledgment, Delivery shall be made EXW (Incoterms 2010), Shipping Point, including without
limitation, freight and insurance costs. If no delivery terms are specified on the Acknowledgement, the method of shipping will be in the sole discretion of Seller.
Unless directed in writing otherwise by Buyer, full invoice value will be declared for all shipments.
5. Title and Risk of Loss. Title and risk of loss passes to Buyer upon delivery of the Goods at the Shipping Point. As collateral security for the payment of the
purchase price of the Goods, Buyer hereby grants to Seller a lien on and security interest in and to all of the right, title and interest of Buyer in, to and under the
Goods, wherever located, and whether now existing or hereafter arising or acquired from time to time, and in all accessions thereto and replacements or
modifications thereof, as well as all proceeds (including insurance proceeds) of the foregoing. The security interest granted under this provision constitutes a
purchase money security interest under the California Commercial Code.
6. Amendment and Modification. These Terms may only be amended or modified in a writing which specifically states that it amends these Terms and is
signed by an authorized representative of each party.

SERIAL DATA COMMUNICATIONS
vi 990-661
7. Inspection and Rejection of Nonconforming Goods.
(a) Buyer shall inspect the Goods within two (2) days of receipt (“Inspection Period”). Buyer will be deemed to have accepted the Goods unless it notifies Seller in
writing of any Nonconforming Goods during the Inspection Period and furnishes such written evidence or other documentation as required by Seller.
“Nonconforming Goods” means only the following: (i) product shipped is different than identified in Buyer’s Acknowledgement; or (ii) product’s label or
packaging incorrectly identifies its contents. Notwithstanding the foregoing, for shipped Goods that require field installation, the “re-verification” terms in the
Acknowledgement shall apply and for custom installations, the inspection and verification shall take place at Buyer’s site immediately after the installation is
completed.
(b) Seller will only accept Nonconforming Goods that are returned under Seller’s Return Material Authorization procedures then in effect (“RMA”). Buyer shall
obtain a RMA number from Seller prior to returning any Nonconforming Goods and return the Nonconforming Goods prepaid and insured to Seller at 1820 South
Myrtle Avenue, Monrovia, CA 91016 or to such other location as designated in writing by Seller for the examination to take place there. If Seller reasonably
verifies Buyer’s claim that the Goods are Nonconforming Goods and that the nonconformance did not developed by use from Buyer, Seller shall, in its sole
discretion, (i) replace such Nonconforming Goods with conforming Goods, or (ii) credit or refund the Price for such Nonconforming Goods pursuant to the terms
set forth herein. Notwithstanding the foregoing, the only remedy for Nonconforming Goods that are custom systems is repair (not refund or replacement). No
returns for Nonconforming Goods are allowed after thirty (30) days from the original shipping date.
(c) Buyer acknowledges and agrees that the remedies set forth in Section 7(a) are Buyer’s exclusive remedies for the delivery of Nonconforming Goods. Except as
provided under Section 7(a) and Section 14, all sales of Goods to Buyer are made on a one-way basis and Buyer has no right to return Goods purchased under this
Agreement to Seller.
8. Price.
(a) Buyer shall purchase the Goods from Seller at the prices (the “Prices”) set forth in Seller’s published catalogue literature in force as of the date of the Sales
Quotation. However, the Prices shown in such catalogue literature or any other publication are subject to change without notice. Unless specifically stated to the
contrary in the Sales Quotation, quoted Prices and discounts are firm for thirty (30) days from the date of the Sales Quotation. Unless otherwise stated, prices are
quoted EXW (Incoterms 2010), Shipping Point. Unless otherwise stated in the Acknowledgement, if the Prices should be increased by Seller before delivery of the
Goods to a carrier for shipment to Buyer, then these Terms shall be construed as if the increased prices were originally inserted herein, and Buyer shall be billed
by Seller on the basis of such increased prices.
(b) All Prices are exclusive of all sales, use and excise taxes, and any other similar taxes, duties and charges of any kind imposed by any governmental authority on
any amounts payable by Buyer. Buyer shall be responsible for all such charges, costs and taxes (present or future); provided, that, Buyer shall not be responsible
for any taxes imposed on, or with respect to, Seller’s income, revenues, gross receipts, personnel or real or personal property or other assets.
9. Payment Terms.
(a) Unless otherwise provided in the Acknowledgement, if Buyer has approved credit with Seller, Buyer shall pay all invoiced amounts due to Seller within thirty
(30) days from the date of Seller’s invoice. If Seller does not have Buyer’s financial information and has not provided pre-approved credit terms for Buyer, the
payment must be made in cash with order or C.O.D. in US dollars. If Buyer has approved credit terms, the payment may be made by cash with order, wire
transfer of immediately available funds, or check in US dollars. Certain products require a down payment. Any payment terms other than set forth above will be
identified in the Acknowledgement. Notwithstanding anything herein to the contrary, all prepaid deposits and down payments are non-refundable. If a deposit
is not received when due, Seller reserves the right to postpone manufacturing of Goods until payment is received. Seller will not be responsible for shipment
delays due to deposit payment delays.
