Amana R-410A User manual

•Allsafetyinformationmustbefollowed
See Installation instructions for more safety precautions.
•RefertotheappropriatePartsCatalogforpartnumber information.
•Models listed on page 3.
PBC/PBE/PBH
Through-The-Wall R-410A
Air Conditioners & Heat Pumps
Copyright © 2010 Goodman Company, L.P.
RT4271001
May2010
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUALAL
ALAL
AL
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does
not assume any responsibility for property damage or personal injury due to improper service
procedures or services performed by an unqualified person.
isaregisteredtrademark ofMaytagCorporationor itsrelatedcompanies and isusedunder license toGoodmanCompany, L.P., Houston,TX. Allrights reserved.

PRODUCT IDENTIFICATION
2
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequesting service orpartsinformation.
PBC 09 3 E 35 A X A A
BASIC MODEL TYPE MAJOR/MINOR DESIGN REV.
PBC = Standard Cooler TTW
PBE = Electric Heat TTW
PBH = Heat Pump TTW
COOLING CAPACITY
09 = 9000 BTUH
12 = 12000 BTUH
RATED VOLTAGE
2 = 115V 60Hz 1Ph
3 = 230/208V 60Hz 1Ph
DESIGN SERIES (Refrig)
A = R-22
E = R-410A FEATURE COD
E
MA = Standard Model R-22
HEATER SIZE AX = Standard Model R-410A
00 = no electric heat
35 = 3.5 kw (230/208V)
Use up to 4 as needed
In alphabetical order
WARNING
WARNING HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING ONLY individuals meeting (at a
minimum) the requirements of
an "Entry Level Technician" as specified by the Air-
Conditioning, Heating, and Refrigeration Institute (AHRI)
may use this information. Attempting to install or repair
this unit without such background may result in product
damage, personal injury, or death.
WARNING
WARNING

PRODUCT IDENTIFICATION
3
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequesting service orpartsinformation.
PBC092E00AX
PBC122E00AX
PBC093E00AX
PBC123E00AX
PBE093E35AX
PBE123E35AX
PBH092E12AX
PBH093E35AX
PBH113E35AX
The United States Environmental Protection Agency (“EPA”) has issued various regulations re-
garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
WARNING
WARNING
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
WARNING
WARNING To prevent the risk of property
damage, personal injury, or death,
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
WARNING
WARNING
HIGH VOLTAGE!
DISCONNECT ALL POWER BEFORE SERVICING OR
INSTALLING THIS UNIT. MULTIPLE POWER
SOURCES MAY BE PRESENT. FAILURE TO DO SO
MAY CAUSE PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.

PRODUCT DESIGN
4
PBC, PBE and PBH through-the-wall room air conditioners
are designed for window installations in residential applica-
tionsand are available in9,000through18,000 BTUH sizes.
Theyaredesignedfor 208/230/115volt singlephaseapplica-
tions.
The provided filter must be installed and under no circum-
stancesshould theunitbeoperatedwithout thefilterin place.
LocationandClearances
Be sure electrical service is adequate for chosen model of
air conditioner or heat pump. Complete electrical rating for
unitis found on serial plate locatedbehindfront grille. Elec-
trical outlet must be close enough to unit for power cord to
reachwithout strain.
Air conditioner should be the only appliance on individual
circuit.
For personal safety and to avoid possible damage to appli-
ance or home, observe all safety instructions.
NOTES:
1. Mechanical experience is required to install the air
conditioneror heat pump.
2. Installation can take from 1 to 3 hours, depending on
installer’s knowledge and skill.
3. If you encounter problems during installation, call our
consumerinformationlinetoll-freeat1-877-376-0214(U.S.
andCanadaonly). If your problem cannot be resolved by
phone, contact an authorized Amana®brand servicer.
Contact and service will be at your expense.

SPECIFICATIONS
5
PBC***E00AX
MODEL PBC092E00AX PBC122E00AX PBC093E00AX PBC123E00AX
Cooling (BTU's) 9200 11800 9200
8900 11800 11400
@EER 9.8 9.4 9.8 9.8
Cooling Watts 940 1260 940 - 910 1200 - 1160
Cooling Amps 8.6 11.6 4.4 - 4.7 5.6 - 6.0
Voltage 115 115 230 -208 230 -208
Plug Type Parallel Parallel Tandem Tandem
PowerCord Rating 15 amp 15 amp 15amp 15 amp
Power Cord Type LCDI LCDI LCDI LCDI
PowerCord length 8 feet 8 feet 6 feet 6 feet
Dehumidification:pints / hour 41 oz./hr 55 oz./hr 41 oz./hr 55 oz./hr
Fan Speeds
CFM cooling : High-Low 275 275 275 275
Fan OnlySpeed 3 Speed 3 Speed 3 Speed 3 Speed
Controls
Thermostattemp. range 64° - 86° 64° - 86° 64° - 86° 64° - 86°
Outercase : insulation panels PBWS01A PBWS01A PBWS01A PBWS01A
Condensate Drain Spout Yes on Outercase Yes on Outercase Yes on Outercase Yes on Outercase
Thermostatic Drain Valve Yes Yes Yes Yes
Adjustable changeover thermostat --- --- --- ---
Chassis Size 26" TTW 26"TTW 26" TTW 26"TTW
Chassis Heighth 15.625" 15.625" 15.625" 15.625"
Chassis Width 26" 26" 26" 26"
Chassis Depth 16.875" 16.875" 16.875" 16.875"

