AMF Tortilla Divider And rounder System User manual

TORTILLA DIVIDER AND
ROUNDER SYSTEM
Low Maintenance Rotary Divider Design
•Extrusion divider system features rotary-designed
mechanisms for continuous, smooth operation
• Eliminates stop-and-go stroke motion wear of
conventional piston dividers
•Highly efficient electric gearmotors eliminate the
maintenance and sanitation issues of hydraulic
drive systems
Belt Rounding for Continuous Operation
•Belt rounding system utilizes a patented concave
rounder bar to round each dough piece as it travels
down the rounder belt in a smooth, non-stop motion
•Eliminates the need for spreader belts and dusting
flour
•Reduces changeover time and maintenance
• Extrusion Technology Reduces Maintenance and Improves
Performance
• Higher Speeds Allow Full Utilization of Multiple Press or
Sheeting Units
Divide and Round without Divider Oil or Dusting Flour
•Extrusion design of our Tortilla Divider and Rounder
system requires no divider oil
•Unique belt rounding system requires no dusting
flour
•PLC-controlled cleaning system reduces operating
and sanitation costs and provides a cleaner,
healthier operating environment
Superior Operating Performance
•Unmatched scaling accuracy (+/- 1% is typical)
•Offers long, continuous runs with no downtime
needed for maintenance
Features &
Benefits

TORTILLA DIVIDER AND ROUNDER
Operator panel is NEMA 4 rated and mounted
on a swivel arm for easy access
Operator panel includes:
Allen Bradley 600C keypad operator interface to
control:
Auger pressure, metering pump speed
Vacuum level
Alarm messages and product codes
Rounder belt speed
Allen Bradley push-buttons for:
Two-button start
Stop and Emergency Stop
Master relay control
NEMA 12 painted remote electrical enclosure
including:
Main disconnect switch
Full voltage magnetic NEMA rated
starters
Allen Bradley 5/03 PLC
Toshiba Inverters
Schmersal key safety switches
Closed loop pressure control system with
pressure transducer
PLC controlled cleaning system for reduced
sanitation cost
Electronic proofer synchronization kit with
proofer drive
• Designed and manufactured in accordance with
BISSC sanitation standards
• Durable stainless steel frame
• Stainless steel guards and 500 lb. hopper for easy
sanitation
• Precision stainless steel tunnel housing for longevity
and sanitation
• Dual auger design for gentle dough handling
• All drives are high-efficiency Class F insulated
Eurodrive Gearmotors with A.C. speed control
including augers, metering pump, cut-off knife
rounder belt and proofer drive
• 3-inch metering pump for precise flow control with
less pressure
• Patented UHMW free-flow manifold for even dough
distribution
• UHMW rotary cut-off knife
• Venturi-style vacuum system with vacuum transducer
• Poly Slick Rounder Belt to prevent sticking
• UHMW Concave Rounder Bars with a patented
Floating Foot to produce round dough pieces without
dough leakage
• Hinged rounder bar frame with gas spring assist for
easy cleaning and maintenance access
• Cantilevered rounder frame design for quick belt
changes
• Independently controlled UHMW Kicker Roller for
precise dough ball transfer control
Electrical
Features
Mechanical
Features
HBD Divider

• Allen Bradley 5/04 PLC Upgrade
• Stainless steel electrical panel in lieu of painted
• Panel air conditioner in lieu of Exair panel cooler
• Panel modem for diagnostics
• CE electrical package
• Operator Interface in lieu of Allen Bradley Panelview 600C
•Automatic divider pushback
• 300 lb. stainless steel hopper in lieu of 500 lb.
• Product memory increase
• Chilled rounder bed option
•Additional machine manuals
• Tool kit
• Spare parts kit
TORTILLA DIVIDER AND ROUNDER
Specifications
Options

TORTILLA DIVIDER AND ROUNDER
Dimensional
Drawing
8-across shown
06/2001
AMF’s continuing engineering is constantly improving product performance. Consequently machinery specifications are subject to change without notice.
For more information please call
your Account Manager or 1-800-BAKERS-1.