(b) In Seller’s sole discretion, Seller may access Buyer interest on all late payments at the lesser of the rate of 1.5% per month or the highest rate permissible
under applicable law, calculated daily and compounded monthly. Buyer shall reimburse Seller for all costs incurred in collecting any late payments, including,
without limitation, attorneys’ fees. In addition to all other remedies available under these Terms or at law (which Seller does not waive by the exercise of any
rights hereunder), Seller shall be entitled to suspend the delivery of any Goods if Buyer fails to pay any amounts when due hereunder and such failure continues
for ten (10) days following written notice thereof.
(c) Buyer shall not withhold payment of any amounts due and payable by reason of any set-off of any claim or dispute with Seller, whether relating to Seller’s
breach, bankruptcy or otherwise.
10. Intellectual Property; Software License.
(a) To the extent that any Goods provided under this Agreement contains software, whether pre-installed, embedded, in read only memory, or found on any
other media or other form (“Software”), such Software and accompanying documentation are licensed to Buyer, not sold and shall remain the sole and exclusive
property of Seller or third party licensors of Seller. Seller grants Buyer a non-exclusive license to use the Software solely as provided in and in connection with the
use of the Goods in which such Software is contained and in accordance with any applicable user documentation provided with such Goods and subject to the
provisions of this Agreement. Certain of Seller’s Goods may include third party software such as computer operating systems. Licenses to such third party
software are subject to the terms and conditions of any applicable third party software license agreements. Unless identified in the Acknowledgement, no license
is granted by Seller with respect to such third party software products that may be provided with the Goods (if any). Seller makes no warranties regarding any
third party software that may accompany the Goods or otherwise and such software is explicitly included in the definition of Third Party Products below.
(b) Buyer shall not copy, modify, or disassemble, or permit others to copy, modify, or disassemble, the Software, nor may Buyer modify, adapt, translate, reverse
assemble, decompile, or otherwise attempt to derive source code from the Software. Buyer shall not transfer possession of the Software except as part of, or
with, the Goods, and each such transfer shall be subject to the restrictions contained herein. Buyer may not sublicense, rent, loan, assign or otherwise transfer
the Software or documentation, and Buyer shall retain on all copies of the Software and documentation all copyright and other proprietary notices or legends
appearing therein or thereon. Seller may terminate this license upon written notice for any violation of any of the terms of this license or any material breach of
any provision of this Agreement. Buyer shall immediately discontinue use of the Software upon any termination of this license or Agreement. This license shall
terminate upon any termination of the Agreement.

SERIAL DATA COMMUNICATIONS
990-661 vii
(c) All patents, trademarks, copyrights or other intellectual property rights embodied in the Goods, including without limitation the Software, are owned by Seller
and its licensors. Seller and its licensors retain all right, title and interest in such intellectual property rights. Except as expressly set forth herein, no license rights
or ownership in or to any of the foregoing is granted or transferred hereunder, either directly or by implication. ALL RIGHTS RESERVED.
(d) If Buyer is the United States Government or any agency thereof, each of the components of the Software and user documentation are a “commercial item,”
and “computer software” as those terms are defined at 48 C.F.R. 2.101, consisting of “commercial computer software” and “commercial computer software
documentation,” as such terms are used in 48 C.F.R. 12.212. Consistent with 48 C.F.R. 12.212 and 48 C.F.R. 227.7202-1 through 227.7202-4, all United States
government Buyers acquire only those rights in the Software and user documentation that are specified in this Agreement.
11. Installation and Other Services. Seller shall provide installation services (“Installation Services”) to Buyer if set forth in the Acknowledgment. If Installation
Services are provided for in the Acknowledgement, Buyer will prepare the location for the installation consistent with Buyer’s written specifications and Buyer will
install necessary system cable and assemble any necessary equipment or hardware not provided by Seller, unless agreed otherwise in writing by the parties. For
Goods that will be operated on or in connection with Buyer supplied hardware or software, Buyer is responsible for ensuring that its hardware and software
conform with Seller minimum hardware and software requirements as made available to Buyer. Seller shall provide other field services, such as maintenance
visits and field repairs (the “Other Services” and together with the Installation Services, the “Services”) if set forth in the Acknowledgement.
12. Limited Warranty.
(a) Subject to the exceptions and upon the conditions set forth herein, Seller warrants to Buyer that for a period of one (1) year from the date of shipment
(“Warranty Period”), that such Goods will be free from material defects in material and workmanship.
(b) Notwithstanding the foregoing and anything herein to the contrary, the warranty set forth in this Section 12 shall be superseded and replaced in its entirety
with the warranty set forth on Exhibit A hereto if the Goods being purchased are specialty products, which include, without limitation, laser products, fiber
markers, custom systems, workstations, Seller-installed products, non-catalogue products and other custom-made items (each a “Specialty Product”).