6
SPECIFICATIONS PBE***E00AX
MODEL PBE093E35AX PBE123E35AX
Cooling (BTU's) 9200
8900 11800 11400
@ EER 9.8 9.8
Cooling Watts 940 - 910 1200 - 1160
Cooling Amps 4.4 - 4.7 5.6 - 6.0
Electric Heat 11000 - 9000 11000 - 9000
Electric Heat Watts 3500 - 2900 3500 - 2900
Electric HeatAmps 15 / 14 15 / 14
Heatpump --- ---
Heatpump Watts --- ---
Heatpump Amps --- ---
Fan Watts Indoor 64 Indoor 64 Indoor
Fan Watts Outdoor 123 Outdoor 123 Outdoor
Voltage 230 -208 230 -208
Plug Type Perpendicular Perpendicular
Power Cord Rating 20 amp 20 amp
Power Cord Type LCDI LCDI
Power Cord length 6 feet 6 feet
Dehumidification: pints / hr. 41 oz./hr 55 oz./hr
Fan Speeds
CFM cooling : High-Low 265/- 265/-
Fan OnlySpeed 3 Speed 3 Speed
Controls
Thermostat temp. range 64° - 86° 64° - 86°
Outercase : insulation panels PBWS01A PBWS01A
Condensate Drain Spout Yes on Outercase Yes on Outercase
ThermostaticDrain Valve Yes Yes
Adjustable changeover thermostat --- ---
Chassis Size 26" 26"
ChassisHeighth 15.625" 15.625"
Chassis Width 26" 26"
ChassisDepth 16.875" 16.875"

SPECIFICATIONS
7
PBH***E00AX
MODEL PBH092E12AX PBH093E35AX PBH113E35AX
Cooling (BTU's) 9000 9000
8700 11500 11100
@ EER 9.4 9.4 9.4
Cooling Watts 960 960 -930 1220 - 1180
Cooling Amps 8.8 4.5 - 4.8 5.7 - 6.2
Electric Heat 3900 11000 - 9000 11000 - 9000
Electric HeatWatts 1150 3500 -2900 3500 - 2900
Electric HeatAmps 11 15/ 14 15 / 14
Heatpump (BTU's) 8500 8500
8200 11000 10700
@ C.O.P. 2.9 2.9 2.7
Heatpump Watts 860 860 - 830 1195 - 1160
Heatpump Amps 7.7 4.0 -4.2 5.2 - 5.6
Fan Watts Indoor 64 Indoor 64 Indoor 64 Indoor
Fan Watts Outdoor 123 Outdoor 123 Outdoor 123 Outdoor
Voltage 115 230 -208 230 -208
Plug Type Parallel Perpendicular Perpendicular
Power Cord Rating 15 amp 20amp 20amp
Power Cord Type LCDI LCDI LCDI
Power Cord length 8 feet 6 feet 6 feet
Dehumidification: pints / hr. 41 oz./hr 41 oz./hr 55 oz./hr
Fan Speeds
CFM cooling : High-Low 265/- 265/- 265/-
Fan OnlySpeed 3 Speed 3 Speed 3 Speed
Controls
Thermostattemp. range 64° - 86° 64° - 86° 64° - 86°
Outercase :insulation panels PBWS01A PBWS01A PBWS01A
Condensate Drain Spout Yes on Outercase Yes on Outercase Yes on Outercase
Thermostatic Drain Valve Yes Yes Yes
Adjustable changeover thermostat Yes Yes Yes
Chassis Size 26" 26" 26"
Chassis Heighth 15.625" 15.625" 15.625"
Chassis Width 26" 26" 26"
Chassis Depth 16.875" 16.875" 16.875"

