Amana PCA24C02E Manual

®
Model and Manufacturing
numbers listed in this manual.
This manual is to be used by qualified HVAC
technicians only. Amana does not assume
any responsibility for property damage or
personal injury for improper service
procedures done by an unqualified person.
Technical
Information MODEL M/N
• Refer to Service Manual RS6300003 for installation, op-
eration,andtroubleshootinginformation.
• Allsafetyinformationmustbefollowedasprovidedinthe
ServiceManual.
• Refer to the appropriate Parts Catalog for part number
information.
RT6321001
July2000
PCA
PACKAGE COOLING UNITS
PCA24C02E P1234801C
PCA30C02E P1234802C
PCA36C02E P1234803C
PCA42C02E P1234804C
PCA48C02E P1234805C
PCA60C02E P1234806C

PCA 60C 0 2 E
Engineering Revision
Product Series
A: 10 SEER Line
C: 12 SEER Line
Design Sequence
Heating Input
0: No factory heat installed.
Voltage
2:230V/60Hz/1ph
Product Type
Single Package
Cooling/Heating
Product Family
C-Cooling
IMPORTANT INFORMATION
CAUTION
The model and manufacturing number are used for positive identification of component parts used in manufacturing. At
which time engineering and manufacturing changes take place where interchangeability of components are affected, the
manufacturingnumberwillchange.
It is very important to use the model and manufacturing numbers at all times when requesting service or parts information.
IF REPAIRS ARE ATTEMPTED BY UNQUALIFIED PERSONS, DANGEROUS
CONDITIONS(SUCHASEXPOSURETOELECTRICALSHOCK)MAYRESULT.
THIS MAY CAUSE SERIOUS INJURY OR DEATH.
AMANA WILL NOT BE RESPONSIBLE FOR ANY INJURY OR PROPERTY
DAMAGEARISINGFROMIMPROPERSERVICEORSERVICEPROCEDURES.
IF YOU PERFORM SERVICE ON YOUR OWN PRODUCT, YOU ASSUME
RESPONSIBILITY FOR ANY PERSONAL INJURY OR PROPERTY DAMAGE WHICH MAY RESULT.
WARNING
WARNING
Nominal Capacity
24:24000BTUH
30:30000BTUH
36:36000BTUH
42:42000BTUH
48:48000BTUH
60:60000BTUH

PRODUCT DESIGN
3
Amana PCA Package Cooling Units are designed for out-
door installations only in either residential or light commer-
cial applications.
The connecting ductwork (Supply and Return) can be con-
nected for either horizontal or vertical airflow. In the vertical
application a matching Roof Curb is recommended.
Areturnairfiltermustbeinstalledbehindthereturnairgrille(s)
or provision must be made for a filter in an accessible loca-
tionwithinthereturnairduct.Theminimumfilterareashould
not be less than those sizes listed in the Specification Sec-
tion. Under no circumstances should the unit be operated
without return air filters.
A 3/4" pipe and external drain trap is provided for removal of
condensate water from the indoor coil. (Do not reduce the
drain line size.)
Refrigerant flow control is achieved by use of restrictor ori-
fices.
The single phase units use permanent split capacitor (PSC)
designcompressors. Startingcomponentsarethereforenot
required. A low MFD run capacitor assists the compressor
to start and remains in the circuit during operation.
The outdoor fan and indoor blower motors are single phase
capacitor type motors.
Air for condensing (cooling cycle) is drawn through the out-
door coil by a propeller fan, and is discharged vertically out
the top of the unit. The outdoor coil is designed for .0 static.
No additional restriction (ductwork) shall be applied.
Conditioned air is drawn through the filter(s), field installed,
across the coil and back into the conditioned space by the
indoorblower.
PCA42C*toPCA60C*modelpackageunitsusetheCopeland
Compliant Scroll compressor, there are a number of design
characteristics which are different from the traditional recip-
rocatingcompressor.
- Due to their design Scroll Compressors are inherently
moretolerantof liquid refrigerant. NOTE:Eventhoughthe
compressorsectionofaScrollcompressorismoretoler-
ant of liquid refrigerant, continued floodback or flooded
start conditions may wash oil from the bearing surfaces
causingprematurebearingfailure.
- Scroll Compressors use white oil which is compatible
with 3GS oil which may be used if additional oil is re-
quired.
- Operatingpressuresandampdrawsmaydifferfromstan-
dard reciprocating compressors. This information may
be found in the "Cooling Performance Data" section.
LocationandClearances
36"
Maximum
Overhang
48" Minimum
Overhang
36" Side
Clearance
for Servicing
Recommended
Minimum 36"
Clearance for
Service Required 0" Minimum
Clearance to
Combustibles
Vinyl Coated
Canvas
Connections
Insulated
Return
Duct
Insulated
Supply
Duct
24" Clearance
(Condenser End)
Ininstallations where the unitis installed above groundlevel
andnot serviceable from the ground (Example: Roof Top in-
stallations)theinstallermustprovideservice platform for ser-
vicepersonwithrailsorguardsinaccordancewithlocalcodes
orordinancesorintheirabsencewiththelatesteditionofthe
UniformMechanical Code Section 305.
NOTE: Unitcanalsouseroofcurb (and platform for leveling,
where necessary) to utilize bottom discharge.
WARNING
TOPREVENTPOSSIBLEPROPERTYDAMAGE,THEUNIT
SHOULDREMAININANUPRIGHTPOSITIONDURINGALL
RIGGING AND MOVING OPERATIONS. TO FACILITATE
LIFTINGANDMOVING IF ACRANEIS USED, PLACETHE
UNITINANADEQUATECABLE SLING.
IMPORTANT: If using bottom discharge with roof curb,
ductwork should be attached to the curb prior to installing
the unit.
Refer to Roof Curb Installation Instructions for proper curb
installation. Curbing must be installed in compliance with
the National Roofing Contractors Association Manual.

PRODUCT IDENTIFICATION
4
BOTTOM
DUCT
OPENING
(SUPPLY)
47-5/32"
12"
INSIDE
12"
INSIDE
12"
INSIDE 12"
INSIDE 3-3/4" 2-7/32"
16-1/4"
REF
3-13/16"
7-1/4"
18-5/8"
ELECTRICAL
(3/4" & 1-1/4" K.O.)
2-7/8"
37-5/32"
ELECT.
CONTROL
BOX
EVAP
COIL
COMPRESSOR
1-7/16"
23-9/16"
30-7/16"
11-5/16"
LOW
VOLTAGE
1/2"
ELECTRICAL
(3/4", 1-1/4" K.O.)
3-7/8"
12-7/8"
CONDENSATE
3/4"
SERVICE
PORT
11-5/16"
LOW
VOLTAGE
1/2"
21.0"
17.0"
C.G.
C.G.
SUPPLY
AIR
RETURN
AIR
1-7/8"
10-5/16"
14" DIA
14" DIA
1-1/2" ELECTRICAL
(3/4", 1-1/4" K.O.
)
8-3/4" 13-1/2"
43-1/16"
2"
10-1/2"
BLOWER
HEATER BOX
21-9/16"
ELECTRICAL
(3/4", 1-1/4" & 2" K.O.)
2-3/8"
BOTTOM DUCT
OPENING
(RETURN)
25-9/16"
PCA24-36
BOTTOM
DUCT
OPENING
(SUPPLY)
47-5/32"
12"
INSIDE
12"
INSIDE
12"
INSIDE 12"
INSIDE 3-3/4" 2-7/32"
16-1/4"
REF
3-13/16"
7-1/4"
18-5/8"
ELECTRICAL
(3/4" & 1-1/4" K.O.)
2-7/8"
37-5/32"
21.0"
17.0"
C.G.
C.G.
BOTTOM DUCT
OPENING
(RETURN)
ELECT.
CONTROL
BOX
EVAP
COIL
COMPRESSOR
1-7/16"
29-9/16"
36-7/16"
7-5/16"
LOW
VOLTAGE
1/2"
ELECTRICAL
(3/4", 1-1/4" K.O.)
3-7/8"
12-7/8"
CONDENSATE
3/4"
SERVICE
PORT
7-5/16"
LOW
VOLTAGE
1/2"
BLOWER
HEATER BOX
27-9/16"
ELECTRICAL
(3/4", 1-1/4" & 2" K.O.)
2-3/8"
RETURN
AIR
1-7/8"
10-5/16" 1-1/2" ELECTRICAL
(3/4", 1-1/4" K.O.)
8-3/4" 13-1/2"
43-1/16"
2"
10-1/2"
29-9/16"
14" x 14"
SUPPLY
AIR
( PCA60)
SUPPLY
AIR
RETURN
AIR
1-7/8"
10-5/16"
14" DIA
1-1/2" ELECTRICAL
(3/4", 1-1/4" K.O.)
8-3/4" 13-1/2"
43-1/16"
2"
10-1/2"
29-9/16"
14" DIA
( PCA42, 48 )

PACKAGE COOLING SPECIFICATIONS
5
WARNING
!
All wires and overcurrent protection devices are sized without electric heaters. If heaters are installed
with above wire size, overheating and fire could occur. Refer to heater kit installation manual for wire size
and overcurrent protection device size with heaters installed. Also refer to the unit nameplate.
** IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
inaccordancewiththeNationalElectricalCodeand/oralllocalcodes. Datashownisw/oelectricheaters. See"ElectricHeaters"intheSYSTEMOPERATION
section for additional information.
PCA24C**E PCA30C**E PCA36C**E
COOLING CAPACITY, BTUH 24,000 29,600 36,000
SEER 10.0 10.0 10.0
VOLTAGE (NAMEPLATE) 208/230-60-1 208/230-60-1 208/230-60-1
UNIT AMPS (TOTAL) 15.2 18.4 20.2
MIN CIRCUIT AMPACITY 17.9 21.9 24.2
MAX OVERCURRENT PROTECTION 25 35 35
TYPE RECIP RECIP RECIP
RATED LOAD AMPS 11.2 14.4 16.2
LOCKED ROTOR AMPS 61 82 96
HORSEPOWER 1/5 1/5 1/5
RPM 825 825 825
FULL LOAD AMPS 1.3 1.3 1.3
LOCKED ROTOR AMPS 2.0 2.0 2.0
BLADE DIAMETER / NUMBER 22" / 4 22" / 4 22" / 4
CFM 2200 2200 2200
FACE AREA - (SQ. FT.) 8.2 8.2 10.2
NUMBER OF ROWS 1 1 1
FINS PER INCH 20 20 20
HORSEPOWER - NO. OF SPEEDS 1/3 - 4 1/3 - 4 1/3 - 4
FULL LOAD AMPS 2.6 2.6 2.6
LOCKED ROTOR AMPS 4.2 4.2 4.2
MOTOR SPEED TAP - COOLING LOW MED - LOW MED - HIGH
RPM 790 840 960
DIAMETER X WIDTH (IN.) 10 X 8 10 X 8 10 X 8
RATED SCFM COOLING 800 1000 1200
MAX EXTERNAL STATIC PRESS .5" wc .5" wc .5" wc
FACE AREA- (SQ. FT.) 3.2 3.2 3.2
NUMBER OF ROWS 2 2 4
FINS PER INCH 14 14 14
FILTER SIZE - (SQ. FT.) 3 3.4 4
DRAIN SIZE 3/4 IN 3/4 IN 3/4 IN
EXPANSION DEVICE ORIFICE ORIFICE ORIFICE
REFRIGERANT CHARGE R-22 53 oz. 59 oz. 64 oz.
POWER SUPPLY ENTRANCE SIZE (IN.) 3/4 1-1/4 3/4 1-1/4 3/4 1-1/4
LOW VOLTAGE ENTRANCE SIZE 3/4" 3/4" 3/4"
SHIPPING WEIGHT (LBS.) 313 323 333
OPERATING WEIGHT (LBS.) 300 308 320
ACCESSORIES COMPRESSOR SOUND BLANKET CSB04A CSB04A CSB04A
ROUND TO SQUARE KIT RSDK01A RSDK01A RSDK01A
SINGLE POINT KIT SPK04A SPK06A SPK06A
FREEZE PROTECTION KIT FSK01A FSK01A FSK01A
50°F COMPRESSOR LOCK OUT LOC501A LOC501A LOC501A
PC/PH ROOF CURB PRC06A1 PRC06A1 PRC06A1
COMBINATION ROOF CURB PRC08A1 PRC08A1 PRC08A1
OVER/UNDER TRANSITION PDTROU4A PDTROU4A PDTROU4A
HORIZONTAL DUCT COVER KIT CHK001A CHK001A CHK001A
AMBIENT THERMOSTAT KIT ATK01A ATK01A ATK01A
COMPRESSOR
CONDENSER
FAN MOTOR
CONDENSER
FAN
CONDENSER
COIL
SPECIFICATIONS
COOLING
CAPACITY
UNIT
ELECTRICAL
SPECIFICATION
EVAPORATOR
BLOWER
MOTOR
EVAPORATOR
COIL
GENERAL
INFORMATION
EVAPORATOR
BLOWER