(c) EXCEPT FOR THE WARRANTY SET FORTH IN SECTION 12(A), SELLER MAKES NO WARRANTY WHATSOEVER WITH RESPECT TO THE GOODS (INCLUDING ANY
SOFTWARE) OR SERVICES, INCLUDING ANY (a) WARRANTY OF MERCHANTABILITY; (b) WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE; (c) WARRANTY OF
TITLE; OR (d) WARRANTY AGAINST INFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS OF A THIRD PARTY; WHETHER EXPRESS OR IMPLIED BY LAW, COURSE
OF DEALING, COURSE OF PERFORMANCE, USAGE OF TRADE OR OTHERWISE.
(d) Products manufactured by a third party and third party software (“Third Party Product”) may constitute, contain, be contained in, incorporated into, attached
to or packaged together with, the Goods. Third Party Products are not covered by the warranty in Section 12(a). For the avoidance of doubt, SELLER MAKES NO
REPRESENTATIONS OR WARRANTIES WITH RESPECT TO ANY THIRD PARTY PRODUCT, INCLUDING ANY (a) WARRANTY OF MERCHANTABILITY; (b) WARRANTY
OF FITNESS FOR A PARTICULAR PURPOSE; (c) WARRANTY OF TITLE; OR (d) WARRANTY AGAINST INFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS OF A
THIRD PARTY; WHETHER EXPRESS OR IMPLIED BY LAW, COURSE OF DEALING, COURSE OF PERFORMANCE, USAGE OF TRADE OR OTHERWISE. Notwithstanding
the foregoing, in the event of the failure of any Third Party Product, Seller will assist (within reason) Buyer (at Buyer’s sole expense) in obtaining, from the
respective third party, any (if any) adjustment that is available under such third party’s warranty.
(e) Seller shall not be liable for a breach of the warranty set forth in Section 12(a) unless: (i) Buyer gives written notice of the defect, reasonably described, to
Seller within five (5) days of the time when Buyer discovers or ought to have discovered the defect and such notice is received by Seller during the Warranty
Period; (ii) Seller is given a reasonable opportunity after receiving the notice to examine such Goods; (iii) Buyer (if requested to do so by Seller) returns such
Goods (prepaid and insured to Seller at 1820 South Myrtle Avenue, Monrovia, CA 91016or to such other location as designated in writing by Seller) to Seller
pursuant to Seller’s RMA procedures and Buyer obtains a RMA number from Seller prior to returning such Goods forthe examination to take place; and (iii) Seller
reasonably verifies Buyer’s claim that the Goods are defective and that the defect developed under normal and proper use.
(f) Seller shall not be liable for a breach of the warranty set forth in Section 12(a) if: (i) Buyer makes any further use of such Goods after giving such notice; (ii) the
defect arises because Buyer failed to follow Seller’s oral or written instructions as to the storage, installation, commissioning, use or maintenance of the Goods;
(iii) Buyer alters or repairs such Goods without the prior written consent of Seller; or (iv) repairs or modifications are made by persons other than Seller’s own
service personnel, or an authorized representative’s personnel, unless such repairs are made with the written consent of Seller in accordance with procedures
outlined by Seller.
(g) All expendables such as electrodes are warranted only for defect in material and workmanship which are apparent upon receipt by Buyer. The foregoing
warranty is negated after the initial use.
(h) Subject to Section 12(e) and Section 12(f) above, with respect to any such Goods during the Warranty Period, Seller shall, in its sole discretion, either: (i) repair
or replace such Goods (or the defective part) or (ii) credit or refund the price of such Goods at the pro rata contract rate, provided that, if Seller so requests,
Buyer shall, at Buyer’s expense, return such Goods to Seller.
(i) THE REMEDIES SET FORTH IN SECTION 12(H) SHALL BE BUYER’S SOLE AND EXCLUSIVE REMEDY AND SELLER’S ENTIRE LIABILITY FOR ANY BREACH OF THE
LIMITED WARRANTY SET FORTH IN SECTION 12(A). Representations and warranties made by any person, including representatives of Seller, which are
inconsistent or in conflict with the terms of this warranty, as set forth above, shall not be binding upon Seller.
13. Limitation of Liability.
(a) IN NO EVENT SHALL SELLER BE LIABLE FOR ANY CONSEQUENTIAL, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR PUNITIVE DAMAGES, LOST PROFITS OR
REVENUES OR DIMINUTION IN VALUE, LOSS OF INFORMATION OR DATA, OR PERSONAL INJURY OR DEATH ARISING IN ANY WAY OUT OF THE MANUFACTURE,
SALE, USE, OR INABILITY TO USE ANY GOODS, SOFTWARE OR SERVICE, ORARISING OUT OF OR RELATING TO ANY BREACH OF THESE TERMS, WHETHER OR NOT
THE POSSIBILITY OF SUCH DAMAGES HAS BEEN DISCLOSED IN ADVANCE BY BUYER OR COULD HAVE BEEN REASONABLY FORESEEN BY BUYER, REGARDLESS OF
THE LEGAL OR EQUITABLE THEORY (CONTRACT, TORT OR OTHERWISE) UPON WHICH THE CLAIM IS BASED, AND NOTWITHSTANDING THE FAILURE OF ANY
AGREED OR OTHER REMEDY OF ITS ESSENTIAL PURPOSE.
