Amana PTC073E Series Operating instructions

RS4200004r8
June2014
Service Instructions
PACKAGE TERMINAL
AIR CONDITIONER/HEAT PUMP
Standard and Remote Applications with LED Control
with R-410A
This manual is to be used by qualified, professionally trained HVAC technicians only.
Goodman does not assume any responsibility for property damage or personal injury
due to improper service procedures or services performed by an unqualified person.
©2010 - 2012, 2014 Goodman Company, L.P.
is a registered trademark of Maytag Corporation or its related companies and is used under license to Goodman Company, L.P., Houston, TX. All rights reserved.

2
Prideandworkmanshipgointoeveryproducttoprovideourcustomerswithqualityproducts. Itispossible,however,
thatduringitslifetimeaproductmayrequireservice. Productsshouldbeservicedonlybyaqualifiedservicetechnician
whoisfamiliarwiththesafetyproceduresrequiredintherepairandwhoisequippedwiththeproper tools,parts,testing
instruments and the appropriate service manual. REVIEW ALL SERVICE INFORMATION IN THE APPROPRIATE
SERVICE MANUAL BEFORE BEGINNING REPAIRS.
IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS
IMPORTANT INFORMATION
WARNING
INSTALLATION AND REPAIR OF THIS UNIT SHOULD BE PERFORMED ONLY BY INDIVIDUALS MEETING (AT
A MINIMUM) THE REQUIREMENTS OF AN “ENTRY LEVEL TECHNICIAN” AS SPECIFIED BY THE AIR-
CONDITIONING, HEATING AND REFRIGERATION INSTITUTE (AHRI). ATTEMPTING TO INSTALL OR REPAIR
THIS UNIT WITHOUT SUCH BACKGROUND MAY RESULT IN PRODUCT DAMAGE, PERSONAL INJURY
OR DEATH.
WARNING
INDEX
PRODUCT IDENTIFICATION................................................................................... 4
SPECIFICATIONS ........................................................................................... 5-14
PROPER INSTALLATION................................................................................. 15-34
MAINTENANCE........................................................................................... 35-37
OPERATIONS.............................................................................................. 38-42
SERVICING ................................................................................................ 43-60
SCHEMATICS.............................................................................................. 61-82

3
Tolocateanauthorizedservicer,pleaseconsultyourtelephonebookorthedealer
from whom you purchased this product. For further assistance, please contact:
CONSUMER INFORMATION LINE -
AMANA®BRAND PRODUCTS TOLL FREE
1-877-254-4729 (U.S. only)
email us at: [email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
Outside the U.S., call 1-713-861-2500.
(Not a technical assistance line for dealers.)
Your telephone company will bill you for the call.
WARNING
THIS AIR CONDITIONER IS NOT MEANT TO PROVIDE
UNATTENDED COOLING OR LIFE SUPPORT FOR
PERSONS OR ANIMALS WHO ARE UNABLE TO
REACT TO THE FAILURE OF THIS PRODUCT.
THE FAILURE OF AN UNATTENDED AIR CONDITION-
ER MAY RESULT IN EXTREME HEAT IN THE COND-
ITIONED SPACE CAUSING OVERHEATING OR
DEATH OF PERSONS OR ANIMALS.
PRECAUTIONS MUST BE TAKEN TO WARN OF OR
GUARD AGAINST SUCH AN OCCURENCE.
WARNING
WARNING
GOODMAN WILL NOT BE RESPONSIBLE FOR ANY INJURY OR PROPERTY DAMAGE ARISING FROM
IMPROPER SERVICE OR SERVICE PROCEDURES. IF YOU INSTALL OR PERFORM SERVICE ON THIS UNIT,
YOU ASSUME RESPONSIBILITY FOR ANY PERSONAL INJURY OR PROPERTY DAMAGE WHICH MAY
RESULT. MANY JURISDICTIONS REQUIRE A LICENSE TO INSTALL OR SERVICE HEATING AND AIR
CONDITIONING EQUIPMENT.
is a registeredtrademarkof Maytag Corporation oritsrelated companies and is usedunder license to Goodman Company,L.P.,Houston,TX. All rights reserved.

4
PRODUCT IDENTIFICATION
PTC 07 3 G 35 A X X X A A
BASIC MODEL TYPE MAJOR/MINOR DESIGN REV.
PTC = Standard Cooler PTAC
PTH = Standard Heat Pump PTHP
DRY = Dehumid Cooler PTAC
COOLING CAPACITY
07 = 7000 BTUH (60 Hz)
09 = 9000 BTUH (60 Hz)
10 = 10000 BTUH (50 Hz)
12 = 12000 BTUH (50 or 60 Hz)
15 = 15000 BTUH (60 Hz)
17 = 16500 BTUH (60 Hz)
RATED VOLTAGE
2 = 115V 60Hz 1Ph
3 = 230/208V 60Hz 1Ph FEATURE CODE Examples
4 = 265V 60Hz 1Ph A = Standard Model PTC073E35AXXX
5 = 240/220V 50Hz 1Ph C = Corrosion Protection (Seacoast) PTC073E50CXXX
D = Power Door PTC073E35CDXX
F = Fuse Holder PTC073E35CQVX
DESIGN SERIES H = Hydronic PTC073E35CDQR
E = R-410A 2010 Ratings K = Added Drain Valve (PTC only)
F = R-410A California Model N = Non-Branded Front
G = R-410A 2012 Ratings P = Condensate Pump
Q = Quiet STC Kit
R = RF Antenna
V = Power Vent
X =
p
lace holder
HEATER SIZE W = Hard Wired
00 = no electric heat Y = High VA Transformer
15 = 1.5 kW
25 = 2.5 kW Use up to 4 as needed
35 = 3.5 kw (230/208V)
= 3.7kW (265V)
50 = 5.0 kW