PACKAGE COOLING SPECIFICATIONS
6
WARNING
!
All wires and overcurrent protection devices are sized without electric heaters. If heaters are installed
with above wire size, overheating and fire could occur. Refer to heater kit installation manual for wire size
and overcurrent protection device size with heaters installed. Also refer to the unit nameplate.
** IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
inaccordancewiththeNationalElectricalCodeand/oralllocalcodes. Datashownisw/oelectricheaters. See"ElectricHeaters"intheSYSTEMOPERATION
section for additional information.
PCA42C**E PCA48C**E PCA60C**E
COOLING CAPACITY, BTUH 40,500 47,000 58,000
SEER 10.00 10.00 10.00
VOLTAGE (NAMEPLATE) 208/230-60-1 208/230-60-1 208/230-60-1
UNIT AMPS (TOTAL) 24 28.9 34.2
MIN CIRCUIT AMPACITY 28.5 34.3 40.9
MAX OVERCURRENT PROTECTION 45 50 60
TYPE SCROLL SCROLL SCROLL
RATED LOAD AMPS 18 21.8 27.1
LOCKED ROTOR AMPS 103 131 175
HORSEPOWER 1/5 1/3 1/3
RPM 825 1100 1100
FULL LOAD AMPS 1.3 2.4 2.4
LOCKED ROTOR AMPS 2.0 5.8 5.8
BLADE DIAMETER / NUMBER 22" / 4 22" / 4 22" / 4
CFM 2200 3000 3000
FACE AREA (SQ FT.) 12 12 12
NUMBER OF ROWS 1 1 2
FINS PER INCH 20 20 20
HORSEPOWER - NO. OF SPEEDS 3/4 - 3 3/4 - 3 3/4 - 3
FULL LOAD AMPS 4.7 4.7 4.7
LOCKED ROTOR AMPS 12.2 12.2 12.2
MOTOR SPEED TAP - COOLING LOW MEDIUM HIGH
RPM 975 1050 1075
DIAMETER X WIDTH (IN.) 10 X 8 10 X 8 10 X 8
RATED SCFM COOLING 1400 1500 1750
MAX EXTERNAL STATIC PRESS .5" wc .5" wc .5" wc
FACE AREA(SQ. FT.) 4.4 4.4 4.4
NUMBER OF ROWS 4 4 3
FINS PER INCH 14 14 14
FILTER SIZE (SQ. FT.) 4.5 5.0 6.5
DRAIN SIZE 3/4 IN 3/4 IN 3/4 IN
EXPANSION DEVICE ORIFICE ORIFICE ORIFICE
REFRIGERANT CHARGE (R-22) 83 oz. 99 oz. 115 oz.
POWER SUPPLY ENTRANCE SIZE (IN.) 3/4 1-1/4" 3/4 1-1/4" 3/4 1-1/4"
LOW VOLTAGE ENTRANCE SIZE 3/4" 3/4" 3/4"
SHIPPING WEIGHT (LBS.) 363 369 410
OPERATING WEIGHT (LBS.) 347 353 394
ACCESSORIES COMPRESSOR SOUND BLANKET CSB08A CSB08A CSB09A
ROUND TO SQUARE KIT RSDK01A RSDK01A RSDK01A
FREEZE PROTECTION KIT FSK01A FSK01A FSK01A
50°F COMPRESSOR LOCK OUT LOC501A LOC501A LOC501A
PC/PH ROOF CURB PRC06A1 PRC06A1 PRC06A1
COMBINATION ROOF CURB PRC08A1 PRC08A1 PRC08A1
OVER/UNDER TRANSITION PDTROU6A PDTROU6A PDTROU6A
HORIZONTAL DUCT COVER KIT CHK001A CHK001A CHK001A
SINGLE POINT KIT SPK07A SPK08A SPK09A
AMBIENT THERMOSTAT KIT ATK01 ATK01 ATK01
EVAPORATOR
COIL
SPECIFICATIONS
GENERAL
INFORMATION
COOLING
CAPACITY
UNIT
ELECTRICAL
SPECIFICATION
COMPRESSOR
CONDENSER
FAN MOTOR
CONDENSER
FAN
CONDENSER
COIL
EVAPORATOR
BLOWER
EVAPORATOR
BLOWER
MOTOR

BLOWER PERFORMANCE DATA
7
Dry Coil Data
Horizontaland Downshot
Horizontal
Downshot
*The shaded area(s) indicates range(s) in excess of maximum external static pressure allowed.
UNIT
STATIC
(in W.C.) CFM WATTS CFM WATTS CFM WATTS CFM WATTS
0.1 840 230 1010 295 1230 385 1660 550
0.2 820 225 990 287 1205 372 1600 530
0.3 800 220 970 280 1180 360 1540 510
0.4 770 210 940 270 1150 345 1480 485
0.5 735 200 905 260 1110 330 1420 460
0.6 700 185 850 250 1060 305 1350 135
0.7 660 170 790 235 1005 290 1280 410
0.8 605 155 700 220 905 275 1205 390
PCA24, 30, 36C**E
High
FAN SPEED
Low Med-Low Med-High
UNIT
STATIC
(in W.C.) CFM WATTS CFM WATTS CFM WATTS
0.2 1540 620 1780 735 2265 1010
0.3 1520 600 1755 705 2160 965
0.4 1495 575 1700 670 2095 925
0.5 1460 555 1640 640 1980 880
0.6 1400 520 1570 600 1885 840
0.7 1335 490 1500 570 1770 795
0.8 1260 450 1400 520 1650 750
PCA42,48,60C**E
LOW MED HIGH
FAN SPEED
UNIT
STATIC
(in W.C.) CFM WATTS CFM WATTS CFM WATTS
0.2 1510 580 1715 665 2040 880
0.3 1475 565 1640 635 1960 855
0.4 1410 535 1580 605 1860 820
0.5 1350 510 1500 570 1770 795
0.6 1280 480 1425 545 1650 755
0.7 1210 450 1335 510 1540 720
0.8 1115 420 1235 475 1430 685
PCA42,48,60C**E
FAN SPEED
LOW MED HIGH

8
BLOWER PERFORMANCE DATA
TEMPERATURERISE

COOLING PERFORMANCE DATA
9
MODEL: PCA24C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.9 22.7 24.8 - 20.8 21.5 23.6 - 19.3 20.0 21.9 -
S/T 0.65 0.55 0.38 - 0.68 0.57 0.39 - 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.75 0.63 0.43 -
Delta T 16 14 10 - 16 14 10 - 16 14 10 - 16 14 11 - 16 14 10 - 15 13 10 -
900 KW 2.05 2.09 2.15 - 2.20 2.25 2.32 - 2.34 2.39 2.46 - 2.46 2.51 2.59 - 2.56 2.62 2.70 - 2.65 2.71 2.80 -
AMPS 9.4 9.6 9.9 - 10.0 10.2 10.5 - 10.7 11.0 11.3 - 11.4 11.6 11.9 - 12.0 12.2 12.5 - 12.6 12.8 13.2 -
HI PR 156 168 178 - 176 189 199 - 200 215 227 - 227 245 258 - 256 275 291 - 283 304 321 -
LO PR 57 60 66 - 60 64 69 - 62 66 72 - 65 69 76 - 68 73 79 - 71 75 82 -
MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -
S/T 0.62 0.52 0.36 - 0.65 0.54 0.37 - 0.66 0.55 0.38 - 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.71 0.60 0.41 -
Delta T 16 14 11 - 17 14 11 - 17 14 11 - 17 14 11 - 16 14 11 - 15 13 10 -
70 800 KW 2.03 2.07 2.14 - 2.18 2.23 2.30 - 2.32 2.37 2.44 - 2.44 2.49 2.57 - 2.54 2.60 2.68 - 2.63 2.68 2.77 -
AMPS 9.4 9.6 9.8 - 10.0 10.2 10.4 - 10.7 10.9 11.2 - 11.3 11.5 11.8 - 11.9 12.1 12.5 - 12.5 12.7 13.1 -
HI PR 155 167 176 - 174 187 197 - 198 213 225 - 225 242 256 - 253 273 288 - 280 301 318 -
LO PR 56 60 65 - 59 63 69 - 62 65 71 - 65 69 75 - 68 72 79 - 70 75 81 -
MBh 21.1 21.8 23.9 - 20.6 21.3 23.4 - 20.1 20.8 22.8 - 19.6 20.3 22.3 - 18.6 19.3 21.1 - 17.3 17.9 19.6 -
S/T 0.60 0.50 0.35 - 0.62 0.52 0.36 - 0.64 0.53 0.37 - 0.66 0.55 0.38 - 0.68 0.57 0.40 - 0.69 0.58 0.40 -
Delta T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 14 11 - 16 14 10 -
700 KW 1.98 2.02 2.09 - 2.13 2.18 2.25 - 2.26 2.31 2.38 - 2.38 2.43 2.51 - 2.48 2.53 2.61 - 2.56 2.62 2.70 -
AMPS 9.2 9.3 9.6 - 9.8 9.9 10.2 - 10.4 10.6 10.9 - 11.0 11.2 11.5 - 11.6 11.8 12.2 - 12.2 12.4 12.8 -
HI PR 150 162 171 - 169 181 192 - 192 206 218 - 218 235 248 - 246 264 279 - 271 292 308 -
LO PR 54 58 63 - 57 61 67 - 60 63 69 - 63 67 73 - 66 70 76 - 68 72 79 -
MBh 23.9 24.6 26.7 28.6 23.4 24.1 26.0 27.9 22.8 23.5 25.4 27.3 22.2 22.9 24.8 26.6 21.1 21.8 23.6 25.3 19.6 20.2 21.8 23.4
S/T 0.74 0.66 0.50 0.32 0.77 0.69 0.52 0.33 0.79 0.71 0.53 0.34 0.81 0.73 0.55 0.35 0.84 0.76 0.57 0.37 0.85 0.76 0.58 0.37
Delta T 18 17 14 9 18 17 14 10 18 17 14 10 19 17 14 10 18 17 14 10 17 16 13 9
900 KW 2.06 2.11 2.17 2.24 2.22 2.27 2.34 2.41 2.36 2.41 2.49 2.57 2.48 2.53 2.61 2.70 2.58 2.64 2.73 2.82 2.67 2.73 2.82 2.91
AMPS 9.5 9.7 9.9 10.2 10.1 10.3 10.6 10.9 10.8 11.0 11.3 11.7 11.4 11.7 12.0 12.4 12.1 12.3 12.7 13.1 12.7 12.9 13.3 13.7
HI PR 158 170 180 187 177 191 201 210 202 217 229 239 230 247 261 272 258 278 294 306 285 307 324 338
LO PR 57 61 66 71 60 64 70 75 63 67 73 78 66 70 77 82 69 74 80 85 71 76 83 88
MBh 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1 22.8 24.7 26.5 21.6 22.2 24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7
S/T 0.71 0.63 0.48 0.31 0.73 0.66 0.50 0.32 0.75 0.67 0.51 0.33 0.78 0.69 0.53 0.34 0.81 0.72 0.55 0.35 0.81 0.73 0.55 0.35
DeltaT1917141019181410191814101918 15 10 19 17 14 10 18 16 13 9
75 800 KW 2.05 2.09 2.15 2.22 2.20 2.25 2.32 2.39 2.34 2.39 2.46 2.55 2.46 2.51 2.59 2.68 2.56 2.62 2.70 2.79 2.65 2.71 2.80 2.89
AMPS 9.4 9.6 9.9 10.2 10.0 10.2 10.5 10.8 10.7 11.0 11.3 11.6 11.4 11.6 11.9 12.3 12.0 12.2 12.6 13.0 12.6 12.8 13.2 13.6
HI PR 156 168 178 185 176 189 199 208 200 215 227 237 227 245 258 270 256 275 291 303 283 304 321 335
LO PR 57 60 66 70 60 64 69 74 62 66 72 77 65 69 76 81 68 73 79 85 71 75 82 88
MBh 21.4 22.1 23.9 25.6 20.9 21.6 23.3 25.0 20.4 21.0 22.8 24.4 19.9 20.5 22.2 23.8 18.9 19.5 21.1 22.7 17.5 18.1 19.6 21.0
S/T 0.68 0.61 0.46 0.30 0.71 0.63 0.48 0.31 0.73 0.65 0.49 0.32 0.75 0.67 0.51 0.33 0.78 0.69 0.53 0.34 0.78 0.70 0.53 0.34
DeltaT1918141019181510191815102018151019181510181714 9
700 KW 2.00 2.04 2.10 2.17 2.15 2.19 2.26 2.34 2.28 2.33 2.40 2.48 2.40 2.45 2.53 2.61 2.50 2.55 2.64 2.72 2.58 2.64 2.73 2.82
AMPS 9.2 9.4 9.7 9.9 9.8 10.0 10.3 10.6 10.5 10.7 11.0 11.3 11.1 11.3 11.6 12.0 11.7 11.9 12.3 12.6 12.3 12.5 12.9 13.3
HI PR 152 163 172 180 170 183 193 202 194 208 220 230 221 237 251 261 248 267 282 294 274 295 312 325
LO PR 55 58 64 68 58 62 67 72 60 64 70 75 63 67 74 78 66 71 77 82 69 73 80 85
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

