Advanced Micro Devices
AMD Turion™ 64 X2 Mobile
Technology Dual-Core Processor
Product Data Sheet
• Compatible with Existing 32-Bit Code Base
– Including supportforSSE,SSE2,SSE3*, MMX™,
3DNow!™technology,and legacy x86 instructions
*SSE3 supported by Rev. E and later processors
– Runs existing operating systems and drivers
– Local APIC on the chip
• AMD64 Technology
– AMD64 technology instruction set extensions
– 64-bit integer registers, 48-bit virtual addresses,
40-bit physical addresses
– Eight additional 64-bit integer registers (16 total)
– Eight additional 128-bit SSE registers (16 total)
• Dual-Core Architecture
– Discrete L1 and L2 cache structures for each core
• Enhanced Virus Protection
– No Execute (NX) bit in page-translation tables
specifies whether code can be executed from the
page
• HyperTransport™ Technology to I/O Devices
– One 16-bit link supporting speeds up to 800 MHz
(1600 MT/s) or 3.2 Gbytes/s in each direction
• 64-Kbyte 2-Way Associative ECC-Protected
L1 Data Cache
– Two 64-bit operations per cycle, 3-cycle latency
• 64-Kbyte 2-Way Associative Parity-Protected
L1 Instruction Cache
– With advanced branch prediction
• 16-Way Associative ECC-Protected
L2 Cache
– Exclusive cache architecture—storage in addition
to L1 caches
– Up to 1 Mbyte per L2 cache
– 1 Mbyte and 512-Kbyte options
• Machine Check Architecture
– Includes hardware scrubbing of major
ECC-protected arrays
Socket S1g1 Processor Specific
Features
• Refer to the Socket S1g1 Processor Functional
Data Sheet, order# 31731, for functional and
mechanical details of socket S1g1 processors.
Refer to the AMD NPT Family 0Fh Processor
Electrical Data Sheet, order# 31119, for
electrical details of socket S1g1 processors.
• Packaging
– 638-pin lidless micro PGA package
– 1.27-mm pin pitch
– 26 x 26 pin grid array
– 35 mm x 35 mm organic substrate
– Compliant with RoHS (EU Directive 2002/95/EC)
withleadused only in small amounts in specifically
exempted applications
• Integrated Memory Controller
– Low-latency, high-bandwidth
– 128-bit DDR2 SDRAM controller operating at up
to 333 MHz
– Supports up to two unbuffered SO-DIMMs
• Electrical Interfaces
– HyperTransport™ technology: LVDS-like
differential, unidirectional
– DDR2 SDRAM: SSTL_1.8 per JEDEC
specification
– Clock, reset, and test signals also use DDR2
SDRAM-like electrical specifications.
• Power Management
– Multiple low-power states including Deeper Sleep
(C1E with AltVID)
– System Management Mode (SMM)
– ACPI compliant, including support for processor
performance states
– AMD PowerNow!™ technology is designed to
dynamically switch between multiple low-power
states based on application performance
requirements.
41407Publication # 3.02Revision:
September 2006Issue Date:

2
41407 Rev. 3.02 September 2006
AMD Turion™ 64 X2 Mobile Technology
Dual-Core Processor Product Data Sheet
Revision History
Date Revision Description
September 2006 3.02 Second public release.
Added RoHS compliance statement for socket S1g1 processor-specific features.
August 2006 3.00 Initial public release.