5
SPECIFICATIONS
* Actual vent CFMperformance will vary due to application and installation conditions.
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heatin
g
ca
p
acit
y
and efficienc
y
based on unit o
p
eration without condensate
p
um
p
; unit automaticall
y
switches to electric heat at a
pp
roximatel
y
24°F outdoor ambient.
6S
p
ecif
y
two-di
g
it heater kW size to com
p
lete model number.
7R-410A refri
g
erant used in all s
y
stems.
8All units meet or exceed ASHRAE 90.1 standards.
9All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refersto com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater performance for total MCA.
COOLING - PTC PTC E SERIES
PTC PTC PTC PTC PTC PTC PTC PTC
073E***X XX 093E***X XX 123E***XX X 153E ***XX X 074E ***XX X 094E***XXX 124E***XXX 154E***XXX
230 / 208 230 / 208 230 / 208 230 /208 265 265 265 265
Capacity (BTU/h) 7,600 / 7,500 8,700 / 8,500 11,500 / 11,200 14,000 /13,600 7,600 8,900 11,600 14,000
3.5 / 3.5 4.1 / 4.1 5.6 / 5.6 7.0 / 7.0 3.0 3.6 4.8 6.0
665 / 640 775 / 745 1,115 / 1,110 1,430 /1,390 600 800 1,125 1,430
EER 11.4 / 11.7 11.2 / 11.4 10.3 / 10.1 9.8 / 9.8 11.5 11.1 10.3 9.8
Unit without Electric Heater
4.24.96.88.53.64.45.97.4
High 290 290 290 340 290 290 290 340
Low 264 264 264 314 264 264 264 314
High 310 310 310 360 310 310 310 360
Low 282 282 282 332 282 282 282 332
65* 65* 65* 65* 65* 65* 65* 65*
(Compressor&Fan)* 6*6*6*6*6*6*6*6*
1.72.23.64.41.72.23.64.4
99 103 106 117 99 103 106 116
114 118 123 134 114 118 123 133
Voltage ¹, ³
Model ¹, 6, 8,9
Dehumidification (Pints/Hr.)
Net Weight (lbs.)
CFM (Dry Coil)
Ventilated Air, CFM
Min. Circuit Amps ², 4, 10
Ventilated Air, CFM (Fan Only)*
CFM (Cool/Wet Coil)
Ship Weight (lbs.)
Amps10
Watts10
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures

6
SPECIFICATIONS PTC G SERIES
COOLING - PTC
PTC PTC PTC PTC PTC PTC PTC
072G**XXX 073G***XXX 092G**XXX 093G***XXX 123G***XXX 153G***XXX 173G**XXX
115 230 / 208 115 230 /208 230 /208 230 /208 230/208
Capacity(BTU/h) 7,000 7,700 / 7,700 9000 9,000 /9,000 11,700 /11,500 15,000 /14,700 16400/16200
6.9 3.5 / 3.5 8.3 4.1 / 4.1 5.6 / 5.6 7.0 / 7.0 8.4
585 670 / 660 795 805 /785 1,135 /1,105 1,500 /1,470 1740/1720
EER 11.9 11.5 /11.7 11.3 11.2 / 11.5 10.3 / 10.4 10.0 / 10.0 9.4
Unit without Elec tric Heate r
8.3 4.2 10.1 4.9 6.8 8.5 10.2
High 290 290 290 290 290 340 340
Low 264 264 264 264 264 314 314
High 310 310 310 310 310 360 360
Low 282 282 282 282 282 332 332
65* 65* 65* 65* 65* 65* 65*
(Compressor&Fan)* 6*6*6*6*6*6*6*
1.7 1.72.32.23.64.44.8
98 98 102 102 102 113 113
113 113 117 117 119 130 130
Min.CircuitAmps ²,4, 10
Ventilated Air,CFM(Fan Only)*
CFM(Cool/WetCoil)
Ship Weight (lbs.)
Amps10
Watts10
Voltage ¹,³
Model ¹, 6, 8,9
Dehumidification (Pints/Hr.)
Net Weight(lbs.)
CFM(DryCoil)
Ventilated Air,CFM
* Actual vent CFMperformance will vary due to application and installation conditions.
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heatin
g
ca
p
acit
y
and efficienc
y
based on unit o
p
eration without condensate
p
um
p
; unit automaticall
y
switches to electric heat at a
pp
roximatel
y
24°F outdoor ambient.
6S
p
ecif
y
two-di
g
it heater kW size to com
p
lete model number.
7R-410A refri
g
erant used in all s
y
stems.
8All units meet or exceed ASHRAE 90.1 standards.
9All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refersto com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater performance for total MCA.
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures
PTC PTC PTC PTC
074G***XXX 094G***XXX 124G***XXX 154G***XXX
265 265 265 265
Capacity(BTU/h) 7,700 9,000 12,000 14,800
3.0 3.6 4.8 6.0
670 795 1,165 1,480
EER 11.5 11.3 10.3 10.0
Unit without Electric Heater
3.6 4.4 5.9 7.4
High 290 290 290 340
Low 264 264 264 314
High 310 310 310 360
Low 282 282 282 332
65* 65* 65* 65*
(Compressor&Fan)* 6* 6* 6* 6*
1.7 2.2 3.6 4.4
98 102 102 113
113 117 119 130
ShipWeight(lbs.)
Amps10
Watts10
Voltage ¹, ³
Model ¹, 6, 8,9
Dehumidification (Pints/Hr.)
Net Weight (lbs.)
CFM(DryCoil)
Ventilated Air,CFM
Min.CircuitAmps ²,4, 10
Ventilated Air,CFM(Fan Only)*
CFM(Cool/WetCoil)