10
COOLING PERFORMANCE DATA
MODEL: PCA24C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 24.3 24.9 26.6 28.4 23.8 24.3 26.0 27.7 23.2 23.7 25.3 27.1 22.6 23.1 24.7 26.4 21.5 22.0 23.5 25.1 19.9 20.4 21.8 23.3
S/T 0.81 0.76 0.62 0.46 0.84 0.79 0.64 0.48 0.86 0.81 0.66 0.49 0.89 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.93 0.88 0.71 0.53
DeltaT201917132020171421201714212017142020171419181613
900 KW 2.08 2.12 2.19 2.26 2.24 2.28 2.36 2.43 2.38 2.43 2.51 2.59 2.50 2.55 2.64 2.72 2.60 2.66 2.75 2.84 2.69 2.75 2.84 2.94
AMPS 9.6 9.8 10.0 10.3 10.2 10.4 10.7 11.0 10.9 11.1 11.4 11.8 11.5 11.8 12.1 12.5 12.1 12.4 12.8 13.2 12.8 13.0 13.4 13.8
HI PR 160 172 181 189 179 193 204 212 204 219 231 241 232 250 264 275 261 281 297 309 288 310 328 342
LO PR 58 61 67 71 61 65 71 75 63 67 74 78 67 71 77 82 70 74 81 86 72 77 84 89
MBh 23.6 24.1 25.8 27.6 23.1 23.6 25.2 26.9 22.5 23.0 24.6 26.3 22.0 22.5 24.0 25.7 20.9 21.3 22.8 24.4 19.3 19.8 21.1 22.6
S/T 0.78 0.73 0.59 0.44 0.80 0.75 0.61 0.46 0.82 0.77 0.63 0.47 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.89 0.84 0.68 0.51
DeltaT212018142120181421201814222118 14 21 20 18 14 20 19 17 13
80 800 KW 2.06 2.11 2.17 2.24 2.22 2.27 2.34 2.41 2.36 2.41 2.49 2.57 2.48 2.53 2.62 2.70 2.58 2.64 2.73 2.82 2.67 2.73 2.82 2.92
AMPS 9.5 9.7 9.9 10.2 10.1 10.3 10.6 10.9 10.8 11.0 11.3 11.7 11.4 11.7 12.0 12.4 12.1 12.3 12.7 13.1 12.7 12.9 13.3 13.7
HI PR 158 170 180 187 177 191 201 210 202 217 229 239 230 247 261 272 258 278 294 306 285 307 324 338
LO PR 57 61 66 71 60 64 70 75 63 67 73 78 66 70 77 82 69 74 80 85 71 76 83 88
MBh 21.8 22.3 23.8 25.5 21.3 21.8 23.3 24.9 20.8 21.3 22.7 24.3 20.3 20.7 22.2 23.7 19.3 19.7 21.0 22.5 17.9 18.2 19.5 20.8
S/T 0.75 0.70 0.57 0.43 0.78 0.73 0.59 0.44 0.80 0.75 0.61 0.45 0.82 0.77 0.63 0.47 0.85 0.80 0.65 0.49 0.86 0.81 0.66 0.49
DeltaT212118142221181422211814222118152221181420191713
700 KW 2.02 2.06 2.12 2.19 2.17 2.21 2.28 2.35 2.30 2.35 2.42 2.50 2.42 2.47 2.55 2.63 2.52 2.57 2.66 2.75 2.60 2.66 2.75 2.84
AMPS 9.3 9.5 9.7 10.0 9.9 10.1 10.4 10.7 10.6 10.8 11.1 11.4 11.2 11.4 11.7 12.1 11.8 12.0 12.4 12.7 12.4 12.6 13.0 13.4
HI PR 153 165 174 182 172 185 195 204 196 211 222 232 223 240 253 264 251 270 285 297 277 298 315 328
LO PR 55 59 64 69 59 62 68 72 61 65 71 75 64 68 74 79 67 71 78 83 69 74 81 86
MBh 24.8 25.2 26.4 28.2 24.2 24.7 25.8 27.6 23.6 24.1 25.2 26.9 23.0 23.5 24.6 26.2 21.9 22.3 23.4 24.9 20.3 20.7 21.6 23.1
S/T 0.85 0.82 0.74 0.60 0.88 0.85 0.77 0.62 0.91 0.88 0.79 0.64 0.94 0.90 0.82 0.66 0.97 0.94 0.85 0.69 0.98 0.95 0.85 0.69
DeltaT222120172221201822222018222220182221201720201916
900 KW 2.10 2.14 2.21 2.28 2.25 2.30 2.38 2.45 2.40 2.45 2.53 2.61 2.52 2.57 2.66 2.75 2.62 2.68 2.77 2.86 2.72 2.78 2.87 2.96
AMPS 9.6 9.8 10.1 10.4 10.3 10.5 10.8 11.1 11.0 11.2 11.5 11.9 11.6 11.9 12.2 12.6 12.2 12.5 12.9 13.3 12.9 13.1 13.5 13.9
HI PR 161 173 183 191 181 195 206 214 206 221 234 244 234 252 266 278 264 284 300 312 291 313 331 345
LO PR 58 62 68 72 62 66 72 76 64 68 74 79 67 72 78 83 71 75 82 87 73 78 85 90
MBh 24.0 24.5 25.7 27.4 23.5 23.9 25.1 26.8 22.9 23.4 24.5 26.1 22.4 22.8 23.9 25.5 21.2 21.7 22.7 24.2 19.7 20.1 21.0 22.4
S/T 0.81 0.79 0.71 0.57 0.84 0.81 0.73 0.60 0.86 0.83 0.75 0.61 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.93 0.90 0.81 0.66
DeltaT222221182322211823222118232321182322211821212017
85 800 KW 2.08 2.12 2.19 2.26 2.24 2.28 2.36 2.43 2.38 2.43 2.51 2.59 2.50 2.55 2.64 2.72 2.60 2.66 2.75 2.84 2.69 2.75 2.84 2.94
AMPS 9.6 9.8 10.0 10.3 10.2 10.4 10.7 11.0 10.9 11.1 11.4 11.8 11.5 11.8 12.1 12.5 12.1 12.4 12.8 13.2 12.8 13.0 13.4 13.8
HI PR 160 172 181 189 179 193 204 212 204 219 231 241 232 250 264 275 261 281 297 309 288 310 328 342
LO PR 58 61 67 71 61 65 71 75 63 67 74 78 67 71 77 82 70 74 81 86 72 77 84 89
MBh 22.2 22.6 23.7 25.3 21.7 22.1 23.1 24.7 21.2 21.6 22.6 24.1 20.6 21.0 22.0 23.5 19.6 20.0 20.9 22.3 18.2 18.5 19.4 20.7
S/T 0.78 0.76 0.68 0.55 0.81 0.78 0.71 0.57 0.83 0.80 0.73 0.59 0.86 0.83 0.75 0.61 0.89 0.86 0.78 0.63 0.90 0.87 0.78 0.64
DeltaT232221182323221923232219232322192323211921212017
700 KW 2.03 2.07 2.14 2.20 2.18 2.23 2.30 2.37 2.32 2.37 2.44 2.52 2.44 2.49 2.57 2.66 2.54 2.59 2.68 2.77 2.63 2.68 2.77 2.87
AMPS 9.4 9.5 9.8 10.1 10.0 10.2 10.4 10.8 10.7 10.9 11.2 11.5 11.3 11.5 11.8 12.2 11.9 12.1 12.4 12.8 12.5 12.7 13.1 13.5
HI PR 155 167 176 183 174 187 197 206 198 213 225 234 225 242 256 267 253 272 288 300 280 301 318 332
LO PR 56 60 65 69 59 63 69 73 62 65 71 76 65 69 75 80 68 72 79 84 70 75 81 87
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ARI Rating Conditions

COOLING PERFORMANCE DATA
11
MODEL: PCA30C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 28.6 29.6 32.5 - 27.9 28.9 31.7 - 27.3 28.2 30.9 - 26.6 27.6 30.2 - 25.3 26.2 28.7 - 23.4 24.3 26.6 -
S/T 0.70 0.58 0.41 - 0.73 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.67 0.46 - 0.80 0.67 0.47 -
Delta T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
1100 KW 2.55 2.60 2.68 - 2.74 2.80 2.89 - 2.92 2.98 3.08 - 3.07 3.14 3.24 - 3.20 3.27 3.38 - 3.31 3.39 3.50 -
AMPS 11.1 11.4 11.7 - 11.9 12.2 12.5 - 12.8 13.1 13.5 - 13.6 13.9 14.3 - 14.4 14.7 15.2 - 15.2 15.5 16.0 -
HI PR 176 189 200 - 197 212 224 - 224 241 255 - 255 275 290 - 287 309 326 - 317 342 361 -
LO PR 58 61 67 - 61 65 71 - 63 67 74 - 67 71 77 - 70 74 81 - 72 77 84 -
MBh 28.2 29.2 32.0 - 27.5 28.5 31.2 - 26.9 27.8 30.5 - 26.2 27.2 29.7 - 24.9 25.8 28.3 - 23.1 23.9 26.2 -
S/T 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.61 0.43 - 0.76 0.64 0.44 - 0.77 0.64 0.45 -
Delta T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
70 1000 KW 2.53 2.59 2.67 - 2.73 2.79 2.88 - 2.90 2.96 3.06 - 3.05 3.12 3.22 - 3.18 3.25 3.36 - 3.30 3.37 3.48 -
AMPS 11.1 11.3 11.6 - 11.8 12.1 12.5 - 12.8 13.0 13.4 - 13.5 13.8 14.3 - 14.3 14.6 15.1 - 15.1 15.4 15.9 -
HI PR 174 188 198 - 196 211 222 - 223 240 253 - 254 273 288 - 285 307 324 - 315 339 358 -
LO PR 57 61 67 - 61 64 70 - 63 67 73 - 66 70 77 - 69 74 80 - 72 76 83 -
MBh 27.7 28.8 31.5 - 27.1 28.1 30.8 - 26.4 27.4 30.0 - 25.8 26.7 29.3 - 24.5 25.4 27.8 - 22.7 23.5 25.8 -
S/T 0.65 0.54 0.37 - 0.67 0.56 0.39 - 0.69 0.57 0.40 - 0.71 0.59 0.41 - 0.74 0.61 0.43 - 0.74 0.62 0.43 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
900 KW 2.50 2.55 2.63 - 2.69 2.75 2.84 - 2.86 2.92 3.02 - 3.01 3.08 3.18 - 3.14 3.21 3.31 - 3.25 3.32 3.43 -
AMPS 10.9 11.1 11.5 - 11.7 11.9 12.3 - 12.6 12.8 13.2 - 13.3 13.6 14.1 - 14.1 14.4 14.9 - 14.9 15.2 15.7 -
HI PR 171 185 195 - 192 207 219 - 219 235 249 - 249 268 283 - 280 302 319 - 310 333 352 -
LO PR 56 60 65 - 59 63 69 - 62 66 72 - 65 69 75 - 68 72 79 - 70 75 82 -
MBh 29.1 29.9 32.4 34.8 28.4 29.2 31.6 34.0 27.7 28.5 30.9 33.2 27.0 27.8 30.1 32.3 25.7 26.4 28.6 30.7 23.8 24.5 26.5 28.5
S/T 0.80 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.91 0.81 0.61 0.39 0.91 0.82 0.62 0.40
DeltaT1918151020181510201815102018151019181510181714 9
1100 KW 2.57 2.62 2.71 2.79 2.77 2.83 2.92 3.01 2.94 3.01 3.11 3.21 3.10 3.17 3.27 3.38 3.23 3.30 3.41 3.53 3.34 3.42 3.53 3.65
AMPS 11.2 11.4 11.8 12.2 12.0 12.3 12.6 13.0 12.9 13.2 13.6 14.1 13.7 14.0 14.5 15.0 14.5 14.9 15.3 15.8 15.3 15.7 16.2 16.7
HI PR 177 191 202 210 199 214 226 236 226 244 257 268 258 278 293 306 290 312 330 344 321 345 364 380
LO PR 58 62 68 72 62 65 72 76 64 68 74 79 67 72 78 83 70 75 82 87 73 78 85 90
MBh 28.6 29.5 31.9 34.3 28.0 28.8 31.2 33.5 27.3 28.1 30.4 32.7 26.6 27.4 29.7 31.9 25.3 26.1 28.2 30.3 23.4 24.1 26.1 28.0
S/T 0.76 0.68 0.52 0.33 0.79 0.71 0.53 0.34 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.88 0.78 0.59 0.38
DeltaT2018151020191511201915112019 15 11 20 19 15 11 19 17 14 10
75 1000 KW 2.55 2.61 2.69 2.78 2.75 2.81 2.90 3.00 2.93 2.99 3.09 3.19 3.08 3.15 3.25 3.36 3.21 3.28 3.39 3.51 3.32 3.40 3.51 3.63
AMPS 11.1 11.4 11.7 12.1 11.9 12.2 12.6 13.0 12.9 13.1 13.5 14.0 13.7 14.0 14.4 14.9 14.4 14.8 15.2 15.8 15.2 15.6 16.1 16.6
HI PR 176 190 200 209 198 213 225 234 225 242 256 267 256 276 291 304 288 310 327 342 318 343 362 377
LO PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 74 81 87 72 77 84 89
MBh 28.2 29.0 31.4 33.7 27.6 28.4 30.7 33.0 26.9 27.7 30.0 32.2 26.2 27.0 29.2 31.4 24.9 25.7 27.8 29.8 23.1 23.8 25.7 27.6
S/T 0.74 0.66 0.50 0.32 0.76 0.68 0.52 0.33 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.84 0.75 0.57 0.37
DeltaT212016112120161121201611222016112120161120181510
900 KW 2.52 2.57 2.65 2.74 2.71 2.77 2.86 2.95 2.88 2.95 3.04 3.15 3.04 3.10 3.21 3.31 3.16 3.24 3.34 3.46 3.28 3.35 3.46 3.58
AMPS 11.0 11.2 11.5 11.9 11.8 12.0 12.4 12.8 12.7 13.0 13.3 13.8 13.5 13.8 14.2 14.7 14.2 14.6 15.0 15.5 15.0 15.3 15.8 16.4
HI PR 173 186 197 205 194 209 221 230 221 238 251 262 252 271 286 298 283 305 322 336 313 337 356 371
LO PR 57 61 66 70 60 64 70 74 62 66 73 77 66 70 76 81 69 73 80 85 71 76 83 88
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

