Deploying the Access Ramp
1. For the Easy-Flex-Ramp: Lift the access ramp up to the
vertical position until it audibly engages.
2. Push the operating lever to the left, to deploy the access
ramp.
3. Fold the access ramp out.
Caution! Keep a firm hold of the access ramp until
it is fully in contact with the ground. Allow the
access ramp to deploy slowly.
For a short wheelbase Caddy:
1. Fold the rear seat up.
2. Remove the seat fixtures or fold them down (see Figure
overleaf).
Loading a Passenger / Wheelchair
1. Secure the rear seats with the standard supports.
2. Accompany the wheelchair to a position in front of the
access ramp.
3. Operate the rocker switch such that the indicator lamp in
the rocker switch lights up.
4. Pull the electrically operated belts out to the wheelchair.
5. Attach the electrically operated belts to the wheelchair.
6. Operate the rocker switch such that the indicator lamp in
the rocker switch goes out.
Warning! The wheelchair can roll back out of
control if the indicator lamp in the rocker switch is
lit up. The passenger in the wheelchair can suffer
injury. Make certain that the indicator lamp in the
rocker switch is not lit up. Push or drive the
wheelchair up the access ramp only when this
has been done.
7. Push or drive the wheelchair into the vehicle.
8. Switch the motor of an electrically driven wheelchair OFF.
Securing the Passenger and Wheelchair in the
Vehicle
1. Attach the retractor belts to the wheelchair.
2. Clip the retractors onto the fittings.
3. Tension the retractor belts by tightening the belt reels.
4. Apply the wheelchair's brake(s).
5. Secure the passenger in the wheelchair using the
restraint systems provided.
6. Fold the access ramp up, until it audibly engages.
Disembarking a Passenger / Unloading a
Wheelchair
1. Fold the access ramp out and slowly lower it to the
ground.
2. Release the retractor belt reels.
3. Disconnect the retractors from the fittings.
4. Detach the retractor belts from the wheelchair.
5. Switch the motor of an electrically driven wheelchair ON.
6. Release the wheelchair's brake(s).
Warning! The wheelchair can roll backwards out
of control. The passenger in the wheelchair can
suffer injury. Stand behind the wheelchair to
prevent it from rolling backwards. Only then
operate the rocker switch such that the
indicator lamp in the rocker switch lights up.
7. Operate the rocker switch such that the indicator lamp
in the rocker switch lights up.
8. Accompany the wheelchair down from the access
ramp.
9. Detach the electrically operated belts from the
wheelchair.
10. Fold the access ramp up, until it audibly engages.