(b) IN NO EVENT SHALL SELLER’S AGGREGATE LIABILITY ARISING OUT OF OR RELATED TO THIS AGREEMENT, WHETHER ARISING OUT OF OR RELATED TO
BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE) OR OTHERWISE, EXCEED THE TOTAL OF THE AMOUNTS PAID TO SELLER FOR THE GOODS SOLD
HEREUNDER.

SERIAL DATA COMMUNICATIONS
viii 990-661
(c) ALL WARRANTIES SET FORTH HEREIN, DIRECT OR IMPLIED, ARE VOIDED IF THE INITIAL INSTALLATION AND START-UP OF THE SUBJECT GOOD IS NOT
SUPERVISED BY AN AUTHORIZED REPRESENTATIVE OF SELLER. AFTER INSTALLATION, ANY RE-ALIGNMENT, RE-CLEANING, OR RE-CALIBRATION, PROVIDED
THEY ARE NOT RELATED TO A PROVEN DEFECT IN MATERIALS OR WORKMANSHIP, SHALL BE PERFORMED BY AN AUTHORIZED REPRESENTATIVE OF SELLERAT
THE CURRENT SERVICE RATES.
(d) WHERE GOODS ARE SUBJECT TO A MOVE TO ANOTHER LOCATION AFTER THE ORIGINAL INSTALLATION HAS BEEN MADE, THE WARRANTY MAY BE
MAINTAINED ONLY IF SUPERVISED BY AN AUTHORIZED REPRESENTATIVE OF SELLER. SELLER, FOR A SERVICE CHARGE, WILL ARRANGE FOR AND SUPERVISE
THE DISCONNECTION, TRANSPORTATION, REINSTALLATION AND START-UP OF THE EQUIPMENT. CLAIMS FOR DAMAGE IN SHIPMENT ARE THE RESPONSIBILITY
OF BUYER AND SHALL BE FILED PROMPTLY WITH THE TRANSPORTATION COMPANY.
14. Return Goods Policy. Seller’s products may be returned to Seller for credit within sixty (60) days of shipment subject to the following conditions.
(a) In order to return products for credit, Buyer must obtain a RMA number from Seller. Upon receipt, it must be executed by an authorized person and then
returned with the Goods. Goods returned to Seller without a RMA will be returned at Buyer’s expense.
(b) Goods are to be returned to Seller at 1820 South Myrtle Avenue, Monrovia, CA 91016 with Freight Prepaid. Seller will not accept collect shipments.
(c) Restocking fees will be assessed in accordance with the following schedules: (i) Goods returned within the first thirty (30) days from shipment date will be
restocked less twenty percent (20%) of the amount billed on the original invoice. (ii) Goods returned over thirty (30) days of shipment but less than sixty (60) days
will be restocked less thirty percent (30%) of the amount billed on the original invoice. (iii) No returns are allowed after sixty (60) days from the original shipping
date.
(d) The restocking fees set forth above are the minimum fees. If a returned Good requires rework to restore it to a saleable condition, further charges will be
assessed. Seller’s quality assurance department will document the condition of the Goods when received by Seller and report their findings to Buyer.
(e) Notwithstanding the foregoing provisions of this Section 14, the following Goods cannot be returned, are not eligible for any credit and cannot be restocked:
(i) custom or modified products and (ii) any expendable product(s) that have been used.
15. Compliance with Law and Indemnification. Buyer shall comply with all applicable laws, regulations and ordinances. Buyer shall maintain in effect all the
licenses, permissions, authorizations, consents and permits that it needs to carry out its obligations under this Agreement. Buyer shall comply with all export and
import laws of all countries involved in the sale of the Goods under this Agreement or any resale of the Goods by Buyer. Goods, Services and technical data
delivered by Seller shall be subject to U.S. export controls. Buyer shall, and shall cause its customers to, obtain all licenses, permits and approvals required by any
government and shall comply with all applicable laws, rules, policies and procedures of the applicable government and other competent authorities. Buyer will
indemnify and hold Seller harmless for any violation or alleged violation by Buyer of such laws, rules, policies or procedures. Buyer shall not transmit, export or
re-export, directly or indirectly, separately or as part of any system, the Goods or any technical data (including processes and Services) received from Seller,
without first obtaining any license required by the applicable government, including without limitation, the U.S. government. Buyer also certifies that none of the
Goods or technical data supplied by Seller under this Agreement will be sold or otherwise transferred to, or made available for use by or for, any entity that is
engaged in the design, development, production or use of nuclear, biological or chemical weapons or missile technology. No Buyer information will be deemed
“technical data” unless Buyer specifically identifies it to Seller as such. Buyer assumes all responsibility for shipments of Goods requiring any government import
clearance. Seller may terminate this Agreement if any governmental authority imposes antidumping or countervailing duties or any other penalties on Goods.