12
COOLING PERFORMANCE DATA
MODEL: PCA30C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 29.6 30.2 32.3 34.5 28.9 29.5 31.5 33.7 28.2 28.8 30.8 32.9 27.5 28.1 30.0 32.1 26.1 26.7 28.5 30.5 24.2 24.7 26.4 28.3
S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.94 0.77 0.57
DeltaT222118142221181522211815222118152221181420191714
1100 KW 2.59 2.64 2.73 2.82 2.79 2.85 2.94 3.04 2.97 3.03 3.13 3.24 3.12 3.19 3.30 3.41 3.26 3.33 3.44 3.56 3.37 3.45 3.56 3.69
AMPS 11.3 11.5 11.9 12.3 12.1 12.4 12.7 13.2 13.0 13.3 13.7 14.2 13.8 14.2 14.6 15.1 14.7 15.0 15.4 16.0 15.5 15.8 16.3 16.9
HI PR 179 193 204 212 201 216 229 238 229 246 260 271 261 280 296 309 293 315 333 347 324 348 368 384
LO PR 59 63 68 73 62 66 72 77 65 69 75 80 68 72 79 84 71 76 83 88 74 78 85 91
MBh 29.1 29.8 31.8 34.0 28.5 29.1 31.1 33.2 27.8 28.4 30.3 32.4 27.1 27.7 29.6 31.6 25.8 26.3 28.1 30.1 23.9 24.4 26.0 27.8
S/T 0.84 0.78 0.64 0.48 0.87 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.96 0.90 0.73 0.55
DeltaT222119152322191523221915232219 15 23 22 19 15 21 20 18 14
80 1000 KW 2.57 2.63 2.71 2.80 2.77 2.83 2.93 3.02 2.95 3.01 3.11 3.22 3.11 3.17 3.28 3.39 3.24 3.31 3.42 3.54 3.35 3.43 3.54 3.66
AMPS 11.2 11.5 11.8 12.2 12.0 12.3 12.7 13.1 13.0 13.2 13.6 14.1 13.8 14.1 14.5 15.0 14.6 14.9 15.4 15.9 15.4 15.7 16.2 16.8
HI PR 178 192 202 211 200 215 227 237 227 244 258 269 259 278 294 307 291 313 331 345 322 346 365 381
LO PR 58 62 68 72 62 66 72 76 64 68 75 79 67 72 78 83 71 75 82 87 73 78 85 90
MBh 28.7 29.3 31.3 33.5 28.0 28.7 30.6 32.7 27.4 28.0 29.9 31.9 26.7 27.3 29.2 31.2 25.4 25.9 27.7 29.6 23.5 24.0 25.7 27.4
S/T 0.81 0.76 0.62 0.46 0.84 0.78 0.64 0.48 0.86 0.80 0.65 0.49 0.88 0.83 0.68 0.50 0.92 0.86 0.70 0.52 0.93 0.87 0.71 0.53
DeltaT242320162423201624232016242320162423201622211915
900 KW 2.54 2.59 2.67 2.76 2.73 2.79 2.88 2.98 2.91 2.97 3.07 3.17 3.06 3.13 3.23 3.34 3.19 3.26 3.37 3.49 3.30 3.38 3.49 3.61
AMPS 11.1 11.3 11.6 12.0 11.9 12.1 12.5 12.9 12.8 13.1 13.5 13.9 13.6 13.9 14.3 14.8 14.4 14.7 15.1 15.7 15.1 15.5 16.0 16.5
HI PR 175 188 199 207 196 211 223 233 223 240 254 265 254 274 289 301 286 308 325 339 316 340 359 375
LO PR 57 61 67 71 61 65 71 75 63 67 73 78 66 71 77 82 69 74 81 86 72 76 83 89
MBh 30.1 30.7 32.1 34.3 29.4 30.0 31.4 33.5 28.7 29.3 30.6 32.7 28.0 28.5 29.9 31.9 26.6 27.1 28.4 30.3 24.6 25.1 26.3 28.1
S/T 0.92 0.88 0.80 0.65 0.95 0.92 0.83 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.74
DeltaT232321192323221923232219232322192223221921212017
1100 KW 2.61 2.66 2.75 2.84 2.81 2.87 2.97 3.06 2.99 3.06 3.16 3.26 3.15 3.22 3.33 3.44 3.28 3.36 3.47 3.59 3.40 3.48 3.59 3.72
AMPS 11.4 11.6 12.0 12.4 12.2 12.5 12.8 13.3 13.1 13.4 13.8 14.3 14.0 14.3 14.7 15.2 14.8 15.1 15.6 16.1 15.6 15.9 16.4 17.0
HI PR 181 195 206 215 203 219 231 241 231 249 263 274 263 283 299 312 296 319 336 351 327 352 372 388
LO PR 59 63 69 74 63 67 73 78 65 69 76 81 69 73 80 85 72 76 83 89 74 79 86 92
MBh 29.7 30.2 31.7 33.8 29.0 29.5 30.9 33.0 28.3 28.8 30.2 32.2 27.6 28.1 29.5 31.4 26.2 26.7 28.0 29.8 24.3 24.7 25.9 27.7
S/T 0.88 0.85 0.76 0.62 0.91 0.88 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.70 1.00 0.97 0.88 0.71
DeltaT242422192424221924242319242423202424221922222118
85 1000 KW 2.59 2.65 2.73 2.82 2.80 2.86 2.95 3.05 2.97 3.04 3.14 3.25 3.13 3.20 3.31 3.42 3.27 3.34 3.45 3.57 3.38 3.46 3.57 3.70
AMPS 11.3 11.6 11.9 12.3 12.1 12.4 12.8 13.2 13.1 13.4 13.8 14.2 13.9 14.2 14.6 15.1 14.7 15.0 15.5 16.0 15.5 15.8 16.3 16.9
HI PR 180 193 204 213 202 217 229 239 229 247 261 272 261 281 297 310 294 316 334 348 325 350 369 385
LO PR 59 63 69 73 62 66 72 77 65 69 75 80 68 72 79 84 71 76 83 88 74 79 86 91
MBh 29.2 29.8 31.2 33.3 28.5 29.1 30.5 32.5 27.9 28.4 29.7 31.7 27.2 27.7 29.0 30.9 25.8 26.3 27.6 29.4 23.9 24.4 25.5 27.2
S/T 0.85 0.82 0.74 0.60 0.88 0.85 0.76 0.62 0.90 0.87 0.78 0.63 0.93 0.89 0.81 0.66 0.96 0.93 0.84 0.68 0.97 0.94 0.85 0.69
DeltaT252523202625242126252421262524212525242024232219
900 KW 2.56 2.61 2.70 2.78 2.76 2.82 2.91 3.00 2.93 3.00 3.10 3.20 3.09 3.16 3.26 3.37 3.22 3.29 3.40 3.52 3.33 3.41 3.52 3.64
AMPS 11.2 11.4 11.7 12.1 12.0 12.2 12.6 13.0 12.9 13.2 13.6 14.0 13.7 14.0 14.4 14.9 14.5 14.8 15.3 15.8 15.3 15.6 16.1 16.7
HI PR 177 190 201 209 198 213 225 235 226 243 256 267 257 276 292 304 289 311 328 342 319 344 363 378
LO PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 75 81 87 73 77 84 90
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ARI Rating Conditions

COOLING PERFORMANCE DATA
13
MODEL: PCA36C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 34.6 35.9 39.3 - 33.8 35.0 38.4 - 33.0 34.2 37.5 - 32.2 33.4 36.5 - 30.6 31.7 34.7 - 28.3 29.4 32.2 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
1300 KW 3.17 3.23 3.33 - 3.41 3.48 3.59 - 3.62 3.70 3.82 - 3.81 3.89 4.02 - 3.96 4.05 4.18 - 4.10 4.19 4.33 -
AMPS 14.2 14.5 14.9 - 15.2 15.5 15.9 - 16.3 16.7 17.2 - 17.3 17.7 18.2 - 18.3 18.7 19.3 - 19.3 19.7 20.4 -
HI PR 174 187 197 - 195 210 222 - 222 239 252 - 253 272 287 - 284 306 323 - 314 338 357 -
LO PR 64 68 74 - 67 72 78 - 70 75 81 - 74 78 86 - 77 82 90 - 80 85 93 -
MBh 34.2 35.5 38.9 - 33.5 34.7 38.0 - 32.7 33.8 37.1 - 31.9 33.0 36.2 - 30.3 31.4 34.4 - 28.0 29.1 31.8 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -
Delta T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 1200 KW 3.16 3.23 3.33 - 3.40 3.47 3.58 - 3.61 3.69 3.81 - 3.80 3.88 4.01 - 3.95 4.04 4.17 - 4.09 4.18 4.32 -
AMPS 14.1 14.4 14.8 - 15.1 15.4 15.9 - 16.3 16.6 17.1 - 17.3 17.7 18.2 - 18.3 18.7 19.3 - 19.3 19.7 20.3 -
HI PR 173 186 197 - 194 209 221 - 221 238 251 - 252 271 286 - 283 305 322 - 313 337 356 -
LO PR 64 68 74 - 67 72 78 - 70 74 81 - 73 78 85 - 77 82 89 - 80 85 92 -
MBh 33.7 35.0 38.3 - 33.0 34.2 37.4 - 32.2 33.3 36.5 - 31.4 32.5 35.6 - 29.8 30.9 33.9 - 27.6 28.6 31.4 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.75 0.63 0.44 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
1100 KW 3.12 3.18 3.28 - 3.35 3.42 3.53 - 3.56 3.64 3.75 - 3.74 3.83 3.95 - 3.90 3.99 4.12 - 4.03 4.12 4.26 -
AMPS 13.9 14.2 14.6 - 14.9 15.2 15.7 - 16.1 16.4 16.9 - 17.0 17.4 17.9 - 18.0 18.4 19.0 - 19.0 19.4 20.0 -
HI PR 170 183 194 - 191 206 217 - 217 234 247 - 248 266 281 - 278 300 316 - 308 331 350 -
LO PR 63 67 73 - 66 70 77 - 69 73 80 - 72 77 84 - 76 80 88 - 78 83 91 -
MBh 35.2 36.2 39.2 42.1 34.4 35.4 38.3 41.1 33.5 34.5 37.4 40.1 32.7 33.7 36.5 39.1 31.1 32.0 34.6 37.2 28.8 29.6 32.1 34.4
S/T 0.79 0.71 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.59 0.38 0.90 0.80 0.61 0.39 0.91 0.81 0.61 0.39
DeltaT201815102018151020181510201815102018151018171410
1300 KW 3.19 3.26 3.36 3.47 3.43 3.51 3.62 3.74 3.65 3.73 3.85 3.97 3.84 3.92 4.05 4.18 4.00 4.09 4.22 4.36 4.14 4.23 4.37 4.52
AMPS 14.3 14.6 15.0 15.5 15.3 15.6 16.1 16.6 16.5 16.8 17.3 17.9 17.5 17.9 18.4 19.0 18.5 18.9 19.5 20.1 19.5 19.9 20.5 21.2
HI PR 176 189 199 208 197 212 224 233 224 241 255 266 255 275 290 302 287 309 326 340 317 341 360 376
LO PR 64 69 75 80 68 72 79 84 71 75 82 88 74 79 86 92 78 83 91 96 81 86 94 100
MBh 34.8 35.9 38.8 41.7 34.0 35.0 37.9 40.7 33.2 34.2 37.0 39.7 32.4 33.4 36.1 38.8 30.8 31.7 34.3 36.8 28.5 29.4 31.8 34.1
S/T 0.77 0.69 0.52 0.34 0.80 0.72 0.54 0.35 0.82 0.73 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.79 0.60 0.38 0.89 0.79 0.60 0.39
DeltaT2119161121191611211916112119 16 11 21 19 16 11 19 18 15 10
75 1200 KW 3.18 3.25 3.35 3.46 3.43 3.50 3.61 3.73 3.64 3.72 3.84 3.96 3.83 3.91 4.04 4.17 3.99 4.08 4.21 4.35 4.13 4.22 4.36 4.50
AMPS 14.2 14.5 15.0 15.4 15.2 15.6 16.0 16.6 16.4 16.8 17.3 17.9 17.4 17.8 18.3 19.0 18.4 18.8 19.4 20.1 19.4 19.9 20.5 21.2
HI PR 175 188 199 207 196 211 223 233 223 240 254 265 254 274 289 302 286 308 325 339 316 340 359 375
LO PR 64 68 75 80 68 72 79 84 71 75 82 87 74 79 86 92 78 83 90 96 80 86 93 99
MBh 34.3 35.3 38.2 41.0 33.5 34.5 37.3 40.1 32.7 33.7 36.5 39.1 31.9 32.9 35.6 38.2 30.3 31.2 33.8 36.3 28.1 28.9 31.3 33.6
S/T 0.75 0.67 0.50 0.32 0.77 0.69 0.52 0.34 0.79 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.86 0.77 0.58 0.37
DeltaT212016112220161122201611222016112220161120191510
1100 KW 3.14 3.21 3.31 3.41 3.38 3.45 3.56 3.68 3.59 3.67 3.78 3.91 3.77 3.86 3.98 4.11 3.93 4.02 4.15 4.29 4.07 4.16 4.30 4.44
AMPS 14.0 14.3 14.8 15.2 15.0 15.4 15.8 16.3 16.2 16.5 17.0 17.6 17.2 17.6 18.1 18.7 18.2 18.6 19.1 19.8 19.1 19.6 20.2 20.9
HI PR 172 185 196 204 193 208 219 229 220 236 249 260 250 269 284 296 281 303 320 333 311 334 353 368
LO PR 63 67 73 78 67 71 78 83 69 74 81 86 73 78 85 90 76 81 89 94 79 84 92 98
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