7
SPECIFICATIONS
* Actual vent CFMperformance will vary due to application and installation conditions.
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heatin
g
ca
p
acit
y
and efficienc
y
based on unit o
p
eration without condensate
p
um
p
; unit automaticall
y
switches to electric heat at a
pp
roximatel
y
24°F outdoor ambient.
6S
p
ecif
y
two-di
g
it heater kW size to com
p
lete model number.
7R-410A refri
g
erant used in all s
y
stems.
8All units meet or exceed ASHRAE 90.1 standards.
9All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refersto com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater performance for total MCA.
COOLING - DRY
DRY
093E***XXX
230 / 208
8800/8600
4.2/4.2
805/775
10.9/11.1
Unit without Electric Heater
5.1
High 280
Low 260
High 310
Low 280
65*
6*
2.8
103
118
Voltage ¹,³
Model ¹, 6, 8,9
Dehumidification (Pints/Hr.)
Net Weight (lbs.)
CFM (Dry Coil)
Capacity(BTU/h)
EER
Ventilated Air, CFM(Compressor & Fan)*
Min.Circuit Amps ²,4, 10
Ventilated Air,CFM(Fan Only)*
CFM(Cool/WetCoil)
Ship Weight(lbs.)
Am ps 10
Watts10
DRY E SERIES
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures

8
SPECIFICATIONS
* Actual vent CFMperformance will vary due to application and installation conditions.
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heatin
g
ca
p
acit
y
and efficienc
y
based on unit o
p
eration without condensate
p
um
p
; unit automaticall
y
switches to electric heat at a
pp
roximatel
y
24°F outdoor ambient.
6S
p
ecif
y
two-di
g
it heater kW size to com
p
lete model number.
7R-410A refri
g
erant used in all s
y
stems.
8All units meet or exceed ASHRAE 90.1 standards.
9All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refersto com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(included and factory-installed on all Amana® brand 265-volt chassis). See heater performance for total MCA.
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures
DRY G SERIES
DRY DRY
093G***XXX 094G***XXX
230 / 208 265
Capacity (BTU/h) 8800/8600 8800
4.7 / 4.7 4.3
785 / 770 785
EER 11.2 / 11.2 11.2
Unit without Electric Heater
5.6 5.1
High 280 280
Low 260 260
High 310 310
Low 280 280
65* 65*
6* 6*
2.8 2.8
103 103
118 118
Ship Weight (lbs.)
Amps10
Watts10
Voltage ¹, ³
Model ¹, 6, 8,9
Dehumidification (Pints/Hr.)
Net Weight (lbs.)
CFM (Dry Coil)
Ventilated Air, CFM (Compressor & Fan)*
Min. Circuit Amps ², 4, 10
Ventilated Air, CFM (Fan Only)*
CFM (Cool/Wet Coil)

9
SPECIFICATIONS
@ 230V @ 208V @ 265V
230/208V 2.5 1 8,500 6,800 - - 2,570 / 2,115 11.2 / 10.1 14.0 15 6-15 P
230/208V 3.5 1 12,000 9,900 - - 3,570 / 2,935 15.5 / 14.1 19.4 20 6-20 P
230/208V 5 1 17,100 14,000 - - 5,070 / 4,160 22.1 / 20.0 27.5 30 6-30 P
265V 2.5 1 - - - - 8,500 2,570 9.7 12.1 15 7-20 P
265V 3.7 1 - - - - 12,600 3,770 14.2 17.8 20 7-20 P
265V 5 1 - - - - 17,100 5,070 19.2 23.9 25 7-30 P
Nominal Heating ( BTU/h)
Power Cord
Tota l
Watts6
Total
Amps
Min. Circuit
Ampacity²
MOD4
(amps)
Voltage
Electric
Heater Size
(kW)
No. of
Stages
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum branch circuit ampacity ratings conform to the National Electric Code; however, local codes should apply.
³ Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
Minimum voltage on 265-volt models is239 volts; maximumis 292volts.
5Heating capacity and efficiency based on unit operation without condensate pump; unit automatically switches to electric heat at approximately 24°F outdoor ambient.
7Specifytwo-digit heater kW size tocomplete model number.
8R-410A refrigerant used in all systems.
9All units meet or exceedASHRAE90.1 standards.
10 All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) power cord and meet UL 484 standards.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay
fuses (included and factory-installed on all Amana® brand 265-volt chassis).
6 Total watts for 15,000 BTU/h models; subtract 20 watts for PT07/09/12
ELECTRIC HEAT PERFORMANCE
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures
PTC***(E,F,G) & PTH***(E,F) Models
DRY***(E, G) Models