For all international shipments, Seller requires that all required Export Control documentations, including Form BIS-711 Statement by Ultimate Consignee and
Purchases, are submitted by Buyer along with the purchase order. Seller reserves the right to postpone shipment until all documentations are completed and
submitted to Seller. Seller will not be responsible for shipment delays due to non-compliance by Buyer of the foregoing two sentences.
16. Termination. In addition to any remedies that may be provided under these Terms, Seller may terminate this Agreement with immediate effect upon written
notice to Buyer, if Buyer: (i) fails to pay any amount when due under this Agreement and such failure continues for ten (10) days after Buyer’s receipt of written
notice of nonpayment; (ii) has not otherwise performed or complied with any of these Terms, in whole or in part; or (iii) becomes insolvent, files a petition for
bankruptcy or commences or has commenced against it proceedings relating to bankruptcy, receivership, reorganization or assignment for the benefit of
creditors.
17. Waiver. No waiver by Seller of any of the provisions of this Agreement is effective unless explicitly set forth in writing and signed by Seller. No failure to
exercise, or delay in exercising, any rights, remedy, power or privilege arising from this Agreement operates or may be construed as a waiver thereof. No single
or partial exercise of any right, remedy, power or privilege hereunder precludes any other or further exercise thereof or the exercise of any other right, remedy,
power or privilege.
18. Confidential Information. All non-public, confidential or proprietary information of Seller, including, but not limited to, specifications, samples, patterns,
designs, plans, drawings, documents, data, business operations, customer lists, pricing, discounts or rebates,disclosed by Seller to Buyer, whether disclosed orally
or disclosed or accessed in written, electronic or other form or media, and whether or not marked, designated or otherwise identified as “confidential,” in
connection with this Agreement is confidential, solely for the use of performing this Agreement and may not be disclosed or copied unless authorized in advance
by Seller in writing. Upon Seller’s request, Buyer shall promptly return all documents and other materials received from Seller. Seller shall be entitled to
injunctive relief for any violation of this Section 18. This Section 18 does not apply to information that is: (a) in the public domain through no fault of Buyer; (b)
known to Buyer at the time of disclosure without restriction as evidenced by its records; or (c) rightfully obtained by Buyer on a non-confidential basis from a
third party.
19. Force Majeure. Seller shall not be liable or responsible to Buyer, nor be deemed to have defaulted or breached this Agreement, for any failure or delay in
fulfilling or performing any term of this Agreement when and to the extent such failure or delay is caused by or results from acts or circumstances beyond the
reasonable control of Seller including, without limitation, acts of God, flood, fire, earthquake, explosion, governmental actions, war, invasion or hostilities
(whether war is declared or not), terrorist threats or acts, riot, or other civil unrest, national emergency, revolution, insurrection, epidemic, lock-outs, strikes or
other labor disputes (whether or not relating to either party’s workforce), or restraints or delays affecting carriers or inability or delay in obtaining supplies of
adequate or suitable materials, materials or telecommunication breakdown or power outage (each a “Force Majeure Event”), provided that, if the event in

SERIAL DATA COMMUNICATIONS
990-661 ix
question continues for a continuous period in excess of thirty (30) days, Buyer shall be entitled to give notice in writing to Seller to terminate this Agreement.
20. Assignment. Buyer shall not assign any of its rights or delegate any of its obligations under this Agreement without the prior written consent of Seller. Any
purported assignment or delegation in violation of this Section 20 is null and void. No assignment or delegation relieves Buyer of any of its obligations under this
Agreement.
21. Relationship of the Parties. The relationship between the parties is that of independent contractors. Nothing contained in this Agreement shall be construed
as creating any agency, partnership, joint venture or other form of joint enterprise, employment or fiduciary relationship between the parties, and neither party
shall have authority to contract for or bind the other party in any manner whatsoever.
22. No Third-Party Beneficiaries. This Agreement is for the sole benefit of the parties hereto and their respective successors and permitted assigns and nothing
herein, express or implied, is intended to or shall confer upon any other person or entity any legal or equitable right, benefit or remedy of any nature whatsoever
under or by reason of these Terms.
23. Governing Law. All matters arising out of or relating to this Agreement is governed by and construed in accordance with the internal laws of the State of
California without giving effect to any choice or conflict of law provision or rule (whether of the State of California or any other jurisdiction) that would cause the
application of the laws of any jurisdiction other than those of the State of California.
24. Dispute Resolution.
(a) If Buyer is an entity formed under the laws of the United States of America, or any of its states, districts or territories (“U.S. Law”), then any dispute, legal suit,
action or proceeding arising out of or relating to this Agreement shall be adjudicated and decided in the federal courts of the United States of America or the
courts of the State of California in each case located in the City of Los Angeles and County of Los Angeles, California and each party irrevocably submits to the
exclusive and personal jurisdiction of such courts in any such dispute, suit, action or proceeding.