14
COOLING PERFORMANCE DATA
MODEL: PCA36C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 35.8 36.6 39.1 41.8 35.0 35.7 38.2 40.8 34.1 34.9 37.3 39.8 33.3 34.0 36.4 38.9 31.6 32.3 34.5 36.9 29.3 29.9 32.0 34.2
S/T 0.86 0.81 0.66 0.49 0.90 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 1.00 0.93 0.76 0.57
DeltaT222118152221181522211815222119152221181521201714
1300 KW 3.22 3.28 3.39 3.50 3.46 3.54 3.65 3.77 3.68 3.76 3.88 4.01 3.87 3.95 4.08 4.22 4.03 4.12 4.26 4.40 4.17 4.26 4.41 4.55
AMPS 14.4 14.7 15.1 15.6 15.4 15.7 16.2 16.7 16.6 17.0 17.5 18.1 17.6 18.0 18.5 19.2 18.6 19.1 19.6 20.3 19.6 20.1 20.7 21.4
HI PR 177 191 201 210 199 214 226 236 226 244 257 268 258 277 293 305 290 312 329 344 320 345 364 380
LO PR 65 69 76 81 69 73 80 85 72 76 83 88 75 80 87 93 79 84 91 97 81 87 95 101
MBh 35.4 36.2 38.7 41.4 34.6 35.4 37.8 40.4 33.8 34.5 36.9 39.4 33.0 33.7 36.0 38.5 31.3 32.0 34.2 36.6 29.0 29.7 31.7 33.9
S/T 0.85 0.80 0.65 0.48 0.88 0.82 0.67 0.50 0.90 0.85 0.69 0.51 0.93 0.87 0.71 0.53 0.97 0.91 0.74 0.55 0.97 0.91 0.74 0.56
DeltaT232219152322191623221916232320 16 23 22 19 15 22 21 18 14
80 1200 KW 3.21 3.28 3.38 3.49 3.45 3.53 3.64 3.76 3.67 3.75 3.87 4.00 3.86 3.94 4.07 4.21 4.02 4.11 4.25 4.39 4.16 4.25 4.39 4.54
AMPS 14.4 14.7 15.1 15.6 15.4 15.7 16.2 16.7 16.6 16.9 17.4 18.0 17.6 18.0 18.5 19.1 18.6 19.0 19.6 20.3 19.6 20.0 20.7 21.4
HI PR 177 190 201 210 198 213 225 235 226 243 256 267 257 277 292 305 289 311 329 343 319 344 363 379
LO PR 65 69 75 80 69 73 80 85 71 76 83 88 75 80 87 93 79 84 91 97 81 86 94 100
MBh 34.9 35.7 38.1 40.7 34.1 34.9 37.2 39.8 33.3 34.0 36.3 38.9 32.5 33.2 35.5 37.9 30.9 31.5 33.7 36.0 28.6 29.2 31.2 33.4
S/T 0.82 0.77 0.62 0.47 0.85 0.79 0.65 0.48 0.87 0.82 0.66 0.50 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.94 0.88 0.72 0.54
DeltaT242320162423201624232016242320162423201622211915
1100 KW 3.17 3.23 3.33 3.44 3.41 3.48 3.59 3.71 3.62 3.70 3.82 3.94 3.81 3.89 4.02 4.15 3.96 4.05 4.19 4.32 4.10 4.19 4.33 4.48
AMPS 14.2 14.5 14.9 15.4 15.2 15.5 15.9 16.5 16.3 16.7 17.2 17.8 17.3 17.7 18.2 18.9 18.3 18.7 19.3 20.0 19.3 19.7 20.4 21.1
HI PR 174 187 197 206 195 210 222 231 222 239 252 263 253 272 287 299 284 306 323 337 314 338 357 372
LO PR 64 68 74 79 67 72 78 83 70 75 81 87 74 78 86 91 77 82 90 95 80 85 93 99
MBh 36.4 37.1 38.9 41.5 35.6 36.3 38.0 40.5 34.7 35.4 37.1 39.6 33.9 34.5 36.2 38.6 32.2 32.8 34.4 36.7 29.8 30.4 31.8 34.0
S/T 0.91 0.87 0.79 0.64 0.94 0.91 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74
DeltaT232322192423221924232219242322192323221921212018
1300 KW 3.24 3.31 3.41 3.52 3.49 3.56 3.68 3.80 3.71 3.79 3.91 4.04 3.90 3.99 4.12 4.25 4.06 4.16 4.29 4.44 4.21 4.30 4.44 4.59
AMPS 14.5 14.8 15.2 15.7 15.5 15.9 16.3 16.9 16.7 17.1 17.6 18.2 17.8 18.2 18.7 19.3 18.8 19.2 19.8 20.5 19.8 20.3 20.9 21.6
HI PR 179 193 204 212 201 216 228 238 229 246 260 271 260 280 296 309 293 315 333 347 324 348 368 383
LO PR 66 70 76 81 70 74 81 86 72 77 84 89 76 81 88 94 80 85 92 98 82 88 96 102
MBh 36.1 36.8 38.5 41.1 35.2 35.9 37.6 40.1 34.4 35.1 36.7 39.2 33.6 34.2 35.8 38.2 31.9 32.5 34.0 36.3 29.5 30.1 31.5 33.6
S/T 0.89 0.86 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.67 0.98 0.94 0.85 0.69 1.00 0.98 0.88 0.72 1.00 0.98 0.89 0.72
DeltaT252423202524232025242320252523202424232023232119
85 1200 KW 3.24 3.30 3.41 3.51 3.48 3.56 3.67 3.79 3.70 3.78 3.90 4.03 3.89 3.98 4.11 4.24 4.05 4.14 4.28 4.42 4.20 4.29 4.43 4.58
AMPS 14.5 14.8 15.2 15.7 15.5 15.8 16.3 16.8 16.7 17.0 17.6 18.2 17.7 18.1 18.7 19.3 18.7 19.2 19.8 20.4 19.8 20.2 20.8 21.6
HI PR 179 192 203 212 200 216 228 237 228 245 259 270 260 279 295 308 292 314 332 346 323 347 367 382
LO PR 66 70 76 81 69 74 80 86 72 77 84 89 76 80 88 94 79 84 92 98 82 87 95 101
MBh 35.5 36.2 37.9 40.5 34.7 35.4 37.0 39.5 33.9 34.5 36.2 38.6 33.0 33.7 35.3 37.6 31.4 32.0 33.5 35.8 29.1 29.6 31.0 33.1
S/T 0.86 0.83 0.75 0.61 0.89 0.86 0.77 0.63 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.66 0.98 0.94 0.85 0.69 0.98 0.95 0.86 0.70
DeltaT252524202625242126252421262624212625242124242219
1100 KW 3.19 3.26 3.36 3.47 3.43 3.51 3.62 3.74 3.65 3.73 3.85 3.97 3.84 3.92 4.05 4.18 4.00 4.09 4.22 4.36 4.14 4.23 4.37 4.52
AMPS 14.3 14.6 15.0 15.5 15.3 15.6 16.1 16.6 16.5 16.8 17.3 17.9 17.5 17.9 18.4 19.0 18.5 18.9 19.5 20.1 19.5 19.9 20.5 21.2
HI PR 176 189 199 208 197 212 224 233 224 241 255 265 255 275 290 302 287 309 326 340 317 341 360 376
LO PR 64 69 75 80 68 72 79 84 71 75 82 88 74 79 86 92 78 83 91 96 81 86 94 100
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ARI Rating Conditions

COOLING PERFORMANCE DATA
15
MODEL: PCA42C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 38.9 40.3 44.2 - 38.0 39.4 43.2 - 37.1 38.5 42.1 - 36.2 37.5 41.1 - 34.4 35.6 39.1 - 31.9 33.0 36.2 -
S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.65 0.45 -
Delta T 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 15 13 10 -
1500 KW 3.53 3.61 3.72 - 3.80 3.88 4.00 - 4.04 4.12 4.26 - 4.25 4.34 4.48 - 4.42 4.52 4.67 - 4.58 4.68 4.83 -
AMPS 16.2 16.5 16.9 - 17.3 17.6 18.1 - 18.6 19.0 19.5 - 19.7 20.1 20.7 - 20.8 21.3 21.9 - 21.9 22.4 23.1 -
HI PR 179 192 203 - 200 216 228 - 228 245 259 - 259 279 295 - 292 314 332 - 323 347 367 -
LO PR 61 64 70 - 64 68 74 - 66 71 77 - 70 74 81 - 73 78 85 - 76 81 88 -
MBh 38.5 39.9 43.8 - 37.6 39.0 42.7 - 36.7 38.1 41.7 - 35.8 37.1 40.7 - 34.1 35.3 38.7 - 31.5 32.7 35.8 -
S/T 0.66 0.55 0.38 - 0.69 0.57 0.40 - 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.76 0.63 0.44 -
Delta T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
70 1400 KW 3.53 3.60 3.71 - 3.79 3.87 4.00 - 4.03 4.11 4.25 - 4.24 4.33 4.47 - 4.41 4.51 4.66 - 4.56 4.66 4.82 -
AMPS 16.1 16.4 16.9 - 17.2 17.6 18.1 - 18.5 18.9 19.5 - 19.6 20.1 20.7 - 20.8 21.2 21.8 - 21.9 22.3 23.0 -
HI PR 178 192 202 - 200 215 227 - 227 244 258 - 259 278 294 - 291 313 331 - 322 346 365 -
LO PR 60 64 70 - 64 68 74 - 66 71 77 - 70 74 81 - 73 78 85 - 75 80 88 -
MBh 38.0 39.3 43.1 - 37.1 38.4 42.1 - 36.2 37.5 41.1 - 35.3 36.6 40.1 - 33.5 34.8 38.1 - 31.1 32.2 35.3 -
S/T 0.64 0.53 0.37 - 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.73 0.61 0.42 - 0.73 0.61 0.42 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 11 -
1300 KW 3.48 3.55 3.66 - 3.74 3.82 3.94 - 3.97 4.06 4.19 - 4.18 4.27 4.40 - 4.35 4.45 4.59 - 4.50 4.60 4.75 -
AMPS 15.9 16.2 16.7 - 17.0 17.4 17.8 - 18.3 18.7 19.2 - 19.4 19.8 20.4 - 20.5 20.9 21.5 - 21.5 22.0 22.7 -
HI PR 175 188 199 - 196 211 223 - 223 240 254 - 254 274 289 - 286 308 325 - 316 340 359 -
LO PR 59 63 69 - 63 67 73 - 65 69 76 - 68 73 79 - 72 76 83 - 74 79 86 -
MBh 39.6 40.7 44.1 47.3 38.7 39.8 43.1 46.2 37.7 38.9 42.1 45.1 36.8 37.9 41.0 44.0 35.0 36.0 39.0 41.8 32.4 33.4 36.1 38.7
S/T 0.77 0.69 0.52 0.33 0.79 0.71 0.54 0.35 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.79 0.60 0.38
DeltaT1917141019171410191714101917141019171410171613 9
1500 KW 3.56 3.64 3.75 3.87 3.83 3.91 4.04 4.17 4.07 4.16 4.29 4.43 4.28 4.37 4.52 4.67 4.46 4.56 4.71 4.86 4.61 4.72 4.87 5.04
AMPS 16.3 16.6 17.1 17.6 17.4 17.8 18.3 18.9 18.7 19.1 19.7 20.3 19.8 20.3 20.9 21.6 21.0 21.4 22.1 22.8 22.1 22.6 23.3 24.1
HI PR 180 194 205 214 202 218 230 240 230 248 262 273 262 282 298 311 295 317 335 350 326 351 370 386
LO PR 61 65 71 76 65 69 75 80 67 71 78 83 71 75 82 87 74 79 86 91 76 81 89 95
MBh 39.2 40.3 43.7 46.9 38.3 39.4 42.7 45.8 37.4 38.5 41.6 44.7 36.5 37.5 40.6 43.6 34.6 35.7 38.6 41.4 32.1 33.0 35.7 38.4
S/T 0.75 0.67 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.86 0.77 0.58 0.38
DeltaT1918151020181510201815102018 15 10 19 18 15 10 18 17 14 9
75 1400 KW 3.55 3.63 3.74 3.86 3.82 3.90 4.03 4.16 4.06 4.15 4.28 4.42 4.27 4.36 4.51 4.65 4.45 4.55 4.70 4.85 4.60 4.70 4.86 5.02
AMPS 16.2 16.6 17.0 17.6 17.4 17.7 18.2 18.8 18.7 19.1 19.6 20.3 19.8 20.2 20.8 21.5 20.9 21.4 22.0 22.8 22.0 22.5 23.2 24.0
HI PR 180 194 204 213 202 217 229 239 229 247 261 272 261 281 297 310 294 316 334 348 325 350 369 385
LO PR 61 65 71 75 64 69 75 80 67 71 78 83 70 75 82 87 74 78 86 91 76 81 89 94
MBh 38.6 39.7 43.0 46.2 37.7 38.8 42.0 45.1 36.8 37.9 41.0 44.0 35.9 37.0 40.0 42.9 34.1 35.1 38.0 40.8 31.6 32.5 35.2 37.8
S/T 0.72 0.65 0.49 0.32 0.75 0.67 0.51 0.33 0.77 0.69 0.52 0.34 0.79 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.83 0.74 0.56 0.36
DeltaT201815102018151020181510201915112018151019171410
1300 KW 3.51 3.58 3.69 3.81 3.77 3.85 3.97 4.10 4.01 4.09 4.22 4.36 4.21 4.30 4.44 4.59 4.39 4.48 4.63 4.78 4.54 4.64 4.79 4.95
AMPS 16.0 16.4 16.8 17.4 17.1 17.5 18.0 18.6 18.4 18.8 19.4 20.0 19.5 19.9 20.5 21.2 20.6 21.1 21.7 22.5 21.7 22.2 22.9 23.7
HI PR 177 190 201 209 198 213 225 235 226 243 256 267 257 276 292 305 289 311 328 343 319 344 363 378
LO PR 60 64 70 74 63 67 74 78 66 70 76 81 69 74 80 86 72 77 84 90 75 80 87 93
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