10
SPECIFICATIONS
HEAT PUMP - PTH
* Actual vent CFM performance will vary due to application and installation conditions.
Not es:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heating capacity and efficiency based on unit operation without condensate pump; unit automatically switches to electric heat at approximately 24°F outdoor ambient.
6Specify two-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refers to com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(
included and factor
y
-installed on all Amana® brand 265-volt chassis
)
. See heater
p
erformance for total MCA.
PTH E SERIES
Model ¹, 6, 8, 9PTH
073E**AXXX
PTH
093E**AXXX
PTH
123E**AXXX
PTH
153E* *AXXX
PTH
074E**AXXX
PTH
094E**AXXX
PTH
124E**AXXX
PTH
154E**AXXX
230 / 208 230 / 208 230 / 208 230 / 208 265 265 265 265
7,600 / 7,500 9,000 / 8,900 11,500 / 11,100 14,000 / 13,900 7,500 9,000 11,500 14,000
3.5 / 3.5 4.1 / 4.1 5.6 / 5.6 7.0 / 7.0 3.0 3.6 4.8 6.0
675 / 660 810 / 800 1,125 / 1,100 1,460 / 1,465 645 810 1,150 1,445
EER 11.3 / 11.4 11.1 / 11.1 10.2 / 10.1 9.6 / 9.5 11.6 11.1 10.0 9.7
Unit without Electric Heater
4.2 4.9 6.8 8.5 3.6 4.4 5.9 7.4
High 290 290 290 340 290 290 290 340
Low 264 264 264 314 264 264 264 314
High 310 310 310 360 310 310 310 360
Low 282 282 282 332 282 282 282 332
65* 65* 65* 65* 65* 65* 65* 65*
(Compressor&Fan)* 6*6*6*6*6*6*6*6*
1.7 2.2 3.6 4.4 1.7 2.2 3.6 4.4
108 112 115 126 108 112 115 125
123 127 132 143 123 127 132 142
CFM (Dry Coil)
Ventilated Air, CFM (Fan Only)*
Ventilated Air, CFM
Voltage ¹, ³
Capacity (BTU/h)
Amps10
Watts10
Min. Circuit Amps², 4, 10
CFM (Cool/Wet Coil)
Dehumidification (Pints/Hr.)
Net Weight (lbs.)
Ship Weight (lbs.)
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures

11
SPECIFICATIONS
HEAT PUMP - PTH
* Actual vent CFM performance will vary due to application and installation conditions.
Not es:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heating capacity and efficiency based on unit operation without condensate pump; unit automatically switches to electric heat at approximately 24°F outdoor ambient.
6Specify two-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refers to com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(
included and factor
y
-installed on all Amana® brand 265-volt chassis
)
. See heater
p
erformance for total MCA.
PTH F SERIES
Model ¹, 6, 8, 9PTH
123F**AXXX
PTH
124F**AXXX
230 / 208 265
Capacity (BTU/h) 11,500 / 11,300 11,600
5.6 / 5.6 4.8
1,125 / 1,095 1,125
EER 10.3 / 10.3 10.3
Unit without Electric Heater
7.0 6.0
High 290 290
Low 264 264
High 310 310
Low 282 282
65* 65*
(Compressor & Fan)* 6* 6*
3.6 3.6
115 115
132 132
Ship Weight (lbs.)
Voltage ¹, ³
Amps10
Watts10
Min. Circuit Amps ², 4, 10
CFM (Cool/Wet Coil)
Dehumidification (Pints/Hr.)
Net Weight (lbs.)
CFM (Dry Coil)
Ventilated Air, CFM (Fan Only)*
Ventilated Air, CFM
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures

12
SPECIFICATIONS
HEAT PUMP - PTH PTH G SERIES
* Actual vent CFM performance will vary due to application and installation conditions.
Not es:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heating capacity and efficiency based on unit operation without condensate pump; unit automatically switches to electric heat at approximately 24°F outdoor ambient.
6Specify two-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refers to com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(
included and factor
y
-installed on all Amana® brand 265-volt chassis
)
. See heater
p
erformance for total MCA.
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures
Model ¹, 6, 8, 9PTH
073G**AXXX
PTH
093G**AXXX
PTH
123G**AXXX
PTH
153G**AXXX
PTH
074G**AXXX
PTH
094G**AXXX
PTH
124G**AXXX
PTH
154G**AXXX
230 / 208 230 / 208 230 /208 230 / 208 265 265 265 265
7,700 / 7,700 9,000 / 9,000 12,000 /12,000 14,400 /14,400 7,700 9,100 12,000 14,400
3.9 /3.9 4.2 / 4.2 5.8 /5.8 7.0 /7.0 3.1 3.7 5.0 6.1
655 / 655 785 / 785 1,125 / 1,100 1,480 /1,480 655 790 1,120 1,480
EER 11.7 /11.7 11.5 / 11.5 10.7 /10.7 9.7 /9.7 11.7 11.5 10.7 9.7
Unit without Electric Heater
4.7 5.1 7.1 8.5 3.8 4.5 6.1 7.4
High 340 330 340 390 340 330 340 390
Low 245 245 245 340 245 245 245 340
High 370 360 370 410 370 360 370 410
Low 270 270 270 370 270 270 270 370
65* 65* 65* 65* 65* 65* 65* 65*
(Compressor & Fan)* 40* 40* 40* 40* 40* 40* 40* 40*
1.7 2.2 3.6 4.4 1.7 2.2 3.6 4.4
108 112 115 126 108 112 115 125
123 127 132 143 123 127 132 142
Voltage ¹,³
Capacity (BTU/h)
Amps10
Watts10
CFM(DryCoil)
Ventilated Air,CFM(Fan Only)*
Ventilated Air,CFM
Ship Weight(lbs.)
Min.CircuitAmps ²,4, 10
CFM(Cool/WetCoil)
Dehumidification (Pints/Hr.)
NetWeight(lbs.)