8
PBC***E00AX
SEN
BTUH SEN
BTUH SEN
BTUH SEN
BTUH
85 95 105 115
75 8675 6555 76 8230 6335 77 7745 6100 79 7235 5860 81
61 80 8630 7675 89 8195 7450 91 7720 7210 93 7330 7330 100
85 8775 8775 100 8420 8420 100 8050 8050 100 7630 7630 100 75 9815 5265 54 9375 5065 54 8760 4860 55 8185 4760 58
67 80 9720 6510 67 9200 6085 66 8650 5875 68 8080 5595 69
85 9560 7575 79 9120 7445 82 8505 7170 84 7970 6745 85 75 11030 3950 36 10450 3735 36 9860 3520 36 9235 3295 36
73 80 10905 5045 46 10335 4835 47 9725 4615 47 9095 4390 48
85 10765 6140 57 10190 5930 58 9575 5710 60 8940 5485 61 75 11175 11175 100 10535 8370 79 9810 8035 82 8770 7645 87
61 80 11130 10140 91 10495 9825 94 9750 9465 97 8875 9055 102
85 11410 11410 100 10880 10880 100 10230 10230 100 9540 9540 100 75 12660 6895 54 12100 6660 55 11230 6300 56 10365 5950 57
67 80 12520 8290 66 11800 7990 68 11025 7675 70 10130 7345 73
85 12315 9750 79 11705 9500 81 10820 9160 85 9915 8825 89 75 14290 5070 35 13515 4780 35 12725 4495 35 11825 4175 35
73 80 14120 6510 46 13335 6220 47 12530 5930 47 11535 5580 48
85 13930 7950 57 13165 7670 58 12265 7375 60 11260 7000 62
MODEL ID WB
ENT ID DB
ENT TOTAL
BTUH SHR TOTAL
BTUH SHR TOTAL
BTUH SHR
PBC "E" MODEL 230V
TOTAL
BTUH SHR
OUTDOOR TEMP
PBC123 PBC09
3
PERFORMANCE DATA

9
PBC***E00AX
SEN
BTUH SEN
BTUH SEN
BTUH SEN
BTUH
85 95 105 115
75 8375 6255 75 7930 6035 76 7445 5800 78 6935 5560 80
61 80 8330 7375 89 7895 7150 91 7420 6910 93 7030 7030 100
85 8475 8475 100 8120 8120 100 7750 7750 100 7330 7330 100 75 9515 4965 52 9075 4765 53 8460 4560 54 7885 4460 57
67 80 9420 6210 66 8900 5785 65 8350 5575 67 7780 5295 68
85 9260 7275 79 8820 7145 81 8205 6870 84 7676 6445 84 75 10730 3650 34 10150 3435 34 9560 3220 34 8935 2995 34
73 80 10605 4745 45 10035 4535 45 9425 4315 46 8795 4090 47
85 10465 5840 56 9890 5630 57 9275 5410 58 8640 5185 60 75 10775 10775 100 10135 7970 79 9410 7635 81 8370 7245 87
61 80 10730 9740 91 10095 9425 93 9350 9065 97 8475 8655 102
85 11010 11010 100 10480 10480 100 9830 9830 100 9140 9140 100 75 12260 6495 53 11700 6260 53 10830 5900 54 9965 5550 56
67 80 12120 7890 65 11400 7590 67 10625 7275 68 9730 6945 71
85 11915 9350 78 11305 9095 80 10420 8760 84 9515 8420 89 75 13890 4670 34 13115 4380 33 12325 4095 33 11425 3775 33
73 80 13720 6110 45 12935 5820 45 12130 5530 46 11135 5180 47
85 13530 7550 56 12765 7270 57 11865 6975 59 10860 6600 61
ID WB
ENT ID DB
ENT TOTAL
BTUH SHRMODEL TOTAL
BTUH TOTAL
BTUH TOTAL
BTUH
SHR SHR
PBE "E" MODEL 208V
SHR
PBC123 PBC09
3
PERFORMANCE DATA

10
PBE***E00AX
SEN
BTUH SEN
BTUH SEN
BTUH SEN
BTUH
85 95 105 115
75 8675 6555 76 8230 6335 77 7745 6100 79 7235 5860 81
61 80 8630 7675 89 8195 7450 91 7720 7210 93 7330 7330 100
85 8775 8775 100 8420 8420 100 8050 8050 100 7630 7630 100 75 9815 5265 54 9375 5065 54 8760 4860 55 8185 4760 58
67 80 9720 6510 67 9200 6085 66 8650 5875 68 8080 5595 69
85 9560 7575 79 9120 7445 82 8505 7170 84 7970 6745 85 75 11030 3950 36 10450 3735 36 9860 3520 36 9235 3295 36
73 80 10905 5045 46 10335 4835 47 9725 4615 47 9095 4390 48
85 10765 6140 57 10190 5930 58 9575 5710 60 8940 5485 61 75 11175 11175 100 10535 8370 79 9810 8035 82 8770 7645 87
61 80 11130 10140 91 10495 9825 94 9750 9465 97 8875 9055 102
85 11410 11410 100 10880 10880 100 10230 10230 100 9540 9540 100 75 12660 6895 54 12100 6660 55 11230 6300 56 10365 5950 57
67 80 12520 8290 66 11800 7990 68 11025 7675 70 10130 7345 73
85 12315 9750 79 11705 9500 81 10820 9160 85 9915 8825 89 75 14290 5070 35 13515 4780 35 12725 4495 35 11825 4175 35
73 80 14120 6510 46 13335 6220 47 12530 5930 47 11535 5580 48
85 13930 7950 57 13165 7670 58 12265 7375 60 11260 7000 62
MODEL ID WB
ENT ID DB
ENT TOTAL
BTUH SHR TOTAL
BTUH SHR TOTAL
BTUH SHR
PBE "E" MODEL 230V
TOTAL
BTUH SHR
OUTDOOR TEMP
PBE09
2
PBE123
PERFORMANCE DATA