16
COOLING PERFORMANCE DATA
MODEL: PCA42C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 40.3 41.2 44.0 47.0 39.3 40.2 43.0 45.9 38.4 39.2 41.9 44.8 37.5 38.3 40.9 43.7 35.6 36.4 38.9 41.5 33.0 33.7 36.0 38.5
S/T 0.84 0.79 0.64 0.48 0.87 0.82 0.66 0.50 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.53 0.96 0.90 0.73 0.55 0.96 0.90 0.74 0.55
DeltaT212017142120181421201814212018142120171419191613
1500 KW 3.59 3.67 3.78 3.90 3.86 3.95 4.07 4.20 4.10 4.19 4.33 4.47 4.32 4.41 4.55 4.71 4.50 4.60 4.75 4.91 4.65 4.76 4.91 5.08
AMPS 16.4 16.7 17.2 17.8 17.5 17.9 18.4 19.0 18.9 19.3 19.8 20.5 20.0 20.4 21.1 21.8 21.2 21.6 22.3 23.0 22.3 22.8 23.5 24.3
HI PR 182 196 207 216 204 220 232 242 232 250 264 276 265 285 301 314 298 321 339 353 329 354 374 390
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 79 87 92 77 82 90 96
MBh 39.9 40.8 43.5 46.5 39.0 39.8 42.5 45.5 38.0 38.9 41.5 44.4 37.1 37.9 40.5 43.3 35.2 36.0 38.5 41.1 32.6 33.4 35.6 38.1
S/T 0.82 0.77 0.63 0.47 0.85 0.80 0.65 0.49 0.88 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.95 0.89 0.72 0.54
DeltaT222118142221181522211815222118 15 22 21 18 14 20 19 17 14
80 1400 KW 3.58 3.66 3.77 3.89 3.85 3.94 4.06 4.19 4.09 4.18 4.32 4.46 4.31 4.40 4.54 4.69 4.49 4.58 4.74 4.89 4.64 4.74 4.90 5.07
AMPS 16.4 16.7 17.2 17.7 17.5 17.9 18.4 19.0 18.8 19.2 19.8 20.4 20.0 20.4 21.0 21.7 21.1 21.6 22.2 23.0 22.2 22.7 23.4 24.2
HI PR 182 195 206 215 204 219 232 242 232 249 263 275 264 284 300 313 297 320 338 352 328 353 373 389
LO PR 62 66 72 76 65 69 76 80 68 72 79 84 71 76 83 88 74 79 86 92 77 82 89 95
MBh 39.3 40.1 42.9 45.8 38.4 39.2 41.9 44.8 37.5 38.3 40.9 43.7 36.5 37.3 39.9 42.6 34.7 35.5 37.9 40.5 32.2 32.9 35.1 37.5
S/T 0.79 0.75 0.61 0.45 0.82 0.77 0.63 0.47 0.84 0.79 0.64 0.48 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.91 0.86 0.70 0.52
DeltaT222118152221191522211915232219152221191521201714
1300 KW 3.53 3.61 3.72 3.84 3.80 3.88 4.01 4.13 4.04 4.12 4.26 4.40 4.25 4.34 4.48 4.63 4.42 4.52 4.67 4.82 4.58 4.68 4.83 4.99
AMPS 16.2 16.5 16.9 17.5 17.3 17.6 18.1 18.7 18.6 19.0 19.5 20.2 19.7 20.1 20.7 21.4 20.8 21.3 21.9 22.6 21.9 22.4 23.1 23.9
HI PR 179 192 203 212 200 216 228 237 228 245 259 270 260 279 295 308 292 314 332 346 323 347 367 382
LO PR 61 64 70 75 64 68 74 79 66 71 77 82 70 74 81 86 73 78 85 91 76 81 88 94
MBh 41.0 41.8 43.8 46.7 40.0 40.8 42.7 45.6 39.1 39.8 41.7 44.5 38.1 38.9 40.7 43.4 36.2 36.9 38.7 41.3 33.5 34.2 35.8 38.2
S/T 0.88 0.85 0.77 0.62 0.91 0.88 0.80 0.65 0.94 0.90 0.82 0.66 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 0.98 0.88 0.71
DeltaT222221182222211822222118232221182222211821201917
1500 KW 3.62 3.69 3.81 3.93 3.89 3.98 4.10 4.24 4.14 4.23 4.36 4.51 4.35 4.45 4.59 4.74 4.53 4.63 4.79 4.95 4.69 4.80 4.95 5.12
AMPS 16.5 16.9 17.4 17.9 17.7 18.1 18.6 19.2 19.0 19.4 20.0 20.7 20.2 20.6 21.2 21.9 21.3 21.8 22.5 23.2 22.5 23.0 23.7 24.5
HI PR 184 198 209 218 206 222 235 245 235 253 267 278 267 288 304 317 301 324 342 357 332 358 378 394
LO PR 62 66 72 77 66 70 77 82 69 73 80 85 72 77 84 89 75 80 88 93 78 83 91 96
MBh 40.6 41.4 43.3 46.2 39.6 40.4 42.3 45.1 38.7 39.4 41.3 44.1 37.7 38.5 40.3 43.0 35.9 36.6 38.3 40.8 33.2 33.9 35.5 37.8
S/T 0.86 0.83 0.75 0.61 0.90 0.86 0.78 0.63 0.92 0.89 0.80 0.65 0.95 0.91 0.83 0.67 0.98 0.95 0.86 0.69 0.99 0.96 0.86 0.70
DeltaT232321192323221923232219232322192323221922212017
85 1400 KW 3.61 3.69 3.80 3.92 3.88 3.97 4.09 4.23 4.13 4.22 4.35 4.50 4.34 4.44 4.58 4.73 4.52 4.62 4.77 4.93 4.68 4.78 4.94 5.11
AMPS 16.5 16.8 17.3 17.9 17.6 18.0 18.5 19.1 19.0 19.4 19.9 20.6 20.1 20.6 21.2 21.9 21.3 21.7 22.4 23.2 22.4 22.9 23.6 24.4
HI PR 183 197 208 217 206 222 234 244 234 252 266 277 267 287 303 316 300 323 341 356 331 357 377 393
LO PR 62 66 72 77 66 70 76 81 68 73 79 84 72 76 83 89 75 80 87 93 78 83 90 96
MBh 40.0 40.7 42.7 45.5 39.0 39.8 41.7 44.5 38.1 38.8 40.7 43.4 37.2 37.9 39.7 42.3 35.3 36.0 37.7 40.2 32.7 33.4 34.9 37.3
S/T 0.83 0.80 0.73 0.59 0.86 0.83 0.75 0.61 0.89 0.85 0.77 0.63 0.91 0.88 0.80 0.65 0.95 0.92 0.83 0.67 0.96 0.92 0.83 0.68
DeltaT242322192423221924232219242422192423221922222118
1300 KW 3.56 3.64 3.75 3.87 3.83 3.91 4.04 4.17 4.07 4.16 4.29 4.43 4.28 4.37 4.52 4.67 4.46 4.56 4.71 4.86 4.61 4.72 4.87 5.03
AMPS 16.3 16.6 17.1 17.6 17.4 17.8 18.3 18.9 18.7 19.1 19.7 20.3 19.8 20.3 20.9 21.6 21.0 21.4 22.1 22.8 22.1 22.6 23.3 24.1
HI PR 180 194 205 214 202 218 230 240 230 248 262 273 262 282 298 311 295 317 335 349 326 351 370 386
LO PR 61 65 71 76 65 69 75 80 67 71 78 83 71 75 82 87 74 79 86 91 76 81 89 95
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ARI Rating Conditions