13
SPECIFICATIONS
HEAT PUMP HEATING DATA
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heatin
g
ca
p
acit
y
and efficienc
y
based on unit o
p
erationwithout condensate
p
um
p
; unit automaticall
y
switches to electric heat at a
pp
roximatel
y
24°F outdoor ambient.
6Specifytwo-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refers to com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(
included and factor
y
-installed on all Amana® brand 265-volt chassis
)
. See heater
p
erformance for total MCA.
PTH E SERIES
PTH F SERIES
PTH
073E**AXXX
PTH
093E**AXXX
PTH
123E**AXXX
PTH
153E**AXXX
PTH
074E**AXXX
PTH
094E**AXXX
PTH
124E**AXXX
PTH
154E**AXXX
230 / 208 230 / 208 230 / 208 230 / 208 265 265 265 265
BTU/h56,800 / 6,800 8,300 / 8,100 10,900 / 10,500 13,500 / 13,300 6,800 8,200 11,000 13,500
3.5 / 3.5 4.1 / 4.1 5.6 / 5.6 7.0 / 7.0 3.0 3.6 4.8 6.0
605 / 605 735 / 720 1040 /1020 1365 / 1345 585 730 1040 1365
COP53.3 / 3.3 3.3 / 3.3 3.1 / 3.1 2.9 / 2.9 3.4 3.3 3.1 2.9
CFM (Dry) 310 310 310 360 310 310 310 360
COP = Coefficiency of Performance; per AHRI Test Procedures, units are rated for capacities and efficiencies.
Heating Capacity¹
Amps10
Watts10
Voltage ¹, ³
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heatin
g
ca
p
acit
y
and efficienc
y
based on unit o
p
erationwithout condensate
p
um
p
; unit automaticall
y
switches to electric heat at a
pp
roximatel
y
24°F outdoor ambient.
6Specifytwo-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refers to com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(
included and factor
y
-installed on all Amana® brand 265-volt chassis
)
. See heater
p
erformance for total MCA.
PTH
123F**AXXX
PTH
124F**AXXX
230 / 208 265
BTU/h510,900 / 10,500 11,000
5.6 / 5.6 4.8
1040 /1020 1040
COP53.1 / 3.1 3.1
CFM (Dry) 310 310
COP =CoefficiencyofPerformance; per AHRITest Procedures,unitsare rated for capacities andefficiencies.
Heating Capacity¹
Amps10
Watts10
Voltage ¹, ³

14
SPECIFICATIONS
HEAT PUMP HEATING DATA
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.
Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
³ Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.
5Heatin
g
ca
p
acit
y
and efficienc
y
based on unit o
p
erationwithout condensate
p
um
p
; unit automaticall
y
switches to electric heat at a
pp
roximatel
y
24°F outdoor ambient.
6Specifytwo-digit heater kW size to complete model number.
7R-410A refrigerant used in all systems.
8All units meet or exceed ASHRAE 90.1 standards.
9 All units less than 250 volts have a Leak Current Detector Interru
p
ter
(
LCDI
)
p
ower cord and meet UL 484 standards.
10 Refer to electricheat
p
erformance data for total MCA and recommended overcurrent
p
rotection. Am
p
s and Watts notation refers to com
p
ressor onl
y
.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses
(
included and factor
y
-installed on all Amana® brand 265-volt chassis
)
. See heater
p
erformance for total MCA.
PTH G SERIES
@ 230V @ 208V @ 265V
230/208V 2.5 1 8,500 6,800 - - 2,570 / 2,115 11.2 / 10.1 14.1 15 6-15 P
230/208V 3.5 1 12,000 9,900 - - 3,570 / 2,935 15.5 / 14.1 19.5 20 6-20 P
230/208V 5 1 17,100 14,000 - - 5,070 / 4,160 22.1 / 20.0 27.6 30 6-30 P
265V 2.5 1 - - - - 8,500 2,570 9.7 12.2 15 7-20 P
265V 3.7 1 - - - - 12,600 3,770 14.2 17.9 20 7-20 P
265V 5 1 - - - - 17,100 5,070 19.2 23.9 25 7-30 P
Electric
Heater Size
(kW)
No. of
Stages
Nominal Heating (BTU/h)
Power Cord
Total
Watts6
Total
Amps
Min. Circuit
Ampacity²
MOD4
(amps)
Voltage
ELECTRIC HEAT PERFORMANCE PTH G SERIES
Notes:
¹ All 265-volt models must use an Amana® brand sub-base (PTSB4**E) or an Amana® brand hard-wire kit (PTPWHWK4).
² Minimum branch circuit ampacity ratings conform to the National Electric Code; however, local codes should apply.
³ Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts.
Minimum voltage on 265-volt models is239 volts; maximumis 292volts.
5Heating capacity and efficiency based on unit operation without condensate pump; unit automatically switches to electric heat at approximately 24°F outdoor ambient.
7Specify two-digit heater kW size to complete model number.
8R-410A refrigerant used in all systems.
9All units meet or exceedASHRAE90.1 standards.
10 All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) power cord and meet UL 484 standards.
4Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay
fuses (included and factory-installed on all Amana® brand 265-volt chassis).
6 Total watts for 15,000 BTU/h models; subtract 20 watts for PT07/09/12 EER - EnergyEfficiency RatioperThe Air-
Conditioning,Heating, andRefrigeration
Institute(AHRI)TestProcedures and
CanadianStandardsAssociation (CSA)
TestProcedures.
COP - CoefficientofPerformance per AHRI
TestProcedures
EER - EnergyEfficiencyRatioper TheAir-Conditioning,
Heating,andRefrigeration Institute(AHRI)Test
Proceduresand Canadian StandardsAssociation
(CSA) Test Procedures.
COP - CoefficientofPerformance perAHRITest
Procedures
PTH
073G**AXXX
PTH
093G**AXXX
PTH
123G**AXXX
PTH
153G**AXXX
PTH
074G**AXXX
PTH
094G**AXXX
PTH
124G**AXXX
PTH
154G**AXXX
230 / 208 230 / 208 230 / 208 230 / 208 265 265 265 265
BTU/h
5
6,800 / 6,800 8,300 / 8,100 11,500 / 11,300 13,800 / 13,600 6,800 8,300 11,400 13,700
3.9 / 3.9 4.2 / 4.2 5.8 / 5.8 7.0 / 7.0 3.1 3.7 5.0 6.1
585 / 570 715 / 700 1085 /1035 1350 / 1330 570 715 1080 1340
COP
5
3.4 / 3.5 3.4 / 3.4 3.1 / 3.2 3.0 / 3.0 3.5 3.4 3.1 3.0
CFM (Dry) 370 360 370 410 370 360 370 410
COP = Coefficiencyof Performance; per AHRITest Procedures, units are rated for capacities and efficiencies.
Model
Amps
10
Watts
10
Voltage ¹, ³