(b) If Buyer is an entity formed under the laws of any country, state, district or territory other than U.S. Law, then the parties irrevocably agree that any dispute,
legal suit, action or proceeding arising out of or relating to this Agreement shall be submitted to the International Court of Arbitration of the International
Chamber of Commerce (“ICC”) and shall be finally settled under the Rules of Arbitration of the ICC. The place and location of the arbitration shall be in Los
Angeles, California, pursuant to the ICC’s Rules of Arbitration and shall be finally settled in accordance with said rules. The arbitration shall be conducted before a
panel of three arbitrators. Each party shall select one arbitrator and the two arbitrators so selected shall select the third arbitrator, who shall act as presiding
arbitrator. Notwithstanding the foregoing, if the matter under dispute is $500,000 or less, there shall only be one arbitrator who shall be mutually selected by
both parties. If the party-selected arbitrators are unable to agree upon the third arbitrator, if either party fails to select an arbitrator, or in the case that only one
arbitrator is required and the parties are unable to agree, then the International Court of Arbitration shall choose the arbitrator. The language to be used in the
arbitral proceeding shall be English. The arbitrator(s) shall have no authority to issue an award that is contrary to the express terms of this Agreement or the laws
of the State of California or applicable US Federal Law, and the award may be vacated or corrected on appeal to a court of competent jurisdiction for any such
error. The arbitrator(s) shall be specifically empowered to allocate between the parties the costs of arbitration, as well as reasonable attorneys’ fees and costs, in
such equitable manner as the arbitrator(s) may determine. The arbitrator(s) shall have the authority to determine issues of arbitrability and to award
compensatory damages, but they shall not have authority to award punitive or exemplary damages. Judgment upon the award so rendered may be entered in
any court having jurisdiction or application may be made to such court for judicial acceptance of any award and an order of enforcement, as the case may be. In
no event shall a demand for arbitration be made after the date when institution of a legal or equitable proceeding based upon such claim, dispute or other
matter in question would be barred by the applicable statute of limitations. Notwithstanding the foregoing, either party shall have the right, without waiving any
right or remedy available to such party under this Agreement or otherwise, to seek and obtain from any court of competent jurisdiction any interim or provisional
relief that is necessary or desirable to protect the rights or property of such party, pending the selection of the arbitrator(s) hereunder or pending the
arbitrator(s)’ determination of any dispute, controversy or claim hereunder.
25. Notices. All notices, request, consents, claims, demands, waivers and other communications hereunder (each, a “Notice”) shall be in writing and addressed to
the parties at the addresses set forth on the face of the Acknowledgement or to such other address that may be designated by the receiving party in writing. All
Notices shall be delivered by personal delivery, nationally recognized overnight courier (with all fees pre-paid), facsimile (with confirmation of transmission) or
certified or registered mail (in each case, return receipt requested, postage prepaid). Except as otherwise provided in this Agreement, a Notice is effective only
(a) upon receipt of the receiving party, upon confirmation of delivery by nationally recognized overnight courier or upon forty-eight (48) hours after being sent by
certified or registered mail (as applicable), and (b) if the party giving the Notice has complied with the requirements of this Section 25.
26. Severability. If any term or provision of this Agreement is invalid, illegal or unenforceable in any jurisdiction, such invalidity, illegality or unenforceability shall
not affect any other term or provision of this Agreement or invalidate or render unenforceable such term or provision in any other jurisdiction.
27. Survival. Provisions of these Terms which by their nature should apply beyond their terms will remain in force after any termination or expiration of this
Order including, but not limited to, the following provisions: Compliance with Laws, Confidentiality, Governing Law, Dispute Resolution, Survival, and the
restrictions on Software in Sections 10(b), (c) and (d).



SERIAL DATA COMMUNICATIONS
990-661 1-1
CHAPTER 1
Description
Serial Data Communications allows you to connect a single Control, or multiple Controls, to a printer or
a computer in order to:
•Retrieve, store, import, and export weld history data, display weld history data in different
graphic formats for detailed analysis.
•Remotely program weld schedules on the Control(s).
•Remotely program menu items on the Control(s).
There are two types of Serial Data Communications; RS-485 and RS-232.
RS-485 connection allows up to 20 Controls to be connected to a computer. This is used for weld
history retrieval, storage and remote weld schedule programming.
The only difference between RS-232 operation and RS-485 operation is that RS-485 can be "Daisy
Chained" for multiple controls, and RS-232 cannot.



SERIAL DATA COMMUNICATIONS
990-661 2-1
CHAPTER 2
Communications Syntax
Data and Display Formats
Most of the data fields are the same for all Power
Supplies. However, Field 1, Field 2, Field 3
, and
Field 4 for the DC25 and UB25 contain
different
data than the HF 25. An HF25D produces 7
extra
fields of data not
produced by the DC25 or UB25.
These differences are described below.
DC25/UB25
Field 1 =
Waveform stability result (% average
deviation).
Field 2 =
Waveform capacity result (% of
deviation).
Field 3 = Waveform stability result (%
average
deviation).
Field 4 =
Waveform capacity result (% of
deviation).
HF25
Field 1 = % of capacity control to reach Pulse 1.
Field 2 = Always zero.
Field 3 = % of capacity control to reach Pulse 2.
Field 4 = Always zero.