COOLING PERFORMANCE DATA
17
MODEL: PCA48C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 45.2 46.8 51.3 - 44.1 45.7 50.1 - 43.1 44.6 48.9 - 42.0 43.5 47.7 - 39.9 41.4 45.3 - 37.0 38.3 42.0 -
S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.65 0.45 -
Delta T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
1600 KW 4.15 4.23 4.36 - 4.45 4.54 4.68 - 4.72 4.82 4.97 - 4.96 5.06 5.22 - 5.16 5.27 5.44 - 5.33 5.45 5.62 -
AMPS 19.3 19.7 20.2 - 20.6 21.0 21.6 - 22.1 22.6 23.3 - 23.5 24.0 24.7 - 24.8 25.3 26.1 - 26.1 26.6 27.4 -
HI PR 177 191 202 - 199 214 226 - 226 244 257 - 258 277 293 - 290 312 330 - 320 345 364 -
LO PR 59 62 68 - 62 66 72 - 64 68 75 - 68 72 78 - 71 75 82 - 73 78 85 -
MBh 44.7 46.3 50.8 - 43.7 45.3 49.6 - 42.6 44.2 48.4 - 41.6 43.1 47.2 - 39.5 41.0 44.9 - 36.6 37.9 41.6 -
S/T 0.66 0.55 0.38 - 0.69 0.57 0.40 - 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.76 0.63 0.44 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 1500 KW 4.14 4.22 4.35 - 4.44 4.53 4.67 - 4.71 4.81 4.96 - 4.94 5.05 5.21 - 5.15 5.26 5.42 - 5.32 5.43 5.61 -
AMPS 19.3 19.7 20.2 - 20.6 21.0 21.6 - 22.1 22.6 23.2 - 23.4 23.9 24.6 - 24.7 25.2 26.0 - 26.0 26.6 27.4 -
HI PR 177 190 201 - 198 214 225 - 226 243 256 - 257 277 292 - 289 311 329 - 319 344 363 -
LO PR 58 62 68 - 62 66 72 - 64 68 74 - 67 72 78 - 71 75 82 - 73 78 85 -
MBh 44.0 45.7 50.0 - 43.0 44.6 48.9 - 42.0 43.5 47.7 - 41.0 42.5 46.5 - 38.9 40.3 44.2 - 36.1 37.4 40.9 -
S/T 0.64 0.53 0.37 - 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.73 0.61 0.42 - 0.73 0.61 0.42 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
1400 KW 4.09 4.17 4.29 - 4.38 4.47 4.61 - 4.65 4.74 4.89 - 4.88 4.98 5.14 - 5.08 5.18 5.35 - 5.25 5.36 5.53 -
AMPS 19.0 19.4 19.9 - 20.3 20.7 21.3 - 21.8 22.3 22.9 - 23.1 23.6 24.3 - 24.4 24.9 25.6 - 25.6 26.2 27.0 -
HI PR 174 187 198 - 195 210 222 - 222 239 252 - 253 272 287 - 284 306 323 - 314 338 357 -
LO PR 57 61 67 - 61 65 70 - 63 67 73 - 66 70 77 - 69 74 81 - 72 76 83 -
MBh 45.9 47.3 51.2 54.9 44.9 46.2 50.0 53.7 43.8 45.1 48.8 52.4 42.7 44.0 47.6 51.1 40.6 41.8 45.2 48.5 37.6 38.7 41.9 45.0
S/T 0.77 0.69 0.52 0.33 0.79 0.71 0.54 0.35 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.79 0.60 0.38
DeltaT201915112019151120191511211916112019151119181410
1600 KW 4.18 4.26 4.39 4.53 4.49 4.58 4.72 4.87 4.76 4.86 5.01 5.17 5.00 5.10 5.26 5.44 5.20 5.31 5.48 5.66 5.38 5.49 5.67 5.86
AMPS 19.5 19.9 20.4 21.0 20.8 21.2 21.8 22.5 22.3 22.8 23.4 24.2 23.6 24.2 24.9 25.7 25.0 25.5 26.3 27.2 26.3 26.9 27.7 28.6
HI PR 179 193 204 212 201 216 228 238 229 246 260 271 260 280 296 309 293 315 333 347 324 348 368 384
LO PR 59 63 69 73 62 66 73 77 65 69 75 80 68 73 79 84 71 76 83 88 74 79 86 91
MBh 45.5 46.8 50.7 54.4 44.4 45.7 49.5 53.1 43.4 44.6 48.3 51.9 42.3 43.6 47.1 50.6 40.2 41.4 44.8 48.1 37.2 38.3 41.5 44.5
S/T 0.75 0.67 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.86 0.77 0.58 0.38
DeltaT2119161121201611212016112120 16 11 21 19 16 11 20 18 15 10
75 1500 KW 4.17 4.25 4.38 4.52 4.48 4.57 4.71 4.86 4.75 4.85 5.00 5.16 4.98 5.09 5.25 5.42 5.19 5.30 5.47 5.65 5.36 5.48 5.66 5.84
AMPS 19.4 19.8 20.4 21.0 20.7 21.2 21.8 22.5 22.3 22.7 23.4 24.2 23.6 24.1 24.8 25.6 24.9 25.5 26.2 27.1 26.2 26.8 27.6 28.5
HI PR 179 192 203 212 200 216 228 238 228 245 259 270 260 279 295 308 292 314 332 346 323 347 367 382
LO PR 59 63 68 73 62 66 72 77 65 69 75 80 68 72 79 84 71 76 83 88 74 78 86 91
MBh 44.8 46.1 49.9 53.6 43.7 45.0 48.8 52.3 42.7 44.0 47.6 51.1 41.7 42.9 46.4 49.8 39.6 40.8 44.1 47.3 36.7 37.8 40.9 43.9
S/T 0.72 0.65 0.49 0.32 0.75 0.67 0.51 0.33 0.77 0.69 0.52 0.34 0.79 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.83 0.74 0.56 0.36
DeltaT212016112220161122201611222016112120161120181510
1400 KW 4.12 4.20 4.33 4.46 4.42 4.51 4.65 4.79 4.68 4.78 4.93 5.09 4.92 5.02 5.18 5.35 5.12 5.23 5.39 5.57 5.29 5.40 5.58 5.76
AMPS 19.2 19.6 20.1 20.7 20.5 20.9 21.5 22.2 22.0 22.4 23.1 23.8 23.3 23.8 24.5 25.3 24.6 25.1 25.8 26.7 25.9 26.4 27.2 28.1
HI PR 176 189 200 208 197 212 224 234 224 241 255 266 255 275 290 302 287 309 326 340 317 341 360 376
LO PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 75 81 87 72 77 84 90
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

18
COOLING PERFORMANCE DATA
MODEL: PCA48C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 46.7 47.8 51.0 54.6 45.7 46.7 49.8 53.3 44.6 45.5 48.7 52.0 43.5 44.4 47.5 50.7 41.3 42.2 45.1 48.2 38.3 39.1 41.8 44.7
S/T 0.84 0.79 0.64 0.48 0.87 0.82 0.66 0.50 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.53 0.96 0.90 0.73 0.55 0.96 0.90 0.74 0.55
DeltaT232219152322191523221915232219152322191521201814
1600 KW 4.21 4.30 4.43 4.56 4.52 4.62 4.76 4.91 4.80 4.90 5.05 5.21 5.04 5.14 5.31 5.48 5.24 5.36 5.53 5.71 5.42 5.54 5.72 5.90
AMPS 19.6 20.0 20.6 21.2 20.9 21.4 22.0 22.7 22.5 23.0 23.6 24.4 23.8 24.3 25.1 25.9 25.2 25.7 26.5 27.4 26.5 27.1 27.9 28.8
HI PR 181 195 206 214 203 219 231 241 231 249 262 274 263 283 299 312 296 318 336 351 327 352 372 388
LO PR 60 64 69 74 63 67 73 78 66 70 76 81 69 73 80 85 72 77 84 89 75 79 87 92
MBh 46.3 47.3 50.5 54.0 45.2 46.2 49.4 52.8 44.1 45.1 48.2 51.5 43.1 44.0 47.0 50.2 40.9 41.8 44.7 47.7 37.9 38.7 41.4 44.2
S/T 0.82 0.77 0.63 0.47 0.85 0.80 0.65 0.49 0.88 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.95 0.89 0.72 0.54
DeltaT232219162423201624232016242320 16 24 23 20 16 22 21 18 15
80 1500 KW 4.20 4.29 4.42 4.55 4.51 4.60 4.75 4.90 4.78 4.88 5.04 5.20 5.03 5.13 5.30 5.47 5.23 5.34 5.51 5.69 5.41 5.52 5.70 5.89
AMPS 19.6 20.0 20.5 21.2 20.9 21.3 21.9 22.6 22.4 22.9 23.6 24.4 23.8 24.3 25.0 25.8 25.1 25.7 26.4 27.3 26.4 27.0 27.8 28.8
HI PR 180 194 205 214 202 218 230 240 230 248 262 273 262 282 298 311 295 317 335 350 326 351 370 386
LO PR 60 63 69 74 63 67 73 78 65 70 76 81 69 73 80 85 72 77 84 89 74 79 87 92
MBh 45.6 46.6 49.8 53.2 44.5 45.5 48.6 52.0 43.5 44.4 47.5 50.7 42.4 43.3 46.3 49.5 40.3 41.2 44.0 47.0 37.3 38.1 40.7 43.6
S/T 0.79 0.75 0.61 0.45 0.82 0.77 0.63 0.47 0.84 0.79 0.64 0.48 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.91 0.86 0.70 0.52
DeltaT242320162423201624232016242320162423201622211915
1400 KW 4.15 4.23 4.36 4.49 4.45 4.54 4.68 4.83 4.72 4.82 4.97 5.13 4.96 5.06 5.22 5.39 5.16 5.27 5.44 5.61 5.33 5.45 5.62 5.81
AMPS 19.3 19.7 20.2 20.9 20.6 21.0 21.6 22.3 22.1 22.6 23.3 24.0 23.5 24.0 24.7 25.5 24.8 25.3 26.1 26.9 26.1 26.6 27.4 28.4
HI PR 177 191 202 210 199 214 226 236 226 244 257 268 258 277 293 306 290 312 330 344 320 345 364 380
LO PR 59 62 68 72 62 66 72 77 64 68 75 80 68 72 78 84 71 75 82 88 73 78 85 91
MBh 47.6 48.5 50.8 54.2 46.5 47.4 49.6 52.9 45.3 46.2 48.4 51.6 44.2 45.1 47.2 50.4 42.0 42.8 44.9 47.9 38.9 39.7 41.6 44.3
S/T 0.88 0.85 0.77 0.62 0.91 0.88 0.80 0.65 0.94 0.90 0.82 0.66 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 0.98 0.88 0.71
DeltaT242422192424232024242320252423202424231922222118
1600 KW 4.24 4.33 4.46 4.60 4.56 4.65 4.80 4.95 4.83 4.94 5.09 5.25 5.08 5.19 5.35 5.52 5.28 5.40 5.57 5.75 5.46 5.58 5.76 5.95
AMPS 19.8 20.2 20.7 21.4 21.1 21.5 22.2 22.9 22.7 23.2 23.8 24.6 24.0 24.5 25.3 26.1 25.4 25.9 26.7 27.6 26.7 27.3 28.1 29.1
HI PR 183 197 208 217 205 221 233 243 233 251 265 276 266 286 302 315 299 322 340 354 330 355 375 391
LO PR 60 64 70 75 64 68 74 79 66 70 77 82 70 74 81 86 73 78 85 90 75 80 88 93
MBh 47.1 48.0 50.3 53.6 46.0 46.9 49.1 52.4 44.9 45.8 47.9 51.1 43.8 44.7 46.8 49.9 41.6 42.4 44.4 47.4 38.5 39.3 41.2 43.9
S/T 0.86 0.83 0.75 0.61 0.90 0.86 0.78 0.63 0.92 0.89 0.80 0.65 0.95 0.91 0.83 0.67 0.98 0.95 0.86 0.69 0.99 0.96 0.86 0.70
DeltaT252523202525232025252320252524202525232023232219
85 1500 KW 4.23 4.32 4.45 4.59 4.55 4.64 4.78 4.93 4.82 4.92 5.08 5.24 5.07 5.17 5.34 5.51 5.27 5.39 5.56 5.74 5.45 5.57 5.75 5.94
AMPS 19.7 20.1 20.7 21.3 21.1 21.5 22.1 22.8 22.6 23.1 23.8 24.5 24.0 24.5 25.2 26.0 25.3 25.9 26.6 27.5 26.7 27.2 28.1 29.0
HI PR 182 196 207 216 204 220 232 242 233 250 264 276 265 285 301 314 298 321 339 353 329 354 374 390
LO PR 60 64 70 74 64 68 74 79 66 70 77 82 69 74 81 86 73 77 84 90 75 80 87 93
MBh 46.4 47.3 49.5 52.8 45.3 46.2 48.4 51.6 44.2 45.1 47.2 50.4 43.1 44.0 46.1 49.1 41.0 41.8 43.8 46.7 38.0 38.7 40.5 43.2
S/T 0.83 0.80 0.73 0.59 0.86 0.83 0.75 0.61 0.89 0.85 0.77 0.63 0.91 0.88 0.80 0.65 0.95 0.92 0.83 0.67 0.96 0.92 0.83 0.68
DeltaT252524202625242126252421262524212625242124232219
1400 KW 4.18 4.26 4.39 4.53 4.49 4.58 4.72 4.87 4.76 4.86 5.01 5.17 5.00 5.10 5.26 5.43 5.20 5.31 5.48 5.66 5.37 5.49 5.67 5.85
AMPS 19.5 19.9 20.4 21.0 20.8 21.2 21.8 22.5 22.3 22.8 23.4 24.2 23.6 24.1 24.9 25.7 25.0 25.5 26.3 27.1 26.3 26.9 27.7 28.6
HI PR 179 193 204 212 201 216 228 238 229 246 260 271 260 280 296 309 293 315 333 347 324 348 368 384
LO PR 59 63 69 73 62 66 73 77 65 69 75 80 68 73 79 84 71 76 83 88 74 79 86 91
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ARI Rating Conditions