15
PROPER INSTALLATION
OPERATING VOLTAGES
WARNING
USE EXTREME CAUTION WHEN CHECKING HIGH VOLTAGE.
Use a voltmeter, check the voltage at the outlet.
The reading must be within the minimums and maximums shown below for the operating voltage.
Operating Voltage Minimum Voltage Maximum Voltage
230/208 197 253
265 238 291
Operating Voltages
NOTE:
1. All 265 volt models must use subbase or hard wire kit.
2. Minimum branch circuit ampacity ratings conform to the National Electric Code. However, local codes should apply
if in conflict.
3. Minimum voltage on 230/208 volt models is 197 volts; maximum is 253 volts. Minimum on 265 volts is 238 volts;
maximum is 291 volts.
4. Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265 volt models
must be cartridge-style time delay fuses (included and factory installed on chassis).
5. Heating capacity and efficiency is based on unit operation without condensate pump. Unit automatically switches to
electric heat at 25° F outdoor coil temperature.
6. Total watts for 15,000 BTUH models; subtract 30 watts for PT*12*E**** and 70 watts for PT*07/09*E****.
7. Please specify 2-digit heater kW size to compete model number.
8. Total amps for 12,000 and 15,000 BTUH models; subtract 0.2 amps for PT*07/09*E****.
•LCDI or AFCI Power Cords - Underwrites Laboratories and the National Electric Code (NEC) now require power cords
that sense current leakage and can open the electrical circuit to the unit on units rated at 250 volts or less. In the
event that unit does not operate, check the reset button located on or near the head of the power cord as part of
the normal troubleshooting procedure.
LCDI Power Cord

16
PROPER INSTALLATION
WALL SLEEVE INSTALLATION
The wall sleeve must be installed before the air conditioner
or heat pump chassis can be set in place. Read the instruc-
tions thoroughly before proceeding.
Pre-installation Considerations
Before proceeding with the sleeve installation, ensure the
followingguidelines for locating the wall opening and sleeve
are met:
• The wall opening must be the correct size. See the fig-
ures below for wall sleeve Dimensions and minimum
wall opening size.
161/16"
410mm
133/4"
350mm
Wall Receptacle Within 58" From
Bottom Right Side Corner on
208/230 VAC Units Only
Wall Sleeve Dimensions
Internal
Adjacent
Wall
Internal
A
d
j
acent
Wall
Outside
Wall
Allow Front Clearance (See Table 1)
Minimum Unit Clearances
• The wall sleeve will need to be installed with minimum
clearances to the floor and adjacent walls. Minimum
projections of the sleeve into and out of the room will
also have to be met. See Minimum Unit Clearances and
Minimum Interior and Exterior Projections Figures as
well as Minimum Clearances and Projections table for
details.
• If installed in a concrete or masonry wall, a lintel must
be provided in the wall opening for support. Do not use
the wall sleeve as a lintel. See Framing with Lintel
Figure for a typical lintel construction.
Framing with Lintel
• When installed in the opening, the wall sleeve must be
horizontally level from side to side and pitched (one
quarter bubble in the sight glass) to the outside. DO
NOT INSTALL LEVEL (FRONT TO BACK) OR SLOPE THE
WALL SLEEVE TOWARD THE ROOM.
• The installer must determine and supply the mounting
bolts and/or screws to attach the wall sleeve to the
sides of the wall opening. Make sure the wall opening is
adequate for strong support.
• The installer must provide adequate sealing and insula-
tion around the sleeve after it is installed (air and wa-
ter tight). See Block and Brick Veneer Installation Fig-
ure for one of many types of constructions.
Steel
Lintel
Caulk Top,
Bottom, and
Both Sides
13 1/2" (340 mm)
Maximum
(No Accessories)
Block and Brick Veneer Installation