ADDITIONAL HF25D Fields
Field A
= Displacement measurement units
(inches/1000) or
(mm) depending on the
display units selected.
Field B = Displacement initial thickness value.
Field C = Displacement final thickness value.
Field D = Displacement value (initial minus
final).
Field E = Time reached in msec.
Field F = SEA limit reached.
Field G = Limit time in msec.

CHAPTER 2: COMMUNICATIONS SYNTAX
SERIAL DATA COMMUNICATIONS
2-2 990-661
Status Message Codes
As shown on the previous page, the STATUS of the weld is the third entry in a line of text data,
represented by a one or two-digit number. Status Messages are defined below.
NOTE: Most Status Messages apply to all Power Supplies, however some messages apply only to the
DC25 and UB25, others apply only to the HF25D.
NUMBER STATUS MESSAGE
0 GOOD
1 CHECK CONTROL SIGNALS INPUT STATUS
2 CHECK INPUT SWITCH STATUS
3 FIRING SWITCH BEFORE FOOT SWITCH
4 STOP ON CONTROL SIGNALS INPUT
5 POWER TRANSISTOR OVERHEATED
6 EMERGENCY STOP - OPERATOR ACTIVATED
7 FIRING SWITCH DIDN'T CLOSE IN 10 SECOND
8 WELD TRANSFORMER OVERHEATED
9 TEST WELD
10 VOLTAGE SELECTION PLUG IS MISSING
11 INHIBIT CONTROL SIGNALS ACTIVATED
12 LOW BATTERY
13 NO CURRENT READING
14 NO VOLTAGE READING
15 LOAD RESISTANCE TOO HIGH
16 NO WELD TRANSFORMER DETECTED
17 WELD SWITCH IN NO WELD POSITION
18 CHECK VOLTAGE CABLE & SECONDARY CIRCUIT
19 CALIBRATION RESET TO DEFAULT
20 LOWER LIMIT GREATER THAN UPPER LIMIT
21 COOL TIME ADDED FOR DIFFERENT FEEDBACK
22 ENERGY SETTING TOO SMALL
23 SYSTEM & SCHEDULE RESET TO DEFAULTS
24 LIMITS ROUND UP

CHAPTER 2: COMMUNICATIONS SYNTAX
SERIAL DATA COMMUNICATIONS
990-661 2-3
NUMBER STATUS MESSAGE
25 CHAINED TO NEXT SCHEDULE
26 SAFE ENERGY LIMIT REACHED
27 P1 LOWER LIMIT DELAYS ADJUSTED
28 P1 UPPER LIMIT DELAYS ADJUSTED
29 P2 LOWER LIMIT DELAYS ADJUSTED
30 P2 UPPER LIMIT DELAYS ADJUSTED
31 UPSLOPE REQUIRED FOR LOWER LIMIT
32 INPUT TOO LARGE
33 INPUT TOO SMALL
34 PRESS RUN BEFORE WELDING
35 ERASE FAILED
36 PROGRAM FAILED
37 NO LOWER LIMIT WITH STOP P1 ACTION
38 LIMIT DELAYS RESET TO 0
39 ACCESS DENIED! SYSTEM SECURITY ON
40 ILLEGAL SECURITY CODE ENTERED
41 NOT USED
42 NOT USED
43 NOT USED
44 NOT USED
45 NOT USED
46 NOT USED
47 ACCESS DENIED! SCHEDULE LOCK ON
48 LVDT INITIAL THICKNESS LOW READING (HF 25D)
49 LVDT INITIAL THICKNESS HIGH READING (HF 25D)
50 LVDT FINAL THICKNESS LOW READING (HF 25D)
51 LVDT FINIAL THICKNESS HIGH READING (HF 25D)
52 LVDT DISPLACEMENT LOW READING (HF 25D)
53 LVDT DISPLACEMENT HIGH READING (HF 25D)
54 LVDT WELD STOP DISPLACEMENT REACHED (HF 25D)

CHAPTER 2: COMMUNICATIONS SYNTAX
SERIAL DATA COMMUNICATIONS
2-4 990-661
NUMBER STATUS MESSAGE
55 CURRENT1 > UPPER LIMIT
56 CURRENT1 < LOWER LIMIT
57 VOLTAGE1 > UPPER LIMIT
58 VOLTAGE1 < LOWER LIMIT
59 POWER1 > UPPER LIMIT
60 POWER1 < LOWER LIMIT
61 RESISTANCE1 > UPPER LIMIT
62 RESISTANCE1 < LOWER LIMIT
63 NOT USED
64 NOT USED
65 SCHEDULES ARE RESET
66 SYSTEM PARAMETERS ARE RESET
67 PULSE 1 LOWER LIMIT REACHED
68 PULSE 1 UPPER LIMIT REACHED
69 WELD TIME TOO SMALL
70 P2 INHIBITED - CAP BANK DEPLETED (DC & UB 25)
71 CURRENT2 > UPPER LIMIT
72 CURRENT2 < LOWER LIMIT
73 VOLTAGE2 > UPPER LIMIT
74 VOLTAGE2 < LOWER LIMIT
75 POWER2 > UPPER LIMIT
76 POWER2 < LOWER LIMIT
77 RESISTANCE2 > UPPER LIMIT
78 RESISTANCE2 < LOWER LIMIT
79 INHIBIT 2ND PULSE
80 WELD STOP - LIMIT REACHED
81 SYSTEM ERROR: BUS ERROR
82 SYSTEM ERROR: SOFTWARE INTERRUPT
83 SYSTEM ERROR: ILLEGAL INSTRUCTION
84 SYSTEM ERROR: DIVIDED BY ZERO

CHAPTER 2: COMMUNICATIONS SYNTAX
SERIAL DATA COMMUNICATIONS
990-661 2-5
NUMBER STATUS MESSAGE
85 SYSTEM ERROR: SPURIOUS INTERRUPT
86 COOL TIME MINIMUM
87 TEST WELD? [MENU]=NO [RUN]=YES
88 CAPACITY EXCEEDED P1 (DC & UB 25)
89 CAPACITY EXCEEDED P2 (DC & UB 25)
90 STABILITY LIMIT EXCEEDED (DC & UB 25)
91 STABILITY LIMIT EXCEEDED (DC & UB 25)