COOLING PERFORMANCE DATA
19
MODEL: PCA60C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 55.7 57.8 63.3 - 54.4 56.4 61.8 - 53.1 55.1 60.3 - 51.8 53.7 58.9 - 49.3 51.0 55.9 - 45.6 47.3 51.8 -
S/T 0.65 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.75 0.63 0.43 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
1850 KW 5.22 5.33 5.49 - 5.61 5.72 5.90 - 5.95 6.08 6.27 - 6.25 6.39 6.59 - 6.51 6.65 6.87 - 6.73 6.88 7.10 -
AMPS 24.9 25.5 26.2 - 26.7 27.2 28.0 - 28.7 29.3 30.2 - 30.4 31.1 32.0 - 32.2 32.9 33.9 - 33.9 34.7 35.7 -
HI PR 171 184 194 - 192 206 218 - 218 235 248 - 248 267 282 - 279 301 317 - 309 332 351 -
LO PR 56 59 65 - 59 62 68 - 61 65 71 - 64 68 74 - 67 71 78 - 69 74 81 -
MBh 55.2 57.2 62.7 - 53.9 55.9 61.2 - 52.6 54.5 59.7 - 51.3 53.2 58.3 - 48.8 50.5 55.4 - 45.2 46.8 51.3 -
S/T 0.64 0.54 0.37 - 0.67 0.56 0.38 - 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.74 0.62 0.43 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
70 1750 KW 5.21 5.31 5.48 - 5.59 5.71 5.89 - 5.94 6.06 6.25 - 6.24 6.37 6.58 - 6.49 6.64 6.85 - 6.72 6.86 7.09 -
AMPS 24.9 25.4 26.1 - 26.6 27.2 28.0 - 28.6 29.2 30.1 - 30.4 31.0 32.0 - 32.1 32.8 33.8 - 33.8 34.6 35.6 -
HI PR 170 183 194 - 191 206 217 - 217 234 247 - 248 266 281 - 278 300 316 - 308 331 350 -
LO PR 55 59 64 - 59 62 68 - 61 65 71 - 64 68 74 - 67 71 78 - 69 74 80 -
MBh 54.4 56.3 61.7 - 53.1 55.0 60.3 - 51.8 53.7 58.9 - 50.6 52.4 57.4 - 48.0 49.8 54.5 - 44.5 46.1 50.5 -
S/T 0.62 0.52 0.36 - 0.64 0.54 0.37 - 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.71 0.59 0.41 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 17 13 - 19 16 12 - 18 15 12 -
1650 KW 5.14 5.24 5.40 - 5.52 5.63 5.81 - 5.86 5.98 6.17 - 6.15 6.28 6.49 - 6.40 6.54 6.75 - 6.62 6.77 6.99 -
AMPS 24.5 25.1 25.8 - 26.3 26.8 27.6 - 28.2 28.8 29.7 - 29.9 30.6 31.5 - 31.7 32.4 33.3 - 33.3 34.1 35.1 -
HI PR 167 180 190 - 188 202 213 - 214 230 243 - 243 262 276 - 274 295 311 - 302 325 344 -
LO PR 54 58 63 - 58 61 67 - 60 64 69 - 63 67 73 - 66 70 76 - 68 72 79 -
MBh 56.7 58.4 63.2 67.8 55.4 57.0 61.7 66.2 54.0 55.6 60.2 64.6 52.7 54.3 58.8 63.1 50.1 51.6 55.8 59.9 46.4 47.8 51.7 55.5
S/T 0.74 0.67 0.50 0.32 0.77 0.69 0.52 0.34 0.79 0.71 0.54 0.34 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.85 0.76 0.58 0.37
DeltaT211916112120161121201611212016112119161120181510
1850 KW 5.26 5.37 5.53 5.71 5.65 5.77 5.95 6.14 6.00 6.13 6.32 6.53 6.30 6.44 6.65 6.87 6.56 6.71 6.92 7.15 6.79 6.94 7.16 7.40
AMPS 25.1 25.7 26.4 27.2 26.9 27.5 28.3 29.2 28.9 29.6 30.4 31.5 30.7 31.4 32.3 33.4 32.5 33.2 34.2 35.4 34.2 35.0 36.0 37.3
HI PR 173 186 196 204 194 208 220 229 220 237 250 261 251 270 285 297 282 304 321 334 312 335 354 369
LO PR 56 60 65 69 59 63 69 73 62 66 72 76 65 69 75 80 68 72 79 84 70 75 81 87
MBh 56.1 57.8 62.5 67.1 54.8 56.4 61.1 65.6 53.5 55.1 59.6 64.0 52.2 53.7 58.2 62.4 49.6 51.1 55.3 59.3 45.9 47.3 51.2 54.9
S/T 0.73 0.65 0.49 0.32 0.76 0.68 0.51 0.33 0.78 0.69 0.52 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.84 0.75 0.57 0.36
DeltaT2220161122201611222016112220 17 11 22 20 16 11 20 19 15 11
75 1750 KW 5.25 5.36 5.52 5.69 5.64 5.76 5.94 6.13 5.98 6.11 6.31 6.51 6.29 6.43 6.63 6.85 6.55 6.69 6.91 7.14 6.77 6.92 7.15 7.38
AMPS 25.1 25.6 26.3 27.2 26.8 27.4 28.2 29.1 28.9 29.5 30.4 31.4 30.6 31.3 32.2 33.3 32.4 33.1 34.1 35.3 34.1 34.9 35.9 37.2
HI PR 172 185 195 204 193 208 219 229 220 236 249 260 250 269 284 296 281 303 320 333 311 334 353 368
LO PR 56 60 65 69 59 63 69 73 61 65 71 76 65 69 75 80 68 72 79 84 70 74 81 87
MBh 55.3 56.9 61.6 66.1 54.0 55.6 60.2 64.6 52.7 54.3 58.7 63.0 51.4 52.9 57.3 61.5 48.8 50.3 54.4 58.4 45.2 46.6 50.4 54.1
S/T 0.70 0.63 0.48 0.31 0.73 0.65 0.49 0.32 0.75 0.67 0.51 0.33 0.77 0.69 0.52 0.34 0.80 0.72 0.54 0.35 0.81 0.72 0.55 0.35
DeltaT222016112220171122201711222017122220161120191511
1650 KW 5.18 5.28 5.45 5.62 5.56 5.68 5.86 6.04 5.90 6.03 6.22 6.42 6.20 6.34 6.54 6.75 6.46 6.60 6.81 7.04 6.68 6.82 7.05 7.28
AMPS 24.7 25.3 26.0 26.8 26.5 27.0 27.8 28.7 28.5 29.1 29.9 30.9 30.2 30.9 31.8 32.9 31.9 32.6 33.6 34.8 33.6 34.4 35.4 36.7
HI PR 169 182 192 200 190 204 216 225 216 232 245 256 246 264 279 291 277 298 314 328 306 329 347 362
LO PR 55 59 64 68 58 62 67 72 60 64 70 75 63 67 74 78 66 71 77 82 69 73 80 85
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

20
COOLING PERFORMANCE DATA
MODEL: PCA60C EXPANDED PERFORMANCE DATA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 57.7 58.9 63.0 67.3 56.3 57.6 61.5 65.8 55.0 56.2 60.0 64.2 53.7 54.8 58.6 62.6 51.0 52.1 55.7 59.5 47.2 48.3 51.6 55.1
S/T 0.82 0.77 0.62 0.47 0.85 0.79 0.65 0.48 0.87 0.81 0.66 0.49 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.94 0.88 0.72 0.53
DeltaT232219162423201624232016242320162423201622211815
1850 KW 5.30 5.41 5.58 5.75 5.70 5.82 6.00 6.19 6.05 6.18 6.37 6.58 6.36 6.49 6.70 6.92 6.62 6.76 6.98 7.21 6.85 7.00 7.22 7.47
AMPS 25.3 25.9 26.6 27.5 27.1 27.7 28.5 29.4 29.2 29.8 30.7 31.7 31.0 31.6 32.6 33.7 32.7 33.5 34.5 35.7 34.5 35.3 36.3 37.6
HI PR 174 188 198 207 196 210 222 232 222 239 253 264 253 273 288 300 285 307 324 338 315 339 358 373
LO PR 57 60 66 70 60 64 70 74 62 66 72 77 65 70 76 81 69 73 80 85 71 75 82 88
MBh 57.1 58.4 62.4 66.7 55.8 57.0 60.9 65.1 54.5 55.6 59.5 63.6 53.1 54.3 58.0 62.0 50.5 51.6 55.1 58.9 46.8 47.8 51.0 54.6
S/T 0.80 0.75 0.61 0.46 0.83 0.78 0.63 0.47 0.85 0.80 0.65 0.49 0.88 0.82 0.67 0.50 0.91 0.85 0.70 0.52 0.92 0.86 0.70 0.52
DeltaT242320162423201624232016242320 16 24 23 20 16 23 22 19 15
80 1750 KW 5.29 5.40 5.56 5.74 5.68 5.80 5.98 6.18 6.03 6.16 6.36 6.56 6.34 6.48 6.69 6.91 6.60 6.75 6.97 7.20 6.83 6.98 7.21 7.45
AMPS 25.3 25.8 26.5 27.4 27.0 27.6 28.4 29.4 29.1 29.7 30.6 31.6 30.9 31.6 32.5 33.6 32.7 33.4 34.4 35.6 34.4 35.2 36.3 37.5
HI PR 174 187 197 206 195 210 222 231 222 239 252 263 253 272 287 299 284 306 323 337 314 338 357 372
LO PR 57 60 66 70 60 64 69 74 62 66 72 77 65 69 76 81 68 73 79 84 71 75 82 87
MBh 56.3 57.5 61.4 65.7 54.9 56.1 60.0 64.1 53.6 54.8 58.6 62.6 52.3 53.5 57.1 61.1 49.7 50.8 54.3 58.0 46.1 47.1 50.3 53.7
S/T 0.77 0.72 0.59 0.44 0.80 0.75 0.61 0.46 0.82 0.77 0.63 0.47 0.85 0.79 0.65 0.48 0.88 0.82 0.67 0.50 0.89 0.83 0.68 0.51
DeltaT242320162423201625232016252421162423201623221915
1650 KW 5.22 5.33 5.49 5.66 5.61 5.72 5.90 6.09 5.95 6.08 6.27 6.47 6.25 6.39 6.59 6.81 6.51 6.65 6.87 7.09 6.73 6.88 7.10 7.34
AMPS 24.9 25.5 26.2 27.0 26.7 27.2 28.0 29.0 28.7 29.3 30.2 31.2 30.4 31.1 32.0 33.1 32.2 32.9 33.9 35.1 33.9 34.7 35.7 37.0
HI PR 171 184 194 202 192 206 218 227 218 235 248 258 248 267 282 294 279 301 317 331 309 332 351 366
LO PR 56 59 65 69 59 62 68 73 61 65 71 75 64 68 74 79 67 71 78 83 69 74 81 86
MBh 58.7 59.8 62.7 66.8 57.3 58.4 61.2 65.3 56.0 57.0 59.7 63.7 54.6 55.7 58.3 62.2 51.9 52.9 55.4 59.1 48.0 49.0 51.3 54.7
S/T 0.86 0.83 0.74 0.60 0.89 0.86 0.77 0.63 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 0.98 0.95 0.86 0.69
DeltaT252523202525232025252420252524202525232023232219
1850 KW 5.34 5.45 5.62 5.80 5.74 5.86 6.05 6.24 6.10 6.23 6.42 6.63 6.41 6.55 6.76 6.98 6.67 6.82 7.04 7.27 6.90 7.05 7.28 7.53
AMPS 25.5 26.1 26.8 27.7 27.3 27.9 28.7 29.7 29.4 30.0 30.9 32.0 31.2 31.9 32.9 34.0 33.0 33.7 34.8 36.0 34.8 35.6 36.7 37.9
HI PR 176 189 200 209 198 213 224 234 225 242 255 266 256 275 291 303 288 310 327 341 318 342 361 377
LO PR 57 61 66 71 60 64 70 75 63 67 73 78 66 70 77 82 69 74 80 86 72 76 83 89
MBh 58.1 59.2 62.0 66.2 56.8 57.9 60.6 64.6 55.4 56.5 59.2 63.1 54.1 55.1 57.7 61.6 51.4 52.3 54.8 58.5 47.6 48.5 50.8 54.2
S/T 0.84 0.81 0.73 0.59 0.87 0.84 0.76 0.61 0.89 0.86 0.78 0.63 0.92 0.89 0.80 0.65 0.96 0.92 0.83 0.67 0.96 0.93 0.84 0.68
DeltaT262524212625242126262421262624212625242124242219
85 1750 KW 5.33 5.44 5.61 5.78 5.73 5.85 6.03 6.23 6.08 6.21 6.41 6.62 6.39 6.53 6.74 6.96 6.66 6.80 7.02 7.26 6.88 7.04 7.27 7.51
AMPS 25.5 26.0 26.7 27.6 27.3 27.8 28.7 29.6 29.3 30.0 30.9 31.9 31.1 31.8 32.8 33.9 32.9 33.7 34.7 35.9 34.7 35.5 36.6 37.8
HI PR 175 189 199 208 197 212 224 233 224 241 255 265 255 275 290 302 287 309 326 340 317 341 360 376
LO PR 57 61 66 71 60 64 70 75 63 67 73 78 66 70 76 81 69 73 80 85 71 76 83 88
MBh 57.2 58.3 61.1 65.2 55.9 57.0 59.7 63.7 54.6 55.6 58.3 62.2 53.2 54.3 56.8 60.6 50.6 51.6 54.0 57.6 46.9 47.8 50.0 53.4
S/T 0.81 0.78 0.70 0.57 0.84 0.81 0.73 0.59 0.86 0.83 0.75 0.61 0.89 0.86 0.77 0.63 0.92 0.89 0.80 0.65 0.93 0.90 0.81 0.66
DeltaT262524212626242126262421262624212626242124242320
1650 KW 5.26 5.37 5.53 5.70 5.65 5.77 5.95 6.14 6.00 6.13 6.32 6.52 6.30 6.44 6.65 6.86 6.56 6.71 6.92 7.15 6.79 6.94 7.16 7.40
AMPS 25.1 25.7 26.4 27.2 26.9 27.5 28.3 29.2 28.9 29.6 30.4 31.5 30.7 31.4 32.3 33.4 32.5 33.2 34.2 35.4 34.2 35.0 36.0 37.3
HI PR 173 186 196 204 194 208 220 229 220 237 250 261 251 270 285 297 282 304 321 334 312 335 354 369
LO PR 56 60 65 69 59 63 69 73 62 66 72 76 65 69 75 80 68 72 79 84 70 75 81 87
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ARI Rating Conditions