17
PROPER INSTALLATION
Minimum Interior and Exterior Projections
in. mm in. mm in. mm
Wall Sleeve Only 3 75 0 0 0 0
Subbase Kit 3 75 3 1/4 85 2 3/4 70
Leveling Legs Kit 3 75 3 75 2 50
Duct Kit 3 75 0 0 1 3/8 35
Drain Kit 3 75 010100
Hard Wire Kit 3 75 1 1/4 30 0 0
H
y
dronic Heat Kit
"A" Series 9230
0 to 3 1/430 to 85332 752
Hydronic Heat Kit
"J" Series 6 150 0 0 2 1/2 65
Option
MINIMUM CLEARANCES AND PROJECTIONS
ABC
Minimum
Clearances
Minimum
Projection
1If inside mounted then B = 1 1/2 inches (40 mm).
2To achieve a flush fit between the hydronic front and the finished
wall, Dimension “C” must be between 3” and 3 1/8”. If this dimen-
sion is more than 3 1/8” there will be a gap between the front and
the wall. This gap could permit occupant access to hydronic lines or
other dangerous parts.
3This dimension can be from 0” to 3-1/4”, but cannot exceed 3-1/4”.
If this dimension exceeds 3-1/4”, the skirt around the front will not
reach the floor.
• For installations in walls deeper than 13-1/2 inches,
special care is necessary to prevent problems with rain
water, condensate drainage and intake/discharge air.
Underthese circumstances, careful job siteanalysis and
precautions are required. You must consult with your
Sales Representative and receive approval before at-
tempting such installations.
• If used, a 230/208 volt wall receptacle must be located
within 58 inches of the lower right sleeve corner. Ex-
tension cords must not be used with the unit. See the
note on Wall Sleeve Dimensions Figure.
421/4"
1075mm
Minimum
161/4"
415mm
Minimum
Dimension "B"
in Table 1
Minimum Wall Opening Dimensions
When 230/208 volt units are to be installed, the power sup-
ply may be either cord connected or permanent wiring. Per-
manentwiring may bedone through theaccessory hard wire
junction box, or the accessory subbase.
When 265 volt units are to be installed, the power supply
must be permanent wiring. Permanent wiring may be done
through the accessory hard wire junction box, or the acces-
sory subbase. An exposed cord connection on 265 volt
units is not permitted.
The subbase accessory includes leveling legs. If added wall
sleeve support is required and the subbase is not to be used
as an accessory, leveling leg kit may be installed.
Drain Kit
An indoor/outdoor drain kit is available as an accessory
item. When a drain kit is to be installed, do so before in-
stalling the wall sleeve in the wall. See the drain kit for
actual installation instructions.
Subbase, Leveling Legs, Main Duct, and Hydronic Heat
Kits
Installation of these kits requires drilling of mounting holes
on both sides of the wall sleeve. The minimum required
clearancedistancebetween the wallsleeve and wallisshown
in Minimum Clearances and Projections Table. If the dis-
tance between wall sleeve and wall will be at or near the
minimumclearance distance,mount these kits on the sleeve
before installing the sleeve in the wall. The kit installation
instructions are included with the accessory kits.

18
Wall Receptacle Within 58" From
Bottom Right Side Corner on
208/230 VAC Units Only
Wall Sleeve Dimensions
Outside Enclosure Panel Removal
The sleeve stiffener must be taken out before the enclo-
sure panel can be removed from the sleeve.
The enclosure panel can be removed by folding the four
flaps up and downward and manipulating the front ends of
the top plus bottom towards the center. The entire panel
can be pulled out diagonally from one side.
Installthe wall sleevecondenser airgrille by using the screws
and holes provided.
Installation (WS900B or WS900D)
After the wall opening is checked and approved for loca-
tion, size, and clearances, complete the following to install
the wall sleeve.
NOTE: Check with Amana®Brand Technical Service when a
chassis is installed in any wall sleeve not supplied by
Goodman.
1. Removetheoutsideenclosurepanelfromthewallsleeve.
2. Slide the wall sleeve into the wall opening. Do not dis-
tort the cabinet shape to fit the wall opening. The unit
chassis must fit snugly and uniformly into the wall
sleeve.
3. Locate the sleeve within the range of minimum projec-
tions, as shown in Minimum Wall Opening Dimensions
and Minimum Interior and Exterior Projections Figures,
so both sides are at least the minimum projection from
thewall.
4. Check the level of the wall sleeve. For proper drainage,
the sleeve should be level from side to side and one-
quarter bubble in the sight glass sloping to the outside.
5. Two holes will need to be drilled in both sides of the
wall sleeve for mounting into the wall. Drill holes of
proper size and in the proper location so the screws will
engage into strong supporting members of the wall. DO
NOT DRILL THROUGH BOTTOM OF SLEEVE. The fol-
lowing figure shows possible fastening methods.
Plastic
Anchor
Expansion
Anchor Bolt
Attaching Wall Sleeve to Opening
6. Check the level of the wall sleeve and adjust if neces-
sary.
7. Caulk or seal around the outside of the entire sleeve.
8. If the unit chassis will not be installed immediately,
replace the enclosure panel on the outside opening of
the sleeve. This will prevent weather damage to the
building interior.
9. Recycle or dispose of packaging materials per local
codes.
OUTDOOR GRILLE
Anoutsidegrille must beinstalledto direct airflowfor proper
unit operation and also protect the outdoor coil. The grille
must be installed before installing the chassis. Refer to the
Installation Instructions supplied with the outdoor grille kit
for a complete description of the installation procedure.
This model requires either a Stamped Grille Kit (Model SGK-
-B) or an Architectural Grille Kit (Model AGK--B). When re-
placing an old chassis with an existing grille, please check
withyour sales representativeto determine if the new chas-
sis should be used with the old outdoor grille. An improper
outdoor grille can decrease cooling or heating capacity, in-
crease energy usage and shorten compressor life.
FRONT REMOVAL
1. Grasp the cabinet front as shown.
2. Pull thebottom ofthe cabinet front away from the chas-
sis until the retaining clips disengage.
PROPER INSTALLATION