92 WELD FIRE LOCKOUT

CHAPTER 2: COMMUNICATIONS SYNTAX
SERIAL DATA COMMUNICATIONS
2-6 990-661
Communication Set-up
The following menu screens tell you how to set the Power Supplies communication options. You will
need to select between “Host” and “Client” communications role (see below for details) and data options
such as baud rate, RS-232 or RS-485 protocol, and the ID number for the weld control.
Rear-mounted RS-232 and RS-485 connectors allow for remote programming, weld schedule selection,
and data logging for SPC purposes. Data output provides the necessary process documentation for
critical applications and permits data logging for SPC purposes.
Appendix E, Communications in this manual lists all of the commands that the Power Supply will
respond to, and instructions on how to format commands sent to the Power Supply so it will respond
properly.
The Power Supply contains internal software that gives you a great deal of flexibility in the setup and
use of your welding system. The Power Supply software displays various menu screens on the LCD,
each containing prompts telling you which of the Power Supplies front panel controls to use in order to
customize operating parameters, set the Power Supply for use in an automated welding system, and
program communication settings for use with data-gathering devices such as a host computer.
1. Communication Role
1. From the
MAIN MENU,
press the
6
key to go to
the COMMUNICATION menu (shown with
default settings).
From the COMMUNICATION menu, toggle the 1
key to select HOST or CLIENT. The
COMMUNICATION ROLE line will now reflect
your role selection.
<COMMUNICATION>
1. COMMUNICATION ROLE : CLIENT
2. BAUD RATE : 9600
3. RS232/485 SELECT : RS232
4. I.D. NUMBER : 1
NUMBERS Select an item, RUN or MENU
•In the HOST role, the Power Supply will:
−Send weld data to the host computer after each weld operation.
−Send text data to a serial printer, providing a printout of the average voltage and
current values for each weld, generating a "paper history" of welds performed.
•In the CLIENT role, the Power Supply will send weld data only when requested by the host
computer. You must use this role for RS-485 installations with mulitple Power Supplies
on one communications channel.
2. Press MENU to return to the MAIN MENU.

CHAPTER 2: COMMUNICATIONS SYNTAX
SERIAL DATA COMMUNICATIONS
990-661 2-7
2. Baud Rate
The baud rate at which the data is sent must match the baud rate of the host computer. To enter the baud
rate, proceed as follows:
1.
From the
COMMUNICATION
menu, press the
2
key to get the BAUD RATE selection screen.
Use the numeric keypad to select the baud rate
of the receiving device. The display
automatically returns to the COMMUNICATION
menu, which shows the new baud rate.
<BAUD RATE>
1. 1200 6. 19.2K
2. 2400 7. 28.8K
3. 4800 8. 38.4K
4. 9600
5. 14.4K
Number Select, Page, RUN or MENU
2. Press MENU to return to the MAIN MENU.
3. RS-232/485 SELECT
Pressing the 3 key will alternately select either RS-232 or RS-485 communications. The default
selection is RS-232.
4. I.D. Number
The host computer may be used to talk with multiple Power Supplies using a single RS-485
communications line. Each Power Supply sharing that line must have a unique identification number.
To enter an identification number for the Power Supply, proceed as follows:
1.
From the
MAIN MENU
, press the
6
key to go to
the COMMUNICATIONS MENU.
2. From the COMMUNICATIONS MENU screen,
press the 3key to get the I.D. NUMBER entry
screen.
<I.D. NUMBER>
I.D. NUMBER : 01
Number Select, Page, RUN or MENU
3. Enter a two-digit number, from 01 to 30, in the I.D. NUMBER field.
4. Press the MENU key to get the COMMUNICATION menu screen. This time the I.D. NUMBER
line will display your I.D. number entry.
5. Press MENU to return to the MAIN MENU.