19
3. Lift the cabinet front off the chassis. Reverse this pro-
cedure to reinstall the cabinet front.
CHASSIS INSTALLATION
1. Remove the cabinet front from the chassis as described
in Front Removal.
2. Insert the chassis into the wall sleeve.
Chassis
Wall Sleeve
Outside
Wall
Slide Chassis In
3. Slide the chassis into the wall sleeve until the chassis
flanges contact the front edge of the wall sleeve.
Chassis
Wall Sleeve
Outside
Wall
4. Secure the chassis to the wall sleeve using three screws
on each side of the chassis to ensure a proper seal be-
tween the chassis and the wall sleeve. The screws are
supplied in a plastic bag which is attached to the power
cord.
IMPORTANT NOTES:
1. The unit is equipped with a rubber grommet mounted
compressor. These grommets are factory set and re-
quire no adjustment.
2. If a standard subbase is used, be sure the right hand
subbase cover is removed before the chassis is installed
in the sleeve.
3. Check the indoor and outdoor grilles for obstructions to
air flow. The unit must be located where curtains, fur-
niture, trees, shrubs or other objects do not block the
air flow to and from the unit. If air is obstructed and/or
deflected back into the unit, the air conditioner’s com-
pressor may cycle on and off rapidly. This could dam-
age the compressor and void the warranty.
Front Mounting Holes - Two mounting holes are provided to
give the owner the option of securing the front to the chas-
sis. The mounting holes are located behind the intake grille.
The owner must supply two 1/2 inch long #8 sheet metal
screws per unit. The two screws must be removed before
the front can be removed.
Front Mounting Screw
accessed
through louvers.
Front Mounting Screws
PROPER INSTALLATION

20
SPECIFICATIONS
WIRING
CAUTION
TO AVOID PROPERTY DAMAGE, PERSONAL INJURY
OR DEATH DUE TO ELECTRICAL SHOCK:
• DO NOT USE AN EXTENSION CORD WITH THIS UNIT.
• USE ONLY COPPER CONDUCTORS.
• WIRING TO THE UNIT MUST BE PROPERLY POLAR-
IZED AND GROUNDED.
Cord connection to a wall socket is not permitted for 265-
volt units. All 265-volt units must be hard wired using the
hard wire kit or make use of the plug-in receptacle in the
standard subbase.
Heaterless Units
Ifa heaterless unitis ordered, fieldprovisions must bemade
for supplemental heat if desired. Refer to the Installation
Instructions supplied with the heater kit for a complete de-
scription of the installation procedures. All 208/230 volt
heaterless units are shipped with a 15 Amp power cord and
allheaterless 265volt unitsare shipped with a 20 Amp power
cord.
When adding a heater kit to a unit, the power cord supplied
with the heater kit must be used in place of the power cord
supplied with the unit. The following table specifies power
cord rating requirements for the various heater kits.
230/208 Volt Units 265 Volt Units
Power Cord Rating
(amp) Power Cord Rating (amp)
1.5 15 20
2.5 15 20
3.5 20 Not Applicable
3.7 Not Applicable 20
530 30
POWER CORD REQUIREMENTS
Heater Size
(kW)
NOTE: Heaterless units are shipped with an auxiliary data
label on the front side of the mid-partition panel. If an
electric heater kit is field installed, the installer must mark
the appropriate box on the label to indicate the electric
heater capacity. If no heater is installed, the box labeled
“None” must be marked. Refer to the unit nameplate for
over current protection data.
CAUTION
DO NOT INSTALL A 5kW HEATER KIT IN ANY 7,000
OR 9,000 BTU CHASSIS.
OPERATING CONTROLS
Users Controls
Two rotary knobs controlling temperature and operational
ON / OFF
MASTER SWITCH
M2
M1
SW2 P10
COM A
P12 P13
IAT
BLACK
DS1 DS2 MS1 MS2 EH IN LS FD1 FD2 TF- TF+ C R GL W2Y/W1B GH
REMOTE THERMOS T
A
T
A
UXILI
A
RY
Mode
Switches
Master Switch
The master switch disconnects power to all of the system
components. When this switch is in the off position, the
compressor, fan motor, reversing valve, and electric resis-
tance heater will all be de-energized.
REMOTE/STANDARD
The remote/standard configuration is used to change the
control of the unit from the standard on board controls in
the standard mode, to a remote wall mounted thermostat
in the remote mode. For remote control configuration set-
tings, refer to Configuration Settings.
PROPER INSTALLATION
